GPS Tracker GPS102 User manual

1
GSM/GPRS/GPS TRACKER
MANUAL
U
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly.
Make sure to read this manual carefully before using this product. Please note that specification and
information are subject to changes without prior notice in this manual. Any change will be integrated in the
latest release. The manufacturer assumes no responsibility for any errors or omissions in this document.

2
Content
1. Summary ...................................................................................................................................................3
2 Applications................................................................................................................................................3
3 Hardware Description..................................................................................................................................3
4 Specs. .........................................................................................................................................................4
5 Usage..........................................................................................................................................................5
5.1 SIM card installation ................................................................................................................................5
5.2 Battery and Charger..................................................................................................................................5
5.3 Startup .....................................................................................................................................................5
5.4 Initialization.............................................................................................................................................6
5.5 Change the password................................................................................................................................6
5.6 Authorization ...........................................................................................................................................7
5.7 Single Locating ........................................................................................................................................7
5.8 Auto Track ...............................................................................................................................................8
5.9 Absolute street address .............................................................................................................................8
5.10 GPS drift suppression .............................................................................................................................9
5.11 Location based service (LBS)..................................................................................................................9
5.12 Monitor (Voice Surveillance) ..................................................................................................................9
5.13 Data logging.........................................................................................................................................10
5.14 Data Load ............................................................................................................................................10
5.15 Shock Sensor Alarm .............................................................................................................................11
5.16 Geo-fence.............................................................................................................................................11
5.17 Movement alert ....................................................................................................................................12
5.18 Overspeed alert:....................................................................................................................................12
5.19 SOS alert..............................................................................................................................................13
5.20 Low battery alert ..................................................................................................................................13
5.21 GPS blind Spot alert .............................................................................................................................13
5.22. Sleep Mode .........................................................................................................................................13
5.22.1 Sleep by time............................................................................................................13
5.22.2. Sleep by shock sensor ..............................................................................................14
5.22.3 No sleep mode..........................................................................................................14
5.23 Forward the third parties’ message ........................................................................................................15
5.24 Charges Inquiry....................................................................................................................................15
5.25 State Checking .....................................................................................................................................15
5.26 IMEI checking:.....................................................................................................................................15
5.27 Terminal (local) Time Setting................................................................................................................15
5.28 TCP/UDP switch ..................................................................................................................................16
5.29 Reset....................................................................................................................................................16
5.30 Configure parameters by USB...............................................................................................................16
5.31 GPRS setting........................................................................................................................................16
5.32 Less GPRS traffic.................................................................................................................................17
5.33 Modes switch between “SMS” and “GPRS” ..........................................................................................18
5.34 Setup monitor center number ................................................................................................................18
5.35 Web platform and PC installation tracking software...............................................................................18
6 .Cautions...................................................................................................................................................19
7 Faults & The solutions...............................................................................................................................19

3
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and
monitor any remote targets by SMS or internet.
2 Applications
Vehicle rental / Fleet management etc
Powerful magnet + water proof, adsorbing in the hidden place of car for tracking secretly.
Protect child / the old / the disabled / pet etc
Provide peace-of-mind for businessmen
Personnel Management
Criminals Tracking
3 Hardware Description
3.1 Front face 3.2 Rear face
3.3 Side face
You can update software,
charge battery from here.
SOS Button
Indicator for signals.
ON /OFF Button

4
3.4 Bottom face
3.5 Interior
4 Specs.
Content
Specs.
Dim.
64mm x 46mm x 17mm(1.8”*2.5”*0.65”)
Weight
50g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS chip
SIRF3 chip
GPS sensitivity
-159dBm
GPS accuracy
5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Car charger
12—24V input
5V output
Wall charger
110－220V input
5V output
Battery
Chargeable changeable 3.7V 800mAh Li-ion battery
Standby
80hours
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +55°C
Humidity
5%--95% non-condensing
Built-in GSM/GPRS antennas
is inside
Microphone
GSM Card Slot
Install the battery like this

5
5 Usage
5.1 SIM card installation
Make sure that there is no call transfer and call display is on, and PIN code off. The SMS
message must in Text format, can’t be identified for PDU format.
Steps:
5.1.1 Open the rear cover, and pick out the battery.
5.1.2 Push the foil up according the arrow on the foil and load the miscro SD card and push
back.
5.1.3 Put the SIM card into the holder as picture shows.
5.2 Battery and Charger
Do charge the battery to capacity in 8 -12 hours for first time. Please use the battery and charger
provided by the manufacturer. This unit adopts built-in Li-ion battery, and full battery can
standby 80 hours. After first use, the battery usually should be charged fully in 3-5 hours.
Cautions:
a: For it’s Li-ion battery, which contains harmful chemicals and may burst, please don’t bump, puncture it
violently and keep it off fire.
b: Please charge the battery in time to keep it working normally.
5.3 Startup
Put the SIM card and battery in place.

