InSinkErator Model SS-100 User manual

PROJECT: ITEM NO.:
Heavy-duty disposer designed for continuous operation in restaurants, hotels, hospitals and cafeterias. Food waste including
steak bones is quickly and efficiently removed with this labor-saving, self-cleaning, environmentally sound disposer.
CC-202 Control Center
(Auto-Reversing)
CC-101 Control Center
(Auto-Reversing)
AS-101 Control Center
“Aqua Saver”
(Auto-Reversing)
Our products appear on The KCL CADalog
CD-ROM based CAD Foodservice Symbol
Library. More information is available from
Kochman Consultants, Ltd. at www.kclcad.com.
Manual Switch
(Single Direction)
Manual Reverse Switch
(Dual Direction)
1/2 – 1-1/4 H.P. DISPOSER MODELS
MODEL & HORSEPOWER/ELECTRICAL REQUIREMENTS
115/208-230V, 60 Hz, 1 Ph, 8.4/4.0/4.2 amps, UL
208-230/460V, 60 Hz, 3 Ph, 2.0/2.2/1.1 amps, UL
SS-50
1-1/2 H.P.
115/208-230V, 60 Hz, 1 Ph, 8.4/4.0/4.2 amps, CSA
208-230/460V, 60 Hz, 3 Ph, 2.0/2.2/1.1 amps, CSA
115/208-230V, 60 Hz, 1 Ph, 10.0/4.2/5.0 amps, UL
208-230/460V, 60 Hz, 3 Ph, 2.5/3.0/1.5 amps, UL
115/208-230V, 60 Hz, 1 Ph, 10.4/4.3/5.0 amps, CSA
208-230/460V, 60 Hz, 3 Ph, 2.5/3.0/1.5 amps, CSA
SS-75
3/4 H.P.
115/230V, 50 Hz, 3 Ph, 7.7/3.7 amps
230/460V, 50 Hz, 3 Ph, 2.7/1.4 amps
380V, 50 Hz, 3 Ph, 1.1 amps
InSinkErator ©2008 Printed in USA Form No. F307-08J-45-02
InSinkErator is a division of Emerson Electric Co.
4700 21st STREET
RACINE, WI 53406
TEL: [phone]
FAX: [phone]
www.insinkerator.com
ELECTRICAL CONTROLS
SPECIFICATIONS
• Grind Chamber: Corrosion Resistant Stainless Steel
• Mounting: 3/4" (19.1 mm) rubber mounting above grinding chamber isolates sound and eliminates
vibration. Mounting is enclosed in chrome plated covers for sanitation and appearance.
• Motor: 1/2 – 1-1/4 HP Induction Motor, 1725 RPM, totally enclosed to provide protection against
outside moisture. Controlled power air flow cools motor for efficiency and longer life. Built-in
thermal overload protection.
• Cutting Elements: Stationary and rotating shredding elements made from cast nickel chrome
alloy for long life and corrosion resistance, designed for reverse action grinding.
• Main Bearings: Double-tapered Timken roller bearings provide a shock absorbing cushion.
• Motor Seals: Triple lip seal protects motor from water damage. Secondary spring-loaded
oil seal provides double protection against water and loss of grease.
• Finish: All Stainless Steel and Chrome plated. Paint-free for lasting sanitation.
• Warranty: 1 year full warranty from date of installation.
• A Disposer Package Includes: 1 Mounting/Bowl Assembly, 1 Electrical Control, 1 Syphon
Breaker, 1 Solenoid Valve, and 1 Flow Control Valve. The standard Flow Control Valve will be
sent with the unit unless the optional valve is specified.
115/208-230V, 60 Hz, 1 Ph, 11.6/5.1/5.7 amps, UL
208-230/460V, 60 Hz, 3 Ph, 2.2/3.0/1.5 amps, UL
115/208-230V, 60 Hz, 1 Ph, 11.6/5.1/5.7 amps, CSA
SS-100
1 H.P.
208-230/460V, 60 Hz, 3 Ph, 2.2/3.0/1.5 amps, CSA
120/208-240V, 60 Hz, 1 Ph, 11.6/5.1/5.7 amps, NOM
100/200-230V, 50/60 Hz, 1 Ph, 10.4/5.2/5.4 amps
115/208-230V, 60 Hz, 1 Ph, 12.8/5.9/6.6 amps, UL
208-230/460V, 60 Hz, 3 Ph, 2.6/3.3/1.9 amps, UL
SS-125
1-1/4 H.P.
