GRAPHTEC Data Platform GL7000 User manual

Das empfohlene Schrauben-
Anzugsdrehmoment beträgt:
0,39 Nm.
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
1
2
Alarm moduleAlarm module
Connector
Nail
During installation, a
4kgf.cm screw tightening
torque is recommended.
GND terminalGND terminal
Grounding
Equipment to
be measured
GL7-HSV-UM-151
BNC Connector BNC Cable
2 How to Install Module
This explains how to attach the module to the main module.
When installing or removing the module, please
make sure that the power is off.
Slide it in the direction of the
arrow. If you pry it at an angle
there is a risk of damaging the
connector.
1, Remove the fixation screws (4 places on the upper part and
lower parts), place the alarm module parallel to the main
module and slide it in the direction of the arrow.
(1) Remove the fixation screws from
the 2 places on the lower part.
(2) Loosen the drop-off prevention
screws on the upper part in 2
places.
(3) Removing the alarm module.
GL7000
High Speed Voltage Module
GL7-HSV
Explanation of the module's part names and functions.
Connector for connecting all kinds of modules.
Fixation screw for the adjoining module.
To prevent drop off, do not remove from
the module.
The Power LED will light up green when
the power has been turned on and the
module has been recognized.
Fixation screw for the adjoining module.
Terminal for inputting analog measurements.
1, Module connector
2, Module fixation screw (Upper part)
3, Power LED
4, Module fixation screw (Lower part) 5, Analog signal input terminal
1, Module connector..............
2, Module fixation screw.......
(Upper part)
3, Power LED..........................
4, Module fixation screw.......
(Lower part)
5,
Analog signal input terminal ..
2, Remove the high speed voltage module's fixation screws
(2 places on the lower part).
Slide it in the direction of the
arrow.
Inserting it at an angle may cause
damage to the nails.
3, Slide the high speed voltage module parallel to the main
module and connect the connector.
5, Similarly, install the alarm module on the last part and fix it with
screws.
4, Fix the high speed voltage module and the main module in
place with the screws. (4 places on the upper and lower parts)
3 How to Connect to Analog Signal Terminal
High-voltage terminal (Terminal
for inputting the high-voltage side
of the input signal)
Low voltage terminal (Terminal
for inputting the low-voltage side of
the input signal)
+:
- :
During wiring, confirm that the
signal's supply source is turned OFF
to prevent electrical shocks.
This explains how to connect the input cable.
+
-
Voltage input
4 Regarding Maximum Input Voltage
To avoid break-downs or short-circuiting accidents, please
make sure to abide by the items written below.
Maximum input voltage
In case the input voltage exceeds the specifications, the
circuit at the input part will break down so even if the input
voltage exceeds the specifications only for an instant, please
don't input.
Please take care that no static electricity is applied on the
analog signal input terminal.
<Input terminal +/- terminal interval (A etc. on the figure below)>
Maximum input voltage : 100 mV to 1 V range 60Vp-p
: 2 V to 100 V range 100Vp-p
<Input terminal (-)/Input terminal (-) interval (B etc. on the figure below)>
Maximum input voltage: 60Vp-p
Withstand voltage: 1000Vp-p/1minute
<Input terminal (-)/GND terminal interval C etc. on the figure below)>
Maximum input voltage: 60Vp-p
Withstand voltage: 1000Vp-p/1 minute
5 Noise Countermeasures
Make absolutely sure to ground the chassis GND
of the measuring object
Absolutely making sure to ground the chassis GND of the
measuring object to a favorable ground may have an effect.
Connecting the chassis GNDs of the measuring
object and the instrument
Connecting the chassis GND of the measuring object and
the GND terminal of the main module with an electrical
cable as short and thick as possible, and further gaining
potential equalization by grounding it may have an effect.
Using the filter function of the instrument
Setting the filter to anything but OFF on the main body's
input settings menu.
(Screen for when the optional
display module is connected)
In case the measured values fluctuate due to exogenous
noise, the following measures are recommended.
(Depending on the type of noise, the result may change.)
GL7-V (High Speed Voltage Module) specifications
Item
Input ch number
Input terminal shape
System
Sampling interval
Built-in RAM
Measurement range
Measurement accuracy

A/D converter
Temperature coefficient
Input resistance
Input signal source
resistance
Maximum input
voltage
Withstand voltage
Insulation resistance
Common mode rejection
S/N (Noise)
Frequency response
Filter
External dimensions
[W×D×H] (approximate)
Weight
Contents
4 ch/1 module
BNC Connector
All ch insulation, simultaneous sampling, unbalanced input
1, 2, 5, 10, 20, 50, 100, 200, 500 nusec,
1, 2, 5, 10, 20, 50, 100, 125, 200, 250, 500 msec,
1, 2, 5, 10, 20, 30 sec , 1, 2, 5, 10, 20, 30 min , 1hour
2,000,000 data
100, 200, 500 mV, 1, 2, 5, 10, 20, 50, 100 V, 1-5 V F.S.

* At least 30 minutes after turning on the power, sampling
1 sec, Filter Line, GND connection
System: sequential comparison system





Input terminal +/- interval : 100 mv to 1 V range 60 vp-p
: 2 V to 100 V range 100 Vp-p
Input terminal (-)/(-) interval: 60 Vp-p
Input terminal (-)/GND interval: 60 Vp-p
Input terminal (-)/(-) interval: 1000 Vp-p/1 minute
Input terminal (-)/GND interval: 1000 Vp-p/1 minute


48 db or more (+/- at short)
DC to 200 k Hz (-3dB)
LPF : OFF, Line (1.5 Hz), 5 Hz, 50 Hz, 500 Hz
(Attenuation) - dB ( - 5.2 dB to - 1.4dB) /6 dB oct
49.2 ×136 ×160 mm (not including protruding parts)
740g
6 Specifications
USER’S MANUAL
Thank you very much for buying this GRAPHTEC product.
This item is a standalone measuring module. Please use it by
installing it on the main module.
These directions describe preparations and cautions before
measurement.
For safe use, please make sure to read “4 Regarding
Maximum Input Voltage”
For the details concerning operation procedures etc., read
the User’s manual recorded on the CD-ROM (included with
the main module)
Confirmation of the exterior
After opening the package, please confirm that there are no
problems (scratches and dirt) on the exterior before use.
Confirmation of the attached items.
User’s manual (this book): 1
If by any chance faults are found, please contact the store where you
bought the item.
* Please note that items mentioned in this book may change without
prior notice.
For details, please refer to the User’s manual recorded on the CD-ROM (included with the main module)
GRAPHTEC Corporation July 1, 2012
