GreenMachine GMSB6200-SS User manual

62V CORDLESS
SNOW BLOWER
Operator’s Manual
Model: #GMSB6200-SS
To reduce the risk of injury, the user must read and understand the
operator’s manual before using this product. Save these instructions for future
reference.
TOLL-FREE HELPLINE: [phone]
WARNING:

Safety Alert
Read the Owner’s
Manual
Do Not Expose to Rain
or Damp Conditions
Use Protective Gear
Recycle symbols
Auger Warning
Unclogging Warning
Precautions that involve your safety.
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER
Section 1 General Safety Rules......................... 3
Section 2 Parts Diagram................................
..............................
...................................
.....................................
....................................
....................
..............................
...................
10
Section 3 Technical Details 11
Section 4 Unpacking 12
Section 5 Assembly 13
Section 6 Operation 14
Section 7 Maintenance and Cleaning 20
Section 8 Troubleshooting 24
Section 9 Limited Warranty Coverage 26
CONTENTS
SYMBOLS MARKED ON THE PRODUCT
GENERAL SAFETY RULES
1
The following symbols may appear on your device before, during, or after use. Take the
time to read over and understand the meaning of each symbol before using your
device.
Page 2-English Page 3-English
To reduce the risk of injury, users must
read and understand the user manual
before using this product.
This symbol indicates that your machine
should not be exposed to water in any
form. Exposing your device to water can
create dangerous conditions and lead to
electrocution.
Always wear proper protective equip-
ment. This includes, but is not limited to,
eye protection, dust masks, non-slip
safety shoes, hard hats, and hearing
protection.
This product contains lithium-ion batter-
ies and should not be disposed of with
household waste. Check with your local
authority or retailer to determine the best
recycling and disposal practices.
The auger rotates at high speeds and will
grab onto objects in its path. Keep hands,
feet, and clothing away from the auger.
Turn off the motor before attempting to
unclog the chute. Wait until all moving
parts have come to a complete stop
before working on the unit.

1.1 WORK AREA SAFETY
1.2 PERSONAL SAFETY
1.3 OPERATION SAFETY
■Prepare your workspace before turning on your machine. Ensuring a clean and
well-lit workspace should always be the first step in using your Green Machine®
Snow Thrower.
■Clear the area before each use. Remove all objects such as rocks, broken glass,
nails, wire, or string that can be thrown or become entangled in the auger.
■Never operate your power tool in the presence of flammable liquids, gases, or dust.
■Do not use on a graveled surface.
■Keep children away and pets away. All non-operators should be kept at a safe distance
from the work area.
■Don’t force the snowblower. It will perform better and be safer at the rate at which it
was designed to operate.
■Keep hands away from moving parts. Keep clear of the discharge opening at
all times.
■Stay alert and entirely focused when operating a power tool. Never use your cordless
snow blower while under the influence of alcohol or drugs. You should also avoid using
your machine while you are feeling overly tired or ill.
■Dress properly. Do not wear loose clothing or jewelry. They can be caught in moving
parts. Wear protective clothing, use work gloves, long pants, a long-sleeved shirt, and
safety footwear is recommended when working outdoors. Wear protective hair covering
to contain long hair.
■Always wear proper protective equipment. This includes, but is not limited to, eye
protection, dust masks, non-slip safety shoes, hard hats, and hearing protection.
■Keep your balance by maintaining a firm stance and footing. Always be sure of your
footing, particularly on slopes or stairs.
■Do not grip the power tool by any non-insulated metal surface located on the machine.
■Maintain personal safety standards for all devices being used for a task. This may
include dust collection tools, lighting, and additional power tools.
■Prevent unintentional starting. Ensure the switch is in the OFF position before connecting
a battery pack, picking up, or carrying the tool. Carrying power tools with your finger on
the switch or energizing power tools that have the switch on invites accidents.
■Do not start the motor if you are standing in front of the discharge chute. Keep away
from the discharge opening.
■If the snow blower strikes a foreign object, follow these steps:
1. Stop and turn off the snow blower.
2. Remove the battery pack(s).
3. Inspect for damage.
4. Repair any damage before restarting and operating the snow blower.
■If the unit should start to vibrate abnormally. Stop the motor and check immediately
for the cause. Vibration is generally a sign that the tool is damaged.
■Stop the motor whenever you leave the operating position, before unclogging the
auger housing or discharge guide, and when making any repairs, adjustments, or
inspections.
Page 4-English Page 5-English
Please read all of the following before operating your machine. The safety instruc-
tions in this manual are designed to protect your safety and guide your use of the
Green Machine®Snow Blower. Failure to read and understand the following informa-
tion may create an unsafe workspace which could constitute a risk of electric shock,
explosions, heavy flying objects, fire, or chemical reactions. Save all warnings and
instructions for future reference.
NOTE: The term “power tool” used in these instructions refers to your battery-operat-
ed, cordless snow blower.
Electromagnetic
Field
Keep hands and feet
away.
This machine produces an electromag-
netic field during operation. This field may
under some circumstances interfere with
active or passive medical implants. We
recommend persons with medical
implants consult their physician and the
medical implant manufacturer before
operating this machine.
Danger-Keep hands and feet away.
KEEP HANDS and FEET AWAY
GARDEZ VOS MAINS et VOS PIEDS Á DISTANCE
MANTENGA LAS MANOS LOS PIES ALEJADOS
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