6
Turn on the unit outdoors by pressing the “on/off”button until the indicator is on.
For first use, please initialize the unit and restore it to default setting. (Please refer to 5.4 for
instruction.)
In 10 or 40 seconds, the unit will begin to work and acquire the GSM signals as well as the
GPS signals. The indicator will keep flashing every 3 seconds when the unit has received
the signals.
When this unit receives GPS signals normally, you can use it and do any setting as the
instructions of this manual.
5.4 Initialization
Send “begin+password”in SMS to the unit, it will reply “begin ok”and initialize all the
settings. (Default password: 123456)
For example, send SMS“begin123456”to the tracker via a cell phone, If succeeded,
if will reply“begin ok”.
5.5 Change the password
5.5.1 Set Password: Send sms: “password+old password+space+new password” to the unit to
change the password.
For Example, pls send sms: “password123456 888888”to terminal device, it will reply sms:
“password OK”. New password 888888 changed in success.
5.5.2 Be sure keep the new password in mind, you have to upload the software to restore the
original setting in case of losing the new password.
5.5.3 Make sure the new password is in 6 digits Arabic numbers, or the tracker can not
recognize the password.
5.5.4 Make sure that all the symbol“+”in sms commends is just for quick understanding, which

7
don’t need to enter “+”in sms, and “space”means press the spacebar button of the cell phone.
5.6 Authorization
There are only 5 cell phone numbers able to be authorized, be sure to set the authorization
phone number before use.
5.6.1 Call the tracker for 10 times continuously and get position correctly, then it will make the
cell phone number as the authorized number automatically.
5.6.2 Send SMS：“ admin+password+space+cell phone number”to set up a authorized number.
The other authorized numbers should be set by the first authorized number. If the number is
successfully authorized, the unit will reply “admin ok!”in SMS.
5.6.3 Send SMS：“ noadmin+password+space+authorized number”to delete the authorized
number.
5.6.4 For roaming purpose, you have to add your country code ahead of the cell phone number,
for example, please send：“ admin123456 [phone]”to tracker to set 13322221111 as
an authorized number.
5.7 Single Locating
5.7.1 If there is no authorized number, when any number dials up the unit, it will report a
Geo-info; If there is already an authorized number, then it will not respond when an
unauthorized number calls it up.
5.7.2 When an authorized number dials up the unit, it will hang up and report a real-time
Geo-info as below:

8
*Tracking location, when no GPS signal, the SMS includes the last valid latitude & longitude
as well as the LAC code of current position, the LAC code can be input in the column of
“manual track”menu of web platform.
5.8 Auto Track
5.8.1 Send SMS command “fix030s005n+password” to the tracker device, it will report the
Geo-info at 30s intervals for 5 times. (s:second, m:minute, h:hour). This command setting
must be in 3 digits and the maximum value is 255.
5.8.2 Unlimited times auto track: Send SMS “fix030s***n+password” to the tracker device, it
will reply the Geo-info continuously at 30 seconds intervals.
5.8.3 Cancellation: Send SMS “nofix+password” to the tracker device.
Note: the interval must not less than 20s.
5.9 Absolute street address
5.9.1 You must set up the APN of your local GSM network for the SIM card in tracker first
before using this function, if there is user name and password for GPRS login, Please
refer to 5.31.1 and 5.31.2 to configure the APN, user name and password for GPRS login.
5.9.2 After configure the APN, send:”address+password”to device, it will reply SMS
including absolute street address. For example: No.113, Nantou Guankou 2nd Rd.

9
Nanshan district, Shenzhen, Guangdong, china.
5.10 GPS drift suppression
5.10.1 This function is deactivated as default, send "suppress+password" to tracker to activate,
it will reply" suppress drift ok". The GPS data stop updating if vehicle is not moving and
latitude and longitude always keep same, and GPS data updates automatically when vehicle
is moving.
5.10.2 Cancel: send "nosuppress+password" to tracker, it will reply" nosuppress ok ".
5.11 Location based service (LBS)
When the tracker device doesn’t receive valid GPS signals, tracker will locate by LBS, the
messages includes the GPS coordinates of the last position in SMS mode, but the LAC in
message is the current new position, the location can be seen by inputting the LAC code in the
menu “Manual Track”of web platform www.gpstrackerxy.com, you can also send command
“address+password” to tracker to get the newest absolute address and newest GPS coordinates
as well; tracker will automatically switch to track by location based service in GPRS mode, and
actualized on the map of web server with LBS mark. And there may be some inaccuracy with
actual location by LBS tracking; the bias depends on GSM reception.
Note: This feature can be used normally in most areas according to the signal of GSM network.
It may not be available in some areas.
5.12 Monitor (Voice Surveillance)
5.12.1 The command to switch between Track and Monitor are “tracker”and “monitor”.
5.12.2 The default mode is “track”(Track mode).
5.12.3 Send SMS “monitor+password”to the unit, and it will reply “monitor ok!” and switch to

10
“monitor”mode.
5.12.4 Send SMS “tracker+password”to the unit, it will reply “tracker ok!” and restore to
“track” mode.
5.13 Data logging
5.13.1 Auto logging：When the tracker devices lost GSM signals or fall offline from GPRS,
tracker will store the tracking position and alerts automatically in the flash upon the pre-set
condition, when GSM signals get back, all the event alerts will be auto-sent to the authorized
numbers or monitoring platform (server), but the stored tracking data should be loaded to the
monitoring platform via SMS command.
5.13.2 Logging upon times: Send SMS: “save030s005n+password”to the tracker unit, it will
reply “save ok”, and will store the lat, long locations every 30 seconds for 5 times. (S: second,
m: minute; h: hour).
5.13.3 Multi-logging：Send sms:”save030s***n+ password”to tracker device, it will reply
“save ok”.
5.13.4: logging Clearance: send SMS: “clear+ password”to tracker device, it will reply “clear
ok”.
5.13.5：Logging Volume: Built-in flash 1MB (store about 16,000 positions); expanded volume
depends on the SD card inserted.
5.13.6 The logged data can be copied to computer via the USB cable in the package. The route
of the stored data can be seen by importing data in the menu “Data Import”of web platform
www.gpstrackerxy.com
5.14 Data Load
5.14.1 Current date Load: Send SMS: “load+ password”to tracker device, it will reply: “load
ok”if the device is working well under GPRS mode; if not, it will reply “load fail! Please check
