GreenTec FR 92-162 User manual

FLAIL MOWER FR 92 –162
FR 92-162
Instruktionsbog DK 1. udg 2021.docx
FORSIDE
1. EDITION 2021

FLAIL MOWER FR 92 –162

FLAIL MOWER FR 92 –162
A
FLAIL MOWER
FR 92 –FR 112 –FR 122 –FR 162
INSTRUCTION MANUAL
1. EDITION –MARCH 2021
ORIGINAL EDITION
! IMPORTANT !
This GreenTec FR Flail Mower must be mounted on an approved tool carrier such as GreenTec
Scorpion Boom Mower.
It is important that the operator is provided with both this instruction manual and the instruction
manual for the tool carrier before the machine is used for the first time.
It is important that the operator fully understands the contents before using the machine.
This instruction manual must accompany the machine and must always be available to the operator.
In the event of later resale of the machine, the instruction manual must accompany the new owner.
The contents of the instruction manual are based on information, standards, and regulations
applicable at the time of publication.
As our products are constantly evolving and improving, there may be changes in specifications.
If there is information that differs on the current machine, updated instructions can be found on our
website or by contacting our Aftersales department.
MANUFACTURER, COMPANY NAME AND
ANDRESS (a)
Merkurvej 25
DK-6000 Kolding
Danmark
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Webadresse: www.greentec.eu

FLAIL MOWER FR 92 –162
B
PREFACE
Dear Customer!
Your new GreenTec machine is designed based on almost 30 years of experience with vehicle-mounted
machines for maintenance of green areas.
The machine is manufactured based on the latest technology as well as approved safety regulations,
standards, and regulations.
We want to make a product available in a way that does not cause damage or misunderstandings during use,
during transport or during maintenance of the machine.
The instruction manual contains information and instructions that are important and useful for maintaining
the GreenTec machine's operational safety, reliability, and value.
Therefore, read this instruction manual carefully as it will familiarize you with installation, use, care, and
maintenance. Pay special attention to safety instructions!
You are welcome to visit our website www.grentec.eu - where you can find technical documentation and
access the latest updates of instruction manuals and spare parts books on our entire product range.
We hope you enjoy your new GreenTec machine!
Kind regards
Signature: ___________________________
John Christensen
Owner, GreenTec A/S
GreenTec’s vision is to develop and sell quality machines for the maintenance of green areas, e.g., in agriculture, industry, airports and
the municipal sector. Through innovative product development, we strive to become a leader in our field.
All machines are developed in a simple, functional, and production-friendly design in close collaboration with dealers and end users. It is
our goal to identify all needs in the market segment with a minimum of 2 different solution proposals.
By in-depth analysis of requirements and serious consultancy, the customer must be offered the best possible solution, where individual
needs can also be met through modular construction of the product program.
We also strive to offer the best possible aftersales service and a fast and efficient spare parts supply.

FLAIL MOWER FR 92 –162
C
CONTENT
MANUFACTURER, COMPANY NAME AND ANDRESS (a)...........................................................................................A
PREFACE.................................................................................................................................................................... B
TABLES AND FIGURES ...............................................................................................................................................F
DECLARATION OF CONFORMITY (c) ......................................................................................................................... 1
1. MACHINE DATA AND USEFUL INFORMATION (b)............................................................................................ 2
1.1 REGISTRATION OF MACHINE DATA .........................................................................................................2
1.2 MANUFACTURERS PLATE.........................................................................................................................3
1.3 WARRANTY................................................................................................................................................3
1.4 USE OF OTHER MANUFACTURERS OF TOOL CARRIERS.........................................................................3
2. GENERAL INFORMATION ................................................................................................................................. 4
2.1 INSTRUCTIONS USING THIS MANUAL .....................................................................................................4
2.2 DEFINITION OF INFORMATION SIGNS .....................................................................................................4
2.3 DEFINITIONS, TERMS AND DESCRIPTIONS ............................................................................................4
3. SAFETY.............................................................................................................................................................. 5
3.1 LOCAL LEGISLATION IN THE COUNTRY OF USE ......................................................................................5
3.2 WARNINGS, PROHIBITIONS AND INSTRUCTIONS...................................................................................5
3.3 SAFETY LABELLING ..................................................................................................................................5
3.3.1 PERSONAL SAFETY EQUIPMENT–LABELS.................................................................................... 5
3.3.2 WARNING LABELS .......................................................................................................................... 6
3.4 OPERATING IN PUBLIC AREAS .................................................................................................................7
3.4.1 WARNING SIGNS IN PUBLIC AREAS............................................................................................... 7
3.4.2 USE OF WARNING SIGNS ............................................................................................................... 7
3.4.3 PROPOSED SIGNS WHEN OPERATING ON PUBLIC ROADS:......................................................... 8
3.5 RECOMMENDATIONS FOR OPTIMAL SAFETY AND OPERATION (l) ........................................................9
3.6 NECCESARY PROTECTIVE MEASURES (m)........................................................................................... 10
3.7 WARNINGS ON HOW NOT TO USE THE MACHINE (h) .......................................................................... 11
3.8 SAFETY INSTRUCTIONS FOR MAINTENANCE, ADJUSTMENT, AND INSPECTION (s) .......................... 12
3.9 SAFETY INSTRUCTIONS FOR THE OWNER / OPERATOR ..................................................................... 12

