Grandstream Networks GXV3601 User manual

For Warranty and RMA information, please visit www.grandstream.com
GXV 3601
IP CAMERA
QuickStart
Guide
http://ArtTel.ru

PRECAUTIONS
PACKAGE CONTENTS
Power Adapter
QUICKSTART GUIDE
12V
1
• Do not attempt to open, disassemble, or modify
the device
• Do not use a third party power adapter
• Do not expose this device to temperatures outside
the range of -10 C to +55 C
• Do not expose the GXV3601 to environments
outside of the following humidity range: 10-90% RH
(non-condensing)
Green Wire Cramper
GXV3601
EN
o o
http://ArtTel.ru

CONNECTING THE GXV3601
2
Refer to the illustration below when following the
instructions on the next page.
NOTE: Choose Option A if using the power supply. Or choose
Option B if using a Power over Ethernet (PoE) switch.
Option B: RJ45 Ethernet
cable to Power over
Ethernet(PoE) switch
Power Port
Network
Port
12V
Option A:
Power Adapter
To AC Outlet
http://ArtTel.ru

Option A
Step 1: Insert the power adapter into the 12V DC
port on the GXV3601. Plug the other end of
the adapter into an AC power outlet.
Step 2: Plug an RJ45 Ethernet cable into the network
port. Plug the other into a hub, switch or
router.
Option B
Step 1: Plug an RJ45 Ethernet cable into the network
port. Plug the other end into a Power over
Ethernet (PoE) switch.
3
http://ArtTel.ru

4
GXV3601 CONFIGURATION
Step 1: Connect your PC and the GXV3601 to the
same network.
Step 2: Set the IP address of your PC to
192.168.1.X. Set the Default Gateway of
your PC to 255.255.255.0.
Conguring the GXV3601 using Microsoft
Internet Explorer
http://ArtTel.ru

5
Step 3: Open Microsoft Internet Explorer on your PC.
Type 192.168.1.168 in the address bar.
Step 4: A pop-up window will appear with prompts
for a user name and password. The default
administrator user name and password are
both set to “admin” at the default factory
conguration.
http://ArtTel.ru

Step 5: Once you log into the GXV3601’s web inter-
face Internet Explorer will indicate that
“This website wants to install to following
add-on: ‘GSViewer.cab’ from Grandstream
Networks, Inc.” Install this add-on by follow-
ing the instructions.
6
Step 6: Once the installation of GSViewX.cab
completes you will see the web page shown
in the screenshot on the next page. Click
the play button to view the video feed.
http://ArtTel.ru

Please download the user manual and FAQ for more
detailed conguration instructions:
http://www.grandstream.com/support/gxv_series_sur-
veillance/gxv3601/documents/gxv3601_usermanual_
english.pdf
Step 7: Click through the menu on the left hand side
of the web UI for more advanced congura-
tion parameters.
7
http://ArtTel.ru

GXV3601 SAMPLE CONNECTION
DIAGRAM
8
http://ArtTel.ru

ES
GXV3601 LENS SPECIFICATIONS
Lens Specications
Lens Mount CS
Lens Format
(Image Sensor Area)
1/3”
Focal Length Variable forcus
3.5 to 8 mm
Aperture (D/f’) 1/1.4
View Angle 81 (Horizontal)
IRIS DC
Minimum Object Distance 0.20 m (0.65 ft)
Size
(Diameter X Length1 X Length2)
36 X 52 X 52 mm
(1.42 X 2.05 X 2.05 in)
Operation Focus (w/lock)
Zoom (w/lock)
Weight 95 g (3.35 oz)
9
