GreenTec SCORPION 530 S User manual

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
REDSKABSRAMME 2302 –2802 –3302
1. EDITION

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
A
SCORPION 5-830 S/PLUS
(530 S, 530 PLUS, 630 S, 630 PLUS, 730 S, 730 PLUS, 830 S & 830 PLUS)
INSTRUCTION MANUAL
1. EDITION –SEPTEMBER 2022
(ORIGINAL VERSION)
! IMPORTANT !
For correct operation, this GreenTec Scorpion 5-830 boom mower must be mounted on an approved vehicle
with an approved GreenTec attachment tool.
It is important that the operator is given both the instruction manual, spare parts book, and all other relevant
technical documentation for both the boom mower, attachment tool and vehicle before the machine is put
into use for the first time.
It is important that the operator fully understands the contents of the instruction material before using the
machine.
This instruction manual must accompany the machine and must always be available to the operator.
In case of later resale of the machine, all relevant technical documentation must be handed over to the new
owner.
The content of the instruction manual is based on information, standards, and regulations, valid at the time
of publication.
As our products are under continuous development and improvement, changes to the specifications may
occur.
If there is information that differs from the current machine, updated instructions can be found on our
webpage or by contacting GreenTec - Aftersales department at: [email protected]
MANUFACTURER, NAME AND ADDRESS (a)
Merkurvej 25
DK-6000 Kolding
Danmark
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Web: www.greentec.eu

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
B
PREFACE
Dear Customer!
Your new GreenTec machine is designed based on almost 30 years of experience with vehicle-mounted
machines for maintaining green areas.
The machine is manufactured based on the latest technology and approved safety regulations, standards
and regulations.
We want to make a product available in a way that does not cause damage or misunderstandings either
during use, during transport or during maintenance of the machine.
The instruction manual contains information and instructions that are important and useful for maintaining
the operational safety, reliability and value of the GreenTec machine.
Therefore, read this instruction manual carefully, as it will make you familiar with assembly, use, care and
maintenance. Pay particular attention to instructions regarding safety!
You are welcome to visit our website www.greentec.eu - where you can find technical documentation and
access the latest updates to instruction- and spare parts books on our entire product range.
We hope that you will be satisfied with your new GreenTec machine!
Kind regards:
Signature:___________________________
John Christensen
Co-owner, Product Development
GreenTec A/S
GreenTec’s vision is to develop and sell quality machines for the maintenance of green areas, i.e. in agriculture, industry, airports and
the municipal sector. Through innovative product development, we strive to become a leader in our field.
All machines are developed in a simple, functional, and production-friendly design in close cooperation with dealers and end users. It is
our goal to cover all needs in the market segment with a minimum of 2 different proposed solutions.
Through in-depth analysis and counseling, the customer must be offered the best possible solution, where individual needs can also be
met through the modular structure of the product range.
The aim is also to offer the best possible after-sales service and a fast and efficient supply of spare parts.

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
C
CONTENTS
MANUFACTURER, NAME AND ADDRESS (A)........................................................................................................................................................ A
PREFACE ...............................................................................................................................................................................................................B
LIST OF TABLES AND FIGURES ............................................................................................................................................................................G
DECLARATION OF CONFORMITY (C)..................................................................................................................................................................... 1
1. MACHINE DATA AND USEFUL INFO (B) .....................................................................................................................................................2
1.1 REGISTRATION OF GREENTEC MACHINE DATA ............................................................................................................................. 2
1.2 NAME PLATE.................................................................................................................................................................................... 3
1.3 WARRANTY TERMS ......................................................................................................................................................................... 3
1.4 COMPLAINTS................................................................................................................................................................................... 4
1.5 USE WITH OTHER MANUFACTURES THAN GREENTEC .................................................................................................................. 4
2. GENERAL INFORMATION ...........................................................................................................................................................................5
2.1 USE OF THE INSTRUCTION MANUAL .............................................................................................................................................. 5
2.2 DEFINITIONS OF INFORMATION SIGNS.......................................................................................................................................... 5
2.3 DEFINITIONS, TERMS AND DESCRIPTIONS ................................................................................................................................... 5
3. SAFETY .......................................................................................................................................................................................................6
3.1 LOCAL LEGISLATION IN THE COUNTRY WHERE THE MACHINE IS USED ...................................................................................... 6
3.2 WARNINGS, PROHIBITIONS, AND INSTRUCTIONS ......................................................................................................................... 6
3.3 SAFETY LABELING........................................................................................................................................................................... 6
3.3.1 PERSONAL SAFETY EQUIPMENT –LABELS .............................................................................................................................. 6
3.3.2 WARNING LABELS ..................................................................................................................................................................... 7
3.4 WORKING IN PUBLICLY ACCESSIBLE PLACES ............................................................................................................................... 9
3.4.1 WARNINGS SIGNS IN PUBLIC PLACES...................................................................................................................................... 9
3.4.2 USE OF WARNINGS SIGNS ........................................................................................................................................................9
3.4.3 SUGGESTED SIGNAGE WHEN WORKING ON PUBLIC ROADS................................................................................................10
3.5 RECOMMENDATIONS FOR OPTIMAL SECURITY AND OPERATION (L) .........................................................................................11
3.6 NECESSARY SAFETY MEASURES (M) ...........................................................................................................................................12
3.7 WARNINGS ON HOW THE MACHINE MUST NOT BE USED (H) ....................................................................................................13
3.8 SAFETY INSTRUCTIONS FOR MAINTENANCE, ADJUSTMENT, AND INSPECTION WORK (S) .......................................................14
3.9 SAFETY INSTRUCTIONS FOR THE OPERATOR / USER .................................................................................................................14
4. MACHINE DESCRIPTION, COMPONENTS AND SPECIFICATIONS............................................................................................................15
4.1 MACHINE DESCRIPTION (D) .........................................................................................................................................................15
4.2 USE OF THE MACHINE ..................................................................................................................................................................18
4.2.1 INTENDED USE OF THE MACHINE (G).....................................................................................................................................18
4.2.2 APPLICATION AND RESTRICTIONS OF THE MACHINE (H) ......................................................................................................18

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
D
4.3 COMPONENTS / MAIN PARTS OF THE MACHINE.........................................................................................................................19
4.3.1 MAIN FRAME IN HIGH STRENGHT STEEL .............................................................................................................................. 19
4.3.1.1 SUPPORT STANDS........................................................................................................................................................ 20
4.3.2 OIL TANK AND RETURN OIL FILTER........................................................................................................................................ 21
4.3.2.1 RETURN OIL FILTER ..................................................................................................................................................... 21
4.3.3 TECHNICAL CABINET (HYDRAULIC AND ELECTRICAL) ........................................................................................................... 22
4.3.3.1 PVG VALVE BLOCK ....................................................................................................................................................... 23
4.3.3.2 ACCUMULATOR FOR HYDRAULIC FLOAT OF ARM ....................................................................................................... 23
4.3.3.3 LOCKING VALVES FOR TRANSPORT ............................................................................................................................ 24
4.3.3.4 SHUT-OFF VALVE FOR TOOL SHIFT.............................................................................................................................. 24
4.3.3.5 ELECTRICAL CABINET (SWITCH BOARD AND POWER SUPPLY).................................................................................. 25
4.3.3.6 OIL COOLER.................................................................................................................................................................. 26
4.3.3.7 HIC-VALVE BLOCK (HYDRAULIC INTERNAL CIRCUIT) .................................................................................................. 26
4.3.4 GEARBOX, PTO-SHAFT & HYDRAULIC PUMP.......................................................................................................................... 27
4.3.4.1 GEARBOX...................................................................................................................................................................... 28
4.3.4.2 PTO-SHAFT.................................................................................................................................................................... 29
4.3.4.3 HYDRAULIC PUMP........................................................................................................................................................ 30
4.3.4.4 HIGH PRESSURE FILTER.............................................................................................................................................. 31
4.3.5 HYBRID ARM SYSTEM W/ DUAL FUNCTION AND HYDRAULIC COLLISION PROTECTION (AHS) ........................................... 32
4.3.5.1 HYDRAULIC COLLISION PROTECTION (AHS: AUTOMATIC HYDRAULIC SECURITY)..................................................... 34
4.3.5.2 INDUCTIVE SAFETY SENSORS ..................................................................................................................................... 35
4.3.6 ROTORFLEX DOUBLE PIVOT SYSTEM W/ AUTOFLEX (PLUS-MODELS) ................................................................................. 37
4.3.7 CONTROL PANEL AND JOYSTICK............................................................................................................................................ 38
4.3.7.1 LOGITEC SAFE CONTROL PANEL ................................................................................................................................. 39
4.3.7.2 DANFOSS JOYSTICK..................................................................................................................................................... 46
4.4 APPROVED ATTACHMENT TOOLS AND OPTIONAL EQUIPMENT (N)............................................................................................48
4.5 OPTIONAL EQUIPMENT .................................................................................................................................................................49
4.5.1 4-POINT LINKAGE SYSTEM (CATEGORY 2, 3 & 4) ................................................................................................................. 49
4.5.1.1 UPPER STABILIZATION................................................................................................................................................. 50
4.5.1.2 LOWER STABILIZATION ................................................................................................................................................ 52
4.5.1.3 CUSTOM TOWING BRACKETS:..................................................................................................................................... 53
4.5.2 AHC (AUTO HEIGHT CONTROL) ............................................................................................................................................... 54
4.5.3 HYDRAULIC QUICK-RELEASE COUPLINGS ............................................................................................................................. 55
4.5.4 MECHANICAL QUICK COUPLING............................................................................................................................................. 56
4.5.5 COUNTERWEIGHTS (430 KG)................................................................................................................................................. 57
4.5.6 LEAF BLOWER (LG) ................................................................................................................................................................. 58
4.5.7 BIO HYDRAULIC OIL ................................................................................................................................................................ 59
4.5.8 FILTER KIT INCL. SEALS.......................................................................................................................................................... 60
4.6 SPECIFICATIONS............................................................................................................................................................................61
4.6.1 POSITIONS AND REACH OF BOOM BOWER............................................................................................................................ 63
4.7 NOISE MEASUREMENT OF AIRBORNE NOISE (U) ........................................................................................................................65
5. INSTRUCTIONS FOR USING THE MACHINE (K) ...................................................................................................................................... 66
5.1 INSTRUCTIONS REGARDING DELIVERY OF THE MACHINE..........................................................................................................66

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
E
5.2 INSTRUCTIONS ON MOUNTING, CONNECTING AND DISCONNECTING (J).................................................................................. 68
5.2.1 PREPARATION OF VEHICLE AND OPERATOR ..........................................................................................................................68
5.2.2 MOUNTING AND CONNECTING THE MACHINE (I)...................................................................................................................69
5.2.2.1 MOUNTING ON VEHICLE WITH 4-POINT LINKAGE SYSTEM ........................................................................................69
5.2.3 CONNECTING THE POWER SUPPLY FROM THE BOOM MOWER TO THE VEHICLE................................................................79
5.2.4 INSTALLING AND MOUNTING CONTROL PANEL AND JOYSTICK ............................................................................................80
5.2.4.1 GENERAL PRINCIPLES FOR INSTALLATION OF CONTROL PANEL AND JOYSTICK ......................................................80
5.2.5 MOUNTING OF ATTACHMENT TOOLS ON BOOM MOWER......................................................................................................85
5.2.6 UN-MOUNT AND DISCONNECT BOOM MOWER FROM VEHICLE............................................................................................89
5.2.7 UN-MOUNT AND DISCONNECT ATTACHMENT TOOL ON BOOM MOWER...............................................................................89
5.3 PREPARING THE MACHINE FOR USE ...........................................................................................................................................90
5.3.1 INITIAL START-UP AND FIRST USE OF THE MACHINE.............................................................................................................90
5.3.2 PROCEDURES BEFORE USING THE MACHINE........................................................................................................................90
5.3.3 STABILITY (O) ...........................................................................................................................................................................90
5.3.3.1 CHECKING THE STABILITY............................................................................................................................................91
5.3.3.2 STABILITY CAN BE INCREASED BY: ..............................................................................................................................91
5.3.3.3 FACTORS INFLUENCING THE STABILITY ......................................................................................................................91
5.4 OPERATING THE MACHINE (E)......................................................................................................................................................92
5.4.1 TRAINING OF THE MACHINE OPERATOR BEFORE USE ..........................................................................................................92
5.4.2 OPERATOR’S WORKPLACE (F).................................................................................................................................................92
5.4.3 TRANSPORTING BOOM MOWER W/ ATTACHMENT TOOL ON VEHICLE (P) ...........................................................................93
5.4.4 OPERATING AND DRIVING INTRUCTIONS ...............................................................................................................................95
5.4.5 ADJUSTING AND SETTING THE MACHINE (R) ...................................................................................................................... 105
5.4.6 STARTING ATTACHMENT TOOLS .......................................................................................................................................... 107
5.4.7 STOPPING ATTACHMENT TOOLS.......................................................................................................................................... 108
5.4.8 START-UP AFTER UNINTENDED / ACCIDENTAL STOPPAGE OF OPERATION Q).................................................................. 109
6. SERVICE AND MAINTENANCE (E, R)..................................................................................................................................................... 110
6.1 INSTRUCTIONS ON SAFE SERVICE AND MAINTENANCE (S)......................................................................................................111
6.1.1 MOVING YOUR GREENTEC MACHINES ................................................................................................................................ 111
6.2 DAILY- AND ROUTINE INSPECTIONS (E) .....................................................................................................................................112
6.3 REPLACING FILTER ELEMENTS ..................................................................................................................................................113
6.3.1 RETURN OIL FILTER REPLACEMENT.................................................................................................................................... 114
6.3.2 HIGH PRESSURE FILTER REPLACEMENT ............................................................................................................................ 115
6.4 CHANGING HYDRAULIC- AND GEARBOX OIL..............................................................................................................................115
6.4.1 CHANGING THE GEARBOX OIL ............................................................................................................................................. 116
6.4.2 CHANGING THE HYDRAULIC OIL .......................................................................................................................................... 117
6.5 CHECKING THE PRESSURE SPECIFICATIONS............................................................................................................................118
6.6 TESTING THE HYDRAULIC COLLISION PROTECTION (AHS: AUTO HYDRAULIC SECURITY) ......................................................119