FLAIL MOWER FR 92 –162
D
4. MACHINE DESCRIPTION, COMPONENTS AND SPECIFICATIONS................................................................. 13
4.1 MACHINE DESCRIPTION (d)...................................................................................................................13
4.2 USE OF THE MACHINE ...........................................................................................................................15
4.2.1 INTENDED USE OF THE MACHINE (g).......................................................................................... 15
4.2.2 APPLICATION AND RESTRICTIONS OF THE MACHINE (h) ........................................................... 15
4.3 MACHINE COMPONENTS / MAIN PARTS ..............................................................................................16
4.3.1 MAIN FRAME................................................................................................................................. 16
4.3.2 HYDRAULIC MOTOR WITH BELT DRIVE ....................................................................................... 16
4.3.3 DOUBLE SPIRAL ROTOR............................................................................................................... 17
4.3.4 REAR ROLLER............................................................................................................................... 17
4.3.5 FLAILS ........................................................................................................................................... 18
4.3.6 ADAPTER FOR TOOL CARRIERS ................................................................................................... 19
4.4 APPROVED TOOL CARRIERS (n) ............................................................................................................19
4.5 OPTIONAL EQUIPMENT ..........................................................................................................................20
4.5.1 MECHANICAL “QUICK-HITCH” (WITH SUPPORTING LEG) ........................................................... 20
4.5.2 QUICK COUPLING FOR HYDRAULIC CONNECTIONS ................................................................... 21
4.6 SPECIFICATIONS ....................................................................................................................................22
4.7 MEASUREMENT OF AIRBORNE NOISE (u) ............................................................................................23
5. INSTRUCTIONS FOR USE OF THE MACHINE (k)............................................................................................ 24
5.1 INSTRUCTIONS ON DELIVERY OF THE MACHINE .................................................................................24
5.2 INSTRUCTIONS FOR MOUNTING AND CONNECTION (j) .......................................................................24
5.2.1 PREPERATION OF THE VEHICLE .................................................................................................. 25
5.2.2 MOUNTING AND CONNECTION OF THE MACHINE (i) ................................................................. 25
5.2.3 MOUNTING OF FR FLAIL MOWER WITH “QUICK-HITCH” ............................................................ 26
5.2.4 STABILITY (o) ................................................................................................................................ 29
5.3 PREPARATION OF THE MACHINE FOR USE ..........................................................................................31
5.3.1 INITIAL START UP AND OPERATION............................................................................................. 31
5.3.2 PROCEDURES BEFORE OPERATING............................................................................................ 31
5.4 OPERATING THE MACHINE (e)...............................................................................................................31
5.4.1 TRAINING OF OPERATOR BEFORE USE....................................................................................... 31
5.4.2 THE OPERATOR’S WORKPLACE (f) .............................................................................................. 31

