gofanco PRO-SDIGen User manual

PRO-SDIGen
12G/6G/3G/HD/SD-SDI Paern Generator with LED monitor
®
Made in Taiwan
User‘s Guide

®
PRO-SDIGen
Congratulaons for owning a gofanco product. Our products aim to meet all your
connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit www.gofanco.com.
For technical support, please email us at [e-mail].
For drivers/manuals download, please go to hp://www.gofanco.com/downloads.

®
PRO-SDIGen
Please read all of these instructions carefully before you use the device. Save
this manual for future reference.
The PRO-SDIGen 12G/6G/3G/HD/SD-SDI Pattern Generator with LED monitor
has been tested for conformance to safety regulations and requirements, and
has been certied for international use. However, like all electronic equipment,
the PRO-SDIGen should be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
• Follow all instructions and warnings marked on this unit.
• Do not attempt to service this unit yourself, except where explained in this
manual.
• Provide proper ventilation and air circulation and do not use near water.
• Keep objects that might damage the device and assure that the placement of
this unit is on a stable surface.
• Use only the power adapter and power cords and connection cables designed
for this unit.
• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the po-
wer to the device before cleaning.
1. Safety and Notice
Table of Contents
1. Safety and Notice ..................................................................3
2. Introduction .......................................................................4
3. Features...........................................................................4
4. Specication ......................................................................5
5. Package Contents ..................................................................6
6. Panel Description ..................................................................7
7. Connection Diagram ...............................................................8
8. Notice.............................................................................8
9. Appedix ...........................................................................9
10. LearningWarranty.................................................................11
3

®
PRO-SDIGen
• Supported output resolution
NTSC 525@60, PAL 625@50,
[email protected]/50/59.94/60,
1080i@50/59.94/60,
[email protected]/24/25/29.97/30/50/59.94/60,
[email protected]/24/25/29.97/30/50/59.94/60
• Bit Rate
2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 5.94Gbps,
5.934Gbps, 11.88Gbps, 11.868Gbps,270 Mbps
• Video Patterns
100% Color Bars, Borderline, Random Noise, Check Field, Black, Verti-
cal Lines, Black / White alternate elds, Full Grey / Full White, Black to
White Gradient, Random Generator for all still patterns, moving squa-
res White noise, Inverse eect with still pattern, Scrolling Title (see
Appendix for illustrations)
• Save Settings to Memory Option
• Control
By LCM, panel buttons & rotary switch
• Video Output
SDI output (SDI, HD-SDI, 3G-SDI, 6G-SDI, 12G-SDI)
• Supports Preset Modes
3. Features
The PRO-SDIGen 12G/6G/3G/HD/SD-SDI Pattern Generator with LED monitor
is an advanced SDI pattern generator with multi-format (12G/6G/3G/HD/SD)
and multi-pattern support. Besides still and moving video test patterns, other
features such as audio (SMPTE-291M) are also provided. PRO-SDIGen can sup-
port up to 8 channel AES compliant audio with 48KHz sample rate. PRO-SDI-
Gen is equipped with four buttons, one rotary switch and LCD screen for easy
device control. This device provides a cost eective way to calibrate and test
SDI enable video devices and displays.
2. Introduction
4

®
PRO-SDIGen
5
4.Specications
Item Description
Technical
Hardware type Pattern generator
SDI standards 12G/6G/3G/HD/SD-SDI
Auto SDI
rate detection Yes
Supported
protocols
SMPTE 259M (270Mbps / 360Mpbs)
SMPTE 292M / HDTV (1.485 & 1.485/1.001Gbps)
SMPTE 424/425M (2.97 & 2.97/1.001Gbps)
SMPTE ST-2081 (5.94&5.94/1.001Gbps)
SMPTE ST-2082 (11.88&11.88/1.001Gbps)
Video support 11.88Gpbs
Audio support 270 / 1483 / 1485 / 2967 / 2970 / 5934 / 5940 / 11868 / 11880 Mbps
Resolution
support
[12G] 4K2K@50/59.94/60
[6G] [email protected]/24, 25, 30
[3G] 1080p@50/59.94/60 (4:2:2)
[HD] 720p50/59.94/60,
1080p24/30, 1035i50/59.94/60,
1080i50/59.94/60
[SD] [email protected], PAL@50Hz
PCB stack-up SMPTE-292M / 259M / 424M / ST-2081 / ST-2082
Input 75
Output [12G-SDI] up to 50m (165ft) / [6G-SDI] up to 100m (330ft) /
[3G-SDI] up to 200m (660ft)
HDMI Input
selection Yes
IR remote control 6-layer board [impedance control — dierential 100 ; single 75 ]
HDMI connector 4x BNC [SDI]
RJ-45 connector 75 interlocking socket
RS-232 connector Amplitude: Within 800mV <10%Long time jitter <1.0 UI Rise overshoot: Less than 2% Timing jitter <1.0 UI
Fall overshoot: Less than 2% Alignment jitter <0.2 UI

