GLEANER R66 User manual

© AGCO Corporation, 2008 All rights reserved.
Part Number 79032996 A Rev. (English)
Printed in U.S.A.
September 2008
Gleaner®
R66 / R76
Rotary Combine
SERVICE MANUAL
79032996 A Rev.
CONTENTS
GENERAL INFORMATION ....................................................................................................................................01
SPECIFICATIONS..................................................................................................................................................02
ENGINE SERVICE MANUAL..............................................................................................................................03A
ENGINE - DRIVES, COOLING AND FUEL.........................................................................................................03B
MATERIAL HANDLING..........................................................................................................................................04
MATERIAL DISCHARGE.......................................................................................................................................05
REAR AXLE ...........................................................................................................................................................06
THRESHING AND SEPARATING.....................................................................................................................................07
FRONT AXLE......................................................................................................................................................................08
HYDRAULICS.....................................................................................................................................................................09
ELECTRICAL......................................................................................................................................................................10
ELECTRONICS...................................................................................................................................................................11
CAB AND HVAC.................................................................................................................................................................12
GRAIN HEADER.................................................................................................................................................................13
CORN HEADER..................................................................................................................................................................14
RESERVED.........................................................................................................................................................................15

79032996 A Rev. 01-i
Contents
Gleaner®
R66 / R76
Combine
SERVICE MANUAL
79032996 A Rev.
01 - General Information
Contents
SAFETY
Safety Alert Symbol ....................................................................................................................................... 01-1
Safety Messages ........................................................................................................................................... 01-1
Informational Messages ................................................................................................................................. 01-1
Safety Signs ................................................................................................................................................... 01-2
A Word to the Operator .................................................................................................................................. 01-2
Fire Prevention and First Aid ......................................................................................................................... 01-3
Prepare for Operation .................................................................................................................................... 01-3
Operation ....................................................................................................................................................... 01-4
Transporting Combine On Public Roads ....................................................................................................... 01-7
Maintenance .................................................................................................................................................. 01-8
Engine Safety ................................................................................................................................................ 01-9
Tire Safety ..................................................................................................................................................... 01-9
Battery Safety .............................................................................................................................................. 01-10
Accumulator Safety ...................................................................................................................................... 01-10
Header Lift Cylinder Stop ............................................................................................................................. 01-11
Shields ......................................................................................................................................................... 01-12
Feeder House ........................................................................................................................................ 01-12
Left-hand Shields .................................................................................................................................. 01-13
Right-Hand Shields ............................................................................................................................... 01-14
Backup Alarm .............................................................................................................................................. 01-14
Fan Leaf Screen .......................................................................................................................................... 01-15
Transmission Screen ................................................................................................................................... 01-15
GENERAL INFORMATION
How a Combine Works ................................................................................................................................ 01-17
Material Handling .................................................................................................................................. 01-17
Threshing and Separating ..................................................................................................................... 01-18
Cleaning ................................................................................................................................................ 01-18
Combine Identification ................................................................................................................................. 01-19
Machine Serial Number ......................................................................................................................... 01-19
Engine Serial Number ........................................................................................................................... 01-19
Fuel Injection Pump Dataplate .............................................................................................................. 01-19
ECM Dataplate ...................................................................................................................................... 01-20
Transmission Serial Number ................................................................................................................. 01-20
Final Drive Serial Number ..................................................................................................................... 01-20
Gearbox Serial Number Plate ............................................................................................................... 01-21
Headers ....................................................................................................................................................... 01-21
Lubrication and Maintenance ....................................................................................................................... 01-21
Lubricants .................................................................................................................................................... 01-21
Service Procedures ..................................................................................................................................... 01-22
Service Periods ............................................................................................................................................ 01-22
Lubrication and Maintenance ....................................................................................................................... 01-23
Lubrication Details ....................................................................................................................................... 01-28
Find manuals at https://best-manuals.com

