Granit BE 150 User manual

Operating Instructions
LED-Headlamp BE 150
12100852
These operating instructions must be read thoroughly before use and followed carefully.
Please retain these operating instructions for future reference.
Translation of the original operating instructions.

Operating Instructions
12100852
2
Table of contents
About these operating instructions and symbol descriptions ...................................... 3
Safety and accident prevention regulations............................................................. 3
Technical specifi cations ....................................................................................... 3
Operating and loading instructions......................................................................... 4
Safety instructions............................................................................................... 5
EU-Declaration of Conformity................................................................................ 6
UKCA-Declaration of Conformity............................................................................ 7
Disposal ............................................................................................................. 8
Warranty............................................................................................................ 8
Adresses ............................................................................................................ 8
Legal notice ........................................................................................................ 8

Operating Instructions
12100852
3
About these operating instructions and symbol
descriptions
Incorrect operation may lead to serious injury or death.
Incorrect operation or negligence may result in personal injury,
cause damage to the device or incorrect measurement results.
Advice and tips for operation.
Numbers in the fi gures (1, 2, 3 ...) refer to the corresponding numbers in brackets
(1), (2), (3) ... in the text next to the item numbers in the tables.
Instructions, for which the order must be followed, are numbered (1, 2, 3, ...).
Lists are marked with bullet points (•, •, ...).
Safety and accident prevention regulations
Do not open the device.
Do not look directly into the light - risk of eye injury!
Do not operate in direct sunlight or in extreme temperatures.
The working temperature is between -10°C and +40°C
Keep away from children! Do not let children play with the device. Use only under
supervision.
Technical specifications
Light source
High-performance COB LED
Lighting Power
ca. 200 (±5%) lm –Normal Mode Full Power
ca. 100 (±5%) lm –Normal Mode ECO
ca. 200 (±5%) lm –Sensor Mode
Use period
ca. 2 h (±15min) ‒Full Power Mode
Ca. 4 h (±40min) –ECO Mode
ca. 2h (±15min) ‒Sensor Mode
Battery Specification
Li-Po 3.7 V, 600 mAh, 2.22Wh
Charging time
ca. 2.5 h (±30min)
Charging input
DC 5V 1A
Protection class
IP 65, IK 07
Operation temperature
‒10 °C bis + 40 °C

Operating Instructions
12100852
4
Operating and loading instructions
Operating instructions Normal mode
Press the Main Switch first time, main light switch to ECO mode
Press the Main Switch second time, main light switch to full power mode
Press the Main Switch third time, whole light switch off
Operating instructions Sensor Mode:
Press the Main switch for a while, main light switch to Sensor mode, you can switch on
or off by waving your hand in front of the light (Sensor distance 0~10±3cm)
Press the Main Switch second time, Sensor mode off and turn to normal mode
Loading instructions
Switch lamp off during charging.
The LED of the indicator switches to green blink during charging.
If charging is completed, green LED illuminate will keep on.
Always only use the charger recommended to charge the lamp. The use
of a NON-recommended charger can lead to a fire and destroy the lamp.
Before taking the hand lamp into service for the first time charge it for 4-5 hours.
Fully charge the hand lamp before it is stored for a longer period.

Operating Instructions
12100852
5
Safety instructions
Do not use the device if there is damage to the housing, plug or cable. If this is the case,
contact your authorized specialist!
Do not open the device!
Repairs or replacement of the battery should only be carried out by a trained specialist.
Only clean the device once the main plug has been disconnected from the power supply.
There is a risk that damage caused by dropping the device could lead to the battery
overheating and self-igniting.
There is a risk of a short-circuit. Repairs to the device should only be carried out by a
trained specialist. In this case, contact your nearest approved dealer.
Protect the battery against heat, continuous and intensive exposure to the sun, fire, water
and moisture. Risk of explosion!
If the battery is damaged or not used correctly, liquids can leak out of
the battery. Avoid touching any liquids. Leaking battery liquids can cause
skin irritation or burns. Rinse your skin off with water if you should come
into contact with battery liquids. Should the battery liquid enter your
eye, it is essential that you seek medical advice.
There is a risk that damage caused by dropping the device could lead to
the battery overheating and self-igniting.
The lamp must not be placed on the light surface while in operation.

Operating Instructions
12100852
6
EU-Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Hereby declares its sole responsibility that the LED-Headlamp BE 150
type/series identification: 12100852
conform to the provisions of the
2014/30/EU Electromagnetic Compatibility Directive (EMC Directive)
2011/65/EU Restriction of the Use of Certain Hazardous Substances in
Electronic and Electrical Equipment (RoHS) ((EU) 2015/863).
The product has been developed in accordance with the following standards:
EN IEC 55015:2019+All
EN 61547:2009
Authorised documentation representative:
Herr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Heeslingen, 16.06.2023
Translation of the original Conformity Declaration
________________________________________
Holger Wachholtz, Executive Board

Operating Instructions
12100852
7
UKCA-Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Hereby declares its sole responsibility that the LED-Headlamp BE 150
type/series identification: 12100852
conform to the provisions of the
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
The product has been developed in accordance with the following standards:
EN IEC 55015:2019+All
EN 61547:2009
Authorised documentation representative:
Herr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Heeslingen, 16.06.2023
Original UKCA Conformity Declaration
________________________________________
Holger Wachholtz, Executive Board

Operating Instructions
12100852
8
Disposal
If a product is marked with the symbol of a dustbin with a cross through it, this indicates
that the product must not be disposed of with the household waste. In the case of
batteries or rechargeable batteries containing mercury (Hg), cadmium (Cd) or lead (Pb),
the chemical symbol is shown under the crossed-out dustbin symbol. The end user has
an obligation to return the batteries or rechargeable batteries. These can be returned
free of charge to the retailer or handed in at any collection point. Electronic devices
and rechargeable batteries should be handed in separately from each other. Make sure
that the batteries or rechargeable batteries are in a discharged state or protected from
short-circuiting, if applicable. When purchasing products, try to ensure that the products
have a long service life to minimise the amount of waste produced. If your electric or
electronic device contains personal data, you are responsible for erasing it.
Because of the substances they contain, improper disposal of batteries or rechargeable
batteries can harm the environment and human health. Special care should be taken
when handling batteries containing lithium. Products should be checked to see if they
can be re-used, for example by being repaired, before you dispose of them.
!!! Always observe local waste disposal regulations!!!
Warranty
The warranty conditions of Wilhelm Fricke SE apply; these can be found in the sales
documents and the current version of the General Terms and Conditions.
In case of questions, please contact the company’s customer service department.
Adresses
Sales/Customer Service Department/ Tel.: [phone]
Spare parts sales: Fax: [phone]
Postal and delivery address: Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Legal notice
Translation of the original operating instructions for the LED-Headlamp BE 150
Manufacturer: Wilhelm Fricke SE - DE-27404 Heeslingen
1st edition June 2023
©2023 Wilhelm Fricke SE
Reproduction in whole or in part is prohibited without the written consent of the company Wilhelm Fricke SE.
All product names mentioned in these operating instructions are trademarks of their respective companies
Printed on paper made from chlorine- and acid-free bleached pulp.