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
F
6.6.1 ”PUSH”-TEST ......................................................................................................................................................................... 120
6.7 TESTING THE HYDRAULIC FLOAT FUNCTION (ARM).................................................................................................................. 121
6.8 TIGHTENING TORQUES OF BOLTS AND HYDRAULIC CONNECTIONS ....................................................................................... 122
6.8.1 TIGHTENING TORQUES: BOLTS ............................................................................................................................................ 122
6.8.2 TIGHTENING TORQUES: HYDRAULIC CONNECTIONS........................................................................................................... 122
6.9 HYDRAULIC HOSES .................................................................................................................................................................... 123
6.10 BUSHINGS, RIVETS AND BEARINGS.......................................................................................................................................... 124
6.11 LUBRICATION OF THE MACHINE................................................................................................................................................ 124
6.11.1 PTO SHAFT LUBRICATION................................................................................................................................................ 125
6.12 CLEANING / WASHING THE MACHINE....................................................................................................................................... 125
6.13 STORAGE OF THE MACHINE....................................................................................................................................................... 126
6.14 DISPOSAL OF MACHINE/MACHINE PARTS................................................................................................................................ 126
7. TROUBLESHOOTING.............................................................................................................................................................................. 127
7.1 TROUBLESHOOTING PROCEDURES........................................................................................................................................... 127
8. APPENDIX .............................................................................................................................................................................................. 129
8.1 HYDRAULIC DIAGRAMS.............................................................................................................................................................. 129
8.1.1 SCORPION 5-830 STANDARD............................................................................................................................................... 129
8.1.2 SCORPION 5-830 PLUS ........................................................................................................................................................ 130
8.2 ELECTRICAL DIAGRAMS............................................................................................................................................................. 131

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
G
LIST OF TABLES AND FIGURES
TABLES IN THIS INSTRUCTION MANUAL
TABLE 1 –MACHINES COVERED BY DECLARATION OF CONFORMITY...............................................................................................................1
TABLE 2 –DECLARED INTERNATIONAL STANDARDS .........................................................................................................................................1
TABLE 3 –MACHINE DATA: FORM.......................................................................................................................................................................2
TABLE 4 –CONTENT OF GREENTEC NAME PLATE.............................................................................................................................................. 3
TABLE 5 –DEFINITIONS, TERMS AND DESCRIPTIONS....................................................................................................................................... 5
TABLE 6 –OVERVIEW OF STANDARD EQUIPMENT ...........................................................................................................................................17
TABLE 7 –OVERVIEW OF ADDITIONAL EQUIPMENT AND OPTIONS .................................................................................................................17
TABLE 8 –SPEC. SHEET: RETURN OIL-FILTER ..................................................................................................................................................21
TABLE 9 –SPEC. SHEET: ELECTRICAL SYSTEM................................................................................................................................................25
TABLE 10 –SPEC. SHEET: GEARBOX ................................................................................................................................................................28
TABLE 11 –SPEC. SHEET: PTO-SHAFT ..............................................................................................................................................................29
TABLE 12 –SPEC. SHEET: HYDRAULIC GEAR PUMP: SCORPION 5-830 STANDARD......................................................................................30
TABLE 13 –SPEC. SHEET: HYDRAULIC GEAR PUMP: SCORPION 5-830 PLUS................................................................................................30
TABLE 14 –SPEC. SHEET: HIGH PRESSURE FILTER ........................................................................................................................................31
TABLE 15 –FUNCTIONS OF HYDRAULIC CYLINDERS (CYLINDER 1-5) ............................................................................................................33
TABLE 16 –APPROVED ATTACHMENT TOOLS AND OPTIONAL EQUIPMENT....................................................................................................48
TABLE 17 –TYPES OF 4-POINT LINKAGE: UPPER STABILIZATION WITH TOP BAR ..........................................................................................50
TABLE 18 –TYPES OF 4-POINT LINKAGE: UPPER STABILIZATION WITH K80 COUPLING ...............................................................................51
TABLE 19 –TYPES OF 4-POINT LINKAGE: UPPER STABILIZATION WITH ZUGMAUL HITCH.............................................................................51
TABLE 20 –TYPES OF 4-POINT LINKAGE: LOWER STABILIZATION WITH DRAWBAR.......................................................................................52
TABLE 21 –TYPES OF 4-POINT LINKAGE: LOWER STABILIZATION WITH ZUGMAUL HITCH ............................................................................52
TABLE 22 –TYPES OF 4-POINT LINKAGE: LOWER STABILIZATION WITH K80 COUPLING ..............................................................................53
TABLE 23 –TYPES OF “FLAT-FACE” QUICK-RELEASE COUPLINGS ON THE MACHINE ....................................................................................55
TABLE 24 –SPECIFICATIONS: LEAF BLOWER (LG) ...........................................................................................................................................58
TABLE 25 –FILTER ELEMENTS (HYDRAULIC) ...................................................................................................................................................60
TABLE 26 –MACHINE SPECIFICATION DATA SHEET.........................................................................................................................................62
TABLE 27 –VERTICAL REACH OF BOOM MOWER (1/2)...................................................................................................................................63
TABLE 28 –HORISONTAL REACH OF BOOM MOWER (2/2) .............................................................................................................................64
TABLE 29 –MEASUREMENT OF A-WEIGHTED SOUND POWER LEVEL (>80 DB) ............................................................................................65
TABLE 30 –COMPONENT LIST: 4-POINT LINKAGE SYSTEM.............................................................................................................................70
TABLE 31 –COMPONENTS LIST: MOUNTING KIT FOR CONTROL PANEL AND JOYSTICK ...............................................................................80
TABLE 32 –CHECKLIST FOR DAILY INSPECTIONS ........................................................................................................................................ 112
TABLE 33 –CHECKLIST FOR 6 MONTH INSPECTION: PREVENTIVE MAINTENANCE .................................................................................... 113

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
H
TABLE 34 –INTERVALS FOR CHANGING FILTER ELEMENTS......................................................................................................................... 114
TABLE 35 –INTERVALS FOR CHANGING HYDRAULIC AND GEARBOX OIL .................................................................................................... 115
TABLE 36 –TIGHTENING TORQUES FOR BOLTS AND NUTS.......................................................................................................................... 122
TABLE 37 –TIGHTENING TORQUES FOR HYDRAULIC CONNECTIONS .......................................................................................................... 122
TABLE 38 –OVERVIEW OF THE DISPOSAL/SCRAPPING OF MACHINE PARTS.............................................................................................. 126
TABLE 39 –IDENTIFYING ERRORS / FAULTY CONDITIONS ........................................................................................................................... 128
FIGURES IN THIS INSTRUCTION MANUAL
FIGURE 1 –NAME PLATE FOR GREENTEC MACHINE..........................................................................................................................................3
FIGURE 2 –SAFETY LABELLING: PERSONAL SAFETY EQUIPMENT.....................................................................................................................6
FIGURE 3 –SAFETY LABELING: WARNING LABELS.............................................................................................................................................7
FIGURE 4 –WARNING LABELS: PTO-SHAFT ........................................................................................................................................................8
FIGURE 5 –WARNING LABELS: TRANSPORT LOCK / STOP VALVES ..................................................................................................................8
FIGURE 6 –PROPOSED SIGNAGE FOR WORK ON PUBLIC ROADS.................................................................................................................. 10

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
1
DECLARATION OF CONFORMITY (c)
MACHINERY DIRECTIVE 2006/42/EC ANNEX II.A
MANUFACTURER: GreenTec A/S
ADDRESS: Merkurvej 25
CITY: DK-6000 Kolding
We, GreenTec A/S, declare under all responsibility that the machine:
TYPE:
PRODUCT:
TO BE MOUNTED WITH:
Boom Mower
Scorpion 5–830 Standard
9992530R-85S, 9992630R-85S,
9992730R-85S, 9992830R-85S
Scorpion 5–830 Plus
9992530R-85P, 9992630R-85P,
9992730R-85P, 9992830R-85P
Flail Mower FR 122 & FR 162
Flail Mower FR 122 B
Quadsaw LRS 2002 & 2402
Rotary Hedge Cutter RC 162
Rotary Mulcher RM 232
Cutterbar HX 170 –270
Cutterbar HS 212 & 242
Rotary Crusher GT 135
Grass Cutterbar S 165 –240
Weed Clearing Brush BR 90
Rotary Ditch Cleaner GR 70
Table 1 –Machines covered by declaration of conformity
is manufactured in accordance with European Parliament and Council Directive 2006/42/EC and
2014/68/EU with references to the following standards associated with its design, construction, and
production:
NAME:
DESCRIPTION:
DS/EN ISO 12100:2011
Safety of machinery - General principles for design - Risk assessment and risk
reduction
DS/EN 14120:2015
Safety of machinery –Guards - General requirements for the design and
construction of fixed and movable guards
DS/EN ISO 4413:2010
Hydraulic fluid power - General rules and safety requirements for systems and
their components
Table 2 –Declared international standards
The declaration applies to the above-mentioned machines, including the machine's connections, or
suspension and stabilization, power transmission and electrical connection.
When connecting the above-mentioned machines to a vehicle and/or with attachment tools other than those
mentioned above, it is the responsibility of every operator and operator to ensure that the vehicle and the
assembled machine meet the applicable requirements in the relevant directives for this.
Date: 01.07.2022
Signature:___________________________
John Christensen
Co-owner, Product Development
GreenTec A/S