FLAIL MOWER FR 92 –162
E
5.4.3 TRANSPORTATION OF FR FLAIL MOWER ON TOOL CARRIERS (p) ............................................. 32
5.4.4 DRIVING INSTRUCTIONS .............................................................................................................. 33
5.4.5 SETTING AND ADJUSTING THE MACHINE (r) ............................................................................... 34
5.4.6 STARTING UP FR FLAIL MOWER WITH A GREENTEC SCORPION BOOM MOWER: .................... 36
5.4.7 TURNING OFF THE FR FLAIL MOWER ON THE GREENTEC SCORPION BOOM MOWER: ........... 36
5.4.8 START-UP AFTER ACCIDENTAL STOP (q) ..................................................................................... 37
6. INSPECTION AND MAINTENANCE (e, r)......................................................................................................... 38
6.1 INSTRUCTIONS ON SAFE MAINTENANCE AND ADJUSTMENT (s)........................................................ 38
6.2 DAILY AND ROUTINE MAINTENANCE (e) .............................................................................................. 39
6.3 TIGHTENING OF BOLTS AND HYDRAULIC CONNECTIONS................................................................... 40
6.3.1 TIGHTENING OF BOLTS ................................................................................................................ 40
6.3.2 TIGHTENING OF HYDRAULIC CONNECTIONS .............................................................................. 41
6.4 HYDRAULIC HOSES ............................................................................................................................... 42
6.5 LUBRICATION OF THE FR FLAIL MOWER.............................................................................................. 43
6.6 ADJUSTMENT AND REPLACEMENT OF BELT ON FR FLAIL MOWER ................................................... 44
6.7 REPLACING THE FLAILS ON THE FR FLAIL MOWER ............................................................................ 48
6.8 REPLACING THE BEARINGS ON THE FR FLAIL MOWER ...................................................................... 49
6.9 STORAGE OF THE MACHINE ................................................................................................................. 49
6.10 DISPOSAL OF MACHINE / MACHINE PARTS: ....................................................................................... 50
7. TROUBLESHOOTING: FR FLAIL MOWER........................................................................................................ 51
7.1 TROUBLESHOOTING PROCEDURES ..................................................................................................... 51

FLAIL MOWER FR 92 –162
F
TABLES AND FIGURES
TABLES IN THIS INSTRUCTION MANUAL
TABLE 1 –MACHINES COVERED BY DECLARATION OF CONFORMITY: FR FLAIL MOWER.................................................................................1
TABLE 2 –DECLARED INTERNATIONAL STANDARDS: FR FLAIL MOWER...........................................................................................................1
TABLE 3 –MACHINE DATA FORM ........................................................................................................................................................................2
TABLE 4 –CONTENTS OF THE MANUFACTURER’S PLATE ..................................................................................................................................3
TABLE 5 –DEFINITIONS, TERMS, AND DESCRIPTIONS IN THE INSTRUCTION MANUAL. ..................................................................................4
TABLE 6 –TYPES OF FLAILS: GREENTEC FR FLAILS MOWER.......................................................................................................................... 18
TABLE 7 –APPROVED TOOL CARRIERS: GREENTEC FR FLAIL MOWER.......................................................................................................... 19
TABLE 8 –DATASHEET AND SPECIFICATIONS: FR FLAIL MOWER................................................................................................................... 22
TABLE 9 –MOUNTING, CONNECTION, AND DISCONNECTION OF FR FLAIL MOWER...................................................................................... 27
TABLE 10 –DATA SHEET FOR HYDRAULIC CONNECTIONS. ............................................................................................................................ 28
TABLE 11 –REAR ROLLER SETTINGS: GREENTEC FR FLAIL MOWER............................................................................................................. 34
TABLE 12 –FRONT SAFETY GUARD - ADJUSTMENT OPTIONS: GREENTEC FR FLAIL MOWER....................................................................... 35
TABLE 13 –CHECKLIST FOR DAILY INSPECTIONS BEFORE OPERATION: FR FLAIL MOWER ......................................................................... 39
TABLE 14 –CHECKLIST FOR SEMI-ANNUAL INSPECTION - PREVENTIVE MAINTENANCE. ............................................................................. 40
TABLE 15 –TIGHTENING TORQUES FOR BOLTS: FR FLAIL MOWER ............................................................................................................... 40
TABLE 16 –TIGHTENING TORQUES FOR HYDRAULIC FITTINGS: FR FLAIL MOWER....................................................................................... 41
TABLE 17 –GUIDE FOR BELT ADJUSTMENT ON FR FLAIL MOWERS .............................................................................................................. 47
TABLE 18 –OVERVIEW OF DISPOSAL / SCRAPPING OF MACHINE PARTS. .................................................................................................... 50
TABLE 19 –IDENTIFICATIONS OF ERRORS: FR FLAIL MOWER........................................................................................................................ 51
FIGURES IN THIS INSTRUCTION MANUAL
FIGURE 1 –MANUFACTURER’S PLATE FOR GREENTEC MACHINES ..................................................................................................................3
FIGURE 2 –SAFETY LABELLING: PERSONAL SAFETY EQUIPMENT.....................................................................................................................5
FIGURE 3 –SAFETY LABELING: WARNING LABELS.............................................................................................................................................6
FIGURE 4 –PROPOSED SIGNAGE ON PUBLIC ROADS ........................................................................................................................................8