■Use the snow blower sideways across the face of slopes; never up and down. Exercise
extreme caution when changing direction on slopes.
■Do not operate the machine on or near drop-offs, ditches, or embankments.
■Never operate the snow blower with a defective auger housing or scraper bar in place.
■Never operate the snow blower near glass enclosures, automobiles, window wells,
etc. without proper adjustment of the snow discharge angle.
■Do not overload the machine capacity by attempting to clear snow at too fast a rate.
■Never operate the machine at high transport speeds on slippery surfaces. Use care
when reversing or pulling the machine towards you.
■Never direct discharge at bystanders or allow anyone in front of the unit.
■Disengage power to the auger when the snow blower is transported or not in use.
■Use only attachments and accessories approved by the snow blower manufacturer
(such as wheel weights, counterweights, cabs, etc.).
■Never operate the snow blower without good visibility or light. Always be sure of your
footing, and keep a firm hold on the handles. Walk; never run.
■Take all possible precautions when leaving the machine unattended by removing
the battery and stopping the motor.
■Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
■Replace worn or damaged parts for safety; Use only genuine replacement parts and
accessories.
■Do not touch the auger before battery packs are removed and the auger has come
to a complete stop.
■Remove the battery packs in each of the following situations:
o whenever leaving the machine unattended.
o before clearing a blockage.
o before checking, cleaning, or working on the machine.
o after striking a foreign object. Inspect the machine for damage and make repairs before
restarting and operating the machine.
o whenever the machine starts vibrating abnormally. Immediately inspect the snow blower
for any damage and replace or repair any damaged parts before restarting and operating
the snow blower and check for and tighten any loose parts.
■Do not tilt the machine when switching on the motor, except if the machine must
be tilted for starting. In this case, do not tilt it more than necessary and lift only the part
which is away from the operator.
■Hand contact with the rotating auger assembly inside the discharge chute is the most
common cause of injury associated with snow blowers. Never use your hand to clean
out the discharge chute.
■To clear the chute:
1. Shut the motor off
2. Wait 10 seconds to be sure the auger assembly blades have stopped rotating.
3. Always use a non-metal tool, not your hands.
■Check that the power switch is off before inserting the battery pack. Your battery pack
should always be removed, and your cordless tool stored securely with the power switch
off between each use.
■Power your snow blower with the Green Machine® battery packs only.
■Recharge only with the Green Machine® charger GMBC6200 provided for use with
the equipment.
■Take special care in storing your battery pack. Keeping your batteries away from other
metal objects such as paper clips, coins, keys, nails, screws, or other small metal objects
will ensure safe storage.
■Avoid any contact with liquid discharged from your battery pack. Liquid will only be
discharged from your battery pack in extreme cases, but it is important to be prepared.
If contact accidentally occurs, flush the exposed area with water immediately. If liquid
contacts the eyes seek medical attention.
■Avoid excessive temperatures. If your battery pack overheats to 212°F or more, the battery
is at risk of exploding. Be mindful of lengthy exposure to intense sun or fire.
■Follow all charging instructions and do not charge the battery pack or tool outside
the temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
■After use and before storage, remove the battery packs from the machine and check
for damage.
■Check shear bolts, motor mounted bolts, etc., at frequent intervals for proper tightness
to be sure the equipment is in safe working condition.
■Run the machine a few minutes after throwing snow to prevent freeze-up of the auger.
■Allow the motor to cool before storing it in any enclosure.
■When servicing the auger be aware that, even though the machine is switched off,
the auger can still move freely.
1.4 BATTERY USE AND CARE
Page 6-English Page 7-English
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

■Do not dispose of the battery in a fire. The cell may explode. Check with local codes for
possible special disposal instructions. When disposing of secondary cells or batteries,
keep cells or batteries of different electrochemical systems separate from each other.
■Do not open or damage the battery. Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if swallowed. Additionally, if your battery pack
has been damaged, seek to dispose of it properly and do not attempt to use it again.
■Exercise care in handling the battery in order not to short it with conducting materials
such as rings, bracelets, and keys. The battery or conductor may overheat and cause burns.
■Keep the battery out of reach of children and in the original package until ready to use.
■Keep batteries and chargers away from children.
■If the battery compartment does not close securely, stop using the product and seek
to repair it.
■Do not use a visibly damaged battery pack or tool.
■Store in a secure setting away from other conductive materials including other batteries.
■Do not subject cells or batteries to mechanical shocks.
■Clean your battery pack regularly to avoid a poor connection.
■Do not maintain secondary cells and batteries on charge when not in use.
■Remove the battery from the equipment when not in use.
■Use the battery only in conjunction with your power tool. This measure alone protects
the battery against dangerous overload.
■Keep the battery charger away from rain or moisture. Penetration of water in the battery
charger may cause damage and increase the chance of injury.
■Do not charge other batteries. The battery charger is suitable only for charging lithium-ion
batteries within the listed voltage range. Otherwise, there is a danger of fire and explosion.
■Keep the battery charger clean. Contamination can lead to a danger of an electric shock.
■Before each use, check the battery charger, cable, and plug. If damage is detected, do
not use the battery charger. Never open the battery charger yourself. Have repairs
performed only by a qualified technician and only using original spare parts. Damaged
battery chargers, cables, and plugs increase the risk of an electric shock.
■Do not operate the battery charger on easily flammable surfaces (e. g., paper, textiles,
etc.) or surroundings. The heating of the battery charger during the charging process can
pose a fire hazard.
1.5 SAFETY WARNINGS FOR BATTERY AND CHARGER ■Use the battery only to power your power tool. Do not use your battery on other tools or
for any other purposes.
Page 8-English Page 9-English
This product uses lithium-ion (Li-ion) batteries marked with the Call2Recycle seal,
which can be recycled at any US or Canada participating retailer or battery recycling
facility in the Call2Recycle program. To locate a participating retailer or facility closest
to you, please call 877-273-2925 or visit www.call2recycle.org. If you are unable to
locate a participating retailer or facility nearby, please consult your local waste authority
for information regarding available recycling and/or disposal options.
SAVE THESE INSTRUCTIONS
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

Cordless Snow Blower: GMSB6200-SS
Rated voltage: 62Vd.c.
Auger no-load speed: MAX:2000RPM
Working height: 13” (330mm)
Working width: 21” (533mm)
Auger diameter: 7” (175mm)
200°
Snow discharge angle range:
Net weight: 28.5kg
Lithium Battery Models*
Rated voltage
GMBA6200-40**
Capacity
62 Vd.c.
Number of battery cells
4.0Ah/216Wh
62 Vd.c.
8.0Ah/432Wh
15pcs
Battery Charger
Model Number
Replacement Parts
GMBC6200
Input
Output 62Vd.c,4A
Charging Temperature Range
GMBA6200-120GMBA6200-80
62 Vd.c.
12Ah/648Wh
45pcs30pcs
GMBC6200-D
100-120Va.c., 60Hz
62Vd.c,8A
32 - 104oF (0-40℃)
3TECHNICAL DETAILS
Upper handle
Chute rotation controls
Headlights button
Snow discharge deflector
Deflector
handle
Lower handle
Power Button
Safety control bar
Speed adjustment
knob
Auger
LED headlight
Cable clamp
Quick-release lever
Battery door
Belt cover
PARTS DIAGRAM
2
Page 10-English Page 11-English
Snow
discharge
guide
Rubber Paddle
Scraper Bar
Drive Belt
Part Number
GMA-RP
GMA-SB21
GMA-DB
*The GMBA6200-25 is not recommended for use with the GMSB6200-SS
**Two GMBA6200-40 batteries come standard with the GMSB6200-SS
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

