Gog Extcy series User manual

eXTCyTM

Operation and adjustment instructions

GOGpaintball.com

QUICK START

01 02 03

Unpack the eXTCyTM and its barrel. Screw the barrel into the front of

the marker, hand tight. Take care not to strip the barrel threads or over-

tighten.

Put the supplied barrel

blocker over the end of the

barrel, securing its cord as far

back on the eXTCyTM body as

possible, and cinching it tight.

Fill the loader with paintballs. If it is a powered loader, turn it on. While wearing ASTM compliant paintball goggles, in an area where all bystanders are protected, remove the barrel

blocker and re over a chronograph to measure the velocity. Using a 5/32-inch allen wrench on the adjuster in the bottom of the vertical regulator, turn clockwise to increase the

velocity/pressure, and counter-clockwise to decrease. Take three or four shots after every adjustment to allow the gas pressure inside the eXTCyTM to stabilize. Adjust until the marker

is ring consistently within the limits for the eld where you are playing (for safety reasons, never adjust the eXTCyTM to re at greater than 300 feet per second). Depending on what

modes of re are allowed at the eld where you are playing (semi-automatic, rebound, etc.) you may need to adjust the eXTCyTM’s ring mode. See the Electronic Adjustment section

for more information.

Fit a paintball loader into the feedneck

of the eXTCyTM. Use a 7/64-inch allen

wrench to lock the loader in place.

Powered force-feed loaders are

recommended, as the eXTCyTM has

little recoil, and can easily outpace an

unpowered or agitating loader.

Gently gas up the eXTCyTM by

slowly turning on the air system

(if HPA system has its own on/

off valve) or turning the bottom-

line ASA knob clockwise.

A gentle rise in pressure is

important, as a sudden blast

may reduce the service life

of the eXTCy®’s internal

components.

Turn on the eXTCyTM by

pressing the power button

momentarily. If the eXTCyTM

does not start, see the battery

section of this manual.

Although the power button

serves as the eXTCyTM’s safety

switch to prevent accidental

ring, it should never be relied

upon in place of a barrel blocker

and proper eye protection.

04 05 06

BARREL BARREL BLOCKER FILL TANK

LOADER TURN ON GAS TURN ON THE eXTCyTM

ADJUST VELOCITY

Have your compressed air

(HPA) or CO2 tank lled by

a person who is properly

trained to do so. If using an

HPA system with an on/off

valve, make sure it is in the

OFF position. If using a CO2

tank or screw-in style preset

HPA system, ll it while it is

removed from the marker.

GOGpaintball.com

Quick Start

Table of Contents and Safety Warnings

Getting Familiar

Barrel Blocker / Hopper

Gasses

Battery

Paint / Velocity

VisionTM Operation

Electronic Adjustment

Trigger Adjustment

Unloading / De-Gassing

Field Stripping

VisionTM / Detent Cleaning

Advanced Maintenance

GripFrame / Body Separation

Circuit Board Removal

Breech Removal

Vertical Regulator

Troubleshooting / Warranty

Parts Diagrams

• THE eXTCyTM IS NOT A TOY.

• MISUSE OF THE eXTCyTM MAY RESULT IN SERIOUS

INJURY OR DEATH.

• EYE PROTECTION DESIGNED FOR PAINTBALL USE

MUST BE WORN BY THE USER AND ANY PERSON

WITHIN RANGE OF THE eXTCyTM.

• GOG PAINTBALL® RECOMMENDS THAT T H E

eXTCyTM ONLY BE SOLD TO PERSONS 18 AND

OLDER.

• THOROUGHLY READ THE eXTCyTM OPERATION

AND INSTRUCTION MANUAL BEFORE OPERATING.

• TREAT EVERY PAINTBALL MARKER AS IF IT WERE

LOADED.

• NEVER LOOK DOWN THE BARREL OF A PAINTBALL

MARKER.

