GLM SET5F User manual

SET5F
SETSFS
SET5W
SET5WS
ElectronicTotal Station
OPERATOR'SMANUAL
Thank you for selectingthe SET5FlSET5FSISET5Wl
SET5WS ElectronicTotal Station.
Before usingthe instrument, please readthis operator's
manual.
Verify that all equipment is includedby referr~ngto
"STANDARDEQUIPMENT", P168.
The specifications and general appearance of the
instrument may be alteredat any time and may differfrom
those appearing in brochuresand this manual.
The pictureonthe cover and illustrationsare of the SET5W.
-
i

b IMPORTAMT * For lithium battery
A lithium battery is usedto power the SET memory.
This ensures "continuousmemory"so that all data
IS
safe. The lithiumbattery containsenough power to
back up the memoryfor upto
10 years. If the lithlum
batteryis completelydischarged, all data will be
cleared. If the lithium battery becomes low,
an error message "Backupbattery
low!",
"RAM clearedand "Code file
checksum error Code file deleted"
will be displayedat power-on.
RAM cleared After that, "deleteall data
?" is
displayed. To downloadthe datato
Code
f i I e
checksum error
Code file deleted
1
Data checksum error!
a personalcomputer, press <No>
and downloadthe data in Data
memory mode.
If cYes> is
pressed,the data will be cleared.
To replacethe lithium battery,
pleasecontact your SOKKlAagent.
When the batteryis replaced,all
data iscleared.
delete all data
?
Yes No
For rechargeable battery
The battery has not been charged at the factory.
Pleasechargethe batteryfully before using, referring
to
"22. POWER SUPPLIES.

* For Tribrach
When the new SET is shipped,the tribrach clamp is
fixed with a screw. Loosenit and leave it loose.
If
the SET is again shipped, fix the tribrach clamp with
this screw to securethe tribrachto the instrument.
/--- Tribrach clamp
lockingscrew
b NOTE
* Ifthe display appears as at leftfor
Password = 000 some reason, please press
<ESC>. The instrumentreturnsto
(Usuallythis mode is not used.)
iii

Table of Contents
Table of Contents
ALWAYS FOLLOW PRECAUTIONSFOR SAFE OPERATION ...... viii
FEATURES ...................................................................................... xii
EXPLANATIONOF SOFTKEYS .................................................. xiii
HOW TO USE THIS MANUAL ....................................................... xiv
Introduction
1 . PRECAUTIONS ................................................................. 3
2 . PARTS OF THE [NSTRUMENT ......................................... 4
3 . DISPLAY SYMBOLS ......................................................... 6
4 . KEY FUNCTIONS .............................................................. 7
5 . MODE DIAGRAM .......................................................... 10
Preparationfor measurement
6 .
MOUNTINGTHE BATTERY ............................................ 13
7 . SETTING UPTHE INSTRUMENT ................................... 14
7.1 Centering ........................................................................ 14
7.2 Levelling
......................................................................... 16
8 . POWER ONAND PREPARATION FOR MEASUREMENT ..... 20
8.1 Power on and off ............................................................. 20
8.2 Indexingthe vertical and horizontalcircles
..................... 22
8.3 Focusingandtarget sighting
........................................... 23
8.4 Displayand reticle illumination
....................................... 25
8.5 Settingthe instrumentoptions
........................................ 26

Table of Contents
=-i
Table of Contents
Measurement
................................................ 9 . ANGLE MEASUREMENT 33
9.1 Measurethe horizontalangle between2 points ............. 34
9.2 Set Horizontalcircleto a requiredvalue
......................... 35
9.3 Horizontalangle display selection
.................................. 36
9.4 Horizontalangle repetition
.............................................. 37
9.5 Slope in
% ..................................................................... 39
10 . DISTANCE MEASUREMENT .......................................... 40
10.1 Atmospheric correction ................................................... 41
10.2Returnsignal checking
................................................... 44
10.3Distanceand angle measurement
.................................. 45
10.4Trackingmeasurement
................................................. 47
10.5 Review of measureddata
............................................... 48
11 . COORDINATE MEASUREMENT .................................... 49
11.1 Instrumentstation coordinatessetting ............................ 50
11.2 Target heightand instrumentheightsetting
.................... 52
11.3 Azimuth angle setting
..................................................... 53
11.4 3-Dimensionalcoordinatemeasurement
........................ 56
Advanced measurementfunctions
12 . RESECTlONMEASUREMENT ....................................... 61
13
. MISSINGLINE MEASUREMENT .................................... 66
......... 13.1 Measuringthe distance between2 or more points 67
13.2 Changingthe starting position
........................................ 69
14 . SETTING-OUT MEASUREMENT .................................... 70
14.1Distancesetting-out measurement ................................. 71
14.2 Coordinatessetting-out measurement
............................ 74
14.3 REMsetting-out measurement
....................................... 77
15 . OFFSET MEASUREMENT ........................................ 78
15.1 Distanceoffset ......................................................... 79
15.2 Angle offset
................................................................ 81
16 . REM MEASUREMENT .................................................. 83

