GME SPK010 User manual

SPK010
SUBWOOFER
MARINE 10 INCH
TECHNICAL SPECIFICATIONS & CUTTING TEMPLATE

www.gme.net.au Part Number: 310438 Drawing Number: 44318-2
CONNECTING
1. Attach the speaker wire (not supplied) to the speaker terminals.
Be sure to connect the striped wire to the negative (–)
terminal, and the other wire to the positive (+)
terminal of the speaker.
2. Connect the other end of the speaker wires to your
amplifier ensuring the negative wire goes to the
negative terminal and the positive goes to the
positive terminal. GME recommends 6 mm (0.2”)
speaker wire is used when cable runs are no longer
than 5 metres (5.5 yards).
MOUNTING
1. Using the template supplied for this subwoofer, mark the correct
mounting location, ensuring there is enough space behind the
location to accommodate the speaker.
2. Push out the template from this leaflet and use to mark the
position of the mounting screws and the outline of the
speaker hole. Drill the mounting holes and cut the hole for
the speaker.
3. Remove the grille of the speaker.
4. Connect the speaker wire as per the earlier instructions.
5. Mount the woofer using the screws supplied.
6. Place the plastic grille back over the subwoofer.
7. The GME SPK010 is a ‘Free Air’ Subwoofer.A Free Air system
consists of woofers mounted to a board attached to an isolated
space in the boat. The board and space acts as an enclosure
which houses the subwoofer and isolates sound from the
back of the speaker, solving the sound cancellation problem of
subwoofers without an enclosure.
SPK010
Power (Watts) 420
Efficiency (1W/1M) 86 db
Frequency Response 30 Hz-2 kHz
Impedance (Ohms) 4
Cone Material Polypropylene
Magnet Structure 30 Oz
Grilles Plastic
Weight (kgs) 3.26
GME limit this warranty to the original purchaser of the equipment.
GME warrant the SPK010 to be free from defects in material and workmanship for a period of thirty six (36)
months from the date of purchase from their authorised retailer.
Should the product require servicing during this period, all labour and parts used to effect repairs will be
supplied free of charge. GME reserve the right to determine whether damage has been occasioned by
accident, misuse
or improper installation whereby the warranty would be void, including equipment which has been damaged
due to:
(a) Incorrect or reverse polarity connection to a battery or power supply or to an incorrect supply voltage.
(b) Operation without an antenna or by connection to an antenna which
has been incorrectly installed, resulting in damage to the speaker’s
output circuit.
(c) Effects of water or moisture penetration.
(d) Non-factory modifications.
Procedure to be followed by claimant: In the event of a defect occurring during the warranty period,
the original purchaser may return the defective unit along with suitable proof of purchase date (i.e. receipt,
docket, credit card slip etc.) and a full description of the defect to the retailer from whom the unit was
purchased. All freight charges incurred for transportation by the retailer or GME are the
purchaser’s responsibility.
GME AFTER SALES SERVICE
Your speaker is especially designed for the environment encountered in land and marine installations. The
use of all solid state circuitry, careful design and rigorous testing, result in high reliability. Should failure
occur however, GME maintain a fully equipped service facility and spare parts stock to meet the customer’s
requirements long after expiry of the warranty period.
MOUNTING INSTRUCTIONS
To Amp
112 mm
4.4”
265 mm
10.4”
SPEAKER DRIVER SPECIFICATIONS
WARRANTY
A Division of Standard Communications Pty. Ltd.
Head Office: SYDNEY- Locked Bag 2086, North Ryde, NSW 1670,Australia. Tel: [phone] Fax : [phone]
MELBOURNE ADELAIDE PERTH BRISBANE SYDNEY AUCKLAND
7 Micro Circuit Unit 1, 14 Phillips Street Unit 1, 10-12 Harvard Way Unit 1, 89-101 Factory Road Unit B, 22-24 College Street Unit 2, 24 Bishop Dunn Place
DANDENONG STH 3165 THEBARTON 5031 CANNING VALE 6155 OXLEY 4075 GLADESVILLE 2111 East Tamaki, MANUKAU 2013
Tel: [phone] Tel: [phone] Tel: [phone] Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
For customers outside Australia and New Zealand please contact your local GME Distributor or email: [email protected]

SPK010 TECHNICAL SPECIFICATION AND CUTTING TEMPLATE
Tear off here
S
p
e
a
k
e
r
h
o
l
e
(
P
u
s
h
o
u
t
)
O
u
t
e
r
e
d
g
e
o
f
s
p
e
a
k
e
r
g
r
i
l
l
e
(
P
u
s
h
o
u
t
)

SPK010 Cutting Template
SPK010 TECHNICAL SPECIFICATION AND CUTTING TEMPLATE
