Gorenje BM589S11X User manual

EN
DETAILED
INSTRUCTIONS
FOR USE OF
MICROWAVE OVEN
www.gorenje.comwww.gorenje.com

We thank you for your
trust and the purchase of our
appliance.
This detailed instruction manual is
supplied to make the use of this
product easier. The instructions
should allow you to learn about your
new appliance as quickly as possible.
Make sure you have received an
undamaged appliance. If you do find
transport damage, please contact the
seller from which you purchased the
appliance, or the regional warehouse
from which it was supplied. The
telephone number can be found on
the invoice or on the delivery note.
Instructions for installation and
connection are supplied on a
separate sheet.
Instructions for use are also available
at our website:
www.gorenje.com / < http://www.
gorenje.com />
Important information
Tip, note

3
CONTENTS
473998
4 MICROWAVE OVEN
7 Technical specifications
8 Control unit (depending on the model)
10 IMPORTANT SAFETY INSTRUCTIONS
13 Before connecting the oven:
14 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
15 SWITCHING ON THE APPLIANCE FOR THE FIRST TIME
16 STEPS OF THE COOKING PROCESS (1–7)
16 Step 1: CHOOSING THE BASIC COOKING MENUS AND SETTINGS
19 Step 2: TIMER FUNCTIONS – DURATION
20 Step 3: STEP COOKING
22 Step 4: START THE COOKING PROCESS
22 Step 5: END THE COOKING PROCESS AND SWITCHING OFF THE
OVEN
24 Step 6: SELECTING ADDITIONAL FUNCTIONS
26 Step 7: CHOOSING THE GENERAL SETTINGS
28 DESCRIPTIONS OF SYSTEMS (COOKING MODES) AND COOKING
TABLES
33 MAINTENANCE & CLEANING
34 CONVENTIONAL OVEN CLEANING
34 USING THE AQUA CLEAN FUNCTION TO CLEAN THE OVEN
35 REMOVING AND CLEANING THE WIRE GUIDES
36 REPLACING THE BULB
37 TROUBLESHOOTING TABLE
38 DISPOSAL
39 COOKING TEST
INTRODUCTION
PREPARING THE
APPLIANCE FOR
THE FIRST USE
COOKING STEPS
MAINTENANCE
& CLEANING
TROUBLE-
SHOOTING
OTHER

4
MICROWAVE OVEN
(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON
THE MODEL)
Control unit
Oven door
Oven handle
Guides
- Cooking levels
4
3
2
1
473998
The figure represents one of the built-in appliance models. Since the appliances for which
these instructions were drawn up may have different equipment, some functions or
equipment may be described in the manual that may not be present in your appliances.

5
WIRE GUIDES
The wire guides allow preparation of the food on four levels (please note that the levels/
guides are counted from the bottom up).
OVEN DOOR SWITCH
The switches deactivate the microwave heating when the oven door is opened during the
cooking process. When the door is closed, the switches turn the microwaves back on.
COOLING FAN
The appliance is fitted with a cooling fan that cools the housing and the appliance control
panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues to operate for a short while in
order to provide additional cooling for the oven. (Extended operation of the cooling fan
depends on microwave operation time.)
473998

6
473998
OVEN EQUIPMENT AND ACCESSORIES
Use the GLASS BAKING DISH for cooking
with microwaves. It can also be used as a
serving tray.
In case of wire guides, the tray should
always be inserted into the groove between
the two wire profiles.
Never use the grid, the shallow baking sheet or the deep baking
tray or any other metal part or accessory when operating a
system with microwaves!