• KEEP YOUR FINGER OFF THE TRIGGER UNTIL

READY TO SHOOT. NEVER POINT THE eXTCyTM AT

ANYTHING YOU DON’T INTEND TO SHOOT.

• KEEP THE eXTCyTM ON SAFE (POWER OFF) UNTIL

READY TO SHOOT (SEE QUICK START).

• KEEP THE BARREL BLOCKING DEVICE ON THE

eXTCyTM’S MUZZLE WHEN NOT SHOOTING (SEE

BARREL BLOCKER SECTION).

• ALWAYS REMOVE PAINTBALLS AND DE-GAS THE

eXTCyTM BEFORE DISASSEMBLY (SEE DE-GASSING

SECTION).

• STORE AND TRANSPORT THE eXTCyTM UNLOADED

AND DEGASSED IN A SECURE PLACE.

• FOLLOW ALL MANUFACTURER’S WARNINGS

AND INSTRUCTIONS FOR PROPELLANT SOURCE

HANDLING, STORAGE AND FILLING.

• DO NOT SHOOT FRAGILE OBJECTS SUCH AS

WINDOWS.

• ALWAYS MEASURE THE VELOCITY OF PAINTBALLS

FIRED BY THE eXTCyTM BEFORE USE, AND NEVER

ADJUST TO FIRE ABOVE 300FPS (91.44M/S).

TABLE OF CONTENTS

GOGpaintball.com

The eXTCyTM has been designed with

simplicity in mind so that you can

concentrate on your game instead of your

marker. It has only one major moving part in

its valve system, with a minimal number of

seals. This DOES NOT mean that you should

neglect your eXTCyTM. If you take care of

it off the eld, your eXTCyTM will take care

of you on the eld. For best performance,

clean and grease your eXTCyTM frequently.

Many players disassemble and clean their

eXTCyTM after every day of use. While this

may seem a bit extreme, being vigilant in the

upkeep of your eXTCyTM will extend its useful

life considerably, and catch any problems

when there is time to correct them before

the next game. Playing in the rain will not

damage your eXTCyTM. In fact, the eXTCyTM.

has been tested and proven to function

underwater. However, long-term exposure

to moisture can cause rust damage to

some of the eXTCyTM’s screws, so if your

eXTCyTM should become waterlogged,

remove the barrel, stock, eye covers and

rubber grips and allow it to dry out, then

follow the disassembly instructions for full

cleaning. Clean out mud and paint with

a damp cloth and alcohol. Lubricate the

eXTCyTM ONLY with GR33SETM pneumatic

grease. Use fresh, high quality paintballs for

best performance.

REQUIRED ITEMS FOR MAINTENANCE

STATISTICS MAINTENANCE

WEIGHT:

OPERATING PRESSURE:

POWER SOURCE:

PROPELLANT:

RATE OF FIRE:

OPERATION:

MODES OF FIRE:

ANTI CHOP SYSTEM:

BARREL THREAD:

LUBRICANT:

1.85 lb

160 psi

9-volt Alkaline Battery

CO2 or Nitrogen/Compressed air

Uncapped Semi-Automatic - up to 20bps ramping / auto

Low pressure electropneumatic

12 modes incl: Semi, PSP, NPPL and Millennium

VisionTM Break-Beam eyes

GOG®

For proper and consistent operation, the eXTCyTM should

only be lubricated with GR33SETM lubricating grease.

• 0.050-inch Allen Wrench (included) Trigger Adjustment /

VisionTM Eye Covers

• 5/64-inch Allen Wrench (included) - Battery Change

• 7/64-inch Allen Wrench (included)- Clamping Feedneck

• 1/8-inch Allen Wrench (included) - Stock/Backplate, Trigger

Adjustment, ASA, Grip, Breech and Circuit Board Screws

• 5/32-inch Allen Wrench (included) - Velocity Adjustment

• 5/16-inch Allen Wrench (included) - Bolt Sleeve

• Snap-Ring Pliers (purchase seperately) - Regulator

Disassembly (Advanced Maintenance)

• GR33SETM (purchase seperately) - Paintball Marker

Lubricant

GETTING FAMILIAR PLEASE READ CAREFULLY

REQUIRED ITEMS FOR USE

• 5/32-inch Allen Wrench (included) - Velocity Adjustment

• Chronograph (provided for use at commercial paintball

eld) - Velocity Adjustment

• Barrel Blocker (included)

• CO2 or HPA tank (purchase seperately)

• ASTM Compliant Paintball Goggles with Mask

(purchase seperately)

• 68 Caliber Paintballs

• Paintball Hopper/Loader (purchase seperately)

• 9-Volt Alkaline Battery

GOGpaintball.com

FIG. 1

FIG. 2

BARREL BLOCKER IN USE

USE HIGH PERFORMANCE LOADER

The Barrel Blocking Device is a critical piece of paintball safety equipment - nearly as important as

paintball goggles. The Barrel Blocker serves to protect against accidental discharge of a paintball by

catching it before it can cause harm. A Barrel Blocker is included with the eXTCyTM and must be used

every time it is handled in an area where people or property are not properly protected by paintball

goggles or paintball eld netting. To use the Barrel Blocker simply slip it over the end of the barrel

and stretch its cord back over the back of the eXTCyTM or the rearmost part over which it can be

securely looped. Use the strap’s adjuster to cinch the strap tight, so that the Barrel Blocker can provide

protection against accidental discharge of a paintball.

The Barrel Blocker should only be removed when the eXTCyTM is on a “live” paintball eld and all

persons involved are wearing proper paintball protection.

The eXTCyTM is a high performance tournament grade paintball marker. Its low-force bolt and VisionTM

anti-chop system will prevent paintballs from being chopped if the hopper is not able to load paintballs

as fast as the eXTCyTM is being red. If you want to realize the eXTCyTM’s maximum repower potential,

you will need to use a high performance loader. High performance loaders, especially those which

provide force-feeding, will yield the best results with the eXTCyTM.

The eXTCyTM is equipped with a clamping feedneck that allows it to adapt to the small size differences

in hopper neck sizes, yet lock or release quickly. Using a 7/64-inch allen wrench, loosen the clamping

feedneck before installing a hopper.

BARREL BLOCKER

HOPPER

BARREL BLOCKER/HOPPER PLEASE READ CAREFULLY

GOGpaintball.com

NEVER PUT OIL IN A COMPRESSED AIR REGULATOR OR

TANK - ONLY APPLY MANUFACTURER RECOMMENDED

LUBRICANTS.

COMPRESSED AIR

The eXTCyTM is a low-pressure paintgun. It operates at approximately 160 psi, which means it is capable of

functioning well with either high-pressure compressed air or CO2as a power source. Proper set up of your

gas system will help you obtain the best possible performance from your eXTCyTM.

Whether using compressed air or CO2it is important that the eXTCyTM is not exposed to sudden “pops”

of pressure. Always turn-on or screw-in a compressed air system or CO2slowly, so that the valve opens

slowly and the gas pressure inside the marker is raised smoothly. Be gentle to the internals of your

eXTCyTM and they will reward you with a long service life.

High Pressure Air systems (HPA) are the preferred power source used in paintball and with the eXTCyTM

because they are unaffected by temperature uctuations and do not have the potential for liquid

problems. HPA systems consist of a tank and a regulator, and are typically rated to store air or nitrogen

at pressures of 3,000 or 4,500 psi. Although pure nitrogen is almost never used in paintball, many players

call compressed air “nitro” as air is made up of more than 70% nitrogen, allowing the two gasses to be

used interchangeably in paintball equipment.

The eXTCyTM is congured for use with screw-in style HPA systems. Although HPA systems pre-set to

deliver approximatly 400 psi (low output) will work with the eXTCyTM, 800 psi (high output) systems are

preferred, to reduce the risk of gas starvation under rapid re.

