Green Power PS700 User manual

GREEN POWER PS700 Portable Power Station
USER MANUAL
3.0 12V1.5A
AC OUTPUT 100-120V
3.0 12V1.5A
PD 30W
PD 100W IN/OUT
USB ON/OFFDC ON/OFF
12V DC/10A
12-28V DC/8A
INPUT/MPPT
Sine - Wave Sine - Wave
AC OUTPUT 100-120V
AC ON/OFF
POWER ON/OFF

1.SAFETY GUIDELINES
2.PRODUCT INTRODUCTIONS
3.SPECIFICATIONS
4.PRODUCT USAGE STATEMENT
4.1 POWER ON/OFF
4.2 AC OUTPUT PORT
4.3 12V DC OUTPUT PORT
4.4 USB OUTPUT PORT
4.5 AC CHARGING
4.6 SOLAR CHARING
4.7 CAR CHARGING
5.FAQS
6.PACKAGE CONTENT
7.MAINTENANCE
8.RECYCLING
9.ERROR CODE
1
2
4
5
5
5
6
6
6
7
7
8
9
9
9
CONTENT
10

Please read these safety guidelines before using your new green power PS700
· Do not immerse the product in water or get it wet. Do not use the product in rain
or damp environments.
· Avoid using or storing the product near any heat source, and strictly follow the
operating environment temperature specified in this user manual.
· Do not pierce the product with sharp objects or strip down the product in any way.
· Do not insert fingers or other objects into vents or outlets of the product.
• Only use officially recommended components or accessories for charging efficiency
and safety.
• Do not use theproduct with wires or charger cable that exhibit any damages or cracks.
• Do not attempt to modify or alter the wires and accessories of the product.
• Do not use the product in flammable liquid, gas, or dust environments.
• Do not drop or place any heavy objects on the product.
• When using or storing the product, please avoid impact, press, falls, or strenuous
vibrations. If the product is seriously impacted by external force, turn it off
immediately and stop using it.
• For better performance, fully charge the product before using it.
• Please kindly keep this product out of reach from children and pets.
01
1.SAFETY GUIDELINES
Caution: Please do not use this product to charge devices that exceed 700W.

2.PRODUCT INTRODUCTIONS
Input & Output Ports
LCD
Screen Car Port
DC Output
12v
DC
Input
USB-C 100W
In/Out USB-C
30W
USB-A
QC 3.0
LED Light
LED Light
Button
02
Main Power
Button
AC Power
Button
DC Power
Button
USB Power
Button
110V
AC Output

03
LCD Screen:
Output Power
Indicator
Exclamation
Mark Icon
Low-temperature
Alarm
Fault Warning
High-temperature
Alarm
Battery Percentage
Fan Light
Charging
DC Output
Indicator
Wireless
Charging
Ac Frequency
Indicator
USB/PD
Battery
Input Power
Indicator
Wireless Charging
%
W
INPUT
OUTPUT
W
60HZ

3.SPECIFICATIONS
GENERAL INFO
Net weight 19.8 lbs (9kg)
Dimensions 11*7.9*9in (28*20*23cm)
Capacity 716Wh(22.4V, 32Ah)
Certification UL Standard, FCC, PSE, CP65, RoHS, MSDS, UN38.3
INPUT PORTS
Adapter Charger 25V⎓8A
Car Charger Supports 12V/24V Battery, 6A
Solar Panels 200W MPPT
USB-C PD Input 5/9/12/15V⎓3A 20V⎓5A
OUTPUT PORTS
AC(×4) Pure Sine Wave, 700W , 110V~(60Hz)
USB-A Fast Charge(×2) 5V⎓3A 9V⎓2A 12V⎓1.5A 18W Max, per port
USB-C(×2) 5/9V⎓3A 12V⎓2.5A 15V⎓2A 33W Max
Wireless Charge(×2) 25W Max
Car Charge(×1) 12V⎓10A, 120W Max
04
5/9/12/15V⎓3A 20V⎓5A 100W Max
DC5525 Output(×2) 12V⎓10A, 120W Max, per port
LED Lighting 3W, 4Modes(High Light/Low Light/SOS/Flash)
BATTERY INFO
Cell Chemistry LiFePO4 Battery
Warranty 2 year (after a full charge)
Cycle Life Keep 80% capacity after 2000 standard cycles at 25±2℃
Protection Over VoltageProtection, Overload Protection,
Over Temperature Protection, Short Circuit Protection,
Over Current Protection, Low Temperature Protection,
Low Voltage Protection
ENVIRONMENTAL OPERATING TEMPERATURE
Optimal Operating Temperature 50°F-68°F(10℃~20℃)
Discharge Temperature 14°F-104°F(-10℃~40℃)
Charge Temperature 41°F-104°F(5℃~40℃)
Storage Temperature -4°F-104°F(-20℃~40℃)
※ Car charger shares power with the DC5525 output port, offering a maximum output of 120W

