GMC 2009 Cadillac DTS Parts list manual

Overview ........................................................ 1-1
Overview .................................................. 1-2
Features and Controls ..................................... 2-1
Features and Controls ................................ 2-2
Navigation Audio System ................................ 3-1
Navigation Audio System ............................ 3-2
Voice Recognition ........................................... 4-1
Voice Recognition ...................................... 4-2
Index ................................................................ 1
2009 Cadillac DTS Navigation System M

GENERAL MOTORS, GM, the GM Emblem, CADILLAC,
the CADILLAC Crest & Wreath, and the name DTS are
registered trademarks of General Motors Corporation.
DTS and DTS Digital
Surround are registered
trademarks of Digital
Theater Systems, Inc.
Dolby
®
is manufactured under license from Dolby
®
Laboratories. Dolby
®
and the double-D symbol
are trademarks of Dolby
®
Laboratories.
The information in this manual supplements the owner
manual. This manual includes the latest information
available at the time it was printed. We reserve the right
to make changes in the product after that time without
notice. For vehicles first sold in Canada, substitute
the name General Motors of Canada Limited for Cadillac
Motor Car Division whenever it appears in this manual.
Keep this manual with the owner manual in the
vehicle, so it will be there if it is needed. If the vehicle is
sold, leave this manual in the vehicle.
Litho in U.S.A.
Part No. 25974042 A First Printing
©
2008 General Motors Corporation. All Rights Reserved.
ii

Canadian Owners
A French language copy of this manual can be obtained
from your dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de ce guide en français
auprès de concessionnaire ou à l’adresse suivante:
Helm Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
helminc.com
iii

✍NOTES
iv

Overview .........................................................1-2
Navigation System Overview ............................1-2 Getting Started ...............................................1-4 Cleaning the Video Screen .............................1-11
Section 1 Overview
1-1

Overview
Navigation System Overview
Screen shown with Map Disc Inserted
1-2

A. Map DVD Slot. See “Installing the Map DVD” under
Maps on page 2-4 for more information.
B. FULL MAP Touch Screen Button. See “NAV ” under
“Hard Keys” under Using the Navigation System
on page 2-2 for more information.
C. North Up/Heading Up Symbol. See Symbols on
page 2-7 for more information.
D. O(Power/Volume) Knob. See “Hard Keys” under
Using the Navigation System on page 2-2 for
more information.
E. No GPS Symbol. See Symbols on page 2-7 for more
information.
F. NAV (Navigation) Key. See “Hard Keys” under Using
the Navigation System on page 2-2 for more
information.
G. Straight Line to Distance Symbol. See Symbols on
page 2-7 for more information.
H. DEST (Destination) Key. See Destination on
page 2-13 for more information.
I. Map Scale. See “Map Scales” under Maps on
page 2-4 for more information.
J. RPT (Repeat) Key. See “Hard Keys” under Using
the Navigation System on page 2-2 for more
information.
K. FAV (Favorite) Key. See “Storing Preset Stations”
under Navigation Audio System on page 3-2 for more
information.
L. V(Zoom In) Touch Screen Button. See “Map
Scales” under Maps on page 2-4 for more
information.
M. Mark Touch Screen Button. See “Adding
Destinations to the Address Book” under Destination
on page 2-13 for more information.
N. Source (AM, FM, XM, CD, etc.) Touch Screen
Button. See Navigation Audio System on page 3-2
for more information.
O. CD/DVD Slot. See CD Player on page 3-10 or DVD
Player on page 3-15 for more information.
P. Z(CD/DVD Video/Audio Eject) Key. See CD
Player on page 3-10 or DVD Player on page 3-15 for
more information.
Q. Clock Touch Screen Button. See Configure Menu on
page 2-28 for more information.
R. f(Tune/Sound) Knob. See Navigation Audio
System on page 3-2 for more information.
S. AUDIO Key. See Navigation Audio System on
page 3-2 for more information.
T. MENU Key. See Configure Menu on page 2-28 for
more information.
U. ¨SEEK Key (Next). See Navigation Audio System
on page 3-2 for more information.
1-3