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
2
Merkurvej 25
DK-6000 Kolding
Danmark
Tel: [phone]
E-mail: [email protected]
Web: www.greentec.eu
Opening hours: mon-fri (08:00-16:00)
1. MACHINE DATA AND USEFUL INFO (b)
Before the machine is put into use for the first time, the importer/retailer is responsible for ensuring that the
buyer receives this document and that the machine is correctly registered via the Extranet on GreenTec's
website: https://greentec.eu/user
If in doubt regarding login information, please contact GreenTec –Aftersales & Service: [email protected]
The dealer/importer must also ensure that the buyer and operator fully understand the contents before the
machine is put into use.
If the machine is re-sold, all the supplied technical documentation must be handed over to the new owner
and must also always accompany the machine.
The fields below are filled in, for future use when ordering spare parts or other enquiries:
1.1 REGISTRATION OF GREENTEC MACHINE DATA
! THESE DATA MUST ALSO BE ENTERED VIA LOGIN IN THE GREENTEC EXTRANET BY DEALER !
Machine
description:
Serial number:
Date of delivery:
Importer and/or
dealer:
E-mail:
Phone:
Table 3 –Machine data: form
DEALER STAMP

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
3
1.2 NAME PLATE
Alle All GreenTec's machines are equipped
with a name plate.
The nameplate contains important
information relating to the machine,
including a unique serial number used for
identification.
CONTENT OF THE NAME PLATE:
Type:
Machine model and type number
Serial No.:
Unique serial number of the machine
Prod. year:
Production year
Weight:
Weight of the machine without optional equipment (kg.)
Model year:
The year of development of the machine model.
The nameplate also provides address information for the manufacturer.
Table 4 –Content of GreenTec name plate
1.3 WARRANTY TERMS
For at opretholde GreenTec’s 2-årige garanti samt produktansvarsforsikring, må der kun anvendes originale
GreenTec reservedele på GreenTec maskiner og udstyr.
GreenTec is not liable for damage caused by illegal or incorrect use of the machine as well as incorrect
connection or connected equipment, or by incorrect maintenance of the machine.
If GreenTec provides a warranty, the warranty must cover defective design, materials, and workmanship.
A warranty issued by GreenTec does not cover faults and defects caused by insufficient maintenance,
incorrect installation, changes made by a third party (end customer, customs etc.) due to incorrect use /
handling of the goods.
GreenTec assumes no other responsibility for such errors. This applies to losses resulting from such a
deficiency, including loss of profit, lost earnings, and other financial loss.
In addition, a warranty does not cover normal wear and tear. GreenTec's warranty obligation is conditioned
on the customer documenting that an identified fault or deficiency is not due to circumstances that are
exempt from the warranty, cf. above mentioned.
The customer must notify GreenTec in writing of errors or defects in the sold goods no later than eight days
after the error was or should have been registered by the customer. If the customer does not notify GreenTec
before the end of the time limit and the warranty period, the customer is not entitled to submit claims
regarding errors or defects.
GreenTec is entitled and obliged to remedy all errors and defects that are covered by a guarantee/warranty
from GreenTec. GreenTec shall be free to determine whether such remedy shall be in the form of repair or
replacement of the defective part(s) under the conditions set forth in Section 1.4 of this document.
The road/traffic regulations must be followed! Remember to place lights and warning triangles etc. Transport
wheels are used for vehicles with too wide a width.
A 24-month warranty is granted on new machines from the date of delivery of the machine. However, no
compensation is provided for driving or other consequential damages.
Figure 1 –Name plate for GreenTec machine