FLAIL MOWER FR 92 –162
1
DECLARATION OF CONFORMITY (c)
ACC. TO MACHINERY DIRECTIVE 2006/42/EC, ANNEX II.A
Manufacturer: GreenTec A/S
Company Adress: Merkurvej 25
Zip code and city: DK-6000 Kolding
We, GreenTec, declare under all responsibility that the machine:
TYPE:
PRODUCT:
CAN BE MOUNTED ON:
Flail Mower
FR 92
Scorpion 430
*Twiga Compact
FR 112
Scorpion 430
Scorpion 630
*Twiga Compact
FR 122
Scorpion 630
Scorpion 830
*Twiga Mid
*Twiga Flex
FR 162
Scorpion 630
Scorpion 830
*Twiga Mid
*Twiga Flex
Table 1 –Machines covered by declaration of conformity: FR Flail Mower
has been manufactured in accordance with the Machinery Directives 2006/42 / EC and 2014/68 / EU of
the European Parliament and of the Council with reference to the following standards associated with its
design, construction, and production:
NAME:
DECRIPTION:
DS/EN ISO 12100:2011
Machine safety - General principles for design - Risk assessment and risk
reduction
DS/EN 14120:2015
Safety of machinery - Guards - General requirements for the design and
construction of fixed and movable guards
DS/EN ISO 4413:2010
Hydraulic fluid power –General rules and safety requirements for systems
and their components.
Table 2 –Declared international standards: FR Flail Mower
The declaration is valid for the above equipment, up to and including the machine's connections, resp.
suspension and stabilization, power transmission and electrical connection.
When connecting the above equipment to a vehicle and/or to tools other than those mentioned above, it is
the responsibility of each owner and operator to ensure that the vehicle and the overall machine comply with
the applicable requirements of relevant directives.
Date: 18.01.2020
Signature: ___________________________
John Christensen
Owner GreenTec A/S
* Not included in this manual! Contact the machine manufacturer for further information regarding use, installation, safety, and risk
assessment

FLAIL MOWER FR 92 –162
2
Merkurvej 25
DK 6000 Kolding
Danmark
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Web: www.greentec.eu
Opening hours: mandag-fredag 8-16
1. MACHINE DATA AND USEFUL
INFORMATION (b)
Before the machine is used for the first time, the seller is responsible for ensuring that the buyer
receives this instruction manual.
The seller must also ensure that the buyer and operator fully understand the contents before using
the machine.
If the machine is resold, the instruction manual must be handed over to the new owner but must
always follow the machine.
The following fields are filled in, for use when ordering spare parts or other inquiries:
1.1 REGISTRATION OF MACHINE DATA
TO BE COMPLETED BY DEALERSHIP:
Name:
Serial number:
Date of Delivery:
Dealership:
E-mail:
Phone:
Table 3 –Machine data form
DEALER STAMP:

FLAIL MOWER FR 92 –162
3
1.2 MANUFACTURERS PLATE
All GreenTec machines are equipped with a
manufacturer’s plate.
The manufacturer’s plate contains
important information related to the
machine, including a unique serial number
used for identification.
CONTENT OF MANUFACTURER’S PLATE:
Type:
Machine model and type number.
Serial No.:
The machines unique serial number.
Prod. year:
Production year of the machine.
Weight:
Weight without optional equipment. (kg)
Model year:
Development year of the machine.
The plate also indicates the address information of the manufacturer.
Table 4 –Contents of the manufacturer’s plate
1.3 WARRANTY
To maintain GreenTec's 2-year warranty and product liability insurance, only genuine GreenTec spare parts
may be used on GreenTec machinery and equipment.
GreenTec is not liable for damage caused by illegal or incorrect use of the machine as well as incorrect
connection or connected equipment.
See GreenTec's warranty conditions in section 5 under the Terms and Conditions of Sale and Delivery
here: https://greentec.eu/en/terms-and-conditions-sale-and-delivery/
1.4 USE OF OTHER MANUFACTURERS OF TOOL CARRIERS
When mounting on tool carriers other than GreenTec’s, a new risk
assessment of the machine must be submitted.
If the machine is mounted on an unapproved tool carrier, the risk assessment
basis lapses, and thereby the validity and guarantee of the declaration of
conformity.
It is the responsibility of each operator to assess the risk of this
interconnection before using the machine.
Figure 1 –Manufacturer’s plate for GreenTec machines