UNPACKING
4
5.1 UNFOLDING THE HANDLE
5ASSEMBLY
Do not attempt to assemble or use this product without all of the necessary parts.
If any parts are missing, please contact our helpline at [phone] and await
the arrival of the missing parts. Use of this product with damaged or missing parts
could result in serious personal injury.
Before assembly, make sure that the tool is switched off and the battery is
removed.
Do not attempt to modify this product or create accessories not recommended for
use with this product
- Green Machine®Cordless Snow Blower
- Snow discharge deflector
- Operator’s manual
- 62V Battery Pack
- Battery Charger
1. Carefully remove the tool and all accessories from the box.
2. Inspect the tool carefully to make sure that nothing was damaged during
transportation.
3. Once you have confirmed that the tool is complete and working, dispose of all
packing materials using responsible recycling and disposal practices.
4. If any parts are damaged or missing, please contact our helpline or return the
product to the place of purchase.
5. Charge your battery pack fully before operation.
1. Place the folded snow blower on the flat floor. (Fig. 2A)
2. Open the quick-release levers on both sides of the unit and pivot the handle from the
folding position to the working position. (Fig. 2B)
3. Close the quick-release levers to lock the lower handle in position and tighten the
locking knobs on both sides to secure the levers. (Fig. 2B)
Always be sure that the snow blower is switched off and the battery pack is
removed before carrying out any work on the tool. Failure to switch off and remove
the battery pack may result in serious personal injury from accidental start-up.
Never start the snow blower unless it is completely assembled. Operation of the
tool in a partially assembled state may result in serious personal injury from
accidental start-up.
Danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type.
Page 12-English Page 13-English
PACKING LIST
Follow these unpacking instructions to begin operating your Green Machine®Cordless
Snow Blower.
Locking knob
2A.giF 2B.giF
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

Fig.3A Fig.3B
5.2 ASSEMBLY OF THE SNOW DISCHARGE GUIDE
1. Put the snow discharge guide on the base and make sure the assembly hole in the
bottom of the snow discharge guide aligns with the holes in the base. (Fig.3A)
2. Fix the snow discharge guide onto the motor housing with the three M6 bolts provided.
(Fig.3A)
3. Tighten the bolts with a Hex wrench. (Fig.3B)
Page 14-English Page 15-English
Snow discharge guide
Bolt
6.1 INSTALL AND REMOVE THE BATTERY PACKS
6OPERATION
Fig. 4
Always exercise caution when using your snow blower, employing strict safety
measures no matter your level of experience or expertise.
Always wear safety goggles or safety glasses with side shields during power tool
operation. Failure to do so could result in objects being thrown into your eyes and
other possible serious injuries.
Only use the attachments recommended by the manufacturer. The use of attach-
ments or accessories not recommended can result in serious personal injury.
Inspect the entire product for damaged, missing, or loose parts before each use.
Tighten all fasteners and do not operate this product until all missing or damaged
parts are replaced.
FULLY CHARGE THE BATTERY PACK BEFORE FIRST USE.
Always remove the battery pack from the product when you are assembling parts,
adjusting, cleaning, or when the blower is not in use. Removing the battery pack will
prevent accidental starting that could cause serious personal injury.
Power your equipment with the Green Machine®battery pack only, models
GMBA6200-40, GMBA6200-80, and GMBA6200-120. The use of any other battery
packs may create a risk of injury and fire. *The use of model GMBA6200-25 is not
recommended with this product.
1. Raise the battery cover. (1, Fig.4)
2. The snow blower is equipped with two battery compartments, which accommodate
two battery packs at the same time.
3. Align the ribs of the battery pack with the mounting slots in the battery port. Insert
the battery pack into the battery holder until you hear a “click”. Ensure that the
latch snaps into place and the battery feels secure. (2, Fig.4）
4. Insert the other battery pack into the other battery compartment in the same way.
5. Close the battery cover.
TO INSTALL THE BATTERY PACK:
NOTE: Check to ensure that the power switch is set to off before battery assembly.
2
1
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

6.2 START/STOP THE SNOW BLOWER
6.3 POWER INDICATOR ON THE SNOW BLOWER
Fig.7
Fig.6A
Use the unit as intended to avoid damage to the machine or yourself.
Only switch the motor on when your hands and feet are away from the rotating parts.
Ensure that other people and pets remain at least 100’ (30m) away from the snow
blower when it is in use.
1. Press the power button and pull the safety control bar upward to the upper handle
and keep it held in. (1,2, Fig. 6A)
2. Once the tool powers on, release the power button and begin operation.
3. To stop the snow blower, release the safety control bar, and the motor will stop.
The snow blower is equipped with a status indicator at the back of the battery cover. It
indicates the charge level of the battery pack(s) and the working status of the snow blower.
(Fig.7)
1. The LED indicator shows green when the motor is started, and 5sec later the LED
shows off in normal working status.
2. If the LED light shows green flashing, it means abnormal conditions appear. The
battery packs may be in depleted capacity, the temperature is too high, or other
abnormal conditions. Remove and charge the battery packs immediately, or cool the
battery packs, if the LED light still shows green flashing, contact our helpline at
800-541-7027.
The Auger starts turning as soon as the motor is started.
The Auger continues to rotate after the motor is switched off.
Always remove the battery pack from the power head during work breaks and after
finishing work.
If snow gets stuck in the chute do not try to remove it before releasing the safety control
bar.
Do not put your hand inside the chute or auger.
Switch handleSafety push-button
21
LED light
Fig. 5
Serious injury could result if the battery pack falls. Remove the heavy battery pack
with caution.
1. Turn off your snow blower.
2. To detach the battery pack, depress the battery-release button to disengage the
battery from the latch (1, Fig. 5)
3. Lift it out of the compartment. (2, Fig. 5)
Page 16-English Page 17-English
TO REMOVE THE BATTERY PACK:
2
1
Battery-release button
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

