GPS Tracker mp2 User manual

Gpstracker.net.in
Freedom is lost now…!
Model no: mp2
Personal GPS Tracker
USERS MANUAL

Gpstracker.net.in
Freedom is lost now…!
1 Product Overview
This tracker shows you with your mobile phone or PC the location of your targets via
SMS or GPRS
TRACKER has the following features
Tracking via SMS or GPRS 

Current location report 

Tracking by time interval 

Two-way conversation 

SOS alert 

Geo-fencing control 

Low battery alert 

Over speed alert 

Four buttons for making phone call and/or sending message to reset numbers 

Removable and rechargeable internal battery 

Built-in speaker and microphone 

Alert when Track enter/exits GPS blind area 

Live Voice monitoring 

Vibrating alert 

Without drift 

Vehicle safeguard 
2 For Your Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the full user manual for more information.
Water Resistance –Track is not water resistant. Keep it dry. Use waterproof bag if
necessary.

Gpstracker.net.in
Freedom is lost now…!
3 Track Parameters& Panel Description
Item
Specification
Charging Voltage
DC 5V/500mA (Micro USB port)
Internal Battery
Rechargeable and removable 830 mAh battery (3.7V)
Operating temperature
-20° to 55° C
Humidity
5% to 95% Non-condensing
GSM module
GSM 900/1800/1900Mhz
GPS Chipset
sirmens (AGPS)
GPS Sensitivity
-158Db
GPS Frequency
L1, 1575.42 MHz
C/A Code
1.023 MHz chip rate
Channels
24 channel all-in-view tracking
Position Accuracy
5 meters, 2D RMS
Velocity Accuracy
0.1 m/s
Time Accuracy
1 us synchronized to GPS time
Default datum
WGS-84
Reacquisition
0.1 sec., average
Hot start
1 sec., average
Warm start
38 sec., average
Cold start
42 sec., average
Altitude Limit
18,000 meters (60,000 feet) max.
Velocity Limit
515 meters/second (1000 knots) max.
Acceleration Limit
Less than 4g
Jerk Limit
20 m/sec
Work time
60 hours in sleep mode and 10 hours in normal mode
LED
3 LED indicators showing power, GPS, GSM status and other
operation status.
G-Sensor
± 2g

Gpstracker.net.in
Freedom is lost now…!
Panel Description

4 Getting Started
4.1 Hardware and Accessories
USB Power Cable 

User Manual 

Other document or software if required 
4.2 Light and Button Functionality++++++ 
TRACKER has four buttons and three LED lights with three different colors to indicate
the status of the unit. All LED is enabled when power on, and short click SOS key to change
GSM & GPS LED enable / disable status. 

Gpstracker.net.in
Freedom is lost now…!
Red LED -- Indicating power status
Off
Power off / charging complete / working / GPS optional
Flashing (on for 0.05s and off for 4.95 s)
Low power
Flashing (on for 1s and off for 4 s)
GPS on
On
Charging
Green LED -- Indicating GPS status
Off
Device is not ready
Flashing (on for 0.05 s and off for 4.95 s)
GPS fix
Flashing (on for 1 s and off for 4 s)
GPS no fix / GPS power off
Blue LED –Indicating GSM status
On
Telephone dial/Have a call/Busy/ GPRS transmit
Flashing (on for 0.05 s and off for 4.95 s)
TRACKER is connected to GSM network
Flashing (on for 1 s and off for 4 s)
TRACKER is not connected to the GSM network
Note: When it is power on, but not finding SIM card or showing errors on SIM card, the three LEDs will
be on and off one by one as a circle repeatedly.
Power Button
To turn on/off
SOS Button
Long press SOS button to send an alarm to location
center and make a phone call and/or send an SMS to
the preset phone number.
Short press SOS button to change GSM & GPS LED
enable / disable status.
1 Button
Long press 1 button to make a phone call and/or send
an SMS to the preset phone number.
2 Button
Long press 2 button to make a phone call and/or send
an SMS to the preset phone number.
3 Button
Long press 3 button to make a phone call and/or send
an SMS to the preset phone number.

Gpstracker.net.in
Freedom is lost now…!
4.3 First Use
Ensure that Tracker has a working SIM installed
Check that the SIM has not run out of credit 

Check that the SIM Lock code is turned off 
Use some other mobile phone to confirm that the PIN code Can not been set ,and
that it can dial out and receive telephone calls, and that it can connect to internet by
GPRS. 
Charge the battery for at least 3 hours in power-off status using the wall charger or
car charger. Red light is on during charging and is off when charging is completed. 
4.4 Operation Instructions
(1) Power On/Off
Power On
Step:1