01-ii 79032996ARev.
Contents
Right Hand Feeder House ..................................................................................................................... 01-30
Left Hand Feeder House ....................................................................................................................... 01-30
Unloader Tube ....................................................................................................................................... 01-31
Left-hand Side ....................................................................................................................................... 01-32
Standard Rear Axle ............................................................................................................................... 01-34
Rear Wheel Assist Rear Axle ................................................................................................................ 01-35
Right Hand Side .................................................................................................................................... 01-35
Idlers ...................................................................................................................................................... 01-36
Cylinder Gearbox .................................................................................................................................. 01-38
Front of Combine ................................................................................................................................... 01-38
Rear of Combine ................................................................................................................................... 01-38
Lateral Tilt .............................................................................................................................................. 01-39
Main Drive Axle ..................................................................................................................................... 01-39
Auto Lube .................................................................................................................................................... 01-40
Auto Lube Intervals ............................................................................................................................... 01-41
Auto Lube Diagnosis ............................................................................................................................. 01-43
Engine Compartment ................................................................................................................................... 01-44
Standard Ladder .................................................................................................................................... 01-44
Rear Powerfold Ladder ......................................................................................................................... 01-45
Engine .......................................................................................................................................................... 01-45
Type of Engine Oil ................................................................................................................................. 01-45
Viscosity ................................................................................................................................................ 01-46
Oil Additives .......................................................................................................................................... 01-46
Checking Oil Level ................................................................................................................................ 01-46
Changing Engine Oil and Filters ............................................................................................................ 01-46
Fuel System ................................................................................................................................................. 01-48
Fuel Tank Filler ...................................................................................................................................... 01-48
Fuel Handling ........................................................................................................................................ 01-48
Shut Off Valve ....................................................................................................................................... 01-48
Fuel Vent Breather ................................................................................................................................ 01-49
Engine Fuel Filter .................................................................................................................................. 01-49
Bleeding the System ............................................................................................................................. 01-49
Engine Idle Speed ................................................................................................................................. 01-49
Maximum No-Load Engine Speed Adjustment ..................................................................................... 01-50
Engine Cooling System ............................................................................................................................... 01-50
Coolant Type ......................................................................................................................................... 01-50
Engine Cooling System Coolant ............................................................................................................ 01-50
Recommended Coolant Change Period ................................................................................................ 01-50
Checking Coolant Level ........................................................................................................................ 01-51
Radiator ................................................................................................................................................. 01-51
Thermostat ............................................................................................................................................ 01-51
Draining Cooling System ....................................................................................................................... 01-52
Filling System ........................................................................................................................................ 01-52
Coolant System Monitoring ................................................................................................................... 01-52
Monitor Warnings .................................................................................................................................. 01-52
Engine Air Cleaner ....................................................................................................................................... 01-53
Aspirated Air Pre-Cleaner ..................................................................................................................... 01-53
Air Cleaner Restriction Switch ............................................................................................................... 01-53
Air Cleaner Filter Element ..................................................................................................................... 01-54
Secondary Filter Element ...................................................................................................................... 01-55
Hydraulics .................................................................................................................................................... 01-56
Checking Oil Level ................................................................................................................................ 01-56
Hydro-Charge Oil Pressure Filter Element ............................................................................................ 01-57
Hydro Return Filter ................................................................................................................................ 01-57
Hydrostatic Oil Cooler ........................................................................................................................... 01-57
Yearly Service ....................................................................................................................................... 01-58
Removing Air From Hydraulic System .................................................................................................. 01-59
Hydraulic Pump ..................................................................................................................................... 01-59
Steering Priority Valve ........................................................................................................................... 01-60
Electro-Hydraulic Valve Assembly Identification ................................................................................... 01-60
Hydraulic Operating Pressures ............................................................................................................. 01-60
Transmission ............................................................................................................................................... 01-61
Checking and Changing Lubricant ........................................................................................................ 01-61
Find manuals at https://best-manuals.com