6.4 LED HEADLIGHT
Fig.8
Fig.9
Your snow blower comes equipped with LED headlights to increase vision in poor light. Notice
that the headlights are not intended to replace proper lighting. You should always use your
snow blower in daylight or with very bright lighting.
1. The LED headlights are located in the front of the unit. (Fig.8).
2. To turn on the lights, press the LED button on the control panel (Fig.8).
3. To turn off the headlights, press the LED button again.
Page 18-English Page 19-English
6.6 ADJUST DISCHARGE DIRECTION AND HEIGHT
6.5 ADJUST THE AUGER SPEED
Fig.11A Fig.11B
Do not adjust the chute deflector while the safety control bar is engaged, and the unit
is on. Make this adjustment only when the motor is stopped. The chute can be adjust-
ed to change both the direction and the distance of the discharged snow.
1. Press and hold the chute rotation button on the left from the view of the operator’s
position, the snow discharge guide turns to the left. (Fig.10)
2. Press and hold the chute rotation button on the right from the view of the operator’s
position, the snow discharge guide turns to the right. (Fig.10)
1. To increase the distance that the snow is thrown, squeeze the trigger on the
chute-deflector handle, and then raise the chute deflector. Release the trigger on
the chute deflector handle to lock the chute deflector in 55 º (Fig.11A/ Fig.11B).
2. To decrease the distance that the snow is thrown, simply lower the deflector with
the chute-deflector handle. Release the trigger on the chute deflector handle to lock
the chute deflector in -5 º (Fig.11B)
To change the direction of the snow discharge:
The direction of snow removal can be adjusted up to 200°by pressing the chute rotation
button. (Fig.10)
To change the distance of the snow discharge:
The throwing distance of the snow blower is adjusted by moving the chute deflector up or
down, the machine offers 5 different positions (-5º~55º).
The speed of the auger can be adjusted to control the throwing distance.
1. To increase the speed, rotate the speed adjustment knob towards the rabbit symbol
to throw the snow farther. (Fig.9)
2. To decrease the speed, rotate the speed adjustment knob towards the tortoise
symbol to throw the snow nearer. (Fig.9)
Speed adjustment knob
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER
Fig.10
200°
Chute rotation button
LED switch
LED headlight
1
2
Trigger

7.1 GENERAL MAINTENANCE
7.3 REPLACE THE SCRAPER BAR
7.2 REPLACE THE RUBBER PADDLE
Fig.12
Make sure to turn off the switch handle and remove the battery packs from the snow
blower before inspecting, cleaning, or performing any maintenance task on your snow
blower.
Always wear gloves when performing any maintenance.
When servicing, use only the manufacturer’s recommended replacement parts and
accessories.
Auger is sharp. Always wear gloves when performing any maintenance on the auger.
The rubber paddle will become worn during operation, change the rubber paddle every
50hrs of working time. (PN: GMA-RP)
Auger is sharp, always wear gloves when performing any maintenance near the auger.
Check frequently for wear and replace the scraper bar every 50 working hours for ideal
working conditions. (PN: GMA-SB21)
1. Rotate the auger to the appropriate position for easy access to the rubber paddle.
(Fig.12)
2. Fix the bolt with a Phillips screwdriver on one side and loosen the nut with a Hex
wrench on the other side.
3. Remove the two M6 bolts and two M6 nuts, then remove the rubber paddle from
the auger.
4. Disassemble the other rubber paddle on the other side in the same way.
5. Replace them with the new rubber paddles and securely tighten them.
1. The scraper bar is located at the bottom of the snow blower housing. In the process
of snow blowing, the bar may touch the ground or stone directly, resulting in wear.
Remove the battery and turn the snow blower on its side to work on the tool. (Fig. 13)
2. Use a Hex wrench to remove the 5 nuts and washers under the bottom of the
housing. Remove the worn scraper bar from the snow blower. (Fig. 13)
3. Attach the new scraper bar to the bottom of the snow blower housing with the shiny
surface facing the inside of the housing and the rough surface with bars facing the
outside of the housing. Align the mounting holes in the scraper bar with the holes in
Do not spray the unit with water. Ingress of water may destroy the control panel and
the electric motor. Clean the unit with a cloth, hand brush, etc.
Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating
oils, etc., come in contact with a plastic part. Chemicals can damage, weaken or
destroy plastic which can result in serious personal injury.
1. Turn off your machine and remove the battery pack.
2. Clear any snow in the auger housing with a hand brush.
3. Clean dirt and debris from the machine using a damp cloth with a mild detergent.
4. Do not use any strong detergents on the plastic housing or the handle. They can be
damaged by certain aromatic oils, such as pine and lemon, and by solvents such as
kerosene.
5. Completely dry your machine before use. A damp machine presents a shock
hazard.
NOTE: Regular inspection is the most important step to proper maintenance. By following
the guidelines below, you can maximize the safety, durability, and effectiveness of your
blower. Should you identify any damaged or excessively worn parts, replace them immediate-
ly. For repairs and service, please work with an authorized service dealer, which can be
located by calling 800-541-7027. Rubber paddle
Bolt
Nut
MAINTENANCE AND CLEANING
7
Page 20-English Page 21-English
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