Gpstracker.net.in
Freedom is lost now…!
Step 2.
Step:3

Gpstracker.net.in
Freedom is lost now…!
Note: When it is power on, but not finding SIM card or showing errors on SIM card, the three LEDs
will be on and off one by one as a circle repeatedly.
Power Off:
When it is on, press the power button for 3 seconds to switch off the power;
Power/GPS/GSM LED will shut off right now. By then, the device is turned off.
(2) SOS Emergency Help Function
When SOS button is long pressed, Track will send alarm to location center, and send a
SMS message and make phone call for emergency help. The phone number can be set by
the users.
When 1 2 3 button is long pressed, Track will make normal phone call. The phone
number can be set by users. The phone number list can be set by SMS command.
(3) Conversation Function
Call In: One can make phone call to Track by simply dialing the SIM card number.
To receive the incoming phone call
To refuse the incoming phone call
Call Out: Track has four speed dial; you can long press preset 4 sets of phone
(4) gprs live tracking
Please follow the 4 steps in quick set up file
5 SMS Command
TRACKER will only accept commands from a user with the correct password.
Commands with wrong password are ignored. The default password is 000000.

Gpstracker.net.in
Freedom is lost now…!
5.1 Basic SMS Commands
5.1.1 Return the location of the tracker
Description: To know the location of your Track, send an SMS to Track and it will report
its location by SMS.
Command: W<password>, <000>
Notes: The default password is 000000.
Example:
SMS sent: W000000, 000
SMS received:
W00,000,$GPRMC,034522,662,A,2232,3126,N,11359,3061,E,000.0,000.0,241209,,,A*6
E
5.1.2 SOS/Call 1/Call 2/Call 3
Description: To authorize a mobile phone number for the SOS, 1, 2 or 3 buttons. When the button is
pressed, a message will be sent and/or simultaneously a call will be made to the authorized number.
Command: W<password>,003,F,P, <telephone number>
Notes:
(a) F =0, cancel this function
=1, set send SMS to the preset number
=2, set call the preset number
=3, set send SMS and also Call the preset number
P =1, set a authorized number for SOS button
=2, set a authorized number for 1 button
=3, set a authorized number for 2 button
=4, set a authorized number for 3 button
(b) When one of the buttons is pressed and a call is made, you can call and talk with the
tracker-holder.
(c) Press END button to hang up the call or cancel a calling
Example:

Gpstracker.net.in
Freedom is lost now…!
SMS sent: W000000,003,3,1,123456789
SMS received: W01,003,Set phone number OK
Meaning: When the SOS button is pressed, Track will send an SMS to telephone number
“123456789” and also make a phone call to it.
When a call is coming in, the blue light is on. Press ACCEPT button to receive the
incoming call and then talk with the caller. To complete the conversation, hang up the call
by pressing END button.
5.2 GPRS Settings by SMS
Tracking via GPRS, you should set APN for Track.
Ensure that your SIM card in Track supports GPRS connection prior to setting.
5.2.1 Set APN
Command: W<Password>,011, <APN>,<APN Name >,<APN Password>,<APN
DNS>,<APN Second DNS>
Note: If no APN name, APN password, APN DNS and APN Second DNS required, input
APN only.
Example: W000000, 011, airtelgprs
TRACK will reply with an SMS (like „W01, 011, Set device APN OK‟) to confirm this
setting.
5.3 Car Safeguard Setting
5.3.1 Opening Function
You can start this function via SMS of your cell phone to set the authorized number for
SOS button. (You can have more reference from setting SOS phone number in 5.1.2 )

Gpstracker.net.in
Freedom is lost now…!
5.3.2 Setting
You can send message “SF” with your cell phone to your reset phone numbers in Tracker to
set it. After that, if your vehicle is illegal moved or abnormal vibrated; it will inform you about it via
SMS right now.
5.3.3 Cancelling
You can send message “CF” with your cell phone to your reset phone numbers in Tracker to
cancel it. After that, the safeguard is closed successfully.
5.3.4 Location
You can send message “DW” with your cell phone to your reset phone numbers in Tracker,
then the Tracker will answer the location of your vehicle via SMS.
5.3.5 Orientation-- The latitude and longitude
You can send message “DWJE” with your cell phone to your reset phone numbers in Tracker, then
the Tracker will only answer the exact data of the latitude, longitude and the site ID of your vehicle
instead of the words description of the location.
Command list
Default password=000000
Description
Command
Remarks
Get current location
W000000,000
Get current location of tracker
Change user’s password
W******,001,######
****** is old password
###### is new password
max 6 characters.
Set interval for automatic timed
report (sms report only)
W000000,002,XXX
XXX is the interval in minute. If
XXX=000 it will stop tracking
Set preset phone number for SOS
button
W000000,003,F,P,T
F=0, to turn off this fuction;
F=1, only sending SMS;
F=2, only calling preset phone number;
F=3, both SMS and calling (default)
P=1, set a authorized number for SOS
button
P=2, set a authorized number for 1 button
P=3, set a authorized number for 2 button
P=4, set a authorized number for 3 button
T: Preset phone number. Max. 16 digits
Set over speed alert
When tracker speeds higher
than the preset value, it will
send one over speed alert to
the SOS preset number.
W000000,005,XX
XX (the preset value of speed)
=00 , to turn off this function
=[01, 20] (unit: 10Km/h)
For example, W000000,005,08, it will
sent alert when it is over 80Km/h
Set Geo-fence alert
When tracker moves out of
preset scope, it will send one
W000000,006,XX
XX ( preset distance to original place )
=00, to turn off this function
=01, 30m

