GreenWorks Pro SN60L611 User manual

SN60L611
EN OPERATOR MANUALSNOW THROWER
ES MANUAL DEL OPERADOREQUIPO QUITANIEVE

1 Description.................................... 4
1.1 Purpose...................................................... 4
1.2 Overview.................................................... 4
2 General power tool safety
warnings........................................ 4
2.1 Training...................................................... 4
2.2 Preparation.................................................5
2.3 Operation....................................................6
2.4 Maintenance...............................................8
3 Proposition 65............................... 9
4 Symbols on the product.................9
5 Risk levels................................... 10
6 Installation................................... 10
6.1 Unpack the machine.................................10
6.2 Install the battery pack............................. 10
6.3 Remove the battery pack......................... 10
6.4 Install the upper handle............................ 11
6.5 Install the middle handle...........................11
6.6 Install the chute deflector......................... 11
6.7 Install the chute control rod...................... 11
7 Operation.....................................12
7.1 Cold weather operation............................ 12
7.2 Start the machine..................................... 12
7.3 Stop the machine..................................... 12
7.4 Adjust the discharge chute....................... 12
7.5 Adjust the chute deflector.........................13
7.6 LED headlights......................................... 13
7.7 Operation tips........................................... 13
8 Maintenance................................13
8.1 General maintenance............................... 13
8.2 Replace the scraper................................. 14
8.3 Replace the impeller.................................14
8.4 Store the machine.................................... 14
9 Troubleshooting...........................14
10 Technical data............................. 15
11 Limited warranty.......................... 15
12 Exploded view............................. 16
3
English EN

1 DESCRIPTION
1.1 PURPOSE
This machine is used to remove and clear away snow
from pavements, gardens, driveways and other ground-
level surfaces.
1.2 OVERVIEW
1
2
3
4
7
8
65
9
10
11
12
13
14
15
1Handle bar
2Bail Lever
3Safety switch button
4Upper handle
5Carrying or lifting handle
6Battery compartment
7Chute deflector
8Discharge chute
9Impeller
10 Scraper
11 Wheel
12 Lower handle
13 Chute control rod
14 Middle handle
15 LED lights
2 GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool.
2.1 TRAINING
• This power tool can be used
by children aged from 8
years and above and
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instructions
concerning use of the
power tool in a safe way
and understand the hazards
involved. Children shall not
play with the power tool.
Cleaning and user
maintenance shall not be
made by children without
supervision.
• Read the operating and
service instruction manual
carefully. Be thoroughly
familiar with the controls
and the proper use of the
power tool. Know how to
stop the unit and disengage
the controls quickly.
• Never allow children to
operate the power tool.
Never allow adults to
operate the power tool
without proper instruction.
4
English
EN

• Keep the area of operation
clear of all persons,
particularly small children,
and pets.
• Exercise caution to avoid
slipping of falling, especially
when operating in reverse.
• Do not use on graveled
surface unless the snow
mover is adjusted for such a
surface in accordance with
the operator’s manual.
• Dress Properly – Do not
wear loose clothing or
jewelry. They can be caught
in moving parts.
• Wear rubber boots when
operating the snow thrower.
• Operation of the snow
thrower in the hand-held
position is unsafe, except in
accordance with the special
instructions for such use
provided in the operator’s
manual.
• Avoid Accidental Starting–
Don’t carry battery pack in
snow thrower with finger on
switch. Be sure switch is off
when insert battery pack.
2.2 PREPARATION
• Thoroughly inspect the area
where the power tool is to
be used and remove all
doormats, sleds, boards,
wires, and other foreign
objects.
• Do not operate the power
tool without wearing
adequate winter garments.
Wear footwear, which will
improve footing on slippery
surfaces.
• Adjust the collector housing
height to clear gravel or
crushed rock surface.
• Never attempt to make any
adjustments while the
machine is running (except
where specifically
recommended by
manufacturer).
• Always wear safety glasses
or eye shields during
operation or while
performing an adjustment or
repair to protect eyes from
foreign objects that may be
thrown from the machine.
• Prevent unintentional
starting. Ensure the switch
5
English EN