7
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
473998
The rating plate indicating the
basic information about the
appliance is located at the edge
of the oven and it is visible when
the oven door is opened.
ASerial number
BCode/ID
CType
DBrand
EModel
FTechnical data
GCompliance symbols

8
473998
CONTROL UNIT
(Depending on the model)
QUICKIES
MICROWAVES
1ON/OFF KEY 2OVEN LIGHTING ON/
OFF KEY 3BACK KEY
Touch briefly to
return to previous
menu.
Touch and hold to
return to main menu.
4Selection and CONFIRMATION
KNOB
Select the setting by
rotating the knob.
Confirm your
selection by pressing
the knob.
AUTOMATIC

9
473998
5MINUTE MINDER/
ALARM 6CHILD LOCK
KEY
Locking the control
unit
7START/STOP KEY
Long touch: START
Long touch during
operation: STOP
8DISPLAY – displays all settings
NOTE:
The keys will respond better if you touch them with a larger area of your fingertip. Each
time you press a key, this will be acknowledged by a short acoustic signal.
MY RECIPES
EXTRA
FUNCTIONS
GENERAL
SETTINGS

10
473998
IMPORTANT SAFETY
INSTRUCTIONS
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM
FOR FUTURE REFERENCE.
This appliance may only be used by children aged 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
supervision or instructions are provided to them concerning
use of the appliance in a safe way and if they understand
the hazards involved. Do not let the children play with the
appliance. Cleaning and user maintenance shall not be made
by children without supervision.
WARNING: The appliance and some of its accessible parts
may become very hot during use. Be careful not to touch
the heaters. Children younger than 8 years should be
constantly supervised.
The appliance becomes very hot during use. Be careful not
to touch the oven heaters.
WARNING: The accessible parts of the appliance may
become hot during use. Children should be kept away from
the oven.
Only use the temperature probe recommended for use in
this oven.
WARNING: Before replacing the light bulb, make sure the
appliance has been disconnected from the power mains, in
order to prevent the hazard of an electric shock.

11
473998
Do not use abrasive cleaners or sharp metal scrapers to clean
the oven as they may damage the finish or the protective enamel
coating. Such damages may lead to cracking of the glass.
Do not use steam cleaners or high pressure cleaners to clean the
appliance as this may result in an electric shock.
The appliance is not intended to be controlled with external
timers or special control systems.
The appliance is intended for household
use. Do not use it for any other purpose,
such as room heating, drying of pets or
other animals, paper, fabrics, herbs etc. as
this may lead to injury or fire hazard.
If the power cords of other appliances
located near this appliance are caught
in the oven door, they may be damaged,
which may in turn result in a short circuit.
Therefore, keep the power cords of other
appliances at a safe distance.
If the power cord is damaged, it should
be replaced by the manufacturer or an
authorized service technician, in order to
avoid hazard.
Do not line the oven walls with aluminium
foil and do not place baking trays or other
cookware on the oven bottom. Aluminium
foil would prevent air circulation in the
oven, hinder the cooking process, and ruin
the enamel coating.
Oven door become very hot during
operation. A third glass is installed for extra
protection, reducing the temperature of the
outside surface (only with some models).
Oven door hinges may be damaged when
under excessive load. Do not place heavy
pans on open oven door and do not lean
against open oven door when cleaning the
oven cavity. Never stand on the open oven
door and do not let children to sit on it.
Appliance operation is safe with and
without tray guides.
Make sure the vents are never covered or
obstructed in any other way.

12
Heed the minimum distance between the
upper edge of the oven and the nearest
object above it.
The appliance is intended for use in
households and similar environments, such as:
- staff pantries in stores and other working
environments;
- family farms;
- accommodation units for guests at hotels,
motels, and other accommodation or lodging
establishments;
- bed and breakfast establishments.
The microwave oven is intended for heating
food and beverages. Drying food or clothing
and heating of hot packs or pads, slippers,
sponges, moist cloths etc. may result in injury,
ignition, or fire.
Only use utensils suitable for use in
microwave ovens.
When heating food in plastic or paper
containers, keep an eye on the oven as such
packaging may ignite.
Microwave heating of beverages can result in
delayed eruptive boiling; therefore take care
when handling the container with the heated
beverage.
The contents of baby bottles and baby food
jars should be shaken or stirred and their
temperature checked before feeding in order
to avoid burns.
Eggs in their shell should not be heated in
microwave ovens since they may explode
even after microwave heating has ended.
If you observe smoke, switch off or unplug the
appliance and keep the oven door closed in
order to stifle any flames.
Always use oven mitts to remove dishes from
the oven. Some pots, pans, or trays absorb
the heat of foods and therefore become very
hot.
Safe use of the microwave oven
WARNING: If your oven allows combined operation (microwaves
combined with other cooking modes), do not allow the children
to use the oven without supervision of an adult person since the
oven will reach very high temperatures in such operation modes.
WARNING: If the door or door sealing is damaged, do not use
the oven until it is repaired by an adequately trained service
technician.
WARNING: It is hazardous for anyone other than a competent
person to carry out any service or repair operation which
involves removal of the cover that protects against exposure to
microwave radiation.
WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
473998

13
Make sure to only use the cookware that
is suitable for use in a microwave oven.
Do not use cookware made of steel or
cookware with golden or sliver rims.
Do not leave any accessories or utensils in
your oven when it is off. To avoid damage,
do not switch on an empty oven.
Do not use receptacles made of porcelain,
ceramics, or clay, if there are pores in the
material
or if the inside is not glazed. Once heated
up, the moisture that would penetrate
these pores could cause cracking. Only
use the cookware intended for use in a
microwave oven.
Always read and observe the instructions
for heating in a microwave oven, specified
on the food packaging.
Be careful when heating alcohol-containing
food, as a combustible mixture of alcohol
and air may form inside the oven. Open the
door carefully.
When using the microwave or the
combined microwave and convection
functions, use of metallic cookware, forks,
spoons, knives or metal clips/fasteners for
frozen food is not recommended.
After heating, stir the food or leave it to
rest until the heat is evenly distributed.
Regularly clean the oven and remove
any food residues. Failure to maintain
cleanliness in the oven may result in
deterioration of its surfaces. This can
negatively affect the useful life of
the appliance and lead to potentially
dangerous situations.
473998
BEFORE CONNECTING THE OVEN:
Carefully read the instructions for use before connecting the
appliance. Repair or any warranty claim resulting from incorrect
connection or use of the appliance shall not be covered by the
warranty.

14
When food is exposed to microwaves, the molecules begin to move rapidly, thereby
generating heat.
The microwaves penetrate approximately 2.5 centimeters deep into the food. If the food
is thicker, the core of the food will be cooked by conduction, as in conventional cooking.
1
473998
BEFORE USING THE APPLIANCE
FOR THE FIRST TIME
Upon receiving the appliance, remove all parts, including any transport equipment, from
the oven. Clean all accessories and utensils with warm water and regular detergent. Do
not use any abrasive cleaners.
Before using the oven for the first time, heat it with the upper and lower heater system
at 200 °C for approximately one hour. The characteristic "new appliance" scent will be
released; make sure the room is well ventilated.
MICROWAVE FUNCTION
Microwaves are used for cooking, roasting, and defrosting of food. They allow quick and
efficient cooking without changing the colour or shape of the food.
Microwaves are a type of electromagnetic radiation. Such radiation is commonly found in
our environment in the form of radio-electric waves, light or infrared rays. Their frequency
is in the 2,450 MHz range.
Their behaviour:
- They are reflected by metals.
- They travel through all other materials.
- They are absorbed by water, fat and sugar molecules.
Never use or activate a microwave system if the oven is empty.

15
473998
SWITCHING ON THE APPLIANCE
FOR THE FIRST TIME
SETTING THE CLOCK
After connecting your appliance or after an extended power outage, 12:00 will flash on
the display.
Set the time of day.
Confirm each setting by pressing the KNOB.
The oven will also work if the clock is not set. However, timer functions are not
available in this case (see chapter Setting the Timer Functions). After a few minutes of
idling, the appliance will switch to standby mode.
CHANGING THE CLOCK SETTING
Clock settings may be changed when no timer function is activated (see chapter
CHOOSING THE GENERAL SETTINGS).
SELECTING THE LANGUAGE
If you are not happy with the language in which the messages on the display are
presented, select another one. English is the preset language.
Rotate the KNOB
and select your
language from the
list. CONFIRM the
selection.
The main menu will
appear.
Press the KNOB to
set the time.
Turn the KNOB and f
rst set the TICK.