V. U(Zoom Out) Touch Screen Button. See “Map
Scales” under Maps on page 2-4 for more
information.
W. ©SEEK Key (Previous). See Navigation Audio
System on page 3-2 for more information.
X. POI (Point of Interest) Touch Screen Button.
See “Displaying Points of Interest (POI) on the
Map Screen” under Symbols on page 2-7 for more
information.
Y. Auxiliary Jack. See Auxiliary Devices on page 3-20
for more information.
Getting Started
Read this manual thoroughly to become familiar with
how the navigation system operates.
The navigation system includes navigation and audio
functions.
While entering the vehicle or when turning the vehicle
off, some DVD Map Disc noise is normal.
Keeping your eyes on the road and your mind on the
drive is important for safe driving. The navigation system
has built-in features intended to help keep your eyes
on the road and mind on the drive. Some features may
be disabled while driving. Note that these functions
will be grayed-out. A grayed-out function indicates it is
not available when the vehicle is moving.
All functions are available when the vehicle is parked.
Do the following before driving:
•Become familiar with the navigation system
operation, hard keys on the faceplate, and
touch-sensitive screen buttons of the navigation
system.
•Set up the audio by presetting favorite stations,
setting the tone, and adjusting the speakers.
•Set up the navigation features before beginning
driving, such as entering an address or a preset
destination.
•Set up your phone numbers in advance so they can
be called easily with the press of a single button or
a single voice command (for navigation systems
equipped with phone capability).
{CAUTION:
Taking your eyes off the road too long or too often
while using the navigation system could cause a
crash resulting in injury or death to you or others.
Focus your attention on driving.
1-4

{CAUTION:
Avoid looking too long or too often at the moving
map on the navigation screen. This could cause a
crash and you or others can be injured or killed.
Use the turn-by-turn voice guidance directions
whenever possible.
Use the navigation system to:
•Plan a route.
•Select a destination using various methods and
choices.
•Follow turn-by-turn route and map guidance with
voice prompts, only if permitted by traffic laws,
controls, and conditions.
You should always be alert and obey traffic and roadway
laws and instructions, regardless of the guidance from
the navigation system. Because the navigation
system uses street map information that does not
include all traffic restrictions or the latest road changes,
it may suggest using a road that is now closed for
construction or a turn that is prohibited by signs at the
intersection. Because the system uses limited
information, you must always evaluate whether following
the system’s directions is safe and legal for the
current conditions.
When the navigation system is turned on, a screen may
appear with the information below, and you must
read and acknowledge the information it contains.
{CAUTION:
Taking your eyes off the road for extended periods
could cause a crash resulting in injury or death to
you or others.
To help avoid a crash in which you or others could be
killed:
•Always concentrate on your driving first by keeping
your eyes and mind on the road, and your hands
on the wheel.
•Follow system directions only if permitted by traffic
laws, controls, and conditions.
•Before using this system, read the owner’s manual
and learn how it operates.
•Some system controls cannot be used the when
vehicle is moving.
1-5

After you acknowledge the start up information you will
be able to access the NAV (navigation) and DEST
(destination) functions. Once accessed, you can enter
or delete information in the navigation system or access
other functions. See instructions later in this section.
Every fifty times the vehicle is started and the navigation
system is turned on, the Caution screen appears. After
reading the caution, select OK to load the map DVD
information. If OK is not selected, all hard keys except
for NAV (Navigation) and DEST (Destination) can be
accessed. You can also press the NAV hard key to have
this Caution screen appear.
When getting started, set the navigation system to your
preference or delete information you may have
entered using various options.
Language — English/Metric
To change the language of the navigation screens, see
“DIC Vehicle Customization” in the Index of your vehicles
owner manual.
To change the navigation screens from English or metric,
see “DIC Operation and Displays” in the Index of your
vehicles owner manual.
Deleting Personal Information
This navigation system can record and store personal
information such as names and addresses. At times,
such as when you are disposing of your vehicle, you
may want to delete this information. See “Edit Address
Book — Edit/View” under Configure Menu on page 2-28
for deleting information from the address book.
1-6