Never use oil or any petroleum based cleaner or lubricant in a compressed air regulator or tank. Exposure to

pressurized air increases oil’s ammability and can cause a serious safety hazard. Only use manufacturer

recommended lubricants with compressed air systems, and follow the manufacturer’s maintenance and

operation instructions explicitly.

If you are using your eXTCyTM with an adjustable output compressed air system, it should be set to deliver

about 800 psi. The eXTCyTM’s vertical regulator can accommodate a wide range of input pressures, so

exact adjustment of the air system is not critical.

FIG. 3 HPA TANK BEING FILLED

GASES

NOTICE

Due to shipping restrictions, CO2 and HPA tanks are sold empty. They must be lled before they can be

used. Most paintball shops and elds are equipped to ll HPA tanks. Paintball shops, elds, many hardware

stores and sporting goods stores will have the equipment and trained personnel to ll paintball CO2tanks.

The eXTCyTM is factory congured for use with

CO2. Its dwell setting must be changed to obtain

optimum performance with HPA. See the Firing

Modes / Dwell section of this manual to learn how.

NOTICE

Although the eXTCyTM can be powered by

compressed air, typical home, garage or industrial

air compressors cannot provide the high pressures

required to ll a paintball HPA tank. Paintball HPA

systems can be relled by paintball elds and

stores which use higher pressure compressors

similar to those used in the SCUBA and reghting

industries.

NOTICE

GOGpaintball.com

CO2is usually not recommended for electronic paintball markers. This is not the case, however with

the eXTCyTM. The eXTCyTM can function extremely well with CO2as a power source, but doing so does

require the correct conguration. The use of CO2will not damage the seals in the eXTCyTM, freeze or

cause damage to its circuit board.

The important thing to remember if using CO2is that best performance can be achieved when only

gasseous CO2is fed to the eXTCyTM, and liquid CO2remains in the tank.

Although the relief valve integrated into the eXTCyTM’s vertical regulator provides the marker with

protection from pressure spikes, those pressure uctuations can cause poor performance, and

temporary blockage of the eXTCyTM’s solenoid valve.

The bottom-line ASA tting on the eXTCyTM places the CO2 level, like in Figure 5. When the marker is

held in typical ring positions the liquid CO2 will pass through the valve into the marker unless an anti-

siphon system is used.

Anti-siphon CO2 tanks contain a J-shaped tube that draws gaseous CO2from the top of the tank

when it is in a horizontal position. Anti-siphon tubes must be professionally installed, to ensure that

critical safety checks are performed during valve installation. Anti-siphon CO2tanks should not be

used with remote hoses.

Alternative CO2arrangements include placing the CO2tank vertically in a pack, and using a paintball

remote hose to feed CO2to the eXTCyTM. This arrangement not only prevents liquid CO2from entering

the marker, but also makes the marker assembly lighter weight. Another possible conguration is to

use a third-party ASA or ASA mounting adapter which mounts a standard CO2tank at an angle like in

Figure 4. In this arrangement gravity keeps the liquid CO2below the valve neck.

The bottom-line ASA tting on the eXTCyTM can be removed by unscrewing the two industry-standard

10-32 mount screws holding it to the grip frame after unscrewing and removing its on/off knob. If

replacing the ASA, be sure the model chosen takes into account the type of gas system being used

(horizontal for anti-siphon CO2tanks or compressed air, angled for standard CO2 tanks).

GASES PLEASE READ CAREFULLY

FIG. 4

FIG. 5

ANGLED CO2[CUTAWAY VIEW]

CO2 WITH ANTI-SIPHON [CUTAWAY VIEW]

CO2 may also be congured with a remote

hose with-out Anti-Siphon. [Not Shown]

IMPORTANT

USING CO2

BOTTOM-LINE ASA

GOGpaintball.com

OVER TIME BATTERIES MAY LEAK. ALWAYS REMOVE THE

BATTERY FROM THE eXTCyTM WHEN STORING FOR FOR

MORE THAN A MONTH.

BATTERY

The eXTCyTM is powered by a standard 9-volt alkaline battery. Lower cost “heavy duty” batteries will not

consistently deliver the amperage needed to operate the eXTCyTM reliably. Erratic performance, especially

drops in velocity or skipped shots during rapid re can result from a battery that is not delivering full

power.

The eXTCyTM is also compatible with 9-volt rechargeable batteries. Because specications of batteries

vary widely from brand to brand, use of any rechargeable battery will require testing to determine if it

can power the eXTCyTM reliably and t correctly in the grip frame. Some NiCD “9v” rechargable batteries

actually operate at 7.2 volts. These types of batteries will not work well with the eXTCyTM.

Each time the eXTCyTM is turned on, the power button LED will blink 5 times rapidly, with its color indicating

the estimated charge level of the battery. Green indicates a charge level between 75% and 100%. Yellow

denotes a charge level between 50% and 75%, while red ashing indicates that the remaining charge is

estimated to be below 50%. It is important to note that different types and even brands of rechargeable

batteries will give different readings than alkaline batteries., so experience will be the best teacher as to

how much remaining use to expect once a reduced charge level is indicated.

Any time the eXTCyTM exhibits erratic performance, drops velocity or skips shots while rapid ring, does

not shoot or does not turn on, the rst step in troubleshooting should always be to replace the battery with

a brand-new, name-brand alkaline battery.

To replace the eXTCyTM battery, use a 5/64-inch allen wrench to remove the two screws from the left side

of the rubber grip, then open the grip. Be careful opening the grip from the grip frame. Folding the grip

back around the trigger frame may seem convenient, but may cause tearing or stretching in the center of

the grip, which will cause it to pucker or t poorly when reinstalled. As an alternative to folding the grip

open, simply remove it entirely by removing the two grip screws from its right side.

Remove the old battery, taking care not to bend, kink or strain its wires. Unsnap the battery from its

connector by pulling on the connector, not the wires. Snap in a fresh battery, then place that in the grip

frame, tucking the wires into place, before closing and re-securing the grip. The battery and connector

should t snugly in the battery space, so that they do not shift around during use. Some off-brand batteries

may be too large to t correctly in the grip frame. If this is the case, do not force the battery into position,

instead replace it with a name-brand alkaline battery.

FIG. 6

BATTERY

ALKALINE BATTERY

GOGpaintball.com

VISION BYPASS

The eXTCyTM is equipped with a VisionTM break-beam anti-chop system, allowing it to acheive the

highest possible rates of re without chopping or mis-feeding paintballs.

The eXTCyTM circuit board is linked to a light emitting diode and detector installed in the marker’s

breech. When a paintball drops down the feedneck into the breech, it breaks the light beam and

the eXTCyTM circuit board detects its presence. When the VisionTM system is activated, the eXTCyTM

will not re until it “sees” a paintball in the breech. This prevents the marker from dry ring or from

chopping a paintball in half by ring before the ball is completely loaded.

There may be times when it is desirable to bypass the VisionTM system, such as dry-ring the eXTCyTM

to test electronic adjustments, or when de-gassing.

While the eXTCyTM is turned on, pressing and holding the power button for approximately one-half

second will turn the VisionTM system off, allowing the marker to re whenever the trigger is pulled,

whether or not there is a paintball in the breech. Pressing for approximately a half second will also turn

VisionTM back on.

When VisionTM is on, the power button will glow green. When it is off, the button will glow red.

VISION OPERATION

FIG. 8 VISIONTM DE-ACTIVATION

GOGpaintball.com

ELECTRONIC ADJUSTMENT

Pulls To Enter: (Power Button LED blinks slowly red) - For ReboundTM Mode, the Pulls To Enter

determines how many times the trigger must be pulled before marker ramps up to more than one shot

per trigger pull. Pulls to enter may be set between 1 and 5 pulls.