16
473998
STEPS OF THE COOKING
PROCESS (1–7)
STEP 1: CHOOSING THE BASIC COOKING
MENUS AND SETTINGS
The process of preparing food in your oven can be controlled in several ways:
Rotate the KNOB
and select the
symbol. The symbol
will turn white.
The NAME of the
selected menu will
appear at the top.
Automatic mode
In this mode, first select the type of food and the desired dish.
This is followed by automatic setting of the quantity and level of
doneness.
The program offers a large choice of preset recipes reviewed by
professional chefs and nutrition experts.
Quickies
This mode offers a selection of preset cooking procedures for
particular dishes. The cooking procedures can also be changed.
Microwaves
This mode is suitable for cooking, roasting, and defrosting of food.
Confirm each setting by pressing the KNOB.

17
473998
A) COOKING BY SELECTING THE TYPE OF FOOD
(Auto mode and Quickies mode)
Confirm each setting by pressing the KNOB.
Rotate the KNOB
and select the Auto
mode. Confirm the
setting by pressing
on the KNOB.
Select the type
of food and the
dish. Confirm the
selection.
Preset values will
appear. Rotate the
KNOB and confirm
by pressing the
KNOB to change
these settings.
1 Amount
2 Doneness
3 Delayed start
4 Cooking duration
5 Cooking system and recommended level
When in the Auto and Rapid mode, choose the duration or system symbol to open
the Professional mode (see section on COOKING BY SELECTING THE OPERATING
MODE).
Touch the START/STOP key to start oven operation.
All selected settings are indicated on the display.
1234 5

18
POWER LEVEL USE
1000 W • Quickly reheating beverages, water and dishes containing a
large volume of liquid.
• Cooking dishes with high water content (soups, sauces etc.).
750 W • Cooking fresh or frozen vegetables.
600 W • Melting chocolate.
• Cooking fish and seafood; reheating on two levels.
• Cooking dried beans at low heat.
• Reheating and cooking of delicate egg-based dishes.
360 W • Low-heat cooking of dairy products or jams.
180 W • Manual defrosting; softening butter or ice cream.
90 W • Defrosting cream-filled pastry.
473998
In microwave systems, the timer function – delayed start is not available.
Touch the START/STOP key to start oven operation.
Selected settings and the time counting down will be displayed on the display unit.
B) COOKING WITH MICROWAVES
Confirm each setting by pressing the KNOB.
Rotate the
KNOB and select
Microwaves. Confirm
the setting by
pressing on the
KNOB.
Select the settings
by rotating the
KNOB and pressing
it to confirm.
1 Microwave system
2 Cooking power
3 Cooking duration
4 Delayed start
5 Step mode (see section STEP COOKING)
12 3 45

19
473998
STEP 2: TIMER FUNCTIONS – DURATION
The "Duration" setting
can be selected in
the basic Microwave
mode.
Setting the cooking time
In this mode, you can define the duration of oven operation (cooking
time). Set the desired cooking time and confirm the setting. (Maximum
operating time is 10 hours.)
Cooking end time is adjusted accordingly.
Press START to start the cooking process. All selected settings are
indicated on the display.
All timer functions can be cancelled by setting the time to "0".
After the set time expires, the oven will automatically stop operating (end of cooking). An
acoustic signal will be heard which you may turn off by pressing the ALARM key. After one
minute, the acoustic signal will be switched off automatically.
After a few minutes of idling, the appliance will switch to standby mode. The time of day will
appear.

20
473998
STEP 3: STEP COOKING
This mode allows you to combine three different cooking modes successively in a single
cooking process.
Choose different settings to cook your food just the way you want it.
The "Step Cook"
setting can be selected
in the basic Microwave
mode. Confirm the
setting by pressing on
the KNOB.
Select: Step 2, Step 3
Confirm the settings
by pressing on the
KNOB.
The first step is already selected.
Set the cooking
power and time.
Confirm the
selection with the
check mark by
pressing the KNOB.
Total cooking time
– end.
Cooking power and duration
of the selected step
Current step
