gofanco Prophecy PRO-3GSDI4P User manual

PRO-3GSDI4P
1x4 3G/HD/SD-SDI Distribuon Amplier with Reclocking
®
Made in Taiwan
User‘s Guide

®
PRO-3GSDI4P
Congratulaons for owning a gofanco product. Our products
aim to meet all your connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit
www.gofanco.com.
For technical support, please email us at
[e-mail].
For drivers/manuals download, please go to
hp://www.gofanco.com/download.

®
PRO-3GSDI4P
• 3G/HD/SDtriple-ratedistribution
• Fourseparatelybueredandreclockedoutputs
• Cableequalization(Beldon1694A)andsignalretiming
• DualcolorLEDindicationofinputlockandrate
• Passesallancillarydata
• Providesautomaticinputcableequalizationupto300m
(1000ft)@SD,150m(500ft)@HDand60m(190ft)
• ReclocksSDIsignalsforcascadingandthuslonger
transmission
• Inter-lockedpowersupplyforbetterxedness
2. Features
1. Introduction
3
ThePRO-3GSDI4PreceivesoneSDIinput,perfectlyduplica-
tesit,andre-transmitsfourSDIoutputsforrealtimemulti-
viewing.ItisareliablevideodevicesplittingaSDI,HD-SDI,
or3G-SDIvideosourcetofourSDIcompliantdisplaysatthe
sametime.Besides,built-inre-clocking&equalizationfea-
turesprovidethebestperformanceforSDIdistributionam-
plier.
• 1xPRO-3GSDI4P
• 1x5Vpoweradapter
• 1xUserManual
3. Package Contents

®
PRO-3GSDI4P
4. Specications
Model Name PRO-3GSDI4P
Technical
SDIstandards SD/HD/3G-SDI
Auto3G/HD/SD
detection Yes
Supportedprotocols SMPTE259M,SMPTE292M,SMPTE424M,SMPTE425M
Videobandwidth [2.97Gpbs&2.97/1.001Gbps]
Datarates 270/1483/1485/2970Mbps
Outputimpedance 75Ω
Reclockingfunction Yes
Cableequalization [3G]upto60m(190ft)/[HD]upto150m(500ft)/
[SD]upto300m(1000ft)
Audiosupport Yes
RP-198pathological
patterns Immune
PCBstack-up 4-layerboard[impedancecontrol—
dierential100Ω;single50Ω]
Input 1xBNC[SDI]
Output 4xBNC[SDI]
BNCconnector 75Ωinter-lockedsocket
Eyepattern
characteristics[HD]
Amplitude:Within800mV±3%(<10%)
Riseovershoot:Lessthan2%(<10%)
Fallovershoot:Lessthan2%(<10%)
Longtimejitter:0.195UI(<1.0UI)
Timingjitter:0.195UI(<1.0UI)
Alignmentjitter:0.127UI(<0.2UI)
4

®
PRO-3GSDI4P
Mechanical
Housing Metalenclosure
Dimensions
[LxDxH]
Model 112x42x25mm[4.4"x1.6"x0.9"]
Package 198x137x74mm[7.8"x5.39"x2.91"]
Carton 420x400x300mm[16.53"x15.75"x11.81"]
Weight Model 174g[6.1oz]
Package 427g[0.9lbs]
Fixedness Inter-lockedpowersupply
Powersupply 5V2ADC
Powerconsumption 10Watts[max]
Operationtemperature 0~40°C[32~104°F]
Storagetemperature -20~60°C[-4~140°F]
Relativehumidity 20~90%RH[nocondensation]
iThe measurement results are from Tektronix WFM-7120 with SDI
through 1m (3.3) long Belden 1694A
5

®
PRO-3GSDI4P
5. Connection Diagram
6

®
PRO-3GSDI4P
6. Panel Description
FrontPanel
RearPanel
1.3G/HD/SD-SDI Output
2.5V DC power jack
3.Power LED indicator
4.3G/HD/SD-SDI Input
5.3G Signal LED indicator
6.HD Signal LED indicator
7.SD Signal LED indicator
8.3G/HD/SD-SDI Output
7
2
5
3
4 67 8
1

®
PRO-3GSDI4P
7. Installation
• Connectacameraorotherdevicesequippedwith3G/HD/
SD-SDIoutputstoPRO-3GSDI4P3G/HD/SD-SDIinput.
• Connectdevicesequippedwith3G/HD/SD-SDIinputs
(e.g.monitorsorvideoprocessors)toPRO-3GSDI4P3G/
HD/SD-SDIoutputs.
• Plugpoweradaptercableinto5VDCpowerjack.
8. Signal Measurement
8

®
PRO-3GSDI4P
9
9. Warranty
TheSELLERwarrantsthePRO-3GSDI4P 1x4 3G/HD/SD-SDI Distribution Amplier
with Reclocking tobefreefromdefectsinthematerialandworkmanshipfor1year
fromthedateofpurchasefromtheSELLERoranauthorizeddealer.Shouldthis
productfailtobeingoodworkingorderwithin1yearwarrantyperiod,TheSELLER,
atitsoption,repairorreplacetheunit,providedthattheunithasnotbeensubjec-
tedtoaccident,disaster,abuseoranyunauthorizedmodicationsincludingstatic
dischargeandpowersurge.ThiswarrantyisoeredbytheSELLERforitsBUYER
withdirecttransactiononly.Thiswarrantyisvoidifthewarrantysealonthemetal
housingisbroken.
Unitthatfailsunderconditionsotherthanthosecoveredwillberepairedatthe
currentpriceofpartsandlaborineectatthetimeofrepair.Suchrepairsarewar-
rantedfor90daysfromthedayofreshipmenttotheBUYER.Iftheunitisdelivered
bymail,customersagreetoinsuretheunitorassumetheriskoflossordamagein
transit.Undernocircumstanceswillaunitbeacceptedwithoutareturnauthorizati-
onnumber.
Thewarrantyisinlieuofallotherwarrantiesexpressedorimplied,includingwit-
houtlimitations,anyotherimpliedwarrantyortnessormerchantabilityforany
particularpurpose,allofwhichareexpresslydisclaimed.
Proofofsalemayberequiredinordertoclaimwarranty.CustomersoutsideTaiwan
areresponsibleforshippingchargestoandfromtheSELLER.Cablesarelimitedto
a30daywarrantyandcablemustbefreefromanymarkings,scratches,andneatly
coiled.
Thecontentofthismanualhasbeencarefullycheckedandisbelievedtobeaccu-
rate.However,TheSELLERassumesnoresponsibilityforanyinaccuraciesthatmay
becontainedinthismanual.TheSELLERwillNOTbeliablefordirect,indirect,inci-
dental,special,orconsequentialdamagesresultingfromanydefectoromissionin
thismanual,evenifadvisedofthepossibilityofsuchdamages.Also, the technical
information contained herein regarding the PRO-3GSDI4P features and specica-
tions is subject to change without further notice.

®
