GolfAchiever II User manual

QUICK SET-UP GUIDE
7. Run the Diagnostics Program. Be sure that all
laser levels are reading above 20. If you find
low readings, go to page 31 of the User Manual
for instructions on Aligning the Lasers.
1. Remove GolfAchiever’s components from the
shipping box. Be sure that all components
have arrived safely. A component list appears
on page 7 of the User Manual.
6. Install the GolfAchiever and Diagnostics
program on your computer (install CD). After
software installation, attach the power and serial
cables to the L-Frame and your computer.
OVER —>
2 . Insert a tee into the mat. Attach the mat to the
Base Holder by placing the “ D ” cut grooves
found at the top-right and -left side of the mat
onto the “ D ” shaped tabs of the Base Holder.
4. Attach the triangle to the L-Frame by first insert-
ing the bottom tab into the notch (inset 1), then
latching the top clamp onto the arm (inset 2).
5. Place hitting turf into position on the hitting
mat.
8. After starting the software, you must enter a
player, select a club, select a tee height, select
ball type, select right or left, and then hit the
play button to begin using your GolfAchiever .
9. This is what your GolfAchiever II system
should look like when fully assembled. You
are ready to use your new GolfAchiever II.
Set up and swing away!
3. Attach the GolfAchiever II L-frame to the Base
Holder by placing the base arm into the Base
Holder’s ridge. Be certain that the Azimuth pin is
placed securely into the Azimuth Pin Slot (see inset).

IMPORTANT! CHANGING TEES ON GOLFACHIEVER IMPOR-
For customer support please call: [phone], x 101 or 119 (M-F 7:30AM-5:00PM PST)
You can also email your questions to: [email protected]
1. Right-handed mode (the “R” icon should be
selected on the Achiever Software). 2. Remove the triangle leg. 3. Carefully lift the L-frame away from the Base Holder.
4. Rotate the L-frame 180° 5. Place the L-frame back into the Base Holder
and re-attach the triangle leg. 6. Left-handed mode (the “L” icon should be selected on the Achiever Software).
1. To prevent breaking the Base Holder when changing tees, use
one foot to stand on the GolfAchiever hitting mat close to the
frame (as shown below). Peel up the back of the hitting mat and
push down on the top of the tee.
2. Reach under the hitting mat and pull the tee out from under the
hitting mat. Insert a new tee by pushing it up from the bot-
tom. If the Base Holder breaks, call Focaltron for replace-
ment—GA accuracy depends on use of the Base Holder!
CHANGING FROM RIGHT TO LEFT