is in the off-position before
connecting to battery pack,
picking up or carrying the
appliance. Carrying the
appliance with your finge on
the switch or energizing
appliance that have the
switch on invites accidents.
• Disconnect the battery pack
from the appliance before
making any adjustments,
changing accessories, or
storing appliance. Such
preventive safety measures
reduce the risk of starting
the appliance accidentally.
• When battery pack is not in
use,keep it away from other
metal objects,like paper
clips,coins,keys,nails,screw
s or other small metal
objects,that can make a
connection from one
terminal to another.Shorting
the battery terminal
stogether may cause burns
or a fire
2.3 OPERATION
• Do not put hands or feet
near or under rotating parts.
Keep clear of the discharge
opening at all times.
• Exercise extreme caution
when operating on or
crossing gravel drives,
walks, or roads. Stay alert
for hidden hazards or traffic.
• After striking a foreign
object, turn the machine off
and remove the battery
pack, and then inspect it for
damage. Repair any
damage before restarting
and using the machine.
• If the power tool should
start to vibrate abnormally,
stop the machine and check
immediately for the cause.
Vibration is generally a
warning of trouble.
• Stop the machine whenever
you leave the operating
position, before unclogging
the collector/impeller
housing or discharge guide,
and when making any
repairs, adjustments, or
inspections.
• When cleaning, repairing, or
inspecting, make certain the
collector/impeller and all
moving parts have stopped.
6
English
EN

• Exercise extreme caution
when operating on slopes.
• Never operate the snow
thrower without proper
guards, keep other safety
protective devices in place
and working.
• Never direct the discharge
toward people or areas
where property damage can
occur. Keep children and
others away.
• Don’t Overreach – Keep
proper footing and balance
at all times.
• Do not overload the
machine capacity by
attempting to clear snow at
too fast a rate.
• Don’t Force Snow Mover –
It will perform better and
safer at the rate for which it
was designed.
• Never operate the power
tool at high transport
speeds on slippery
surfaces. Use care when
reversing.
• Never direct discharge at
bystanders or allow anyone
in front of the power tool.
• Disengage power to the
collector/impeller when the
power tool is transported or
not in use.
• Use only attachments and
accessories approved by
the manufacturer of the
snow thrower (such as
wheel weights,
counterweights, or cabs).
• Never operate the power
tool without good visibility or
light. Always be sure of your
footing, and keep a firm
hold on the handles.
• Walk, never run.
• Never touch a hot engine or
muffler.
• Clearing a Clogged
Discharge Chute.
• Hand contact with the
rotating impeller inside the
discharge chute is the most
common cause of injury
associated with snow
throwers. Never use your
hand to clean out the
discharge chute. To clear
the chute:
1.SHUT THE ENGINE
（Motor） OFF!
7
English EN

2.Wait 10 seconds to be
sure the impeller blades
have stopped rotating.
3.Always use a clean-out
tool, not your hands.
• If the snow thrower strikes a
foreign object follow these
steps:
1.Stop snow thrower.
Release the switch.
2.Remove the battery pack.
3.Inspect for damage.
4.Repair any damage
before restarting and
operating the snow
thrower.
2.4 MAINTENANCE
• Check shear bolts; engine-
mounted bolt, etc., at
frequent intervals for proper
tightness to be sure the
power tool is in safe
working condition.
• Always refer to owner’s
guide instructions for
important details if the
power tool is to be stored
for an extended period.
• Store Idle Snow Movers
Indoors – When not in use,
snow movers should be
stored indoors in dry,
locked-up place – out of
reach of children.
• Store Idle Snow Movers
Indoors – When not in use,
snow movers should be
stored indoors in dry,
locked-up place – out of
reach of children.
• Run the power tool a few
minutes after throwing snow
to prevent freeze-up of the
collector/impeller.
• Do not use a battery pack
or appliance that is
damaged or
modified.Damaged or
modified batteries may
exhibit unpredictable
behavior resulting in fire，
explosion or risk of injury.
• Do not expose a battery
pack or appliance to fire or
excessive
emperature.Exposure to fire
or temperature
above130°Cmay cause
explosion.The temperature
of 130°C can be replaced
by the temperature of
265°F.
8
English
EN

