Grandbeing YH0101 User manual

Operating Instructions
HDMI Converter
Model No. YH0101
Operating Instructions（P/N of this Instructions is INSYH0101）
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
zEasy to Use: Install in seconds, no need for setting.
zConversion: It could convert YPbPr and SPDIF audio into complete HDMI.
zHDCP compliant.
NOTICE
and any accompanying documentation without prior written notice.
１
Vision HD reserves the right to make changes in the hardware, packaging

Operating Instructions
TABLE OF CONTENTS
Introduction
Package Contents
Panel Descriptions
Connecting and Operating
Specifications
Maintenance
Product Service
Warranty
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE:
1) DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
2) DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED.
3) TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO
OVERHEATING, DO NOT OBSTRUCT THE UNIT’S VENTILATION
OPENINGS WITH NEWSPAPERS, TABLECLOTHS, CURTAINS, AND
SIMILAR ITEMS.
4) DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS,
HEAT REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING
AMPLIFIERS) THAT PRODUCE HEAT.
5) DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
6) CLEAN THIS APPARATUS ONLY WITH DRY CLOTH.
7) UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN
UNUSED FOR LONG PERIODS OF TIME.
8) PROTECT THE POWER CORD FROM BEING WALKED ON OR PINCHED
PARTICULARLY AT PLUGS.
9) ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
10) REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL.
INTRODUCTION
input into HDMI output. YH0101 has the ability of buffering and amplifying. It
achieves long-distance transmission of HDMI signal of more than 15 meters.
YH0101 offers solutions for digital entertainment center, HDTV retail and show
site, HDTV, STB, DVD and Projector factory, noise, space and security concerns,
２
Vision HD’s YH0101 is a component video(YPbPr) converter. It converts YPbPr

Operating Instructions
data center control, information distribution, conference room presentation, school
and corporate training environments.
PACKAGE CONTENTS
1) Main unit. P/N_YH0101
2) 5V DC Power Adapter.P/N_VDC0502
3) Operating Instructions. P/N_INSYH0101
* HDMI cables are optional.
PANEL DESCRIPTIONS
Input Panel
1) YPbPr video input..
2) SPDIF audio input.
Output Panel
３

Operating Instructions
1) Power input.
2) Power indicator
3) HDMI output.
4) Test Switch.
CONNECT AND OPERATE
1) Connect the input sources into YH0101. (Input cables are optional)
2) Connect the HDMI device into the HDMI Output slot in the back of YH0101.
3) Insert the DC side of 5v power supply into YH0101 and then connect the AC
side of the power supply into the wall outlet.
MAIN FEATURES OVERVIEW
Analog Video Input Front End Interface
Triple ADC with 12 - 140 MHz Sampling Rate
Integrated line locked PLL generates pixel clock from HSYNC
Integrated 5-bit pixel clock phase adjustment for precise sample timing control
Integrated clamp with timing generator
Integrated Brightness & Contrast controls
Integrated precision voltage reference
Compatible with VGA through SXGA RGB graphics signals, and component TV,
４

Operating Instructions
DTV and HDTV
Mid-Scale Clamping
Fully Sync Processing
Black and mid-level precision clamp and calibration*
Input video mode status detection
Digital Video Input Front End Interface
ITU-R BT. 656 …… 8 bits/channel ....…………… 1 channel
RGB 444 ………….. 8/10/12 bits/channel ....…..… 1/ 3 channel
YCbCr 444 .…..…... 8/10/12 bits/ channel ….…… 1/ 3 channel
YCbCr 422 .…..…... 8/10/12 bits/ channel ….…… 1/ 2 channel
Multi-format digital input up to 200M Pixel/sec
Video data input pins re-order function
Input video mode status detection
YCbCr Color format conversion (422 to 444)
Color space conversion (YCbCr to RGB)
Inverse Gamma Correcting (De-Gamma)
Programmable Data Enable (DE) generator
Programmable Vertical Sync (VS) generator
Programmable Horizontal Sync (HS) generator
Digital Audio Input Front End Interface
I2S input interface Up to 8 channel 192k sample rate
S/PDIF input interface
IEC60958 PCM audio
IEC61937 compressed audio
Digital Data Link Engine
HDMI 1.1/1.0
HDCP 1.1/1.0 with external Key link through micro processor
DVI 1.0
Supports DTV/ HDTV resolutions : 480i/ 576i/ 480p/ 576p/ 720p/ 1080i/ 1080p
Supports video optional formats : EIA/CEA-861-B
Analog TMDS Interface
TMDS data link up to 2.0G-bit/s each channel
Including 3 data channel and 1 clock channel
DDC link base on Micro-processor (suggest 8051uP)
Hot Plug detection
TMDS Clock Channel Plug detection
SPECIFICATIONS
Operating temperature range……………….…………… -5 to +35℃(-41 to +95℉)
Operating humidity range………………………… 5 to 90 % RH (no condensation)
Power Consumption.....................…............................................. 10 Watts (max.)
Power Supply....…..................................................................................... 12VDC
Dimensions..................................…........................ 89mmW x 29mmH x 68mmD
Mass............................................…..…………..........................................0.68 Kgs
Note: Specifications are subject to change without notice. Mass and dimensions are
５

Operating Instructions
approximate.
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to
clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a) The DC power supply cord or AC adaptor has been damaged;
(b) Objects or liquids have gotten into the unit;
(c) The unit has been exposed to rain;
(d) The unit does not operate normally or exhibits a marked change in
performance;
(e) The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to
authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses
parts specified by the manufacturer or parts that have the same
characteristics as the original parts. Unauthorized substitutes may result in
fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or
length of the period indicated as below, （Parts (1) Year，Labor(90) Days）which
starts with the date of original purchase (“Limited Warranty period”), at its option
either (a) repair your product with new or refurbished parts, or (b) replace it with a
new or a refurbished product. The decision to repair or replace will be made by
the warrantor.
During the “Labor” Limited Warranty period there will be no charge for labor.
During the “Parts” warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is
extended only to the original purchaser and only covers product purchased as
new. A purchase receipt or other proof of original purchase date is required for
Limited Warranty service.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
６
workmanship, Vision HD (referred to as “the warrantor”) will, for the

Operating Instructions
preferably in the original carton. Include a letter detailing the complaint and
provide a day time phone and/or email address where you can be reached.
IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF
OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND
PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR
OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic
damage. The Limited Warranty ALSO DOES NOT COVER damages which
occurred in shipment, or failures which are caused by products not supplied
by the warrantor, or failures which result from accidents, misuse, abuse,
neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, misadjustment of consumer controls, improper maintenance,
power line surge, lightning damage, modification, or service by anyone other
than a Factory Service center or other Authorized Servicer, or damage that is
attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF
THIS WARRANTY. (As examples, this excludes damages for lost time, cost
of having someone remove or re-install an installed unit if applicable, travel to
and from the servicer, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration
only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
Customer Services Directory
