DESIGN
Series “I” with 6” rotor has no floor support. It is designed primarily
for the small restaurant kitchen or for the larger kitchen’s salad
preparation area. This smaller model is made with the same
rugged construction as the larger models. This is the ideal
disposer for a small church, small snackbar, or small elementary
school, where food waste volume is light. Standard 1 HP motor
is recommended.
SERIES I 6” ROTOR
COMMERCIAL FOOD WASTE DISPOSER
STANDARD EQUIPMENT
• 1 HP motor
6245 State Road
Philadelphia, PA 19135-2995
215-624-4800
215-624-6966 FAX
800-344-4802
www.insingermachine.com
OPTIONAL EQUIPMENT
• Stainless steel cone or sink attachment (includes vinyl silver trap
ring, solenoid valve, flow control valve, vacuum breaker)
• 3/4 HP motor- lighter duty
• Cones 12”, 15” & 18”
NOTE: Sink attachments and s/s cones need to be welded into table

Disposer shown with cone mounting assemblyDisposer shown with sink mounting assembly
Table Cutout
13” for 12” cone
16” for 15” cone
19” for 18” cone
5” for 12” cone
6” for 15” cone
7” for 18” cone
Sink mounting assembly
will fit standing 3 1/2” to
4” diameter opening
6 5/8”
18 1/8” (with 3 phase motor)
18 5/8” (with 1 phase motor)
19 3/8” (with 3 phase motor)
19 7/8” (with 1 phase motor)
Drain
Drain
Water inlet
3 1/4” inside
diameter
3 1/4””
5 1/2”
9”
7 7/8” 6 5/8”
1”
Note: For all rough in connections see Installation and Layout Detail Drawing
I-6 DISPOSER
DESIGN AND CONSTRUCTION
• Waste chamber design permits dual directional operation when used with reversing control or switch, doubling the life
cycle of the shattering mechanism.
• Basic body components are cast gray iron, machined, primed and painted. 6” diameter rotor with (2) cast-on impact
bars and sizing ring are cast ductile iron, machined, balanced and heat treated.
• Flexible drain connector. Fastens quickly to either metal or PVC drain line (1 1/2” pipe size).
• Disposer suspends from cone or sink assembly.
• Center support leg (2” height adjustment). (Optional)
MOTOR
• Reversing, continuous duty, 1725 RPM (1425 RPM, 50 Hz), full rated horsepower, double sealed, permanently
lubricated ball bearings.
• Thermal overload protection with manual reset button.
• Available for single phase or three phase installations.
• Available in 3/4 and 1 horsepower, single and three phase.
• Dual voltage windings allow multi-voltage operation by motor lead connection. (See motor wiring diagram)
115-230 Volts, 60Hz; 1 Phase
208-230/460 Volts, 60 Hz; 3 Phase
(See table for ampere draw per horsepower, volts & phase)
CONTROLS
Electrical switches or control centers not included, must be selected as required.
Note: All plumbing and electrical connections should be made according to local codes.
HP SINGLE PHASE THREE PHASE
Volts Amps* Volts Amps*
3/4 115
230 5.4 10.8
208
230
460
2.8
2.8
1.4
1115
230 12.8 6.4
208
230
460
3.6
3.6
1.8
*Ratings are for 60 Hz operation.