Enter Rate: (Power Button LED blinks slowly green) - For ReboundTM Mode, the Enter Rate determines

how frequently the trigger must be pulled before the marker ramps up to more than one shot per trigger

pull. Enter rate may be set between 4 and 12 trigger pulls per second.

Sustain Rate: (Power Button LED blinks slowly yellow) - For ReboundTM Mode, the Sustain Rate

determines how frequently the trigger must be pulled to continue ramping more than one shot per

trigger pull after ramping has begun. Sustain Rate may be set between 1 and 10 trigger pulls per

second.

FSDO Compensation: (Power Button LED blinks slowly red and green) - When a marker rests, its bolt

may stick in position and cause a low-velocity shot the next time it is red. This is known as First Shot

Drop-Off, or FSDO. FSDO Compensation increases the dwell time of the rst shot of a group, providing

additional time to break friction between the breech and the bolt’s o-rings before the bolt moves

forward. FSDO Compensation may be adjusted from zero (off) to 15 milliseconds in 1 millisecond

increments. When the marker rests for 20 seconds or more, the next shot red will have the FSDO

Compensation value added to its dwell time. The default FSDO setting is 20 milliseconds.

VisionTM Hardware: (Power Button LED blinks slowly yellow and green) - This setting provides

compatibility between the eXTCyTM circuit board and other markers. By default this setting will be 1, for

use with the eXTCyTM’s wired VisionTM eyes. A setting of 2 would be used for compatibility with circuit

board style VisionTM eyes, such as those used for upgrade on the G-1TM and eNVyTM.

GOGpaintball.com

The length of the eXTCyTM trigger pull is fully adjustable.

A setscrew in the lower half of the trigger sets the post-travel adjustment, or how far back the trigger

can be pulled. Turning the screw clockwise with a 0.05-inch allen wrench will shorten the trigger

pull. Turning counter-clockwise will increase it. When setting post-travel limit, it is important that the

trigger pull is not set so short that the trigger does not activate the microswitch on the eXTCyTM’s

circuit board, as this would leave the marker unable to re. Similarly, the post-travel adjustment screw

must butt up against the trigger frame when the trigger is pulled. If the post-travel screw is under-

adjusted the trigger will stop against the microswitch inside the marker, instead of on the screw. This

situation can cause damage to the microswitch and or circuit board when the trigger is pulled hard.

The forward limit of the trigger’s movement, or pre-travel is adjusted by the use of a 1/8-inch allen

wrench. The pre-travel trigger adjustment screw is located at the bottom of the trigger guard where it

meets the grip frame. It may be helpful to remove the marker’s rubber grips to provide easier access

when making adjustments. As when changing the battery, it is better to completely remove the rubber

grip than to only open one side and fold it past the trigger guard. Turning the pre-travel adjustment

screw clockwise decreases how far forward the trigger can move, while turning counterclockwise

increases. If the trigger is not adjusted to swing far enough forward when released, the microswitch

inside the eXTCyTM will not be able to reset, resulting in the marker not ring.

Always check the trigger after making adjustments. Be sure that the trigger switch clicks when the

trigger is pulled, and again when it is released. Also make sure that when the trigger is pulled it is

being stopped by the post-travel adjustment screw, not by pressing up against the microswitch

inside the marker.

TRIGGER ADJUSTMENT

FIG. 9 TRIGGER ADJUSTMENT POINTS

THE TRIGGER MUST COME TO A STOP WITH ITS

ADJUSTMENT SCREW AGAINST THE GRIP FRAME OR

DAMAGE TO THE CIRCUIT BOARD AND OR TRIGGER

SWITCH MAY OCCUR.

IMPORTANT

PRE-TRAVEL

POST-TRAVEL

GOGpaintball.com

At the end of each day’s use and before performing maintenance work on your eXTCyTM, it will

need to be de-gassed, and all paintballs must be removed.

In an area where it is safe to shoot (such as the chronograph area at a paintball eld) and while

wearing paintball goggles, remove the hopper from the eXTCyTM. By turning the eXTCyTM upside

down, you can empty any extra paintballs from the feedneck into your hand. Turn the eXTCyTM on.

