Grace THRIVE User manual

LED LINEAR
LED LINEAR USER GUIDE
LED LINEAR USER GUIDE
THRIVE Adjustable SM
Installation Manual
THRIVE Adjustable SM Installation Manual

WARNING
1.Switch off before installation.
2.Switch on only after complete installation and examination of the circuit.
3.Professional electrician for installation and maintenance only.
Installation Procedure
Turn Off power supply before starting any installation. Read instructions & check you have all the tools
& accessories to complete the installation correctly.
Suspended:
To ensure correct function and safety, please read and follow all instructions carefully before using the product:
1. Turn off power before installation or before doing any maintenance work.
2. Do not install any luminaire near the heat source.
3. Do not exceed the nominal supply voltage or amperage ratings.
4. Dimmable version could be compatible with a wide range of recommended TRIAC dimmers.
5. All wiring and installation of the light fitting must adhere to local and national wiring rules.
6. Take care not to pull any electrical wires during unpacking as this may damage the connection.
7. Lay out all the components on a smooth surface and make sure there are no components missing before
assembling.
8. To avoid injury or damage to the fitting, please ensure that power leads and screws are secure before connecting
the power.
9. Please keep instructions for future reference.
Safety Instructions
STEP 1 STEP 2
STEP 5 STEP 6
STEP 3 STEP 4
STEP 7
STEP 8
Insert the anchoring into the wall, fix the nut. Adjust the length of suspended wires.
Set the DC wires into the block.
Fix the surface mounting bracket on the ceiling. Connect the AC wires .
Fix the mounted box on the bracket by screws.
Set the DC plugs , installation finished.
Set the DC wires into the block.
1.if the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar qualified
person in order to avoid a hazard.
Warning:
2.The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person.
1. Turn off power before installation or before doing any maintenance work.
2. Do not install any luminaire near a heat source.
3. For Indoor use.
4. Do not exceed the nominal supply voltage or amperage ratings.
5. All wiring and installation of this luminaire must adhere to local and national wiring rules eg AS/NZS 3000:2007 Amendment 2:2012
Electrical Installation
6. Take care not to pull any electrical wires during unpacking as this may damage the connection.
7. Lay out all the components on a smooth surface and make sure there are no components missing before assembling.
8. To avoid injury or damage to the tting, please ensure that power leads and screws are secure before connecting the power.
9. Please keep instructions for future reference.
1 - Loosen the M3 screws
Rotate the back base off the
lamp anti-clock wise
How to install
2 - Drill 2 holes of 6mm
diameter in the ceiling accord-
ing to position on back base
3 - Fix the back base on the
ceiling by tapping screws
4 - Connect the AC power to
the connectors
5 - Align the driver box to the counter-
point and rotate clock wise to x onto the
back base
6 - Lock base with grubb screw