Table of Contents
.--
Table of Contents
Using Data memory function
17 . DATA MEMORY FUNCTION ........................................... 89
.................................... 17.1 Changingthe instrumentoptions 91
...................................................................
17.2 Job selecting 92
... 17.3Instrumentstation data and Measureddata recording 93
17.4lnstrumentstationdata and Measureddata
rev~ewing / deleting / outputting .................................... 101
................ 17.5Featurecode inputting / deleting / reviewing 104
............
17.6 Coordinatedata inputting / deleting / reviewing 107
Troubleshooting
18 . ERROR MESSAGES ..................................................... 163
19 . CHECKS AND ADJUSTMENTS .................................... 1116
19.1 Plate level ...................................................................... 116
19.2Circularlevel
............................................................... 118
19.3Tilt sensor
................................................................... 119
19.4Reticle
.......................................................................... 123
19.5 Optical plummet
........................................................... 128
19.6 Distancemeasurement check flow chart
...................... 130
19.7Additive distanceconstant
............................................ 131

Table of Contents
Table of Contents
Measurement options selection
20 . CHANGING INSTRUMENTPARAMETERS ................. 135
21
. CHANGINGLOCATIONOF FUNCTIONSFOR KEYS ... 144
21.1 Key function allocating ............................................. 146
21.2 Registered location recalling ......................................... 151
22 . POWER SUPPLIES ..................................................... 153
23
. REFLECTINGPRlSMSANDACCESSORIES .............. 156
Appendices
Appendix 1 : Manually indexingtheveslical circle by face
left. face right measurements
...................... 161
Appendix
2: For distance measurement of the highest
accuracy
........................................................ 162
Appendix 3: Earth-curvature and refraction correction
. 164
Appendix 4: Standard accessories ................................... 165
Appendix
5: Optional accessories .................................... 166
S'ITANDARDEQUIPMENT ................................................. 168
.................................................................... MAINTENANCE 169
....
SPEClFlCATiONS ............................................................... 170
ATMOSPHERlC CORRECTIONCHART .............................. 174
....................................................................
REGULATIONS 175

ALWAYS FOLLOWPRECAUTIONSFOR SAFE OPERATION
-
For the safe use of the productandpreventionof injuryto
operatorsand other personsas well as preventionof property
damage, itemswhich shouldbe observed are indicatedby an
exclamationpoint within a triangle usedwith WARNING and
CAUTIONstatementsinthis operator's manual.
The definitionsof the indicationsare listed below. Be sure you
understandthem beforereadingthe maintext.
Definitionof Indication
f
Ignoring this indication and making an operation
errorcouldpossiblyresultindeathor seriousinjury
to the operator
Ignoring this indication and making an operation
7 CAUTION errorcouldpossiblyresultinpersonalinjuryor prop-
A erty damage
Definitionof Symbols
This symbol indicates items for which caution (hazard warn-
ings inclusive)is urged.
Specific detailsare printed inor nearthe symbol.
This symbol indicates items which are prohibited.
Specificdetails are printed inor nearthe symbol.
This symbolindicatesitemswhich mustalwaysbeperformed.
Specificdetails are printedinor nearthe symbol.

ALWAYS FOLLOW PRECAUTIONS FOR SAFE OPERATlON
General
AWARNING
Never look at the sun throughthe telescope.
Lossof eyesightcould result.
8
Do not lookat reflectedsunlightfrom a prism or other reflecting
objectthroughthe telescope. Lossof eyesightcould result.
Directviewing of the sun insun observationwill cause loss of
eyesight.Usethe solar filter (option)for sun observation.
Do not performdisassemblyor rebuilding. Fire, electricshock
or burnscouldresult.
Do not use the main unit inareas exposedto highamountsof
8 dust or ash, inareaswhere there is inadequateventilation, or
nearcombustiblematerials.An explosioncouldoccur.
Secure handleto main unit with lockingscrews.
Q Failuretoproperlysecurethe handlecouldresultintheunitfalling
off while beingcarried,causing injury.
Tighten the adjustmenttribrach clamp securely.
@ Failureto properlysecurethe clamp couldresult inthe tribrach
falling off while beingcarried, causing injury.
8
Do notwield or throw the plumb bob.
A personcouldbe injured if struck.
Do not place the instrument in a case with a damaged catch,
@ belt or handle.
The case or instrumentcould bedroppedandcause injury.
Do notusethecarryingcase asa footstool.The caseisslippery
and unstableso a personcouldslip andfall off of
it.