Dry-re 2 or 3 shots in a safe direction to ensure that no paintballs remain in the eXTCyTM. In order

to dry-re the marker, the VisionTM anti-chop system must be turned off (see VisionTM operation) or

set to one of its delayed modes (see Electronic Adjustment).

Turn off the HPA system if it is equipped with its own on/off control, or turn off the HPA system or

CO2 tank by turning the bottom-line ASA control knob counter-clockwise. Dry re the eXTCyTM in

a safe direction until all of the gas pressure inside has been released. At this point the only sound

you should hear when you pull the trigger is the click of the solenoid valve. Often this sound will

be too quiet to hear. Turn off the eXTCyTM.

If using a CO2 tank or screw in HPA system, unscrew it from the bottom-line ASA.

EVEN WITH NO CO2 OR COMPRESSED

AIR SYSTEM ATTACHED, THE

EXTCYTM MAY STILL HAVE ENOUGH

GAS PRESSURE STORED IN THE

REGULATOR AND FIRE CHAMBER TO

FIRE 2 OR MORE SHOTS. YOU MUST

DE-GAS YOUR EXTCYTM BEFORE

PERFORMING ANY MAINTENANCE

PROCEDURES.

UNLOADING/DE-GASSING PLEASE READ CAREFULLY

ALWAYS WATCH COMPRESSED GAS

CYLINDERS (CO2 OR HPA) TO MAKE

SURE THAT THE CYLINDER AND VALVE

ARE UNSCREWING FROM THE ASA,

AND THAT THE CYLINDER IS NOT

UNSCREWING FROM ITS VALVE. IF THE

CYLINDER DOES BEGIN TO SEPARATE

FROM ITS VALVE, STOP IMMEDIATELY,

AND SEEK PROFESSIONAL

ASSISTANCE.

GOGpaintball.com

The valve system in the eXTCyTM has only one major moving part. Regular cleaning and lubrication is necessary to ensure accurate and consistent performance. The eXTCyTM

should be eld stripped, cleaned and lubricated any time it shows erratic performance, becomes contaminated with paint, dirt or other debris, or for general maintenance after

3 or 4 days of use.

Unload and de-gas the eXTCyTM. Remove the barrel and use a 5/16-inch allen wrench to unscrew and remove the bolt sleeve from the back.

Using a soft, non-marring tool like a wooden chopstick or plastic toothbrush, push the bolt and bolt stop out the back of the eXTCyTM. Clean the interior of the receiver, the bolt

sleeve, bolt and bolt stop with a clean cloth or paper towel. Inspect their o-rings for signs of damage such as cuts or rips, and replace if necessary. Lightly lubricate all o-rings

with GR33SETM paintgun grease. Use GR33SETM sparingly, as over-lubrication can cause the eXTCyTM to operate inconsistently. Do not lubricate the rearmost o-ring on the bolt

sleeve, it provides friction to keep the bolt sleeve in place during operation.

Slide the bolt stop onto the bolt from the rear. Slide the rear of the bolt into the bolt sleeve. Hold this entire assembly vertically with the front of the bolt pointing upward, and

insert it up into the back of the eXTCyTM. Screw the bolt sleeve into the back of the eXTCyTM by hand, taking care not to cross-thread it into the receiver.

Use the long end of a 5/16-inch allen wrench to turn the bolt sleeve until it is snug. Take care not to over-tighten the bolt sleeve, it only needs to t snugly in place.

FIG. 10

FIELD STRIPPING CLEANING

BOLT BOLT STOP BOLT SLEEVE

GOGpaintball.com

The VisionTM eye covers of the eXTCyTM are easily removed to provide access to both the VisionTM sensors and the marker’s ball-detents. To remove the eye covers, rst unload

and de-gas the marker following the instructions in this manual, then use a 0.050-inch allen wrench through the eye-cover access hole to unscrew the eye cover retaining screw,

then tilt the eXTCyTM to the side, and if necessary tap it lightly against one hand to work the eye cover out.