FLAIL MOWER FR 92 –162
4
2. GENERAL INFORMATION
2.1 INSTRUCTIONS USING THIS MANUAL
Read this instruction manual carefully before mounting and commissioning the machine.
If in doubt, contact your local dealer or GreenTec - Aftersales department.
The illustrations in this instruction manual are for the sole purpose of
instructing, informing, and substantiating the general procedures and
instructions.
Illustrations may appear different from the current machine, e.g., by being
fitted with accessories and / or in a different size variant.
2.2 DEFINITION OF INFORMATION SIGNS
The following definitions apply to this entire instruction manual:
DANGER!
Warns of a potential situation that could result in death or permanent
disabling injuries if the regulations are not followed carefully!
WARNING!
Warns of a potential situation that could result in partially disabling injuries or
serious bodily injury if the regulations are not followed carefully!
CAUTION!
Warns of a potential situation that could result in serious damage to the
machine or equipment if the instructions are not followed carefully!
NOTICE!
Specific or general information that is deemed important or useful.
2.3 DEFINITIONS, TERMS AND DESCRIPTIONS
Operator:
Daily user and/or starter of the machine.
Owner:
Buyer, owner or those responsible for the operation and maintenance.
Attachment tool:
GreenTec FR Flail Mower, machine, or working tool handled and carried by tool
carrier during operation
Tool carrier:
GreenTec Scorpion Boom Mower, support arm, or lift that controls, handles and
carries the attachment tool during operation.
Vehicle:
Machine that transports tool carrier + attachment operation.
LH + RH:
Left Hand and Right Hand.
These terms are used when the machine is mounted on the vehicle, seen from
behind. These designations are also used when referring to the vehicle.
PTO:
Power Take Off-shaft from the vehicle to machine.
Table 5 –Definitions, terms, and descriptions in the instruction manual.

FLAIL MOWER FR 92 –162
5
3. SAFETY
3.1 LOCAL LEGISLATION IN THE COUNTRY OF USE
The use of the machine may be restricted by the laws of the countries in which it is used.
It is important that the responsible owner and operator familiarizes himself with the country's laws and
regulations regarding cutting, mowing and maintenance of fences and hedges.
3.2 WARNINGS, PROHIBITIONS AND INSTRUCTIONS
The instructions derive from the current national accident prevention regulations, which the operator and
operator must comply with:
For all types of work on the machine, this must be disconnected from all
hydraulics!
Only authorized personnel may perform service work on the machine!
Read the instruction manual carefully before using the machine!
3.3 SAFETY LABELLING
The machine is affixed with safety labels, these are located at the identified hazards to which one is exposed,
when working with, and staying near, the machine:
3.3.1 PERSONAL SAFETY EQUIPMENT–LABELS
It is recommended that the following safety equipment is used when working on or performing maintenance
on the machine:
WORKING SUIT
SAFETY SHOES
SAFETY GLASSES
HEARING
PROTECTION
SAFETY HELMET
PROTECTIVE
GLOVES
Figure 2 –Safety labelling: personal safety equipment
The recommended safety equipment, together with the points of attention mentioned in this and the
following sections, covers the precautions GreenTec has deemed necessary for use.
The varying circumstances that may occur while working with this machine cannot always be foreseen.
No good advice can replace "common sense", "timely care" and "paying attention", but the above
recommendations are a good start to the safe use of the GreenTec machine.