79032996 A Rev. 01-iii
Contents
Brakes .......................................................................................................................................................... 01-61
Master Cylinder Oil Reservoir ............................................................................................................... 01-61
Bleeding Brake System ......................................................................................................................... 01-61
Final Drive .................................................................................................................................................... 01-62
Tires and Wheels ......................................................................................................................................... 01-63
Tire Pressure ......................................................................................................................................... 01-63
Dual Tires .............................................................................................................................................. 01-63
Sidehill Use ........................................................................................................................................... 01-63
Care of Tires .......................................................................................................................................... 01-63
Removing Wheel from Combine ........................................................................................................... 01-64
Wheel Installation .................................................................................................................................. 01-65
Tire Dimensions .................................................................................................................................... 01-66
Chaffer and Sieve Removal ......................................................................................................................... 01-66
Chopper Knives ........................................................................................................................................... 01-66
Knife Bolt Torque ................................................................................................................................... 01-66
Knife Replacement ................................................................................................................................ 01-66
Cylinder Gearbox ......................................................................................................................................... 01-67
Drive Belts ................................................................................................................................................... 01-67
Banded Drive Belt ................................................................................................................................. 01-67
Maintenance of Belts ............................................................................................................................. 01-68
Belt Changing Guides ........................................................................................................................... 01-68
Belt Sheave Alignment .......................................................................................................................... 01-70
Belt Run In Procedure ........................................................................................................................... 01-71
Belt Troubleshooting ............................................................................................................................. 01-71
Belt Problem and Wear Guide ............................................................................................................... 01-71
Roller Chains ............................................................................................................................................... 01-85
Inspection of Drive Chains and Sprockets ............................................................................................ 01-85
Drive Chain Adjustment and Tightening ................................................................................................ 01-85
Drive Chain Sprocket and Idler Alignment ............................................................................................ 01-86
Drive Chain Elongation and Sprocket Wear .......................................................................................... 01-87
Normal Tooth Wear ............................................................................................................................... 01-88
Not Normal Tooth Wear ........................................................................................................................ 01-88
Worn Chain on New Sprockets ............................................................................................................. 01-89
Drive Chain Service Tips ....................................................................................................................... 01-89
Chain Replacement ............................................................................................................................... 01-90
Cleaning and Lubricating Chains .......................................................................................................... 01-90
Drive Chain Lubrication ......................................................................................................................... 01-91
Drive Chain Lubricants .......................................................................................................................... 01-92
Good Drive Chain Lubrication ............................................................................................................... 01-92
Roller Chain Drive Troubleshooting Guide ............................................................................................ 01-94
Speed of Components ................................................................................................................................. 01-97
Drives Listing and Specifications ........................................................................................................... 01-99
Air Conditioning System ............................................................................................................................ 01-101
Compressor ......................................................................................................................................... 01-101
Condenser ........................................................................................................................................... 01-102
Receiver-Drier ..................................................................................................................................... 01-102
Cab Air Filters ............................................................................................................................................ 01-103
Cab Filter - Primary ............................................................................................................................. 01-103
Cab Filter - Secondary ........................................................................................................................ 01-103
Recirculation Filter ............................................................................................................................... 01-103
Air Filter Cleaning Procedure .............................................................................................................. 01-104
Storage Preparation ................................................................................................................................... 01-105
Combine .............................................................................................................................................. 01-105
Engine ................................................................................................................................................. 01-105
Preparation for Use After Storage ............................................................................................................. 01-105
Combine .............................................................................................................................................. 01-105
Engine ................................................................................................................................................. 01-105
Torque Charts ............................................................................................................................................ 01-106
Standard Torque Specifications .......................................................................................................... 01-106
Metric Capscrew Markings and Torque Values ................................................................................... 01-107
Metric Conversions .................................................................................................................................... 01-108
Fractions, Decimals, and Millimeters Conversion Chart ............................................................................ 01-109
Decimal Equivalents of 8ths, 16ths, 32nds, and 64ths .............................................................................. 01-112
Find manuals at https://best-manuals.com