4.PRODUCT USAGE STATEMENT
05
GREEN POWER PS700 works like an oversized rechargeable battery. Like any other
rechargeable batteries, you must first power the battery before you can use it to
charge electronic devices. When your GREEN POWER PS700 has run out of power,
it will need to be recharged before you can use it again.
4.1 POWER ON/OFF
1. Short press the Main Power Button to turn on the product; the LCD Screen will
light up and the Remaining Battery Percentage icon will display.
2. To power off the product, press and hold the Main Power Button.
Caution: If the product has no operation for 5 minutes, it will enter sleep mode
and the LCD Screen will automatically turn off. To turn the LCD Screen on or off,
please short press the Main Power Button.
4.2 AC OUTPUT PORT
1. With the Main Power Button turned on, short press the AC Power Button to use the
AC Output ports.
2. Insert the power cable of the device into the AC Output ports, and total AC power
output will display on the LCD Screen.
3. Short press the AC Power Button again to turn it off when not in use to save power
consumption.
Caution: The maximum AC output power of PS700 is 110V/60Hz 700W. If the power
requirement of the device exceeds 700W, please do not connect the device to the
product.
The default standby time of the AC Output port is 12 hours. Without any load access
for 12 hours, the AC Power Button will automatically turn off.
Press to Turn On/Off
Short Press AC
Power Button

06
4.3 12V DC OUTPUT PORT
1. With the Main Power Button turned on,
short press the DC Power Button to use
the 12V DC Output ports.
2.Insert the power cable of the device into
the 12V DC Output ports, and total DC
power output will display on the LCD
Screen.
3.Short press the DC Power Button again
to turn it off.
4.5 AC CHARGING
1. First, connect the supplied AC Adapter to a standard 120V AC socket.
2. Connect the AC Adapter with the DC Input Port on the front of PS700.
3. On the LCD screen, you can see the charging status and current power.
Disconnect the AC adapter until it is fully charged.
4.4 USB OUTPUT PORT
1. With the Main Power Button turned on,
short press the USB Power Button to use
the USB Output ports,and Wireless Charging.
2.Insert the power cable of the device into
the USB Output ports and total USB
power output will display on the LCD
Screen.
3.Short press the USB Power Button again
to turn it off when not in use to save
power consumption.
AC Charging
Cable
Short Press DC Power Button
Short Press USB Power Button
Caution: You can speed up rechargeability of the power station through the AC
adapator and 100W PD USB-C port simultaneously. It takes only 2 hours to
recharge 80% battery of the power station by this way.
Caution: With the DC Power Button on, the
product will not automatically shut down.
Caution: With the USB Power Button on, the
product will not automatically shut down.

07
4.6 SOLAR CHARING
1. First, open the Ample 200 and place it in direct sunlight.
2. Connect the MC4 interface of Ample 200 with the DC InputPort of PS700 through
the Solar Charging Cable as shown in the figure.
3. On the LCD screen, you can see the charging status and current power. You may
need around 6 hours of direct sunlight to fully charge PS700 when using Ample200
（Depending on Weather）.
4.7 CAR CHARGING
1. First, start the car and connect the supplied Car Charging Cable to the car
charging port.
2. Connect the Car Charging Cable with the DC Input Port on the front of PS700.
3. On the LCD screen, you can see the charging status and current power. It
supports 24V Max car chargers and an 6A Max charging current to quickly meet your
electricity needs while on the road.
Caution: Please charge using the car charger after you’ve started the car to avoid
failure to start due to insufficient car battery.
Car Charging Cable
MC4
Solar Charging
Cable

08
Q1: What battery does the product use?
A: PS700 uses premium LiFePO4 battery, which offers the power station more than
2000 cycles.
Q2: How to know the working times for my device? Why does the duration of
some devices deviate from the actual usage data?
A: The actual working time = 716Wh * 0.9 / operating power of your device. The
duration of our equipment is based on laboratory data, and the duration of
specific equipment usage may vary under different situations.
Q3: Does PS700 include a built-in MPPT controller?
A: Yes, PS700 has a built-in MPPT controller.
Q4: To fully recharge the power station, how long does it need?
A:
Note: The actual charging time by solar depends on the weather, solar condition, and
the angle of the solar panels
Q5: How long can the product charge my devices?
A: The charging time is shown on PS700 LCD Screen, which can be used to
estimate the charging time of most appliances with stable power usage.
Q6: What devices can this PS700 support?
A: PS700 can support devices that operate at less than total 700W.
Q7: Can I use the power station to run other equipment while it is charging?
A: No, it will cut off all output ports automatically to protect the battery while it is
charging.
Q8: How can I know if the product is charging?
A: When it’s charging, the remaining battery percentage and the input power will
be shown on the LCD Screen.
5.FAQS
There are 4 ways to recharge the power station: about 3 hours by using an AC
wall adapter (include); about 7 hours by using an PD adapter (not include); about
6 hours from Ample 200 (depending on weather, not include); about 5 hours by
using the car charger (include).
