Godrej GSC 12NTC3-WUA User manual

GSC 12NTC3-WUA
Cooling
230 V
50 Hz/1 Ø
3350 W
950 W
730 CMH
4.40 A
R-32
0.48 kg
22.5 A
IDU 9.00 kg
ODU 27.00 kg
WEIGHT
RATED POWER INPUT (W)
AIR FLOW VOLUME
RATED INPUT CURRENT
REFRIGERANT
REFRIGERANT CHARGE
COMP LRA
PERFORMANCE PARAMETERS
MODEL NAME
OPERATING MODE
RATED VOLTAGE
RATED FREQUENCY/PHASE
COOLING CAPACITY (W)

Protection of environment
“Protection of environment" is one of the core values of Godrej and we seek your co-operation to make sure that the
product, packaging and plastic material is not disposed as unsorted municipal waste.
In line with the company's policy of continual product improvement, the aesthetic and dimensional characteristics,
technical data and accessories of this appliance may be changed without notice.
This symbol is known as the "Crossed-out Wheelie Bin Symbol". It means that the product should not
be disposed of with your general house-hold waste.
It should be disposed of only through the company's collection points with special treatment so as to
prevent any damage to the environment. Please call: 1800 209 5511 for applicable buy back
arrangement or visit: www.godrejappliances.com/green-think for details about Godrej appliances
authorised collection points.

“POWER” indicator : This symbol is ON when the system is in standby mode and
blinks during antifungi features.
“TIMER” indicator : This symbol is ON when ON/OFF timer is activated.
“Compressor” indicator : This symbol is ON when the compressor is running.
0
“Temperature” indicator : This symbol shows the set temperature in C in
0
COOL/DRY/AUTO mode and room temperature in C in FAN mode. when the
indicator displays Error Codes, it means that there is an issue in the running of
the Air Conditioner.
temperature
temperature

FAN
If user want to make the room air cool quickly, user can press"turbo" button in cool mode initially.
the air
conditioner
Press this button for activation
and deactivation of E-saving
mode.
Press this button for
activation and deactivation
sleep mode

Not applicable
Displayed in according with
vertical swing positions.
Displayed when pressing E-
saving button. Set temp. will
0
becomes 24 C and Fan speed
be comes medium and not
changeable.
Displayed the set temperature.
Displayed clock time, press “Set
time” and “HOU/MIN” buttons to
set the time and it also display
timer value in hours only.
Displayed ON symbol when
user press timer key once in
remote OFF state. when user
set the ON timer, the ON symbol
will flash.
Displayed OFF symbol when
user press timer key once in
remote ON state. when user set
the OFF timer, the OFF symbol
will flash.
FAN
on the remote controller, use soft cloth for cleaning if it occurs.

FAN
COOL, FAN, DRY, HEAT and AUTO operation
1. When “COOL” mode is set, in accordance with D-Value between indoor room temperature and set
temperature, air conditioner will start or stop the cooling operation. User can change fan speed Low,
Medium, High and Auto as per requirement.
2. When “FAN” mode is set, Set Temperature can't be adjusted, only Fan Speed can be adjust to Low,
Medium and High. In this mode, Compressor will always remain off. Display will show indoor room
temperature.
3. When “DRY” mode is set, in accordance with D-Value between indoor room temperature and set
temperature, air conditioner will start or stop the cooling operation and fan speed will change
automatically to decrease room humidity. Fan speed cannot be changed in DRY mode.
4. When “AUTO” mode is set, in accordance with D-Value between indoor room temperature and set
temperature, air conditioner will start or stop the cooling operation. In this, mode Set temperature
become 24˚C and fan speed become Auto. Set Temperature and Fan speed can't be adjusted.
5. When “E-Saving” mode is set (in cool mode), Set temperature become 24˚C and Fan speed become
Medium. Set Temperature and Fan speed can't be adjusted.
6. When “SLEEP” mode is set (in cool mode), “SL” icon will appear on display for 2sec. Sleep Function
will run as per following logic:
For first hour Set temp maintains
For next 2 hours: Set temp. + 1°C maintains
For next 5 hours: Set temp. + 2°C maintains
After 8 hours Sleep function gets cancelled.
7. “HEAT” mode is not applicable.

Press timer button in remote off state to set ON
timer. The timer value can be adjusted from 1h to
12h by pressing “ ” or “ ” button
should be in OFF state.
will get disappeared.
y
Press "timer " button in remote off state, timer value
will appear on display. User can adjust timer value
from 1h to 12h. Once the value is set, press again
timer button to set the ON timer.

Press “ ” or “ ” button to adjust the timer
time from 1h to 12h. The “ ” or “ ” is used
for increment or decrement the timer value.
Press "timer " button in remote on state,
timer value will appear on display. User can
adjust timer value from 1h to 12h. Once the
value is set, press again timer button to set
the OFF timer.
should be in ON state.
will get disappeared.

If press the “H-SWING” on the remote controller, horizontal louver blades can be set at the fixed position (Fig. 1)
or auto swing.
“V-SWING”
in ON state

set temperature set by user.