01-iv 79032996ARev.
Contents
Decimal Equivalents Of Letter Size Drills .................................................................................................. 01-113
Decimal Equivalents of Number Size Drills ............................................................................................... 01-113
Tap Drill Sizes - S.A.E. & Metric ................................................................................................................ 01-114
American Standard Pipe Thread and Tap Drill Sizes ................................................................................ 01-117
Electrical Formulas .................................................................................................................................... 01-118
Amperes (Current Flow) ...................................................................................................................... 01-118
Volts (Electromotive Force) ................................................................................................................. 01-118
Ohms (Resistance) .............................................................................................................................. 01-118
Watts ................................................................................................................................................... 01-118
Horsepower ......................................................................................................................................... 01-118
Belt Speed Calculation Formulas .............................................................................................................. 01-118
Geometrical Formulas ............................................................................................................................... 01-119
Circumference of a Circle .................................................................................................................... 01-119
Area of a Circle .................................................................................................................................... 01-119
Volume of a Cylinder ........................................................................................................................... 01-119
Volume of a Sphere ............................................................................................................................. 01-119
Area of a Triangle ................................................................................................................................ 01-119
Metric to Imperial and Imperial to Metric Conversion Factors ................................................................... 01-119
Measures of Temperature ................................................................................................................... 01-119
Measures of Power ............................................................................................................................. 01-119
Measures of Pressure ......................................................................................................................... 01-119
Measures of Length ............................................................................................................................. 01-119
Measures of Area ................................................................................................................................ 01-119
Measures of Volume (Dry) .................................................................................................................. 01-120
Measures of Volume (Liquid) .............................................................................................................. 01-120
Measures of Mass (Weight) ................................................................................................................ 01-120
Measures of Effort (Torque) ................................................................................................................ 01-121
Reference Tables ................................................................................................................................ 01-121
INDEX ........................................................................................................................................................... 01-123
Find manuals at https://best-manuals.com

79032996 A Rev. 01-1
Safety
SAFETY
SAFETY ALERT SYMBOL
FIG. 1: The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this manual and
on safety signs on this machine. The safety alert symbol
will direct your attention to information that involves your
safety and the safety of others.
SAFETY MESSAGES
FIG. 2: The words DANGER, WARNING or CAUTION
are used with the safety alert symbol. Learn to recognize
these safety alerts and follow the recommended
precautions and safety practices.
mDANGER: Indicates an imminently
hazardous situation that, if not avoided, will
result in DEATH OR VERY SERIOUS
INJURY.
mWARNING: Indicates a potentially
hazardous situation that, if not avoided,
could result in DEATH OR SERIOUS
INJURY.
mCAUTION: Indicates a potentially
hazardous situation that, if not avoided,
may result in MINOR INJURY.
INFORMATIONAL MESSAGES
The words IMPORTANT and NOTE are not related to
personal safety, but are used to give additional
information and tips for operating or servicing this
machine.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly observed, could
result in damage to or destruction of the
machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more
efficient and convenient repair or operation.
FIG. 1 Saf
FIG. 2 WC1957
Find manuals at https://best-manuals.com

Safety
01-2 79032996ARev.
SAFETY SIGNS
mWARNING: Do not remove or obscure any
safety signs. Replace any safety signs that
are not readable or are missing.
Replacement signs are available from your
dealer in the event of loss or damage. The
actual location of the safety signs is
illustrated at the end of this section.
If a used machine has been purchased, make sure all
safety signs are in the correct location and can be read.
See Safety Sign Location of this section for illustrations.
Replace any safety signs that can not be read or are
missing. Replacement safety signs are available from
your dealer.
A WORD TO THE OPERATOR
FIG. 3: Read and understand this manual and the
manual for all attachments before operating the combine.
Learn how to operate the combine and how to use the
controls properly.
Do not let anyone operate the combine without instruction
and training.
For your personal safety and the personal safety of
others, follow all safety precautions and instructions found
in the manuals and on signs affixed to the combine and its
attachments.
Personal injury or death may result if these precautions
are not followed.
mWARNING: An operator must not use
alcohol or drugs which can affect their
alertness or coordination. An operator
taking prescription or over the counter
drugs needs medical advice on whether or
not they can properly operate machines.
FIG. 3 S-1123
Find manuals at https://best-manuals.com