FLAIL MOWER FR 92 –162
6
3.3.2 WARNING LABELS
Warning labels that identify the dangers to which you are exposed when working and when staying near the
machine:
Warning!
Read the relevant instruction
manuals carefully before using this
machine.
Follow all instructions and safety
instructions when using the
machine.
Warning!
Danger of being hit by stones or
other objects hit by the flails.
Persons must keep a distance
from the machine when it is in
operation.
Warning!
Check for every 8 hours of use that
all bolts / nuts are tightened.
Warning!
Bearings and couplings etc. can be
damaged by persistent rain and
weathering.
Warning!
Beware of oil in case of skin contact
or inhalation of oil vapors, as well as
high pressure in case of leakage or
handling.
Switch off the engine, remove the
key and apply the parking brake
before maintenance or repair work.
Warning!
There is a risk of crushing and
collision when the machine is
running.
Keep distance! No one may stay in
the work zone during operation
Warning!
The machine continues to rotate
after stopping.
Keep a distance until the machine
is completely stationary. Remember
handbrake, and off engine.
Figure 3 –Safety labeling: warning labels

FLAIL MOWER FR 92 –162
7
3.4 OPERATING IN PUBLIC AREAS
When operating in publicly accessible areas, such as at roadside, the residence of others in the area must be
considered.
Stop the machine immediately when e.g., pedestrians, cyclists, riders, etc. are approaching the safety zone.
Only resume work when these are at a safe distance again.
When using the machine on public areas, the applicable traffic laws must be complied with at all events.
3.4.1 WARNING SIGNS IN PUBLIC AREAS
The operating area should be marked with appropriate signage, this is a legal requirement in public
areas.
Signage must be clearly and correctly placed so that the danger is made clear.
Contact the authorities for detailed information on current legislation.
Road authorities should be advised before starting work on public roads.
3.4.2 USE OF WARNING SIGNS
On two-way roads, warning signs are posted in both directions.
The work should be within 1 km of signage.
Only perform work when visibility is good and when the risk is low - e.g., outside rush hour.
The vehicle must be equipped with a flashing orange light boom.
Vehicles should be in a striking colour.
Material debris should be removed from the road and sidewalk as soon as practicable, and at
appropriate intervals.
The work must be carried out before removing warning signs and the operator must wear visible
clothing.
Collect all road signs as soon as the work is completed.

FLAIL MOWER FR 92 –162
8
3.4.3 PROPOSED SIGNS WHEN OPERATING ON PUBLIC ROADS:
Command sign
•”Hold left”
•White and blue arrow sign
•Sign visible on the back of the machine.
Warning sign:
•”Road work”
•Apply text for work performed with appropriate
distance.
•Example: ”Verge cutting 0-1 km”
Warning sign:
•”Road chicane”
•Apply following text:
o”One lane only”
Figure 4 –Proposed signage on public roads
The above signage applies within EU mainland where traffic passes to the left
of the machine working in the direction of travel.
Signage, use of, and colors on arrow signs as well as indications depend on
the language, laws, and regulations of each country.
VERGE CUTTING
0-1 KM
HOLD LEFT
ONE LANE ONLY

FLAIL MOWER FR 92 –162
9
3.5 RECOMMENDATIONS FOR OPTIMAL SAFETY AND
OPERATION (l)
Always be aware of the following risks when using the machine!
To achieve optimal safety and operation, it is important that the operator understands how dangerous the
machine is and anticipates the danger before it occurs:
You may get stuck when the machine is engaged or disconnected and when the tool carrier is moved
out or in, up or down and forward or back!
The machine can tip over when the tool carrier is raised!
You can be caught by the rotating shaft from the PTO!
You may be hit or caught by the moving parts, e.g., flails, knives, drive shaft and wings from mounted
attachment tools.
You may be hit by flying materials or machine parts in case of machine damage!
The machine can tip over, even when not in use!
The attachment tools are powered by hydraulic oil from the hydraulic system in the machine or from
the power-providing vehicle. The operator of the vehicle should have knowledge of how the hydraulic
oil should be handled! (Read in the safety data sheet for the oil)
High pressure oil spray from damaged fittings or hydraulic hoses can penetrate the skin and cause
serious injury!
Accident in case of collision with other vehicles or lost objects on the roads.
Always pay attention to overhead lines!
Between the electrical poles there will always be a risk of touching the overhead
lines. If in doubt - contact the local power plant for safety distance instructions.