7.4 REPLACE THE DRIVE BELT
7.5 TRANSPORT AND STORE THE SNOW BLOWER
Fig. 13
the housing. Insert the 5 bolts into the mounting holes from the inside, shiny surface
of the scraper bar.
4. Place the five washers and nuts on the bolts (from the outside of the housing) and
use a hex wrench to fasten the scraper bar to the housing securely.
Always wear gloves when performing any maintenance. Over time, the drive belt may
become worn, excessively cracked, frayed, or otherwise damaged. (PN: GMA-DB)
1. Unscrew five screws with a Phillips screwdriver to remove the drive belt cover.
(Fig.14A)
2. Remove the spring from the hook to release the belt tension (Fig.14B).
3. Pull the tension pulley out a little for easy removal of the belt.
4. Remove the drive belt by slowly turning the auger pulley counterclockwise while
pulling the belt outwards (Fig. 14B).
5. Install a new belt. Rotate the new drive belt first around the motor pulley, then
around the auger pulley. Slowly turn the auger pulley clockwise to drive the belt
inwards (Fig. 14C).
6. Place the tension pulley in place.
7. Re-install the spring onto the hook to tension the drive belt.
8. Re-install the drive belt cover with four screws.
Do not store or transport the snow blower while it is running. Always remove the battery
packs before storing or transporting them.
Lift the front of the machine while transporting and crossing gravel or road
surfaces.
Always exercise caution to avoid the sharp auger, even when your machine is
turned off.
Before storage, wipe any moisture, dirt, or debris from the battery area.
Wipe the snow blower with a clean dry cloth.
Check all nuts, bolts, knobs, screws, etc., for tightness.
Inspect moving parts for damage, breakage, and wear. Have repairs made on
any damaged or missing parts.
Fold the handle to the storage position.
When not in use store the machine and battery in a dry, well-ventilated area,
out of the reach of children.
Do not store near corrosive materials such as fertilizer or rock salt.
Fig.14A Fig.14B Fig.14C
Bolt
Nut
Spring washer
■
■
■
■
■
■
■
■
■
Page 22-English Page 23-English
screw
Spring
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER
Motor pulley
Tension pulley
Auger pulley

TROUBLESHOOTING
8
The following chart lists problem symptoms, possible causes, and corrective action if
your product does not operate properly. If these do not identify and correct the problem,
contact our helpline at 800-541-7027.
Page 24-English Page 25-English
Before performing any maintenance or cleaning work, always remove the battery and
wait until the auger has come to a standstill.
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
The battery is not secureThe machine
fails to start
Battery is depleted Charge the battery pack.
Possible wiring or
electrical contact
problems
Remove battery, check contacts, and re-install
the battery pack.
The power button is
not pressed before
grasping the safety
control bar.
The auger is frozen.
The battery is
overheated. The LED
indicator on the battery
flashes green.
The auger is jammed.
Press down the power button and with it
depressed, grasp the safety control bar.
Remove the battery pack(s) first and use a
non-metal tool to clear the snow or ice that
obstructs the auger. Restart the snow blower.
Remove the overheated battery from the snow
blower and wait until the battery pack cools
down, then re-install the battery and restart the
snow blower.
Remove the battery pack from the tool. Remove
the obstruction carefully and then reinsert the
battery and restart the tool.
To secure the battery pack, make sure the
battery packs snap into place.
The motor is overloaded
The battery pack or the
motor is too hot.
The machine
stops while
working
Use a non-metal tool to clear the snow or ice
that obstructs the auger. Do not clear snow at
too fast a rate.
Allow the battery pack or the motor to cool
down.
The battery pack is
disconnected
The motor is
on, but the
auger does
not turn.
The snow
blower leaves
a layer of
snow on the
ground after
passing
through.
Battery is depleted
The drive belt is worn
or broken.
The scraper bar is worn.
Re-install the battery pack.
Charge the battery pack according to the
instructions.
Replace the drive belt as described in the
section “REPLACING THE DRIVE BELT” in this
manual.
Replace the scraper as described in the section
“REPLACING THE SCRAPER BAR” in this
manual.
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

WARRANTY PERIOD
Item Consumer Use Commercial Use
Garden Tool
Battery and Charger
5 years 1 year
3 years 45 days
LIMITED WARRANTY COVERAGE
9
The manufacturer warrants that it will repair or replace, free of charge, any failure
due to defects in materials or workmanship or both occurring during the applicable
warranty period, subject to the exclusions and limitations outlined in the following
paragraphs. Limited Warranty coverage only applies to Green Machine@products
that are purchased from an authorized Green Machine@retailer located in the United
States, U.S. territories, or Canada. This warranty is effective for and is subject to the
periods and conditions stated below. For warranty service, the purchaser must make
the product available to the nearest Authorized Service Dealer, which can be found
by contacting the helpline at 800-541-7027.
Persons Covered This Limited Warranty
This warranty is valid for the original retail purchaser from the date of initial retail
purchase and is not transferable.
"Consumer Use"
“Consumer Use” means personal residential household use by a retail consumer.
"Commercial Use"
"Commercial Use" means uses for commercial, income-producing purposes. This
warranty is void if the product has been used for rental purposes.
Page 26-English Page 27-English
What are the limits on Manufacturer’s Liability?
Duties of the Consumer
Duties of the Manufacturer
The manufacturer shall not be liable for any incidental or consequential damages of
any kind resulting from the purchase, use or misuse of, or inability to use the product
including incidental, special, consequential, or similar damages or loss of profits, or
for any claim brought against the purchaser by any other party. There are no express
warranties other than those set forth herein. Any warranty implied by state law
(whether of merchantability or fitness for a particular use or otherwise) shall be
effective for any product only for the duration of the applicable limited warranty
period listed above. Some states or jurisdictions do not allow the exclusion or limita-
tion of incidental or consequential damages or limitations on how long an implied
warranty lasts, so the above limitations or exclusion may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights that vary
from state to state or jurisdiction to jurisdiction. Please do not return this product to
the place of purchase.
This warranty applies only to products that have been properly assembled, adjusted,
operated, and maintained in accordance with the instructions furnished.
This warranty does not apply to any product which has been subjected to alteration,
misuse, abuse, improper assembly or installation, delivery damage, or normal wear
of the product.
This warranty does not cover normal wear of parts or damage resulting from any of
the following: negligent use or misuse of the product, use on improper voltage or
current, use contrary to the operating instructions, disassembly, repair, or alteration
by anyone other than an authorized service dealer. Further, the warranty does not
cover acts of God, such as fire, flood, hurricanes, and tornadoes.
Keep the original sales receipt for the length of the limited warranty period as proof
of purchase. Proof of purchase is required to obtain a warranty. The manufacturer
reserves the right to request a copy of the receipt to verify limited warranty coverage
in the event a warranty repair is made to the product.
Use reasonable care in the maintenance, operation, and storage of the product as
explained in the operator’s manual.
Transportation charges on products or parts submitted for repair or replacement
under this warranty must be paid by the purchaser unless such repair or replace-
ment is requested by the manufacturer.
Any defective product or part covered by this limited warranty will be repaired or
replaced at the option of the Manufacturer.
Product failures covered by this limited warranty will be scheduled and repaired
according to the normal workflow of the Authorized Service Dealer to whom the
product is delivered for service depending upon the availability of replacement parts
or products.
A.
A.
A.
B.
B.
B.
C.
C.
D.
GREEN MACHINE 62V CORDLESS SNOW BLOWER GREEN MACHINE 62V CORDLESS SNOW BLOWER