79032996 A Rev. 01-3
Safety
FIRE PREVENTION AND FIRST AID
FIG. 4: Be prepared for emergencies. Always carry one
or more suitable fire extinguishers (1) - ABC rating, dry
chemical, 2.2 KG (5 lb). Check fire extinguishers regularly
to ensure they are properly charged and in operating
condition.
Mounting a fire extinguisher near the operator cab and a
fire extinguisher near the engine compartment is
recommended.
FIG. 5: To reduce the risk of fire or damage if fire occurs:
• Check for overheated components.
• Frequently clean the engine compartment of any
chaff and crop debris.
• Frequently clean areas of the machine & header
where crop can accumulate.
• Mount a fire extinguisher within easy reach at the
front and rear of the machine.
If any flame cutting, welding, or arc welding is to be done
on the machine or header, make sure to clear any crop
material or debris from around the area. Make sure the
area below the work area is clear of any flammable
material as falling molten metal or sparks can ignite the
material.
PREPARE FOR OPERATION
Make sure the combine is in the proper operating
condition as stated in the combine operator manual. Make
sure the machine has the correct equipment needed by
local regulations.
Read and understand all operating instructions and
precautions in this manual before operating or servicing
the machine. Make sure you know and understand the
positions and operations of all controls.
Make certain that all controls are in neutral and the
parking brake is engaged before starting the machine.
Make certain that all people are well away from your area
of work before starting and operating the machine.
All equipment has a limit. Make sure you understand the
speed, brakes, steering, stability, and load characteristics
of the machine before you start. Check all controls in an
area clear of people and obstacles before starting your
work.
Be aware of the machine size and have enough space
available to allow for operation. Never operate the
machine at high speeds in crowded places.
FIG. 4
1
D-12491
FIG. 5
Wc1946
Find manuals at https://best-manuals.com

Safety
01-4 79032996ARev.
OPERATION
mWARNING: In order to provide a better
view, certain photographs and illustrations
in this manual may show an assembly with
the shield removed. Do not operate
combine unless all shields are in place.
Replace shields immediately upon
completion of inspection, repairs, cleaning
or adjustments and before operation
begins/resumes.
FIG. 6: Wear close fitting clothing and personal
protection equipment appropriate for operating and/or
performing lubrication and maintenance on the combine.
Tie up long hair to prevent hair from becoming entangled
in moving parts.
FIG. 7: Face the ladder and use the handrails when
getting on or off the combine.
FIG. 8: Never operate the engine in a closed building
unless exhaust is vented outside.
FIG. 6
S-1127A
FIG. 7
Wc1940
FIG. 8
Wc1949
Find manuals at https://best-manuals.com

79032996 A Rev. 01-5
Safety
FIG. 9: Always wear the seat belt when combine is
moving. If another person is riding in the instructor's seat,
make sure the person wears a seat belt. Seat belts must
be worn fitted snugly around the hips and not twisted.
FIG. 10: Never allow anyone on any part of the combine
or attachments except in the operator seat and the
instructor's seat when the engine is running.
Do not attempt to get on or off the combine while the
combine is moving.
FIG. 11: Avoid contact with electrical power lines. Always
put the grain tank unloader tube in the transport position
and lower radio aerial before moving combine near
electrical wires. Contact with electrical power lines can
cause electrical shock, resulting in very serious injury or
death.
FIG. 12: Use extra care and reduce speed when
operating on hillsides or near ditches or embankments
especially with a full grain tank to avoid rollover. Travel
speed must be such that complete control and machine
stability is maintained at all times. Shift to a lower gear
before descending a steep hill.
FIG. 9 Wc1953a
FIG. 10
Wc1945
FIG. 11
Wc1937
FIG. 12
Wc1937a
Find manuals at https://best-manuals.com