115/208-230V, 60 Hz, 1 Ph, 12.8/5.9/6.6 amps, CSA
208-230/460V, 60 Hz, 3 Ph, 2.6/3.3/1.9 amps, CSA
NOTE: All amp ratings denote amp draw during a grind load.
The Emerson logo is a
trademark and a service mark
of Emerson Electric Co.

DIMENSIONS
IMPORTANT: Use dimension chart below for adaptor height in place
of InSinkErator bowl sink height when mounting directly to a sink.
Bowl
Sinks
Flange O.D.
X
Work Table Hole
Y
Flange I.D.
Z
Height
12"
(304.8 mm)
13-1/2"
(342.9 mm)
12-1/4"
(311.2 mm)
12"
(304.8 mm)
6-1/2"
(165.1 mm)
15"
(381 mm)
16-1/2"
(419.1 mm)
15-1/4"
(387.4 mm)
15"
(381.0 mm)
6-1/2"
(165.1 mm)
18"
(457.2 mm)
19-1/2"
(495.3 mm)
18-1/4"
(463.6 mm)
18"
(457.2 mm)
6-1/2"
(165.1 mm)
Adaptors X Y Z Height
No. 5 Fits Standard Sink Opening:
3-1/2" – 4" (88.9 mm – 101.6 mm)
2-3/4"
(69.9 mm)
No. 6 7-13/16"
(198.4 mm)
6-7/8"
(174.6 mm)
6-5/8"
(168.3 mm)
1-3/16"
(30.2 mm)
No. 7 9-1/8"
(231.8 mm)
7-7/8"
(200.0 mm)
7-5/8"
(193.7 mm)
2-1/16"
(52.4 mm)
Z
Y
6-5/8"
(168.3 mm)
X
6-13/16"
(173.0 mm)
4-7/8"
(123.8 mm)
6-3/8"
(161.9 mm)
1-1/2"
(38.1 mm)
3-3/8"
(85.7 mm)
6-1/2"
(165.1 mm)
7-11/16"
(195.3 mm)
17"
(431.8 mm)
EXTERNAL ELECTRICAL
CONNECTIONS
1/2-14 N.P.T.
WATER INLET
InSinkErator
BOWL SINK
NOTE:
• Adaptors are available upon request for all competitor
sink bowls or cones.
• Please have sink bowl/cone type with the necessary
dimensions when ordering adaptors.
RECOMMENDED INSTALLATION
DISPOSER MOUNTING ASSEMBLIES (choose one)
Collar Mounts
#6 Collar Adaptor for welding into trough, provides
6-5/8" (168.3 mm) opening, includes splash baffle
#7 Collar Adaptor for welding into sink, provides
6-5/8" (168.3 mm) opening, includes splash baffle
and stopper
#5 Sink Flange Mounting Assemblies for 3-1/2" – 4"
(88.9 mm – 101.6 mm) sink opening (support legs
are recommended)
Bowl Mounts
Type A Sink Bowl Assembly: Includes bowl, water
nozzle(s), bowl cover, splash baffle
Type B Sink Bowl Assembly: Includes bowl, water
nozzle(s), silver guard, splash baffle
Type C Sink Bowl Assembly: Includes bowl, water
nozzle(s), splash baffle
Sink Bowl Assembly Size
12" (304.8 mm) with one adjustable water nozzle
15" (381.0 mm) with one adjustable water nozzle
18" (457.2 mm) with two adjustable water nozzles
Standard Optional
SS-50 3 GPM
(11.4 LPM) N/A
SS-75 3 GPM
(11.4 LPM) N/A
SS-100 5 GPM
(18.9 LPM)
3 GPM
(11.4 LPM)
SS-125 5 GPM
(18.9 LPM)
3 GPM
(11.4 LPM)
For additional information, see
Foodservice Product Information Binder.
RECOMMENDED WATER USAGE
