GraceSense HSM User manual
QUICK START GUIDE
Installation of the GraceSense™ Hot Spot Monitor (HSM) has been engineered to be simple and
straightforward. This document will describe in detail the 3 steps needed for installation.
No specialized knowledge of fiber optics is necessary. A basic understanding of electrical equipment
topology and mounting methods is required.
REQUIRED FOR INSTALLATION
Tools for Fiber Mounting:
• Adjustable Wrench
• 1.5 mm Allen Key
• Guillotine Cutter
Components for Hardware
Installation:
• 35 mm DIN rail (6”-8”) and
mounting hardware
• CAT5 Ethernet cable
(if connecting to SCADA
or computer.)
Power Supply Requirements:
• Voltage: 12-24 VDC
(0.12A@24VDC)
• Power: 3 Watts (Max)
1. MOUNTING AND FIBER INSTALLATION
A. Secure the mounting xture to Busbar and Connect Fiber
B. Route the ber to Low-Voltage Compartment
NAVIGATION MAP
The HSM is equipped with a simple LCD display and a set of buttons which allow for navigation as well as
basic data display and configuration as shown below.
Quick Start Guide
HSM
-;
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
I. Insert the screw with the washer through
the ring-type connector and busbar.
II. Insert the washers and secure it with a
nut. Ensure the hole for fiber insertion is
pointed in the direction of the fiber routing.
III. Insert fiber into the holding fixture and
secure it with a 1.5mm hex screwdriver.
DO NOT bend fiber tighter than
12mm (1/2”) radius
DO NOT fasten or attach ANY
mounting hardware (tie-wraps,
etc.) to at least a 30cm (12”)
length of fiber
between the
portion of the
probe at high
voltage and
its first non-
energized point
of contact.
Avoid running fibers on sharp
edges or in the direction of the
fold of the boot to minimize
bending and damage to the fiber.
Keep away from sources of
excessive heat whenever possible.
Fiber probe shall not be attached
to surfaces with temperatures
exceeding 120°C or 248°F
unless used along with the high
temperature probe (sold separately).
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
FOR MORE INFORMATION VISIT GRACESENSE.COM OR CALL 1.800.280.9517
HSM-QSG-EN 1702
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
GraceSense Hot Spot Monitoring (HSM) device
electrical equipment
Quick Start Guide
Grace Engineered Products, Inc.
1515 E. Kimberly Road
Davenport, IA 52807
R
! !
!
FOR MORE INFORMATION VISIT GRACESENSE.COM OR CALL 1.800.280.9517
2. HARDWARE INSTALLATION
A. Mount on 35 mm DIN Rail B. Insert the Fibers
Star Topology (Ethernet)
Typical Serial Topology (MODBUS RTU)
(within cabinet) or connec�ng with twisted pair cables (cabinet to cabinet)