Safety
01-6 79032996ARev.
FIG. 13: All shields and guards must be in the correct
operating position and in good condition.
Do not open, remove, or reach around shields while the
engine is operating. Entanglement in rotating belts or
moving parts can cause serious injury or death. Stay
clear of rotating or moving components.
FIG. 14: Never allow anyone behind the combine while
the engine is running or the combine is in operation.
Objects can be thrown from the straw chopper or chaff
spreader at a high rate of speed. Objects thrown from the
straw chopper or chaff spreader can cause serious injury
or death.
The straw chopper and chaff spreader can continue to
move after the thresher has been disengaged or the
engine shut off. Wait for all components of the combine to
stop moving prior to inspecting, cleaning, or servicing the
combine.
FIG. 15: Always shut off the engine, shift the
transmission to neutral, set parking brake, remove the
ignition key and take the ignition key with you before
leaving the operator station. Never allow anyone to
inspect, clean, lubricate, adjust or repair any part of the
combine or attachments while the engine is operating
unless specifically instructed otherwise in this manual.
Never leave combine unattended while the engine is
operating.
FIG. 16: Never permit anyone to work under the header
or feeder house, unless the stop is properly engaged on
the header lift cylinder, the engine is stopped, the parking
brake is set, and the start key is removed from the start
switch.
FIG. 13
71389544
FIG. 14 D-8278
FIG. 15 D-8518
FIG. 16
Wc1954

79032996 A Rev. 01-7
Safety
FIG. 17: Never allow anyone around the header or the
feeder when the engine is running. Personnel can
become entangled in the moving parts of the header or
feeder, or be pulled in to the feeding mechanism of the
combine.
Stay clear of any cutting or gathering devices on the
header as these devices can cause serious injury or
death.
FIG. 18: Always stop the combine engine before
refueling. Do not smoke while refueling.
TRANSPORTING COMBINE ON PUBLIC
ROADS
FIG. 19: Consult your local law enforcement agency for
local regulations regarding movement of farm equipment
on public roads.
Use headlights, flashing warning lights, taillights and turn
signals, day and night, unless prohibited by local law.
Make sure lights, reflectors and SMV emblem (if required)
are installed, in good condition and wiped clean.
Lock brake pedals together with the locking strap so that
both front wheel brakes will be applied simultaneously.
Engage the transport switch located in the right-hand
console.
Be aware of other traffic on the road. Keep well over to
your own side of the road and pull over, whenever
possible, to let faster traffic pass.
Adjust travel speed to maintain control at all times. Never
allow combine to coast down hills.
FIG. 17
Wc1942
FIG. 18
Wc1959
FIG. 19
S-1025

Safety
01-8 79032996ARev.
MAINTENANCE
FIG. 20: Escaping fluid under high pressure can be
almost invisible but penetrate the skin causing serious
injury.
Consult a doctor immediately if you sustain an injury by
escaping fluids. Fluid injected into the skin must be
surgically removed within a few hours or gangrene may
result.
FIG. 21: Use a piece of cardboard or wood to search for
possible leaks, never use your hands.
Relieve pressure from the hydraulic and fuel injection
systems by lowering raised equipment, shutting off
accumulator valve and shutting off the engine before
loosening any part of the systems. Tighten all
connections securely before applying pressure.
FIG. 22: Be aware that the surfaces in and around the
engine compartment will be hot if the engine has been
running, even for a short time.
Always permit parts that contain hot fluid to cool before
handling or disconnecting.
FIG. 23: Do not remove radiator cap if engine is hot.
Only remove cap when the cap is cool enough to touch
with bare hands. Loosen cap slowly to first notch to relieve
pressure, then remove cap.
FIG. 20
Wc1938
FIG. 21
D-5842a
FIG. 22
Wc1947
FIG. 23
Wc1951

