Gomax SP-3004G User manual

1x4 3G/HD/SD-SDI Distribution
Amplifier with Reclocking
User Manual
rev: 180730
Made in Taiwan
S
SP P- -3 30 00 04 4G G

Safety and Notice
The SP-3004G 1x4 3G/HD/SD-SDI Distribution Amplifier with Reclocking has been tested for
conformance to safety regulations and requirements, and has been certified for international use.
However, like all electronic equipments, the SP-3004G should be used with care. Please read and
follow the safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
●Follow all instructions and warnings marked on this unit.
●Do not attempt to service this unit yourself, except where explained in this manual.
●Provide proper ventilation and air circulation and do not use near water.
●Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
●Use only the power adapter and power cords and connection cables designed for this unit.
●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION................................................................................................................1
FEATURES ........................................................................................................................1
PACKAGE CONTENTS......................................................................................................1
SPECIFICATIONS..............................................................................................................2
PANEL DESCRIPTIONS....................................................................................................3
HARDWARE INSTALLATION ............................................................................................4
WARRANTY.......................................................................................................................5
SIGNAL MEASUREMENT..................................................................................................6

INTRODUCTION
The SP-3004G receives one SDI input, perfectly duplicates it, and re-transmits four SDI outputs for
real time multi-viewing. It is a reliable video device splitting a SDI, HD-SDI, or 3G-SDI video source to four
SDI compliant displays at the same time. Besides, built-in re-clocking & equalization features provide the
best performance for SDI distribution amplifier.
FEATURES
● 3G/HD/SD triple-rate distribution
● Four separately buffered and reclocked outputs
● Cable equalization (Beldon 1694A) and signal retiming
● Dual color LED indication of input lock and rate
● Passes all ancillary data
● Provides automatic input cable equalization up to 300m (1000ft)@SD, 150m (500ft)@HD and
60m(190ft)
● Reclocks SDI signals for cascading and thus longer transmission
● Inter-locked power supply for better fixedness
PACKAGE CONTENTS
●1x SP-3004G
●1x 5V power adapter
●1x User Manual
1

SPECIFICATIONS
Model Name
SP-3004G
Technical
SDI standards
SD/HD/3G-SDI
Auto 3G/HD/SD
detection
Yes
Supported protocols
SMPTE 259M, SMPTE 292M, SMPTE 424M, SMPTE425M
Video bandwidth
[2.97Gpbs & 2.97/1.001Gbps]
Data rates
270 / 1483 / 1485 / 2970 Mbps
Output impedance
75Ω
Reclocking function
Yes
Cable equalization
[3G] up to 60m (190ft) / [HD] up to 150m (500ft) / [SD] up to 300m (1000ft)
Audio support
Yes
RP-198 pathological
patterns
Immune
PCB stack-up
4-layer board [impedance control — differential 100Ω; single 50Ω]
Input
1x BNC [SDI]
Output
4x BNC [SDI]
BNC connector
75Ωinter-locked socket
Eye pattern
characteristics [HD]
Amplitude: Within 800mV ±3% (<10%)
Rise overshoot: Less than 2% (<10%)
Fall overshoot: Less than 2% (<10%)
Long time jitter: 0.195 UI (<1.0 UI)
Timing jitter: 0.195 UI (<1.0 UI)
Alignment jitter: 0.127 UI (<0.2 UI)
Mechanical
Housing
Metal encosure
Dimensions
[L x W x H]
Model
112 x 42 x 25mm [4.4" x1.6" x0.9"]
Package
175 x 128 x 134mm [6.9" x5" x5.3"]
Carton
662 x 366 x 290mm [2'2" x 1'2" x 1']
Weight
Model
174g [0.4 lbs]
Package
440g [0.9 lbs]
Fixedness
Inter-locked power supply
Power supply
5V 2A DC
Power consumption
10 Watts [max]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]
The measurement results are from Tektronix WFM-7120 with SDI through 1m (3.3ft) long
Belden 1694A.
2

PANEL DESCRIPTIONS
Front Panel
1. 3G/HD/SD-SDI Output
2. 3G/HD/SD-SDI Output
3. 5V DC power jack
Rear Panel
4. Power LED indicator
5. 3G/HD/SD-SDI Input
6. 3G Signal LED indicator
7. HD Signal LED indicator
8. SD Signal LED indicator
9. 3G/HD/SD-SDI Output
10. 3G/HD/SD-SDI Output
3

HARDWARE INSTALLATION
1. Connect a camera or other devices equipped with 3G/HD/SD-SDI outputs to SP-3004G
3G/HD/SD-SDI input.
2. Connect devices equipped with 3G/HD/SD-SDI inputs (e.g. monitors or video processors) to
SP-3004G 3G/HD/SD-SDI outputs.
3. Plug power adapter cable into 5V DC power jack.
CONNECTION DIAGRAM
4

WARRANTY
The SELLER warrants the SP-3004G 1x4 3G/HD/SD-SDI Distribution Amplifier with
Reclocking to be free from defects in the material and workmanship for 1 year from the date of
purchase from the SELLER or an authorized dealer. Should this product fail to be in good
working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit,
provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized
modifications including static discharge and power surge. This warranty is offered by the
SELLER for its BUYER with direct transaction only. This warranty is void if the warranty seal on
the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price
of parts and labor in effect at the time of repair. Such repairs are warranted for 90 days from the
day of reshipment to the BUYER. If the unit is delivered by mail, customers agree to insure the
unit or assume the risk of loss or damage in transit. Under no circumstances will a unit be
accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without
limitations, any other implied warranty or fitness or merchantability for any particular purpose, all
of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are
responsible for shipping charges to and from the SELLER. Cables are limited to a 30 day
warranty and cable must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate.
However, The SELLER assumes no responsibility for any inaccuracies that may be contained in
this manual. The SELLER will NOT be liable for direct, indirect, incidental, special, or
consequential damages resulting from any defect or omission in this manual, even if advised of
the possibility of such damages. Also, the technical information contained herein regarding
the SP-3004G features and specifications is subject to change without further notice.
5

SIGNAL MEASUREMENT
6