ALWAYS FOLLOW PRECAUTIONSFOR SAFE OPERATION
Power Supply
Donotusevoltageother thanthe specifiedpowersupplyvoltage. \
Fireor electrical shock could result.
Useonlythe specifiedbatterychargerto rechargethe batteries.
@ Other chargersmay be of differentvoltage ratingor polarity
causingsparkingwhich could leadto fire or burns.
Do not place articles such as clothing on the battery power
@ chargerwhile charging batteries.
Sparks could be inducedleadingto fire.
Do not use damaged power cords, plugsor looseoutlets.
Fireor electric shock could result.
Do not use batteriesor the batterycharger if wet.
Resultantshortingcouldleadto fire or burns.
@ Battery BDC25A meets IPX7 specificationfor waterproofing
(immersion-proof). But shorting could occur
if the terminals
become wet.
Do not use power cords other than those designated.
Fireor electric shock could result.
To preventshortingof the battery instorage,apply insulating
tape or the equivalentto the batteryterminals.
Otherwiseshorting could occur resultinginfire or burns.
Do not heator throw batteriesinto fire.
An explosioncouldoccur resultingin injury.
Do notconnector disconnectpowersupplyplugswithwet
Electricshock could result.
Do not touch liquidleakingfrom batteries.
Harmfulchemicalscouldcause burnsor blisters.

ALWAYS FOLLOWPRECAUTIONSFOR SAFE OPERATION
- 2
I
When mountingtheinstrumenttothetripod,tightenthecentering \
8
screw securely.
Failuretotightenthescrew properlycouldresultinthe instrument
falling off the tripod causing injury.
I
Securely tightenthe legfixing screwsof the tripod on which the I
instrumentis mounted.
Failuretotightenthescrewscouldresultinthetripodcollapsing,
causinginjury.
Do not carry the tripod with the tripod shoes pointed at other
Q persons.
A personcould be injured if struck by the tripod shoes.
Keephandsandfeet awayfromthetripodshoeswhenfixing
the
@ tripod inthe ground.
A handor foot stab wound couldoccur.
Tightenthe legfixingscrewssecurelybeforecarryingthetripod.
@ Failure to tighten the screws could lead to the tripod legs
extending, causinginjury.

FEATURES
-
WATERPROOF(SETSWISWS)
SET WANS conformsto IPgrade X7 specificationfor
waterproofing(Immersion-proof)when the Connector caps
areattached andthe BatteryBDC25A is mounted.
DUALAXIS TILT SENSOR
* The vertical and horizontalangle value can be
compensated.
Q Vertical angle value only can be compensated.
SOFTKEYS
Q All 4 function keys can be customizedfor your needs.
RESUME FUNCTION
* The previousmode at power off is memorizedfor about 1
week. When the SET is switchedon, the previousmode is
resumed.
AVERAGE IS CALCULATED
* The averageof horizontalanglecan be calculated and
displayed inthe repetitionmode.
Q The average of distancecan be calculated and displayedin
the average measurement mode.
ADVANCED MEASUREMENT
Resectionmeasurement Missingline measurement
* Setting-outmeasurement * REMmeasurement
DATA CAN BE STORED IN AN INTERNAL MEMORY
Q 3000 point data can be stored in an internal memory.
DATA OUTPUT
The SET RS-232Ccompatibledataoutput connector is
providedfor use with a data collectoror an externaldevice.

EXPLANATIONOF SOFTKEYS
-
Softkeys
* The bottomlineof the SET display lists 4 softkeys.Asoftkey
is a software key; the definition of the key is shown inthe
bottom line of the display. Onlythe softkeys relevantto your
currenttask appear. If you pressthe key underthe
displayedfunction, the function is performed.Upto
4
softkeysareavailable at a time.
For example, if you pressthe number one leftkey at the
followingdisplay, the horizontalangledisplay isbeenset to
0.
IzA 900000' -I: 1
HAR 125" 56'40"
OSET
HOLD Ti l t -+P3
By pressingthe key under "+PX, the next page is
displayed.
"ESC" key is availableinany mode. By pressingthe
"ESC"
key, the mode isclosed and the display returnsto Basic
mode. By pressingand holding,the power off and
illuminationfunctionsare displayed.
Allocatingfunctions for each key
When SET leftthe factory, the locationof the functionsfor
each key were set to defaults. Any function can be
allocatedinany pageof any mode. For a descriptionof how
to allocate functions, please refer to
"21. CHANGING
LOCATIONSOF FUNCTIONSFOR
KEYS.
-
xiii

HOW TO USETHIS MANUAL
The SET allowsyou to changethe locationof functionsfor
each key, so it is difficultto determineon which mode and
page a function is located.
Therefore,inthis manual, the operationsare mainly
explainedusingthe default locationof the functionsfor keys.
Typefaces are usedinthis manualas follows:
<Key>
Indicatesa keyboardkey that causesan immediate
action.
Examples:
<Sdist>, < l >, < 1 >, <Enter> .
B NOTE lndicatesadditionalinformation.
b IMPORTANT lndicates important information.
b PRECAUTION lndicates precautioninformation.
BP EXAMPLE lndicates an operationexample.
b EXPLANATION lndicatesan explanationfor a particularterm or opera-
tion.
b PROCEDURE lndicates an operationprocedure.