Gpstracker.net.in
Freedom is lost now…!
Geo-fence SMS to the SOS
preset number.
=02, 50m
=03, 100m
=04, 200m
=05, 300m
=06, 500m
=07, 1000m
=08, 2000m
Extend Settings
W000000,008,ABCDEFG
A=0, turn off the function of sending an
SMS location report to the authorized
phone number when it makes a call to tracker.
A=1, turn on the function of sending an
SMS location report to the authorized
phone number when it makes a call to tracker.
B=0, reserved
B=1, location data complies with NMEA 0183 GPRMC protocol.
For example:
$GPRMC,072414.000,V,3114.3763,N,
12131.3255,E,0.00,0.00,050805,*00
C=0, turn off the function to automatically hang up an incoming call.
C=1, turn on the function to automatically hang up an incoming call
after 4 - 5 rings.
D=0, Turn off the function of sending an SMS when tracker is turned on.
D=1, Turn on the function of sending an SMS to SOS number when
tracker is turned on.
E=0, reserved
E=1, tracker shuts down automatically
when the power voltage lower than 3V.
F=0, Turn off the alert when tracker
enters GPS blind area.
F=1, Turn on the alert when tracker
enters GPS blind area. SMS is to be
sent to SOS number
G=0, 3 LED lights work normally
G=1, 3 LED lights stop flashing when
tracker working.
(default value is: ABCDEFG=0100100 )
Presetting by SMS for GPRS tracking (Ensure that your SIM card supports GPRS connection prior to setting)
Set ID for tracker
W000000,010,ID
Tracker ID must not over 14 digits.
Set APN
W000000,011,APN,APN Name, APN
Password
If no APN name and password
required, just insert APN only;
APN defaulted as ‘airtelgprs’;
APN+APN name + password not over 39 characters.
Set IP Address and Port
W000000,012,37.59.232.31, 11200,
11200
IP: xxx.xxx.xxx.xxx
Port: [1,65534]
Enable GPRS Tracking
Function
W000000,013,X
X=0, turn off GPRS tracking (default);
X=1, enable TCP
Set Time Interval for
Sending GPRS Packet
W000000,014,XXXXX
XXXXX should be in five digitals and in unit of 10 seconds.
XXXXX=00000, to turn off this
function;
XXXXX=00001~65535, time interval for sending GPRS packet and in unit
of 10 seconds.
Note:1 to increase the call volume –just call the tracker , recive the call and press 1key to decrese and press 3 key to increase call volume
Note2 : to increase the ringer volume switchon the tracker press 3key for 3to 5 times and to decrease ringer volume press 1key for 3 to 5 times it becomes
mute

Gpstracker.net.in
Freedom is lost now…!
Position by sms GOOGLE MAP LINK URL : W000000,100
Set phone number for
Voice surveillance
W000000,030,T
T is the telephone number for
wiretapping and max. 16 digits
Set time zone difference
W000000,032,T
T=0, to turn off this function
T=[-720, 720] to set time difference in
minute to GMT. Default value is GMT
For those ahead of GMT, just input the time difference in minute
directly. For example, W000000,032,120
‘-‘is required for those behind GMT. For example, W000000,032,-120.
Set character for SOS alert message
W000000,033,P,Char
P is the button number. P=1, 2, or 3.
P=1, SOS button
P=2, 1 button
P=3, 2 button
P=4, 3 button
Char is the character in SOS message and max 32 characters
Get IMEI
W000000,601
To get IMEI
Get current location
W000000,051
Get current location of Track, Google Earth
format
Language
W000000,032,330
english
Get current location
W000000,052
Get current location of Track, plain address
Note:1. to know additional features of server plz click on this link. http://www.gpstracker.net.in/premiumserversupport.html
2.for quick setup manual download from below link http://www.gpstracker.net.in/QuickSetup_Downloads/mv2.pdf
3.. download android gps settings application : http://gpstracker.net.in/download/Gps%20Settings.apk
4.Download desktop application from http://www.gpstracker.net.in/download/pwebtrack.rar
5.forother network sim card apn names: http://www.gpstracker.net.in/download/apnnames.pdf
If you have any more queries regarding installation please can call us on 09700025002 or 040 64559002 or mail us at
[email protected] website: www.gpstracker.net.in 13-100 meerpet, Hyderabad 97

Gpstracker.net.in
Freedom is lost now…!
