GRACE DESIGN LUNATEC V3 FIRMWARE
UPGRADE PROCEDURE
•PARTS NEEDED:
oLunatec V3 Firmware Chip
•TOOLS NEEDED:
o#2 Phillips Screwdriver
oSmall Flathead Screwdriver
•TIME REQUIRED:
oApproximately 6 3 minutes
BEFORE YOU BEGIN!
The Lunatec V3 Firmware Chip is a static sensitive device Do not
touch or remove the chip from its protective packaging until you
are ready to install it When performing the upgrade, you should
do so on a clean solid surface (not on the carpet) Additionally be
sure any static buildup on your body is discharged by touching a
grounded object before starting the upgrade
UPGRADE IT!
1 Disconnect the power from your V3
2 Position your V3 such that the front is facing you
3. Using the #2 Phillips screwdriver, remove the four top cover screws Lift the
top cover off and set it aside
4 Locate the ADC board, which is located in the upper right hand corner of your
V3
5 Now locate the firmware chip location on the ADC board

6 Using the small flathead screwdriver carefully remove the old firmware chip
7. Install the new V3 firmware chip in your V3 A few things to note here:
a Make sure that the dot cutout on the firmware chip is towards the rear
of your V3
b Make sure all the pins are aligned
c Apply gentle pressure to seat the chip fully
8 Reinstall the top cover using the #2 Phillips screwdriver
9 Reconnect power to your V3 and enjoy!