With the eye cover removed, an o-ring pick can be used to pry the VisionTM LED or detector out of its pocket by one of its top corners. Care must be taken not to scratch the

dome shaped lens molded into the body of the eye. With the eye gently folded out of the way, the eye, eye pocket and ball detent opening in the breech may all be thoroughly

cleaned with a cotton swab.

If the ball detent is worn to the point that it does not protrude slightly into the breech, or dirty to the point that it does not spring easily in or out, it may be removed from the eye

cover for cleaning or replacement. To remove the ball detent, use an o-ring pick to carefully pry back the ball detent retaining ngers one at a time and work the detent out of the

eye cover. If the ball detent is excessively worn, it must be replaced for proper operation of the eXTCyTM. The ball detent spring may become bent or damaged during removal

of the ball detent. If this happens, it must be replaced. After cleaning or replacement, t the ball detent spring into the ball detent, set its other end on the spring guide in the eye

cover, then carefully work the detent past the detent retaining ngers. Note the alignment of the ball detent for a proper t, its wider at edges should be at the top and bottom.

When re-installing the eye cover, use the long end of the allen wrench to tighten the eye cover retaining screw. Take care not to cross-thread the eye cover retaining screw, or

tighten it beyond a snug t, these can cause permanent, non-repairable damage to the breech.

FIG. 11

VISION/DETENT CLEANING CLEANING

FIG. 12 FIG. 13

EYE COVER REMOVAL EYE CLEANING BALL DETENT REMOVAL

GOGpaintball.com

The internal gas lines and electronic components of the eXTCyTM are well protected inside its body – however they are delicate and may be damaged by improper handling

or re-installation. For this reason it is highly recommended that full disassembly of the eXTCyTM be performed by an airsmith with GOG PaintballTM factory training, and then

only when necessary to x a problem or install an upgrade. Removal of internal hoses from their barbed ttings will stretch them to the point that they cannot be re-used

without causing leaks. In other words, if it ain’t broke, don’t x it.

Occasionally a more thorough disassembly of the eXTCyTM receiver is necessary to remove paint or debris that has worked between the breech and body shell, replace a

damaged component or install an upgrade. These tasks require removal of the grip frame and or disassembly of the body.

Unload and degas the eXTCyTM, remove the barrel, rubber grip and battery, following the instructions in this manual. Similarly, eld strip the bolt/valve system.

Using a 1/8-inch allen wrench, remove the breech screw from the front of the breech. Next remove the two grip frame screws securing the grip frame to the body. Carefully

slightly separate the grip frame from the receiver. Be aware that the clear power button can fall out of its position in the side of the grip frame. Be careful not to drop or lose

it. The body will still be connected to the grip frame by the hose running between the front of the grip frame and the solenoid valve on the circuit board.

Tilt the body slightly away from the grip frame and carefully use a 1/8-inch allen wrench to unscrew the barbed banjo tting which connects the gas supply hose to the grip

frame. Alternatively, the hose may be pulled off of the barb in the grip frame - doing so will require the hose to be replaced however, as its end will have been stretched by

the barbed tting and will no longer seal reliably.

Completely separate the body from the grip frame. Watch to make sure the battery clip does not snag in the grip frame as the two parts are separated.

Reassembly of the grip frame to the body is done in the reverse order, taking care not to allow the battery wires to or hoses to become pinched or entrapped while joining

the body to the grip frame. Use the long end of the allen wrench when reinstalling the banjo ttings and grip frame screws, to avoid over-tightneing.

Over-tightening or cross threading screws or ttings may result in permanent, nonrepairable damage to the breech.

FIG. 15 GRIP FRAME REMOVAL

FIG.14 BREECH SCREW REMOVAL

ADVANCED MAINTENANCE NOTE: Unload and degas the eXTCyTM before

any cleaning or maintenance work.
