Gourmia GSI-170 User manual

MODEL#GSI-170
ICE CREAM
MAKER
SWEET SCOOP
WITH DIGITAL TIMER
FROZEN YOGURT, SORBET &
1.5 QUARTSTAINLESS STEEL

USER
MANUAL
Safety Precautions 4
Product Specs 5
Using Your Device 6
Cleaning and Care 8
Warranty Details 9
MODEL#GSI-170
ICE CREAM
MAKER
SWEET SCOOP
WITH DIGITAL TIMER
FROZEN YOGURT, SORBET &

SAFETY PRECAUTIONS:
4 5
Disclaimer: Manual instructions should always be read and implemented prior to
product use. Manufacturer/ importer advisory boards are not responsible for
improper use due to instruction manual negligence or failure to follow directions.
This product is intended for indoor use only!
Keep this device out of the reach of children or unqualified persons, since the
misuse of contents and packaging materials may result in hazard or death.
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Before plugging in appliance, please check that the voltage indicated on the
bottom of the appliance is in accordance with the main voltage of your
home.
3. Do not use near any heat sources.
4. To protect against electrical shock, do not put any part of the appliance in
water or other liquids.
5. Use the appliance on a level, stable work surface.
6. CAUTION: Do not pour the ice cream mixture into the machine before it is
plugged in and the paddle starts to rotate. Otherwise, the paddle will be
easily blocked and the motor will be damaged by the bottom freezing ice
cream mixture.
7. The appliance should not be used by children younger than 8, and by
persons with reduced physical, sensory or mental capabilities and
knowledge without supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance should not be
done by children. Keep appliance and it’s cord out of the reach of children
under 8 years old.
8. Always disconnect the appliance from electrical supply if it is left
unattended, and before assembling, disassembling or cleaning.
9. Do not operate any appliance with a damaged cord or plug or after
appliance malfunctions, or is dropped or damaged in any manner. If the
supply cord is damaged, it me be replaced by the manufacturer, its service
agent or similar qualified person in order to avoid a hazard.
10. Do not let cord hang over edge of table or counter.
11. Do not pull the power cord with forced or put it on shard edged objects or
heat sources such as oven.
12. Do not use appliance for other than intended use.
13. This appliance is household and indoor use only.
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
PRODUCT SPECS
1. CONTROL BOX
2. TOP COVER
3. LOCK
4. PADDLE
5. FREEZER BOWL
6. BASE

USING YOUR DEVICE
6 7
a) Before first use, ensure that all packaging materials are removed. Take out
Freezer bowl (5). Clean it thoroughly and dry any surfaced moisture. Store it in a
freezer below 0 degrees for at least 12 hours. (Shake the freezer bowl to check
where if there is liquid moving inside the inner layer. If you cannot hear any liquid
move, this indicates that the liquid is fully frozen. Otherwise, please freeze for a
longer amount of time).
b) Prepare proper amount ( proposed 400-500 ml) of ice cream mixture as per
recipe and store in fridge for 2 to 4 hours.
c) ASSEMBLY:
• Take out Freezer bowl (5) from the freezer and assemble it into Base (6)
as shown in figure below
• Clean Paddle (4), and insert the upper end of the paddle through the Top
cover (2) hole, push into the gear hole of the Control box (1) until it clicks into
place. When you hear a “click” sound, this indicates paddle is in place and
assembled as figure below:
• Place the assembled top cover unit onto the base as figure below, find
the arrow marks on the top cover and housing and make sure they are
aligned. Press down until you hear it click.
• Plug in the power cord. LCD light will go on. The default preset timing is 20
minutes. You can press the “Timer” button to change the preset time. Add time in
increments of one minute by pressing the “Time” button, for up to 40 minutes.
Once the time setting is finished, press the “Start/ Pause” button, and the paddle
starts to rotate, and the digital time begins count down. As figure below:
• Open the Filling Lid, and pour the ice cream mixture through the lid into the
machine. Close the lid and wait until machine stops rotating. (If you want to reset
time during the process, press the “Start/Pause” Button to pause the machine,
and the re-press the “Timer” button to set the time.
• Unplug the appliance after use. First pull upright while pressing down the Lock
(3) at both sides to remove the top cover unit. Then take out the freezer bowl and
ice cream as figure below:
Start/PauseTimer
LCD Display= mm:ss

8 9
WARRANTY DETAILS
This product is guaranteed under a one year limited warranty period, applicable
to the original purchaser and not transferable to a third party user.
Repair or replacement of defective parts are at the seller's discretion. In the event
that repair isn't possible, the seller will replace the product/ part. If product repair/
replacement won’t suce, the seller has the option of refunding the cash value of
the product or component returned.
Product defects not covered under the warranty provisions include normal wear
and damage incurred from use or accidental negligence, misuse of instruction
specifications, or repair by unauthorized parties. The manufacturing company is
not liable for any incidental or consequential damages incurred by such circum-
stances.
STORAGE AND DISPOSAL
This product must not be disposed together with the domestic waste.
This product has to be disposed at an authorized place for recycling of
electrical and electronic appliances. By collecting and recycling waste,
you help save natural resources, and make sure the product is disposed
in an environmental friendly and healthy way.
CLEANING AND CARE
a) Be sure to unplug appliance.
b) Remove the Paddle (4) with force from the top cover as shown in figure below:
c) Pull upright while pressing down the Lock (7) to remove the Control box (1)
as shown below:
c) Rinse all other parts except the Control box (1), which can only be cleaned
with a dry cloth.
Storage:
• Store the appliance in a cool, dry and clean place, out of the reach of children
and pets.
• Please keep the packaging for transporting the appliance or for storing your
appliance when not in use for a prolonged time period.
Disposal:
