GoMax Electronics PG-303K User manual
12G/6G/3G/HD/SD-SDI Pattern
Generator
User Manual
rev: 171124
Made in Taiwan
PG-303K
Safety and Notice
The PG-303K12G/6G/3G/HD/SD-SDI Pattern Generator has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic
equipments, the PG-303K should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the unit.
●Follow all instructions and warnings marked on this unit.
●Do not attempt to service this unit yourself, except where explained in this manual.
●Provide proper ventilation and air circulation and do not use near water.
●Keep objects that might damage the device and assure that the placement of this unit is on a stable
surface.
●Use only the power adapter and power cords and connection cables designed for this unit.
●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
TABLE OF CONTENTS
INTRODUCTION................................................................................................................2
FEATURES ........................................................................................................................2
PACKAGE CONTENTS......................................................................................................2
SPECIFICATIONS..............................................................................................................2
PANELDESCRIPTIONS.....................................................................................................3
CONNECTION DIAGRAM..................................................................................................4
NOTICE..............................................................................................................................5
APPENDIX .........................................................................................................................6
WARRANTY.......................................................................................................................8
INTRODUCTION
The PG-303K12G/6G/3G/HD/SD-SDI Pattern Generator is an advanced SDI pattern generator with
multi-format (12G/6G/3G/HD/SD) and multi-pattern support. Besides still and moving video test patterns,
other features such as audio (SMPTE-291M) are also provided. PG-303K can support up to 8 channel
AES compliant audio with 48KHz sample rate. PG-303K is equipped with four buttons and LCM screen to
ease the control. This device provides a cost effective way to calibrate and test SDI enable video devices
and displays.
FEATURES
●Supported output resolution
4K2K @30, 4K2K @50, 4K2K @59.94, 4K2K @60
Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 5.94Gbps, 5.934Gbps, 11.88Gbps,
11.868Gbps,270 Mbps
Resolution: 10bit
●Video Patterns
100% Color Bars, Borderline, Random Noise, Check Field, Black, Vertical Lines, Black / White
alternate fields, Full Grey / Full White, Black to White Gradient, Random Generator for all still
patterns, moving squares White noise, Inverse effect with still pattern, Scrolling Title (see Appendix
for illustrations)
●Save Settings to Memory Option
●ANC Data
EDH (RP-165), SMPTE 352M, SMPTE291M
●Control
By LCM & panel buttons
●Video Output
SDI output (SDI, HD-SDI, 3G-SDI, 6G-SDI, 12G-SDI)
PACKAGE CONTENTS
●1x PG-303K
●1x 12V power supply unit
●1x User Manual
1
SPECIFICATIONS
Model Name
PG-303K
Technical
Role of usage
Pattern generator
SDI standards
12G/6G/3G/HD/SD-SDI
Auto SDI rate detection
Yes
Supported protocols
SMPTE 259M (270Mbps / 360Mpbs)
SMPTE 292M / HDTV (1.485 & 1.485/1.001Gbps)
SMPTE 424/425M (2.97 & 2.97/1.001Gbps)
SMPTE ST-2081 (5.94&5.94/1.001Gbps)
SMPTE ST-2082 (11.88&11.88/1.001Gbps)
Video bandwidth
11.88Gpbs
Data rates
143 / 270 / 1483 / 1485 / 2967 / 2970 / 5934 / 5940 / 11868 / 11880 Mbps
Video support
[12G] 4K2K@50/59.94/60
[6G] 4K2K@23.97/24, 25, 30
[3G] 1080p@50/59.94/60 (4:2:2)
[HD] 720p50/59.94/60, 1080p24/30, 1035i50/59.94/60, 1080i50/59.94/60
[SD] NT[email protected], PAL@50Hz
SDI signal type
SMPTE-292M / 259M / 424M / ST-2081 / ST-2082
Output impedance
75Ω
Cable (Belden 1694A)
equalization /
transmission
[12G-SDI] up to 50m (165ft) / [6G-SDI] up to 100m (330ft) / [3G-SDI] up to
200m (660ft)
Audio support
Yes
PCB Stack-up
6-layer board [impedance control — differential 100Ω; single 75Ω]
Output
2x BNC [SDI]
BNC connector
75Ωinterlocking socket
[HD] Eye pattern
characteristics
Amplitude: Within 800mV <10%Long time jitter <1.0 UI
Rise overshoot: Less than 2% Timing jitter <1.0 UI
Fall overshoot: Less than 2% Alignment jitter <0.2 UI
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
150 x 190 x 32mm [5.9” x 7.5” x 1.3”]
Package
175 x 270 x 100mm [6.9” x 10.6” x 3.9”]
Carton
450 x 370 x 300mm [1’6” x 1’3” x 1’]
Weight
Model
660g [1.5 lbs]
Package
1260g [2.8 lbs]
Fixedness
Interlocking power supply
Power supply
12V 2A DC
Power consumption
8 Watts [max]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]
2
PANELDESCRIPTIONS
Front/ Rear Panel
1.POWER LED: Power LED indicator
2.SDI OUTPUT :Connect to a SDI device for SDI signal output either from the chosen pattern
or the SDI source signal
3.Mini-USB: F/W update
4. +12V DC: Connect to a 12V DC power supply unit
5. SDI INPUT: Connect to a SDI source
6. PUSH BUTTON:
Button Function
Menu Trigger the menu operation
Enter Enter the menu item
Up Choose the last menu item
Down Choose the next menu item
3
CONNECTION DIAGRAM
4
NOTICE
1. In HDMI bypass mode, users must be aware of that the jitters coming from HDMI sources, such as
DVD players, may be much higher than typical requirement according to SMPTE request on HD-SDI
signals. This will result in SDI output with high jitters or even no SDI outputs!
2. Due to the high frequency bandwidth and low jitter requirement of 3G-SDI signals, it is strongly
recommended to use just one SDI OUTPUT with one 75 ohm.
3. The features including new timings and patterns may increase without notice after the firmware is
updated! This may affect the menu items, but will keep the same framework for users!
5
APPENDIX
Data Identification Word of Ancillary Data Packet
ANC Data
DID
SDID/DBN
352M
0x41
0x01
RP-165-EDH*
0xF4
0x00
* Data Type 1(SMPTE-291M)
Built-in Video Patterns
6
7
WARRANTY
The SELLER warrants the PG-303K12G/6G/3G/HD/SD-SDI Pattern Generator to be free from
defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an
authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The
SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident,
disaster, abuse or any unauthorized modifications including static discharge and power surges.
Unit that fails under conditions other than those covered will be repaired at the current price of parts
and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment
to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss
or damage in transit. Under no circumstances will a unit be accepted without a return authorization
number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations, any
other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly
disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible
for shipping charges to and from the SELLER. Cables are limited to a 30 day warranty and cable must be
free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The
SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting
from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the
technical information contained herein regarding the PG-303K features and specifications is
subject to change without further notice.