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
4
Warranty work is settled per hour at a standard rate of DKK 450/hour. = 60 euros/hour.
Hydraulics, gear oil, fuel and various propellants are not covered by the warranty. When using non-original
spare parts, GreenTec waives product liability and further warranty liability.
Guaranteed parts, unless otherwise agreed, are returned free of charge to GreenTec's service department no
later than 14 days after replacement.
Please read through GreenTec's overall terms and conditions of sale and delivery here:
https://greentec.eu/en/terms-and-conditions-sale-and-delivery
1.4 COMPLAINTS
Risk for the goods is transferred to the customer immediately upon delivery. Complaints about goods must
be made in writing and submitted to GreenTec without undue delay and no later than 8 days after delivery. If
GreenTec has not received a complaint within the mentioned time limit, the customers lose all rights to
complain about the quantity and quality of the goods delivered.
GreenTec has the right and obligation to remedy all errors resulting from defective design, materials, and
workmanship.
GreenTec decides whether the remedy must be in the form of repair or replacement of the defective part(s).
If GreenTec chooses to repair the goods, the customer is obliged to deliver and collect the goods from a
workshop indicated by GreenTec, without GreenTec incurring costs in this context.
If GreenTec chooses to replace the defective part(s), customers must send the defective part(s) to GreenTec
without GreenTec incurring costs in this regard. Instead, GreenTec is entitled to supply replacement goods.
GreenTec's liability only applies to defects, in connection with the sold goods, which are indicated within 2
years from the delivery date.
GreenTec assumes no responsibility for defects that exceed what is stipulated in this provision. This applies
to losses resulting from such a deficiency, including loss of profit, lost earnings, and other financial loss.
1.5 USE WITH OTHER MANUFACTURES THAN GREENTEC
When installing other makes of attachment tools than GreenTec, a new risk
assessment of the equipment used must be submitted.
If the boom mower is fitted with an unapproved attachment tool, the basis for
risk assessment will no longer apply, and thereby the validity and guarantee
of the declaration of conformity.
It is every operator's own responsibility to risk assess this interconnection
before using the machine.

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
5
2. GENERAL INFORMATION
2.1 USE OF THE INSTRUCTION MANUAL
Read this instruction manual thoroughly before assembling and putting the machine into use. If you have any
questions, contact your local dealer or GreenTec - Aftersales department.
The illustrations in this instruction manual have the sole purpose of
instructing, informing, and substantiating the general procedures and
instructions.
Illustrations may appear different from the actual machine, e.g., by being
fitted with additional equipment and/or in a different size variant.
2.2 DEFINITIONS OF INFORMATION SIGNS
The following definitions apply throughout this instruction manual:
DANGER!
Warns of a potential situation that could result in death or permanent
disabling injury if instructions are not followed carefully!
WARNING!
Warns of a potential situation that could result in partially disabling injuries or
serious bodily injury if the instructions are not followed carefully!
CAUTION!
Warns of a potential situation that could result in serious damage to the
machine or equipment if the instructions are not followed carefully!
NOTICE!
Specific or general information deemed important or useful.
2.3 DEFINITIONS, TERMS AND DESCRIPTIONS
Operator:
Daily user and/or operator of the machine.
Owner:
Owner, buyer and/or those who are responsible for the operator and maintenance.
Boom mower:
GreenTec boom mower, support arm / lift arm which controls, handles, and carries
attachment tools during operation.
Attachment tool:
GreenTec attachment tool that is handled and carried by boom mower during
operation.
Vehicle:
Machine that transports boom mower + attachment tool during operation.
LH + RH:
Left Hand (LH) and Right Hand (RH)
These designations are used when the machine is mounted on the vehicle, seen from
the rear. Follow designations are also used when referring to the vehicle.
Table 5 –Definitions, terms and descriptions

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
6
3. SAFETY
3.1 LOCAL LEGISLATION IN THE COUNTRY WHERE THE
MACHINE IS USED
The use of the machine may be restricted by the legislation of the countries where it is used. It is important
that the responsible owner and operator familiarize themselves with the country's laws and regulations
regarding cutting, cutting and maintenance of fences and hedges.
3.2 WARNINGS, PROHIBITIONS, AND INSTRUCTIONS
Instructions come from the applicable national accident prevention regulations, which the operator and
operator must comply with.
For all types of work on the machine, it must be disconnected from all
hydraulics!
Only authorized personnel may carry out service and maintenance on the
machine!
Read the instruction manual carefully before using the machine!
3.3 SAFETY LABELING
The machine is marked with safety and warning labels, these are placed at the identified dangers to which
you are exposed when working with and staying near the machine.
3.3.1 PERSONAL SAFETY EQUIPMENT –LABELS
It is recommended that the following safety equipment is worn when working with or performing maintenance
on the machine:
WORKING SUIT
SAFETY SHOES
SAFETY GLASSES
HEARING
PROTECTION
SAFETY HELMET
PROTECTIVE
GLOVES
Figure 2 –Safety labelling: personal safety equipment
The recommended safety equipment together with the points of attention mentioned in this and the following
section cover the precautions GreenTec has deemed necessary for use.
The varying circumstances that may arise when working with this machine cannot always be predicted.
No good advice can replace "common sense", "due care" and "attention", but the above recommendations
are a good start to safe use of the GreenTec machine.

