Glopex Networks GPS G53 User manual

GPS G53
Portable Automobile
Navigation System
Quick Started Guide
ʄFull version of GPS G 53 instruction manual,
please refer to DVD Auto-run program.
Version: V.01
January 2007
Support info
Glopex and GPS G53 are trademarks of Glopex Networks Inc.
All other trademarks belong to each registered companies.
Note
zContents of this manual will be modified without further notice.
zThe proper operation temperature of the product is between 0ഒ~40к.
Operating or recharging in an environment with temperature over 45к
might cause system to stop functioning. Yet this should be considered as a
normal phenomenon. Please do not operate in an extreme temperature
environment.

Operating Methods
Startup
1. For first time use, please turn the
system power switch at the rear side
On.
2. Press and hold the power button for
about two seconds to turn on the
power.
Note: Before the first time use, please
switch the system power on.
Shutdown
1. While power is on, press the power
button to turn off power.
2. If the unit will not be used for a long time, turn the system power switch
at the rear side Off.
Power
button
System
power
switch

Using GPS Cradle / Suction Cup Holder
The included in GPS Cradle set can be securely suctioned on the front
windshield, or using the adhesive plate, securing on top of the glove
compartment. This device will effectively secure the GPS unit in the
vehicle. Follow the procedures below to secure the bracket:
1. Follow the arrows and slide the unit into
the GPS Cradle fitting holes to secure.
2. Gently push down until the unit is tightly
fixed with the bracket.
Note: Please note the directions
of the arrows, when fitted the
assembly should be tight. If these
directions are not followed, a
loose fit will result, and
components must be
reassembled.

GPS Mounting Kit Contents:
GPS Cradle Suction Cup Holder Adapter Plate
G53 Cradle Adapter Plate
Suction Cup Holder

Step up GPS Mounting Kit in Your Car:
Note: When receiving the GPS Mounting Kit, the Adapter Plate is
already connecting to the GPS Cradle. If not, please follow the
instruction shown below.
When Adapter Plate is not connecting to the GPS
Cradle…
* Place the Adapter Plate on the GPS Cradle and securely connected
as the pictures shown below.
Step 1. Hold the Suction Cup Holder Base firmly against your windshield,
and then press forward while Suction Cup Holder in place.
Push the Plate to
the right to connect

Step 2. Connect the Cradle to the Suction Cup Holder.
Step 3. The GPS Cradle set up is complete.
9When using the GPS Mounting Kit, do not install in a location that
will block the view of the driver
The GPS Mounting Kit should be resting securely on the windshield
to prevent excessive shock.

Adjusting the Suction Cup Holder
1. Loosen both vertical adjustment knobs and change the angle of the
central joint so that the connecting flange is vertical when the suction cup is
held against your vehicle’s windscreen. Tighten the knobs to lock in place.
2. Unfasten the horizontal adjustment knobs and change the horizontal
angle of the connecting flange so that it is facing in your preferred direction:
in line with the vehicle, towards the driver, or towards the passenger.
Tighten the knob to lock in place.
Using the Car Charger
While using the device in a vehicle, use the included car charger for long
duration of usage.
1. Plug in the small plug into the
power jack on the rear of the GPS
Cradle.
2. Insert the other end into the
cigarette lighter.

System Reset
Only under extremely few circumstances will it be required to
reboot the system. Reset your system if the following
situations occur:
1. Heavy lag experienced with screen refresh or
operations, resulting in an inoperable system.
2. Cannot turn off the system with power button.
3. No response with selection on the screen.
If any of above occurs, press the Reset button on the right
side of the unit to reboot the system.
Main Menu
During the first startup, the screen will show the main screen consisting of
four functions: navigation, music, photo, and settings. Directly select the
icon onscreen to use the
function.
GPS Loads the navigation program and navigation
screen
Note: If the SD card with navigator software is
inserted, the system will enter GPS function
automatically after startup.
Music Plays MP3 music
Photo Plays images
Other Enter expansive functions (Video, eBook) and
system setup
Reset
button