SOPLADORA DE NIEVE
SIN CABLE 62
Manual del operador
Modelo: #GMSB6200-SS
ADVERTENCIA: Para reducir el riesgo de lesiones, el usuario debe leer y
comprender el manual del operador antes de utilizar este producto. Guarde estas
instrucciones para futuras consultas.
LÍNEA DE AYUDA GRATUITA:[phone]

Alerta de seguridad
Lea el manual del
propietario
No exponer a la
lluvia o condiciones
de humedad
Usa equipo de
protección
Símbolos de reciclaje
Advertencia de
Barrena
Advertencia de
Desobstrucción
Precauciones que involucran su seguridad.
GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62 GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62
Sección 1 Normas generales de seguridad .............. 3
Sección 2 Diagrama de piezas...........................
.............................
.................................
.....................................
....................................
....................
.......................
.............
11
Sección 3 Detalles técnicos 12
Sección 4 Desembalaje 13
Sección 5 Montaje 14
Sección 6 Operación 15
Sección 7 Mantenimiento y limpieza 21
Sección 8 Solución de problemas 26
Sección 9 Cobertura de la garantía limitada 28
CONTENIDOS
SÍMBOLOS MARCADOS EN EL PRODUCTO
NORMAS GENERALES DE SEGURIDAD
1
Los siguientes símbolos pueden aparecer en su dispositivo antes, durante o después
de su uso. Tómese el tiempo de leer y entender el significado de cada símbolo antes
de usar su dispositivo.
Página 2-Español Página 3-Español
Para reducir el riesgo de lesiones, los usuari-
os deben leer y comprender el manual del
usuario antes de utilizar este producto.
Este símbolo indica que su máquina no
debe exponerse al agua de ninguna forma.
Exponer su dispositivo al agua puede crear
condiciones peligrosas y provocar una
electrocución.
Utilice siempre el equipo de protección
adecuado. Esto incluye, pero no se limita a,
protección para los ojos, máscaras contra el
polvo, zapatos de seguridad antidesli-
zantes, cascos y protección para los oídos.
Este producto contiene baterías de iones de
litio y no debe desecharse con la basura
doméstica. Consulte con su autoridad local
o minorista para determinar las mejores
prácticas de reciclaje y eliminación.
La barrena gira a altas velocidades y agarrará
objetos en su camino. Mantenga las manos,
los pies y la ropa alejados de la barrena.
Apague el motor antes de intentar destapar
el conducto. Espere hasta que todas las
piezas móviles se hayan detenido por
completo antes de trabajar en la unidad.

1.1 SEGURIDAD EN EL ÁREA DE TRABAJO
1.2 SEGURIDAD PERSONAL
■
■
■
■
■
■
Prepare su espacio de trabajo antes de encender su máquina. Garantizar un
espacio de trabajo limpio y bien iluminado siempre debe ser el primer paso al
usar su lanzador de nieve Green Machine®. Utilice dispositivos de extracción y
recolección de polvo si están disponibles.
Limpiar el área antes de cada uso. Retire todos los objetos como piedras, vidrios
rotos, clavos, alambres o cuerdas que puedan salir disparados o enredarse en la
barrena.
Nunca opere su herramienta eléctrica en presencia de líquidos, gases o polvo
inflamables.
No utilice la máquina en una superficie con grava.
Mantenga fuera del alcance de los niños y animales domésticos. Todas las personas
que no sean operarios deben mantenerse a una distancia segura del área de trabajo.
No fuerce la sopladora de nieve. Funcionará mejor y será más segura a la velocidad
para la que fue diseñada.
■
■
■
■
■
■
■
■
■
Mantenga las manos alejadas de las piezas móviles. Manténgase alejado de la
abertura de descarga en todo momento.
Manténgase alerta y totalmente concentrado cuando maneje una herramienta
eléctrica.No utilice nunca la sopladora de nieve sin cable bajo la influencia del
alcohol o las drogas. También debe evitar utilizar la máquina cuando se sienta
excesivamente cansado o enfermo.
Vístase adecuadamente. No lleve ropa suelta ni joyas.Pueden quedar atrapadas
en las piezas móviles. Lleve ropa de protección, utilice guantes de trabajo,
pantalones largos, camisa de manga larga y se recomienda el uso de calzado de
seguridad cuando trabaje al aire libre. Lleve una cubierta protectora para conten-
er el pelo largo.
Lleve siempre el equipo de protección adecuado.Esto incluye, entre otros, protec-
ción ocular, máscaras antipolvo, calzado de seguridad antideslizante, cascos y
protección auditiva.
No se extienda demasiado. Mantenga el equilibrio manteniendo una postura y un pie
firmes.Asegúrese siempre de estar bien parado, especialmente en pendientes o
escaleras.
No agarre la herramienta eléctrica por ninguna superficie metálica no aislada
situada en la máquina.
Mantenga las normas de seguridad personal para todos los dispositivos que se
utilicen para una tarea.Esto puede incluir herramientas de recogida de polvo,
iluminación y herramientas eléctricas adicionales.
Evite el arranque involuntario.Asegúrese de que el interruptor está en la posición de
apagado antes de conectar un paquete de baterías, recoger o transportar la herramienta.
Transportar las herramientas eléctricas con el dedo en el interruptor o energizar las
herramientas eléctricas que tienen el interruptor encendido invita a los accidentes.
No ponga en marcha el motor si se encuentra delante del conducto de descarga.
Manténgase alejado de la abertura de descarga.
■Si la sopladora de nieve golpea un objeto extraño, siga estos pasos:
1. Deténgase y apague la sopladora de nieve.
2. Retire la(s) batería(s).
3. Inspeccione si hay daños.
4. Repare cualquier daño antes de volver a poner en marcha y hacer funcionar la
sopladora de nieve.
Página 4-Español Página 5-Español
Lea todo lo siguiente antes de operar su máquina.Las instrucciones de seguridad de
este manual están diseñadas para proteger su seguridad y guiarle en el uso de la
sopladora de nieve Green Machine®. No leer y comprender la siguiente información
puede crear un espacio de trabajo inseguro que podría constituir un riesgo de descar-
ga eléctrica, explosiones, objetos voladores pesados, incendios o reacciones quími-
cas. Guarde todas las advertencias e instrucciones para referencia futura.
NOTA: El término “herramienta eléctrica” que se usa en estas instrucciones se refiere
a su soplador de nieve inalámbrico que funciona con baterías.
Campo
Electromagnetico
Esta máquina produce un campo electromagnéti-
co durante su funcionamiento. Este campo
puede, en algunas circunstancias, interferir con
los implantes médicos activos o pasivos. Para
reducir el riesgo de lesiones graves o fatales,
recomendamos que las personas con implantes
médicos consulten a su médico y al fabricante del
implante médico antes de operar esta máquina.
GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62 GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62
KEEP HANDS and FEET AWAY
GARDEZ VOS MAINS et VOS PIEDS Á DISTANCE
MANTENGA LAS MANOS LOS PIES ALEJADOS
Mantenga las manos
y los pies alejados Peligro-Mantenga las manos y los pies
alejados