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
7
3.3.2 WARNING LABELS
Warning labels that identify the dangers to which you are exposed when working with and when staying near
the machine:
WARNING LABELS: USE OF MACHINE
Warning!
Read relevant instruction manuals
carefully before using this machine.
Follow all instructions and safety
regulations when using the
machine.
Warning!
Always pay attention to overhead
lines! Between the electricity
masts, there will always be a risk
of touching the overhead lines.
If in doubt - contact the local
electricity company for instructions
on safety distance.
Warning!
Check every 8 hours of use that all
bolts/nuts are tight.
Warning!
Beware of oil in case of skin
contact or inhalation of oil vapours,
as well as high pressure in case of
leakage or handling.
Switch off the engine, remove the
key and apply the handbrake
before maintenance or repair work.
Warning!
There is a risk of crushing and
collision when the machine is
running.
No one must stay in the work zone.
Warning!
Rotating shaft!
Power transmission output (PTO)
Before handling: Turn off the
vehicle engine, remove the key
and apply the parking brake.
Warning!
There is a risk of crushing when the
machine is connected to the vehicle.
No one must stay between the
vehicle and the boom mower.
Figure 3 –Safety labeling: warning labels

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
8
WARNING LABELS: PTO SHAFT (RPM)
Scorpion 5-830 Standard
(Rear mounted)
Scorpion 5-830 Plus
(Rear mounted)
Figure 4 –Warning labels: PTO-shaft
WARNING LABELS: TRANSPORT LOCKS / STOP VALVES
4x transport locks on all Scorpion
models: both front and rear
mounted.
The inner handle at the top,
blocks cylinder 1.
(Turn of arm)
The outermost handle at the top,
blocks cylinder 3.
(In- and out movement of arm)
The inner handle at the bottom,
blocks cylinder 2.
(Up-down movement of arm)
The outer handle at the bottom
blocks either cylinder 5 and/or the
rotor cylinder.
(Tilt of head / attachment tool)
Figure 5 –Warning labels: Transport lock / stop valves
Location of transport locks / stop valves on the Scorpion 5-830 boom mower

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
9
3.4 WORKING IN PUBLICLY ACCESSIBLE PLACES
When working in publicly accessible places, such as roadsides, consideration must be given to the presence
of others in the area.
Immediately stop the machine when, for example, pedestrians, cyclists, horse riders etc. approach the safety
zone. Only resume work when they are at a safe distance again.
When the machine is used on public roads, applicable traffic laws must be observed in every event.
3.4.1 WARNINGS SIGNS IN PUBLIC PLACES
-The work area should be marked with appropriate signage, this is a legal requirement in public places.
-Signage must be clear and correctly placed so that the danger is made clear.
-Contact the local road authority for detailed information on applicable legislation.
-The local road authority should be notified before work begins on a public road.
3.4.2 USE OF WARNINGS SIGNS
-On two-way roads, signage must occur in both directions.
-The work should be within 1 km of signage.
-Only carry out work when visibility is good and when the risk is the least –e.g., outside rush hour.
-The vehicle must be equipped with flashing orange light beams.
-Vehicles should be in a conspicuous color and the operator should be wearing visible clothing.
-Remaining material should be removed from the road and pavement as soon as practicable and at
suitable intervals.
-The work must be carried out before warning signs are removed.
-Collect all road signs as soon as the work is completed.

SCORPION 6 & 8 S/PLUS (530, 630, 730 & 830)
10
3.4.3 SUGGESTED SIGNAGE WHEN WORKING ON PUBLIC ROADS
Mandatory sign:
"Keep left"
White and blue arrow signage
Visibly marked on the back of the machine
Warning sign:
"Road work"
Supplementary text for work carried out at a suitable
distance
Example: "Verge cutting 0-1 km"
Warning sign:
"Road narrowing"
Adding text: "One lane only"
Figure 6 –Proposed signage for work on public roads
The above signage applies within i.e., EU mainland, where traffic passes on
the left of the machine working in the direction of travel.
Signage, use of and colors on arrow signs as well as indications depend on
the language, laws, and regulations of the individual country.
Keep left
Verge cutting
0-1 km
One lane only
