Global Invacom DB60L4 Instruction manual

DB60L4 Mesh Sat. Dish with Quad LNB for Sky and Free to Air

Parts List
Assembly Instructions
1.Fix Antenna Bracket (2) to Antenna (1) using 4 off M6x12
painted posi pan screws (11) & M6 nuts (10). Leave bottom 2 nuts
loose until Feed Leg (4) is secure.
2. Insert Feed Leg (4) into Antenna Bracket (2) through
hole in the dish face and secure in place using an
M6x40 posi pan screw (13) & an M6 nut (10). Note;
tighten bottom 2 nuts on the Antenna.
Item
Description
Qty
1.
Antenna
1
2.
Antenna Bracket
1
3.
Elevation Bracket
1
4.
Feed Leg
1
5.
L Tube
1
6.
Wall Mount
1
7.
Fixing Kit
1
Quad LNB
1
Item
Description
Qty
10.
M6 serrated flange nuts
17
11.
M6x12 painted Posi Pan
4
12.
M6x16 cup squares
4
13.
M6x40 Posi Pan Screw
1
14.
M6 U Bolt (43mm ctrs)
4
1
2
3
6
7
5
4

3. Attach Elevation Bracket (3) to Antenna Bracket
(2) using 4 off M6x16 cup square screws (12) & M6
nuts (10).
4. Insert L Tube (5) into Wall Mount Bracket (6) & secure using 2 off M6 U Bolts (14) & 4
off M6 nuts (10). If the horizontal angle of the antenna from the wall is between +/- 55°
then the short end of the L Tube should be fixed to the wall mount, if the angle is to
increase above 55° (+/-90°) then the long end should be fixed to the wall mount.
5. After the Wall mount has been fixed to the wall, clamp the dish assembly to the wall
mount assembly using 2 off M6 U Bolts (14) & 4 off M6 nuts (10).

LNB Alignment
1. Carry out basic alignment of your dish, setting the angle of elevation above the
horizontal and azimuth angle from magnetic North.
2. Loosen the screw on the collar and slide the bracket on the LNB to the front.
3. Roughly align the polarisation angle of the LNB (Astra 28.2) then connect your
meter for the final fine tuning. When aligned tighten the screw on the collar.
4. Remove the meter and connect the down-leads to the receivers or multiswitch,
using f-connectors, then pull down the weather shield.
