Goldmedal Sterno Pretzel Warmer User manual

Part No. 50005
Revised: March 2005
Sterno Pretzel Warmer
Instruction Manual
Model #6501
Cincinnati, OH 45241-4807 USA
a

SAFETY PRECAUTIONS
a

Sterno Pretzel Warmer
Model #6501
3
INTRODUCTION
This manual covers the model # 6501 Sterno Pretzel Warmer.
Your Sterno Pretzel Warmer warranty is described on the back page of this manual.
CHECKING SHIPMENT
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be
filed immediately with the transportation company. The warranty also does not cover damage that occurs in
transit or damage caused by abuse or consequential damage due to the operation of this machine, since it
is beyond our control.
FUEL REQUIREMENTS
We recommend the use of “STERNO BRAND” “CANNED HEAT” cooking fuel, or equivalent. This type of
fuel is a pink, jellied, ethanol- alcohol. Any other type of fuel may result in unsatisfactory performance.
OPERATING INSTRUCTIONS
Features and their Functions:
Water Pan:
Remove pan cover to fill this pan with water. This controls the humidity in the holding cabinet. If no
humidity is desired, leave pan empty.
Seven Station Pretzel Rack:
This is the rack on which the pretzels are displayed. Two rows are left out to prevent burning of product and
to improve circulation of heat.
Fuel Drawer:
The fuel drawer has an insert with three holes. One hole is to be positioned directly under the water pan
while the remaining two are positioned under the heat vent holes on the operator right side of the unit.
Note: The fuel drawer insert must be in the fuel drawer and positioned as outlined above
to achieve proper results
EASY STEPS FOR USING UNIT
Prepare Warmer for operation:
1. Pour enough water in the water pan to fill ½ inch deep.
2. Remove lids from “Sterno” canisters.
3. Pull fuel drawer open and place “Sterno” canisters in proper locations.
4. Light “Sterno” canisters per instructions on sterno canister, and close fuel drawer.
5. Load pretzels onto rack. Note: Frozen pretzels should be ready in approximately 45 minutes to 1
hour.
6. Check “Sterno” canisters periodically to ensure that they are still lit and functioning properly.
a

Sterno Pretzel Warmer
Model #6501
4
MAINTENANCE INSTRUCTIONS
CARE AND CLEANING
The stainless steel body of the Warmer is easy to keep clean. Usually a damp cloth will remove all dirt and
grease spots. NEVER USE ABRASIVES on the stainless steel body. The glass should be cleaned on a
regular basis to keep the glass clean and sparkling.
a

Sterno Pretzel Warmer
Model #6501
5
ORDERING SPARE PARTS
1. Identify the needed part by checking it against the photos, illustrations, and/or the parts list.
2. When ordering, please include part number, part name, and quantity needed.
3. Please include your model name, serial number, and date of manufacture (located on the machine
nameplate) with your order.
4. Address all parts orders to:
Parts Department
Gold Medal Products Co.
10700 Medallion Drive
Cincinnati, Ohio 45241-4807
or, place orders at:
[phone]
[phone]
Fax: [phone]
E-mail: [email protected]
Web Page: www.gmpopcorn.com
The parts shown in the following photographs and parts list reflect the most common replaced
and/or lost parts on the machine. If parts are needed, that are not shown, please contact our parts
department at the above number.
© The text, descriptions, graphics and other material in this publication are the proprietary and
exclusive property of Gold Medal Products Company and shall not be used, copied, reproduced,
reprinted or published in any fashion, including website display, without its express written consent.
a

Sterno Pretzel Warmer
Model #6501
6
Parts Breakdown – Front View
1
a

Sterno Pretzel Warmer
Model #6501
7
Parts Breakdown – Rear View
1
3
2
a

Sterno Pretzel Warmer
Model #6501
8
Parts Breakdown – Inside Cabinet
4
5 6
7
a

Sterno Pretzel Warmer
Model #6501
9
Parts Breakdown – Drawer Components
10
9 8
a

Sterno Pretzel Warmer
Model #6501
10
Parts List
Item # Part Number Description
1 43295 Pretzel Decal
2 42627 Hinge Pin
3 87247 Rubber Foot
4 49980 Pretzel Rack
5 42621 Pan Cover
6 49984 Inner Pan
7 42614 Water Pan
8 49998 Drawer Weldment
9 49987 Drawer Insert
10 47120 Knob
a

WARRANTY
WE WARRANT to the original purchaser the Gold Medal equipment sold by us to
be free from defects in material or workmanship under normal use and service. Our
obligation under this warranty shall be limited to the repair or replacement of any
defective part for a period of six (6) months from the date of sale to the Original
Purchaser with regard to labor and two (2) years with regard to parts and does not
cover damage to the equipment caused by accident, alteration, improper use, voltage,
abuse, or failure to follow instructions.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESSED
OR IMPLIED, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR
PART, INCLUDING THE IMPLIED WARRANTY OF MERCHANTIBILITY.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF. We neither assume, nor authorize any other person
to assume for us, any other obligation or liability in connection with the sale of said
GOLD MEDAL equipment or any part thereof.
The term “Original Purchaser” as used in this warranty shall be deemed to mean that
person, firm, association, or corporation who was billed by the GOLD MEDAL
PRODUCTS COMPANY, or their authorized distributor for the equipment.
THIS WARRANTY HAS NO EFFECT AND IS VOID UNLESS THE ORIGINAL
PURCHASER FIRST CALLS GOLD MEDAL PRODUCTS COMPANY AT 1-800-
543-0862 TO DISCUSS WITH OUR SERVICE REPRESENTATIVE THE
EQUIPMENT PROBLEM, AND, IF NECESSARY, FOR INSTRUCTIONS
CONCERNING THE REPAIR OR REPLACEMENT OF PARTS.
