Grandbeing MX0404-330 User manual

Model No.: MX0404-330
Operating Instructions
Thanks for purchasing our product.
Please be sure to read this instruction manual
carefully before using our product.

Introduction
Grandbeing’s MX0404-330 is a 4-by-4 DVI/HDMI true matrix. It allows any
source (Blue-Ray player, HD DVD player, satellite receiver, game system, etc.)
to be shown on the any of the four displays simultaneously, no matter the
source is HDCP or not. Extra infrared receiver extension, IR emitter are
supplied for the control.
MX0404-330 has the ability of equalization and amplification to ensure HDMI
signal's transmission through long cable without quality loss.
MX0404-330 offers solutions for digital entertainment center, HDTV retail and
show site, HDTV, STB, DVD and projector factory, noise, space and security
concerns, data center control, information distribution, conference room
presentation, school and corporate training environments.

Contents
HDMI Matrix..................................................................................................... 1
Product Overview ............................................................................................ 1
Features........................................................................................................... 1
Package Contents............................................................................................ 3
Panel Descriptions........................................................................................... 3
Connections and Operations ...........................................................................4
SPECIFICATIONS ........................................................................................... 7
Typical Application ........................................................................................... 8
Maintenance .................................................................................................... 9
Product Service ............................................................................................... 9
●Provided Service .......................................................................................... 9
●Mail-In Service.............................................................................................. 9
●Warranty ..................................................................................................... 10
●Warranty Limits And Exclusions.................................................................. 10

Page 1
HDMI Matrix (Router Type)
■Product Overview ( Model Number: MX0404-330 )
■Features
zEasy to use: install in seconds.
zAllows up to four HDMI audio/video devices to be independently switched
to four HDMI monitors, HDTV’s, or projectors.
zThe four outputs could show the same or different source simultaneously
no matter the source is HDCP or not.
zSupport high definition resolutions 1080p, 1080i, 720p and other standard
video formats.
zEach port supports HDMI or DVI inputs.
zWith extra infrared receiver extension.
zTwo switching modes: panel buttons, local IR.
zHDCP compliant.
zHDMI 1.4 version.
"Notice
Grandbeing Inc. reserves the right to make changes in the hardware,
packaging and any accompanying documentation without prior written notice.

Page 2
Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
p
lu
g
s.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.

Page 3
■Package Contents
①Main unit. P/N_MX0404-330.
②5VDC Power Supply.P/N_VDC0504.
③ 1x Remote (Battery type: CR2025 3V).
④ 4x IR_RX (IR receiver) extension cable.
⑤ 4x IR_TX (IR emitter) extension cable.
⑥4x IR_RX cable extender jack pair. (Refer to page 8).
⑦ Operating Instructions. P/N_INS MX0404-330.
⑧ 2x Mounting Ear.
NOTE: PART NUMBER (Abbreviation as P/N).
■Panel Descriptions
Front Panel
① Output selection and indicator of input for output port 1 to 4.
② IR window.
③ Key lock button.
④ Indicator of locking status, when the output selection buttons are locked,
LED inside lit.
⑤ Power switch.
⑥ IR TX OUTPUT 1 to 4.
⑦ USB port for ISP.
⑧ DIP switch.

Page 4
Back Panel
① Power input.
② IR extension 1to 4.
③ Output 1 and 2 with HDMI.
④ Input ports 1 to 4 with HDMI.
⑤ Output 3 and 4 with HDMI.
NOTE: RS232 port and LAN port are for matrix control. The LAN port is connected to
the computer via direct UTP and connected to the router via cross UTP.
■Connections and Operations
1) Connect the HDMI input sources (such as HD-DVD, PS3, STB etc) into
MX0404-330.
2) Connect the HDMI outputs (such as HD-LCD, HD-DLP) into MX0404-330.
3) Connect the IR RX receiving cable into MX0404-330IR extension and
connect the IR TX cable into MX0404-330IR emitter.
4) Power on the input source you want to show. (Keep the unused input power
off, otherwise it may interfere the normal display.)
5) Connect the power supply into MX0404-330 and turn on the display you
want to watch.
6) Use remote or push the button to choose input source. Extra infrared
receiver extensions, IR emitter, are supplied for remote control.
7) The IR signal of any IR extension will through "TX IR" port to send the signal
out.
8) Source - Sink Auto fit Function

Page 5
This function applies to the situation when the source's HDMI version exceeds
the sink's HDMI version. (This function can be used to fix the deep color, 1080P, 1080i, 2ch
audio, multi channel audio issue.)
For example:
When the TV is HDMI 1.2 version and PS3 source is HDMI 1.4 version, it will
output HDMI 1.2 version.
(1) Under default mode, this machine will output 1.2 version HDMI signal (1080P
and stereo audio).
(2) Under button mode.
There are two modes to update the EDID data according to the DIP setting.
When the DIP is in default mode (0, 0, 0), the matrix will be in mix mode.
A、When the source is HDMI1.4, (e.g., HDMI output from PS3), OUTPUT1 to 4
both support HDMI1.4 displays, press “selection of OUTPUT1” and “lock key"
simultaneously, the machine will output HDMI1.4 signals.
B、When the source is HDMI1.4, (e.g., the HDMI output from PS3), OUTPUT 1 to
4 are connected to the displays that can only support HDMI 1.2 MAX, press
"selection of OUTPUT1" and "lock key" simultaneously (no matter whether
HDMI OUTPUT port is connected to the display that supports HDMI 1.4 or not), it
will output HDMI 1.2 signals.
When the DIP is in default mode (0, 0, 0), the matrix will be in copy mode.
Note: The method to reset the machine to default EDID setting: Disconnect the input and
output. Please press "selection of OUTPUT1” and “lock key" Simultaneously for at least 3
seconds, and EDID of all the four input ports will be reset to the default setting. The audio
setting of the default EDID is stereo. It is suitable for TV sets.

Page 6
9) DIP switch setting
Position ID
1 2 3 Mix the low version EDID.(default) (note 1)
0 0 0 reserved
0 0 1 reserved
0 1 0 reserved
0 1 1 Copy the EDID of the display which connected the
OUTPUT1(note 2)
1 0 0 reserved
1 0 1 reserved
1 1 0 reserved
1 1 1 reserved
Note1: The matrix will mix the EDID data of the sink devices. The mixed EDID data will
use the lowest resolution of the video and the least channel number of the audio. For
example, some sink device support 1080P, some sink device only support 1080i, some
support 5.1 audio, but some only support stereo. Then the mixed EDID will be 1080i and
stereo.
Note2: If user wants to just use one sink device’s EDID data, this DIP setting can be
used.
Attention: Please insert or extract cables gently.

Page 7
■SPECIFICATIONS
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Signaling Rate 2.25Gbit/s
Video Format Supported
DTV/HDTV:
1080p/1080i/720p/576p/480p/576i/480i
Audio Format Supported DTS-HD、Dolby trued
Output Video HDMI1.2 and HDMI 1.4
Maximum Transmission Distance <15m (If needed, HDMI extender is
optional)
Power Consumption 12wtts (Max.)
Dimensions
300mmL×96mmW×26mmH
/11.8''L×3.8''W×1''H
Mass (Main Unit) 0.7kg/4.4lb
Note: Specifications are subject to change without notice. Mass and dimensions are
approximate.
IR receiver cable extender jacks.
When the display device is not near to the matrix, the IR_RX cable will be too
short. There is pair of jacks to extend the IR_RX cable. Customer or installer
can use the headphone cable or 4-line telephone cable to form the IR cable
extender.