®
PRO-SDIGen
Mechanical
Housing Metal enclosure
Dimensions
[L x D x H]
Model 167 x 112 x 24mm[6.5" x 4.4" x 0.9"]
Package 325 x 196 x 92mm[12.7" x 7.7" x 3.6"]
Carton 490 x 426 x 352mm[1'6" x 1'4" x 1'2"]
Weight Model 303g [0.6 lbs]
Package 533g [1.1 lbs]
Power supply 12VDC
Power consumption 5 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
6
• 1x PRO-SDIGen
• 1x 12V power supply unit
• 1x User Manual
5. Package Contents

®
PRO-SDIGen
6. Panel Description
1. SDI OUT1-2: 12G/6G/3G/HD/SD-SDI output
2. SDI OUT3-4: 3G/HD/SD-SDI outpu
3. Rotary Switch: For 0-7 preset mode
4. LCD: 2.0” LCD monitor
5. PUSH BUTTON:
7
2 3 5 6 7 841
Button Function
Menu Opens the OSD
Enter Enter the menu item
Up Choose the last menu item
Down Choose the next menu item
6. Micro USB: Micro-USB port for F/W update
7. +12V DC: 12V DC power jack
8. Power Switch: Power ON/OFF

®
PRO-SDIGen
7. Connection Diagram
8. Notice
8
1. Due to the high frequency bandwidth and low jitter requirement of SDI signals,
it is strongly recommended to use just one SDI OUTPUT with one 75 ohm.
2. Features such as new timings, test patterns and menu items, due to rmware or
other updates is subject to change without further notice.

®
PRO-SDIGen
9
9. Appendix
Built-in Video Patterns

®
PRO-SDIGen
10

®
PRO-SDIGen
11
10. Limited Warranty
The SELLER warrants the PRO-SDIGen 12G/6G/3G/HD/SD-SDI Pattern Generator
with LED monitor to be free from defects in the material and workmanship for 1
year from the date of purchase from the SELLER or an authorized dealer. Should this
product fail to be in good working order within 1 year warranty period, The SELLER,
at its option, repair or replace the unit, provided that the unit has not been subjec-
ted to accident, disaster, abuse or any unauthorized modications including static
discharge and power surges.
Unit that fails under conditions other than those covered will be repaired at the
current price of parts and labor in eect at the time of repair. Such repairs are war-
ranted for 90 days from the day of reshipment to the BUYER. If the unit is delivered
by mail, customers agree to insure the unit or assume the risk of loss or damage in
transit. Under no circumstances will a unit be accepted without a return authorizati-
on number.
The warranty is in lieu of all other warranties expressed or implied, including wi-
thout limitations, any other implied warranty or tness or merchantability for any
particular purpose, all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan
are responsible for shipping charges to and from the SELLER. Cables are limited to
a 30 day warranty and cable must be free from any markings, scratches, and neatly
coiled.
The content of this manual has been carefully checked and is believed to be accura-
te. However, The SELLER assumes no responsibility for any inaccuracies that may
be contained in this manual. The SELLER will NOT be liable for direct, indirect, inci-
dental, special, or consequential damages resulting from any defect or omission in
this manual, even if advised of the possibility of such damages. Also, the technical
information contained herein regarding the PRO-SDIGen features and specications
is subject to change without further notice.
The product name and brand name may be registered trademarks of related manufacturers. TM and ®
may be omied on the user‘s guide. The pictures on the user‘s guide are just for reference, and there
may be some slight dierences with the actual products.
We reserve the rights to make changes without prior noce to a product or system described herein to
improve reliability, funcon, or design.
Disclaimer

Thank you for choosing gofanco
®
www.gofanco.com
Jul, 2021 Ver. A Copyright © by gofanco, LLC. All rights reserved.
