Gooseneck ST-5000 User manual

ST-5000
Gooseneck Microphone Combo
PARTS IDENTIFICATION
5
FEATURES
✜Supercardioid pick up pattern
✜Push ON/OFF
✜LED indicator
✜Balanced XLR male output
1. Capsule
2. Gooseneck
3. LED Indicator
4. ON / OFF Switch
5. 3P XLR-Male Connector
1
4
3
2
The ST-5000 is the easiest gooseneck mic can be found. Designed with
Push ON/Push Off switch and XLR male output it meets basic
requirements for all installed applications.
Thanks for choosing JTS ST-5000 Gooseneck Microphone. In order to obtain the best efficiency, you are recommended to read this manual before applying.

TYPE: Back Electret Condenser
FREQUENCY RESPONSE: 80~18,000Hz
POLAR PATTERN: Supercardioid
OUTPUT LEVEL(at 1,000 Hz): -60±3 dB* (1mV)*0dB=1V /μbar
IMPEDANCE: 220Ω
MAX. SPL FOR 1％THD: 125dB
POWER SUPPLY: 12-48 VDC Phantom power
CURRENT CONSUMPTION: ≤5.8mA
DIMENSIONS
SPECIFICATION
OUTPUT CONNECTOR: XLR-M type
SWITCH : Push ON/OFF
GOOSENECK LENGTH: 368mm
BASE DIMENSIONS: 96mm(W)*46mm(H)*113mm(D)
NET WEIGHT: 541 grams
www. jts .com.tw
59010-090-01
443
397
113
96
+10
0
-10
20 100 200 500 1k 2k 5k 10k 20kHz
}
}
125Hz
250Hz
500Hz
1000Hz
2000Hz
4000Hz
8000Hz
16000Hz