79032996 A Rev. 01-9
Safety
FIG. 24: Remove spilled oil, antifreeze or fuel
immediately from operator ladder and platform and other
access areas.
Keep all access areas clean and free of obstructions.
ENGINE SAFETY
FIG. 25: Make sure that all shields, guards and access
doors are in place and properly closed before starting the
engine.
Start the engine from the operator seat only. Be sure that
the transmission is in neutral and the header, separator
and unloader clutches are disengaged.
Be sure that all bystanders are clear of the combine
before starting the engine.
FIG. 26: Engine is equipped with an electric starting aid.
Do not use aerosol starting fluid! Use of this fluid can
cause an explosion that can result in severe injury or
death.
TIRE SAFETY
FIG. 27: Tire explosion and/or serious injury can result
from over inflation. Do not exceed the tire inflation
pressures. See the Specifications Section for the correct
tire pressure.
Replace worn or damaged tires. When tire service is
needed, have a qualified tire mechanic service the tire.
See the Specifications Section for the correct tire size.
Do not weld on the rim when a tire is installed. Welding
will cause an explosive air/gas mixture that will ignite with
high temperatures. This can happen to tires that are
inflated or deflated. Removing the air or breaking the
bead is not enough.
FIG. 24
Wc1939
FIG. 25
Wc1955
FIG. 26
EXPLOSION
FIG. 27
D-8386

Safety
01-10 79032996ARev.
BATTERY SAFETY
FIG. 28: Electrical storage batteries give off highly
flammable hydrogen gas. Keep lighted smoking material
and open flame or electrical sparks away from the battery.
Do not lay tools or other conductive materials on the
battery.
Be careful when connecting booster cables to combine
batteries. Electrical component damage or battery
explosion can result if booster cables are not installed
correctly.
Do not charge a frozen battery as the battery can
explode. Warm battery to 16°C (60°F).
FIG. 29: Fluid in electrical storage batteries contains
sulfuric acid. Avoid all contact of fluid with eyes, skin or
clothing. If contact does occur, flush off immediately with
large amounts of water.
ACCUMULATOR SAFETY
FIG. 30: The accumulator (1) is charged with dry
nitrogen gas. Use only dry nitrogen when charging the
accumulator. Do not use air or oxygen or an explosion will
occur.
Do not drop the accumulator. A charged accumulator
contains nitrogen under pressure. If the shut off valve
breaks away from the accumulator, the escaping nitrogen
will propel the accumulator at a high rate of speed.
mCAUTION: Service of the accumulator must
be done by authorized personnel only.
Nitrogen gas when released can cause
localized freezing and injury.
FIG. 28
WC1950
FIG. 29
Wc1948
FIG. 30
1
N718803

79032996 A Rev. 01-11
Safety
HEADER LIFT CYLINDER STOP
A header lift cylinder stop is provided on the left-hand
header lift hydraulic cylinder.
FIG. 31: Header lift cylinder stop (1) in the disengaged
position.
FIG. 32: Header lift cylinder stop (1) in the engaged
position.
Properly engage the header lift cylinder stop as shown
before going under the header or feeder house for any
reason whatsoever.
To engage the header lift cylinder stop:
1. Raise the feeder house until the cylinder rod is fully
extended to allow engagement of the header lift
cylinder stop.
2. Release the hook and lower the header lift cylinder
stop onto the cylinder rod.
3. Lower feeder house until the header lift cylinder stop
contacts the end of the cylinder.
FIG. 31
1
N516689
FIG. 32
1
N516587

Safety
01-12 79032996ARev.
SHIELDS
NOTE: Some pictures in this manual will show shields
removed for visibility or access to parts of the
combine. Numerous shields must be opened
and/or removed to perform normal service and
adjustment procedures.
mWARNING: Never operate the combine or
allow others to operate the combine unless
all shields supplied with the combine and
the combines attachments are properly in
place.
Feeder House
FIG. 33: Left-hand feeder housing shield (1) shown in
latched position. To remove, release latch (2) and lift
shield off mounting brackets.
FIG. 34: Left-hand feeder housing shield (1) shown
removed with tether (2).
FIG. 35: Right-hand feeder housing shield (1) shown in
latched position. To remove, release latch (2) and lift
shield off mounting brackets.
FIG. 33
12
H716001
FIG. 34
2
1
H716006
FIG. 35
1
2
H716004