FLAIL MOWER FR 92 –162
10
3.6 NECCESARY PROTECTIVE MEASURES (m)
The machine must be used in the following ways:
Make sure that the operator of the machine has read this instruction manual, as well as instruction
manuals for the tool carrier and used vehicle.
Make sure that the operator of the machine has been instructed in the use of the machine.
Wear hearing protection if the machine is operated from a cabin that is not soundproof or if the cabin
windows are open.
Make sure all warning labels are always visible and that none of them are missing, damaged or
illegible.
Check that all guards are fitted correctly and that there are no damaged or loose parts.
Make sure that all hydraulic pipes and hoses are positioned correctly to avoid rubbing, stretching,
squeezing, or breaking them.
Check the work area and remove any strings, poles, large stones, and other dangerous objects before
operation.
Drive at a safe speed adapted to the terrain as well as any other vehicles and obstacles.
Make sure that the vehicle is stable and meets the machine manufacturer's recommendations for
minimum weight - if necessary, use extra counterweight.
Pay attention to electric wires, if in doubt about distance contact local power plant.
It is recommended to use impact-resistant guards on the vehicle.
Check that the machine's fittings, connections, and couplings are in good condition.
Follow the manufacturer's instructions for removing and installing the machine from the vehicle.
Disconnect the hydraulics for the machine, stop the engine, apply the parking brake, and remove the
key before leaving the cab.
If necessary, remove annoying residual material from the area.
When inspecting, repairing or other work on the stationary machine, great care must be taken.
Always wear gloves, safety shoes, safety glasses and appropriate tools to carry out the work.

FLAIL MOWER FR 92 –162
11
3.7 WARNINGS ON HOW NOT TO USE THE MACHINE (h)
Do not use the machine in the following ways!
Do not operate the machine until the relevant instruction manuals have been read and understood!
The operator must also be familiar with the operating handles according to the instruction manual for
the connected tool carrier!
Do not operate the machine if there are others within machine safety distances!
Do not allow an inexperienced person to operate the machine unattended!
Do not walk within the working area / safety zone of the machine. (Risk of injury!)
Do not try to locate a leak in the hydraulics by hand, use a piece of cardboard instead!
At no time should children be allowed to play on or near the machine!
Do not perform any maintenance or adjustment without first removing the hydraulic pressure from the
machine, lowering the tool carrier to the ground, stopping the vehicle's engine, applying the parking
brake, and removing the key!
Do not use and / or mount the machine on a vehicle that does not meet the manufacturer's
specifications!
Do not use the machine if the hydraulic system shows signs of damage!
Do not stop the engine while the hydraulic pressure is activated!
Do not attempt to use the machine for any purpose other than that for which it was intended!
Do not leave the cab of the vehicle without removing the ignition key!
Do not transport the machine while the hydraulic pressure is activated!
Do not use a machine that is not maintained or if some of its guards are missing or damaged!
Do not operate the vehicle or any of the control levers from a position other than the driver's seat!
Do not drive with mounted machines where rotating parts are facing the cab of the vehicle, as this
poses a risk of stones and material being thrown at the driver!

FLAIL MOWER FR 92 –162
12
3.8 SAFETY INSTRUCTIONS FOR MAINTENANCE,
ADJUSTMENT, AND INSPECTION (s)
The machine must be maintained in the following ways:
The operator must ensure that all maintenance, inspection, and installation work is carried out by
authorized and qualified professionals who, after reading the relevant instruction manuals, are in
possession of sufficient knowledge.
Maintenance, inspection, and installation work may only be carried out with the hydraulics
disconnected.
When carrying out maintenance work under the tool carrier, secure with suitable support elements.
When replacing machines, check the hydraulic system for residual pressure.
A possible residual pressure is reduced to zero. (0 bar)
Use only suitable tools and wear heavy gloves, safety shoes and glasses.
Handle the hydraulic oil and grease properly. Always be familiar with the safety data sheets.
Immediately after completion of work, all safety and protection devices must be fitted and reactivated.
3.9 SAFETY INSTRUCTIONS FOR THE OWNER / OPERATOR
It is important to familiarize yourself with all controls and equipment as well as their function before
starting the work. If the work has only begun, it may be too late.
Check the immediate area before starting and during operation of the work the machine must
perform. (People, children, animals, or obstacles such as stones, fence posts, steel wire).
Ensure adequate visibility and illuminated work area. The safety distance specified in the machine’s
instruction manual must be strictly observed.
The operator's clothing must be tight. Avoid loose clothing.
The operator must be fresh and rested before using the machine, as well as taking breaks in case of
fatigue, to ensure their own and others' safety.
The operator should ensure varying working positions and take frequent breaks to avoid
musculoskeletal disorders.
The operator must not leave the driver 's seat while driving.
It is not permitted to “ride along” on the machine during transport and operation.
When working on high-voltage power lines, additional distance and caution are required.