1.3 SEGURIDAD DE FUNCIONAMIENTO
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Si la unidad comienza a vibrar de forma anormal.Detenga el motor y compruebe
inmediatamente la causa. La vibración es generalmente una señal de que la
herramienta está dañada.
Detenga el motor siempre que abandone la posición de funcionamiento, antes
de desatascar la carcasa del sinfín o la guía de descarga, y cuando realice
cualquier reparación, ajuste o inspección.
Use el soplador de nieve de lado a través de las pendientes; nunca arriba y
abajo.Extreme las precauciones al cambiar de dirección en pendientes.
No opere la máquina en o cerca de desniveles, zanjas o terraplenes.
No limpie la nieve a través de la cara de las pendientes.Extreme las precauciones al
cambiar de dirección en las pendientes. No intente limpiar pendientes pronunciadas.
Asegúrese siempre de pisar bien en las pendientes.
Nunca opere el soplador de nieve con una carcasa de barrena o una barra raspado-
ra defectuosas en su lugar.
No utilice nunca la sopladora de nieve cerca de cerramientos de cristal,
automóviles, huecos de ventanas, etc. sin ajustar adecuadamente el ángulo de
descarga de la nieve.
No sobrecargue la capacidad de la máquina intentando quitar la nieve a un ritmo
demasiado rápido.
No utilice nunca la máquina a altas velocidades de transporte en superficies
resbaladizas. Tenga cuidado al dar marcha atrás o al tirar de la máquina hacia usted.
No dirija nunca la descarga hacia los transeúntes ni permita que nadie se ponga
delante de la unidad.
Desconecte la alimentación del sinfín cuando la sopladora de nieve sea transporta-
da o no esté en uso.
Utilice únicamente los accesorios aprobados por el fabricante de la sopladora de
nieve (como pesos en las ruedas, contrapesos, cabinas, etc.).
No utilice nunca la sopladora de nieve sin una buena visibilidad o luz. Asegúrese
siempre de estar bien parado y mantenga un agarre firme de las asas. Camine; nunca
corra.
Tome todas las precauciones posibles cuando deje la máquina desatendida quitan-
do la batería y apagando el motor.
Mantenga todas las tuercas, pernos y tornillos apretados para asegurarse de que
el equipo está en condiciones seguras de funcionamiento.
■
■
■
■
■
■
■
■
■
Sustituya las piezas desgastadas o dañadas por seguridad; Utilice únicamente
piezas de repuesto y accesorios originales.
No toque el sinfín antes de retirar los paquetes de baterías y de que el sinfín se haya
detenido por completo.
Retire las baterías en cada una de las siguientes situaciones:
o siempre que deje la máquina desatendida.
o antes de despejar un atasco.
o antes de revisar, limpiar o trabajar en la máquina.
o después de golpear un objeto extraño. Inspeccione la máquina en busca de daños y
realice las reparaciones pertinentes antes de volver a ponerla en marcha y hacerla
funcionar.
o siempre que la máquina comience a vibrar de forma anormal. Inspeccione inmediata
mente la sopladora de nieve en busca de daños y sustituya o repare las piezas dañadas
antes de volver a poner en marcha y hacer funcionar la sopladora de nieve, y comprue
be si hay piezas sueltas y apriételas.
No incline la máquina al encender el motor, excepto si es necesario inclinarla para el
arranque.En este caso, no la incline más de lo necesario y levante sólo la parte que esté
alejada del operador.
El contacto de la mano con el conjunto del sinfín giratorio dentro del conducto de
descarga es la causa más común de lesiones asociadas a los sopladores de nieve.Nun-
ca utilice la mano para limpiar el conducto de descarga.
Para limpiar el conducto:
1.Apague el motor.
2.Espere 10 segundos para asegurarse de que las cuchillas del conjunto del sinfín
han dejado de girar.
3.Utilice siempre una herramienta que no sea de metal, no sus manos.
Compruebe que el interruptor de encendido está apagado antes de insertar la batería.
El paquete de baterías debe retirarse siempre, y la herramienta inalámbrica debe
guardarse de forma segura con el interruptor de alimentación apagado entre cada
uso.
Accione su sopladora de nieve sólo con los paquetes de baterías Green Machine®.
Recargue sólo con el cargador Green Machine®GMBC6200 suministrado para su uso
con el equipo.
1.4 USO Y CUIDADO DE LA BATERÍA
Página 6-Español Página 7-Español
GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62 GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62

