Gree GWH09KF-A3DNB1A User manual

QUICK-START GUIDE
INDOOR UNIT FRONT PANEL DISPLAY: Look here for LED display of system
status, setpoint, indoor and outdoor temperatures and malfunction codes.
HIGH-WALL DUCTLESS
AIR CONDITIONING &
HEATING SYSTEM
Models:
GWH09KF-A3DNB1A,GWH12KF-A3DNB1A
GWH09KF-D3DNB1C,GWH12KF-D3DNB1C
GWH18KG-D3DNB1C,GWH24KG-D3DNB1A
NOTE: Ple se re d the complete owner’s m nu l
c refully before oper tion.
Press to power the unit on or off.
Press to select and adjust each mode.
Press to control vertical angle of louvers and to redirect airflow.
Press to boost cooling or heating capacity.
uickest way to reach preset temperature.
Press to select fan speed (Auto, Low, Medium or High.)
Auto is default.
Press to raise or lower settings including temperature and time.
Press once for slow adjustment, hold down for fast adjustment.
Press to select one of three SLEEP modes, each offering
varying levels of comfort control while sleeping.
See Owner's Manual for more details.
Press to start or stop the timer. (Adjust with “+”and“–” buttons.)
See Owner's Manual for more details.
Press to run fan after cooling cycle to dry off coil and help
inhibit growth of bacteria and mildew.
Press to turn on lights on the unit’s Front Panel Display.
Press again to turn off.
Press to set desired room temperature.
(Adjust with “+” and “-” buttons.)
: AUTO
: COOL
: DRY
:
FAN ONLY
: HEAT
ON/OFF
TURBO
FAN
SLEEP
TIMER
_
+
X-FAN
LIGHT
TEMP
MODE

DEFROST FUNCTION
This increases room comfort and saves energy by sensing the need for defrosting and eliminating unnecessary defrost cycles.
SLEEP MODE
You design a cycle to automatically adjust room temperatures during your sleep time, to maximize comfort and reduce utility bills.
TURBO MODE
This capacity boost function is the fastest way to reach a desired temperature setpoint, either in heating or cooling. Once setpoint is achieved,
you can deactivate Turbo Mode for normal operation.
X-FAN MODE
Especially useful in humid areas, this function allows the indoor fan to run for a pre-determined amount of time after the unit is turned off,
to remove additional moisture from the coil.
PRIVACY LOCK MODE
This prevents unauthorized access or tampering. To lock the remote controller, push the "+" and "-" buttons simultaneously for 2 seconds.
Repeat to unlock.
OPTIONAL PHOTOCATALYTIC FILTER
Advanced technology to improve indoor air quality and prevent the spread of bacteria and viruses.
KEY FEATURES & FUNCTIONS
FAQs
Why does the f n continue to run even when the unit is not cooling or he ting?
To maintain consistent temperatures and minimize energy-loss from constant starts and stops, the fan keeps air flowing past the thermostat.
Wh t temper ture is displ yed on the remote controller?
The remote always displays your desired indoor temperature. (You may view current indoor and outdoor temperatures on the indoor unit’s
Front Panel Display.)
Wh t h ppens if the remote is lost or d m ged?
Use the Manual Override button to manually operate the unit. Lift up the front panel section on the indoor unit and locate the button
on the right-hand side. Press the button to turn ON the unit. (Not all functions will be available.) Press again to cancel Manual Override Mode
and transfer control back to the remote controller.
Not all features available on all models. Your actual air conditioning and heating system and related devices may differ from the images shown in this manual.
Specifications are subject to change without notice. Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. ©2013. All rights reserved.
For complete instructions on these and other functions,
as well as important safety information, see the Owners Manual.
For more inform tion, visit GreeComfort.com.
