U S E R M A N U A L
SPDIF/TosLink/Coaxial
Digital Audio Converter
Model No: ADCN0002M1(Toslink To Coaxial)
ADCN0003M1(Coaxial To Toslink)

INTRODUCTION
Dear customer
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating or adjusting this product. Please keep
this manual for future reference.
Our series of converters, switchers, extenders, matrixes and splitters are designed to make
your A/V device use more convenient, more comfortable, more productive and more cost-
efficient.
SPDIF/TosLink/Coaxial Digital Audio Converter can let the optical fiber signal convert to
coaxial signal(Toslink To Coaxial) or coaxial signal convert to optical fiber signal (Coaxial To
Toslink). It can be easily implemented swaps between the two interfaces.
Our devices offer solutions for noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate training
environments.
FEATURES
One ways of optical fiber signal input convert to one ways of coaxial signal
output.( Toslink To Coaxial)
One ways of coaxial signal input convert to one ways of optical fiber signal output.
(Coaxial To Toslink)
Audio format support : LPCM2.0/DTS/Dolby-AC3
The highest support 192 KHz sampling rate.
Used optical fiber cable loss less the 0.2Db/m, Output distance is up to 30m. (Coaxial To
Toslink)
Use the standard coaxial cable output can be up to 10m.( Toslink To Coaxial)
Wide voltage input, It can support DC 5V~ 12V input
Installs in minutes
The accessories with the machines lists：
1. USB to DC 5.5mm Power cable 1pcs
2. Operation Manual 1pcs

Physical Connection Showing Picture：
Toslink To Coaxial
1. Toslink input port
2. Coaxial output port
3. Power indication
4. DC Power Adaptor Interface(DC 5V~12V)
Coaxial to Toslink
1. Toslink output port
2. Coaxial input port
3. Power indication
4. DC Power Adaptor Interface(DC 5V~12V)

Operating and Connecting：
1. To use the optical fiber cable or coaxial cable to connect the optical fiber signal source or
coaxial signal source (such as blue-ray player, the computer and so on) with the converter input.
2. The converter output port through the optical fiber cable or coaxial cable connected to the
optical fiber signal receiver or coaxial signal receiver (such as AV amplifier and so on).
3. Connect DC power supply to the converter DC input port (DC 5V~12V)
SPECIFICATIONS:
Support audio format………………………………………………..LPCM2.0/DTS/Dolby-AC3
Peak wavelength………………........................................................................………650nm
Max baud rate…..…………….…...………………………………………………………25Mbps
Optical fiber cable output distance ….≤30m(Use the optical fiber cable loss less the 0.2Db/m)
Coaxial cable output distance……………………... ≤10m(Use the standard coaxial cable )
Max working current………………………………………………………..……20mA/12V DC
Operating Temperature range……..…………….………………………………… (0 to +40℃)
Operating Humidity range…………….………….….……....5 to 85%RH (No Condensation)
Storage Temperature range……………………………………………………….(-10 to +55℃)
Storage Humidity range………………………………………0 to 90%RH (No Condensation)
Dimension (L x W x H)………………………………….………….…………60x48.5x20 (mm)
Weight…..………………………………………………………..……………………………75g

Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the machine.
1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty,
Erosive, and oxidative environment.
2. All parts will be free from the strong shake, hit, fall.
3. Touching the power adaptor with the wet hands is prohibited.
4. Pls hold the power adaptor head and do not pull the power cord when cut off from the
socket.
5. Pls turn the power off when the machine is not used for long time.
6. Pls do not open the cover and do not touch the inside parts.
7. Pls use the original factory power adaptor.
Before power on, pls check the connection line carefully. And make sure that all interfaces
are normally connected. The common trouble shooting way shows below:
Serial NO
Trouble
Description
Cause and Ways to deal with
1
Non-Power-
Connected
1、Check if the power adaptor head is truly and
correctly inserted the power socket.
2、Check the power switch if it is in on status.
2
No sound output
1、Check the signal receiving equipment and the
machine connection are in good condition.
2、To check if the signal source is on and well
connected.
3、Check the system connection quality.
4、Check if the line is all good quality.
3
Sound
interrupted
1、To try again to connect the cable to be free from the
unsuccessful connection.