■
■
■
■
■
■
■
■
■
Tenga especial cuidado al almacenar su paquete de baterías. Mantenga las baterías
alejadas de otros objetos metálicos como clips, monedas, llaves, clavos, tornillos u otros
objetos metálicos pequeños para garantizar un almacenamiento seguro.
Evite cualquier contacto con el líquido descargado de su paquete de baterías. El líquido
sólo se descargará de su paquete de baterías en casos extremos, pero es importante
estar preparado. Si se produce un contacto accidental, lave la zona expuesta con agua
inmediatamente. Si el líquido entra en contacto con los ojos, busque atención médica.
Evite las temperaturas excesivas. Si el paquete de baterías se sobrecalienta a 212 °F o
más, la batería corre el riesgo de explotar. Tenga cuidado con la exposición prolongada al
sol intenso o al fuego.
Siga todas las instrucciones de carga y no cargue el paquete de baterías o la
herramienta fuera del rango de temperatura especificado en las instrucciones. Una
carga inadecuada o a temperaturas fuera del rango especificado puede dañar la batería
y aumentar el riesgo de incendio.
Después del uso y antes del almacenamiento, retire los paquetes de baterías de la
máquina y compruebe si hay daños.
Compruebe a intervalos frecuentes el correcto apriete de los pernos de la cizalla, de los
pernos montados en el motor, etc., para asegurarse de que el equipo está en
condiciones de trabajo seguras.
Ponga en marcha la máquina unos minutos después de lanzar la nieve para evitar la
congelación del sinfín.
Deje que el motor se enfríe antes de guardarlo en cualquier recinto.
Cuando realice el mantenimiento del sinfín, tenga en cuenta que, aunque la máquina
esté apagada, el sinfín aún puede moverse libremente.
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Mantenga la batería fuera del alcance de los niños y en el embalaje original hasta que
esté lista para su uso.
Mantenga las baterías y los cargadores fuera del alcance de los niños.
Si el compartimiento de la batería no cierra de forma segura, deje de usar el producto
y busque repararlo.
No utilice una batería o herramienta visiblemente dañada.
Guárdelo en un lugar seguro, lejos de otros materiales conductores, incluidas otras
baterías.
No someta las pilas o baterías a golpes mecánicos.
Limpie el paquete de baterías regularmente para evitar una mala conexión.
No mantenga las celdas y baterías secundarias en carga cuando no estén en uso.
Retire la batería del equipo cuando no lo utilice.
Utilice la batería sólo en combinación con su herramienta eléctrica. Sólo esta medida
protege la batería contra una sobrecarga peligrosa.
Mantenga el cargador de baterías alejado de la lluvia o la humedad. La penetración de
agua en el cargador de baterías puede causar daños y aumentar la posibilidad de
lesiones.
No cargue otras baterías. El cargador de baterías sólo es adecuado para cargar baterías
de iones de litio dentro del rango de tensión indicado. De lo contrario, existe peligro de
incendio y explosión.
Mantenga limpio el cargador de baterías. La contaminación puede provocar un peligro
de descarga eléctrica.
Antes de cada uso, compruebe el cargador de baterías, el cable y el enchufe. Si se
detectan daños, no utilice el cargador de baterías. No abra nunca el cargador de baterías
usted mismo. Encargue las reparaciones únicamente a un técnico cualificado y sólo con
piezas de repuesto originales. Los cargadores de baterías, cables y enchufes dañados
aumentan el riesgo de sufrir una descarga eléctrica.
No haga funcionar el cargador de baterías sobre superficies fácilmente inflamables
(por ejemplo, papel, textiles, etc.) o alrededores. El calentamiento del cargador de
baterías durante el proceso de carga puede suponer un riesgo de incendio.
Utilice la batería sólo para alimentar su herramienta eléctrica. No utilice la batería en
otras herramientas ni para otros fines.
■
■
■
No tire la batería al fuego. La pila puede explotar. Consulte los códigos locales para
conocer las posibles instrucciones especiales de eliminación. Cuando deseche pilas o
baterías secundarias, mantenga separadas las pilas o baterías de diferentes sistemas
electroquímicos.
No abra ni dañe la batería. El electrolito liberado es corrosivo y puede causar daños en
los ojos o en la piel. Puede ser tóxico si se ingiere. Además, si la batería se ha dañado,
procure deshacerse de ella adecuadamente y no intente volver a utilizarla.
Tenga cuidado al manipular la batería para no provocar un cortocircuito con materiales
conductores como anillos, pulseras y llaves. La batería o el conductor pueden
sobrecalentarse y causar quemaduras.
1.5 ADVERTENCIAS DE SEGURIDAD PARA LA BATERÍA Y EL CARGADOR
Página 8-Español Página 9-Español
GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62 GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62

GUARDE ESTAS INSTRUCCIONE
Página 10-Español Página 11-Español
Este producto utiliza baterías de iones de litio (Li-ion) marcadas con el sello Call2Recy-
cle, que pueden reciclarse en cualquier minorista o instalación de reciclaje de baterías
de EE.UU. o Canadá que participe en el programa Call2Recycle. Para localizar el punto
de venta o instalación participante más cercano a usted, llame al 877-273-2925 o visite
www.call2recycle.org. Si no puede encontrar una tienda o instalación participante cerca
de usted, consulte a su autoridad local de residuos para obtener información sobre las
opciones de reciclaje o eliminación.
GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62 GREEN MACHINE SOPLADORA DE NIEVE SIN CABLE 62
Asa superior
Controles de rotación
del conducto
Botón de faros
Asa de
Deflector
Deflector de
descarga de nieve Asa inferior
Botón de encendido
Barra de control
de seguridad
Pomo de ajuste de
la velocidad
Sinfín
Faro LED
Abrazadera del cable
Palanca de cierre rápido
Puerta de la batería
Cubierta de la correa
DIAGRAMA DE PIEZAS
2
Guía de
descarga
de nieve