79032996 A Rev. 01-13
Safety
FIG. 36: Right-hand feeder housing shield (1) shown
removed with tether (2).
Left-hand Shields
FIG. 37: To open shields:
1. Position unloader tube in the out position.
2. Unlatch lower swing-up shield (1) and raise the shield
up fully.
3. Unlatch upper swing-up shield (3) and swing the
shield up.
NOTE: The lower swing-up shield (1) can be opened or
closed with the unloader tube in the out or in the
stored position.
NOTE: The upper swing-up shield (3) can be opened or
closed only with the bin unloader tube in the out
position and the lower swing-up shield fully open.
NOTE: Top swing-down shield (2) can only be opened
when the unloader tube is in the out position.
mCAUTION: The top swing-down shield is
not equipped with a gas spring and must be
lowered slowly and carefully to prevent
injury or damage to shield.
FIG. 38: To close shields:
1. Close upper top swing-down shield (1) and latch in
place.
2. Close the upper swing up shield (2) and latch in
place.
3. Close down lower swing-up shield (3) and latch in
place.
NOTE: Moving the bin unloader tube from the OUT
position to the STORED position with the shields
open will result in damage to the shields and/or to
the bin unloader tube.
FIG. 36
1
2
H716010
FIG. 37
2
13
M672711b
FIG. 38
2
31
M627741b

Safety
01-14 79032996ARev.
Right-Hand Shields
FIG. 39: To open shields:
1. Unhook swing-down shield/step (1) and swing shield
down.
2. Open swing-up shield (2) at the front of the shield.
Pull down on release handle and raise the shield.
NOTE: Only raise or lower swing-down shield/step with
the swing-up shield in closed and latched
position.
FIG. 40: To close shields:
1. Using the handle provided, close and latch the
swing-up shield (2).
IMPORTANT: Do not pull on gas spring to close the
shield.
2. Swing up the swing-down step/shield (1) and hook
the shield in place.
BACKUP ALARM
FIG. 41: The combine is factory equipped with a backup
alarm (1) that activates when the control handle is moved
into reverse and the back up lights engage.
The backup alarm is located forward of the batteries next
to the battery jumper post.
FIG. 39
2
1M627646b
FIG. 40
2
1
FIG. 41
1
L615852

79032996 A Rev. 01-15
Safety
FAN LEAF SCREEN
FIG. 42: To open:
1. Make sure everything is cleared from under the
machine.
2. Locate release handle on either side of combine
separator frame.
3. Pull release handle. Doors will open rapidly and
automatically.
To close:
1. Hold front door in closed position and swing rear door
shut with enough force to latch the doors together.
mCAUTION: Make sure hands and fingers
are clear when shutting the doors. NEVER
operate or transport or allow others to
operate or transport the combine unless
ALL SHIELDS supplied with the combine
and its attachments are PROPERLY IN
PLACE AND PROPERLY LATCHED.
TRANSMISSION SCREEN
FIG. 43: To open:
1. Make sure everything is cleared from under the
machine.
2. Locate release handle on either side of combine
separator frame.
3. Pull release handle. Doors will open rapidly and
automatically.
To close:
1. Hold rear door in closed position and swing front door
shut with enough force to latch the doors together.
mCAUTION: Make sure hands and fingers
are clear when shutting the doors. NEVER
operate or transport or allow others to
operate or transport the combine unless
ALL SHIELDS supplied with the combine
and its attachments are PROPERLY IN
PLACE AND PROPERLY LATCHED.
FIG. 42 H715001
FIG. 43 M501429