Infroduc~LE'on
1 . PRECAUTIONS ................................................... 3
.............................
2 . PARTS OF THE INSTRUMENT 4
..................................................
KEY FUNCTIONS 7
.................................................
.
5 MODE DIAGRAM 10

1. PRECAUTIONS
111
* Never placethe SET directly on the ground.
Avoid damaging the tripod head and centeringscrew with sand
or dust.
Do not aim the telescopeat the sun.
Avoid damagingthe LEDof the EDMby usinga solar filter
when the telescope is pointedat the sun.
Protectthe SET with an umbrellaagainstdirect sunlight, rain
and humidity(SET FIFS).
* Handlethe SETwith care. Avoid heavy shocks or vibration.
* When the operatorleaves the SET, the vinyl cover should be
placedon the instrument.
Always switchthe power off beforeremovingthe standard battery.
Removethe standard batteryfrom the SET before putting it in
the carryingcase.
When the SET is placed in the carrying case, follow the layout plan.
* Make surethat the insideof the carrying case and the
instrumentare dry beforeclosingthe case. If moistureis
trapped insidethe case, it may causethe instrumentto rust.
PRECAUTION for SET 5Wf5WS
SET WiWS conformsto IP gradeX7 specificationfor
waterproofing(Immersion-proof)only when the Connectorcaps
are attachedand the BatteryBDC25A is mounted.IPX7does
notguarantee the instrumentif it isusedor leftinwater.
Degree of water resistance
@ Mount the BatteryBDC25Aand attach the Connectorcaps
correctly. When remountingthe batteryor Connectorcaps,
make surewater does not come in contactwith the battery
terminals and connectors. If moistureenters the insideof the
instrument,itcould damage the product.
Make surethatthe inside of the carrying case and the
instrumentare dry before closingthe case. If moisture is
trapped insidethe case, it may causethe instrumentto rust.
* The standardor optionalaccessoriesotherwisethe Battery
BDC25Ado not meet IPX7specifications.

2. PARTS OF THE INSTRUMENT
@ Handle
@ Circular leveladjustingscrews
@ Instrumentheightmark @ Circularlevel
@ Display
@ Levellingfoot screw
@ Keyboard Tribrach
@ Tribrachclamp
6) Optical plummet eyepiece
@ Base plate
@ Optical plummet reticle
adjustingcover
@ Optical plummet focussing ring
@ Objectivelens
@ Handle securingscrew

2. PARTS OF THE INSTRUMENT
111.
@ Tubular compassslot
@ Externalpower source
@ Battery connector
l Connector cap
8 Horizontalclamp
@ Platelevel
(D Horizontalfine motionscrew
@ Plateleveladjustingscrew
@ Dataoutput connector /
@ Vertical clamp
Connector cap
@ Vertical fine motionscrew
@ Telescopeeyepiece
@ Telescope focusing ring
@ Peep sight
@ Instrumentcenter mark
-
5

3. DISPLAYSYMBOLS
, rn
1 3. DISPLAY SYMBOLS
ZA : Zenith angle (Z=O)
VA
: Vertical angle (H=O) /
Vertical angle (H=0i90°)
: Slope in O/O
HAR : Horizontalangle right
HAL
: Horizontalangle left
HAh : Horizontalangle hold
HARP : Horizontalangle repetition
dHA : Horizontalanglefrom
setting-outdata
X
: Tilt angle insighting direction
Y
: Tilt angle in horizontalaxis
direction
I+
: Tilt angle compensationon
S
: Slopedistance
: Slope in % at Missingline
measurement
H
: Horizontaldistance
V
: Heightdifference
Ht.
: REMvalue
tk
: Trackingmeasurement data
-
- -A:Average measurement data
Stn: Instrumentstationcoordinates
P : Coordinatesetting-outdata
N : N coordinatedata
E
: E coordinatedata
Z : Z coordinatedata
<Remainingbatterypower>
(BDC25A,Temperature=25"C, EDMon)
&3: 90t0 100%
&2:50to 90%
hl :lOto 50%
10: Oto 10%