• Follow all charging
instructions and do not
charge the battery pack or
appliance outside of the
temperature range specifie
in the instructions. Charging
improperly or at
temperatures outside of the
specifie range may damage
the battery and increase the
risk of fire.
• Have servicing performed
by a qualifie repair person
using only identical
replacement parts. This will
ensure that the safety of the
product is maintained.
• Do not modify or attempt to
repair the appliance or the
battery pack (as applicable)
except as indicated in the
instructions for use and
care.
• Maintain Snow Thrower
With Care – Follow
instructions for lubricating
and changing accessories.
3 PROPOSITION 65
WARNING
This product contains a chemical known to the state of
California to cause cancer, birth defects or other
reproductive harm. Some dust created by power
sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and other
masonry products;
• Arsenic and chromium from chemically treated
lumber.
Your risk of exposure to these chemicals varies
depending on how often you do this type of work. To
reduce your exposure to these chemicals, work in a
well-ventilated area, and work with approved safety
equipment, such as dust masks that are specially
designed to filter out microscopic particles.
Save these instructions.
4 SYMBOLS ON THE PRODUCT
Some of the following symbols may be used on this tool.
Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate
the tool better and safer.
Symbol Explanation
Direct current
Precautions that involve your
safety.
Read and understand all instruc-
tions before operating the prod-
uct, and follow all warnings and
safety instructions.
Wear eye and ear protection.
Thrown objects can ricochet and
result in personal injury or proper-
ty damage. Wear protective cloth-
ing and boots.
Keep bystanders a safe distance
from the machine.
Keep hands away from the dis-
charge area.
9
English EN

Symbol Explanation
Stay away from moving parts.
Keep all guards and shields in
place.
Keep feet out of impeller. Keep
feet away from rotating impeller.
Stop the motor and remove the
battery before leaving the product.
5 RISK LEVELS
The following signal words and meanings are intended
to explain the levels of risk associated with this product.
SYM-
BOL
SIGNAL MEANING
DANGER Indicates an imminently
hazardous situation,which,
if not avoided, will result in
death or serious injury.
WARNING Indicates a potentially haz-
ardous situation,which, if
not avoided, could result in
death or serious injury.
CAUTION Indicates a potentially haz-
ardous situation, which, if
not avoided, may result in
minor or moderate injury.
CAUTION (Without Safety Alert Sym-
bol) Indicates a situation
that may result in property
damage.
6 INSTALLATION
WARNING
Do not change or make accessories that are not
recommended by the manufacturer.
WARNING
Do not connect to power supply until you assemble all
the parts.
6.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts have damage, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
6.2 INSTALL THE BATTERY PACK
2
3
1
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
1. Open the battery door(1).
2. Align the ribs on the battery pack(2) with the
grooves in the battery compartment.
3. Push the battery pack(2) into the battery
compartment until the battery pack(2) locks into
place.
4. When you hear a click, the battery pack(2) is
installed.
5. Close the battery door(1).
6.3 REMOVE THE BATTERY PACK
1. Open the battery door(1).
10
English
EN

2. Push and hold the battery release button(3).
3. Remove the battery pack(2) from the machine.
6.4 INSTALL THE UPPER HANDLE
1. Align the holes in the middle handle and the upper
handle.
2. Insert the bolt(1) through the middle handle and
upper handle.
3. Tighten the handle knob(2) onto the bolt(1).
4. Repeat for left/right side.
6.5 INSTALL THE MIDDLE HANDLE
21
1. Align the holes in the middle handle and the lower
handle.
2. Put the bolts(1) through the middle handle and the
lower handle.
3. Tighten the handle knob(2) onto the bolt(1).
4. Repeat for left/right side.
6.6 INSTALL THE CHUTE DEFLECTOR
1
3
5
2
3
5
4
1. Align the tabs(2) on to the slots(3) on one side first.
2. Once you have engaged one tab on one slot push
until you hear a click. Repeat on other side.
3. Push the chute deflector(1).
4. Make sure that the tabs(2) engage the slots(3) on
the two sides.
5. Make sure that the posts(4) engage the holes(5) on
the two sides.
6.7 INSTALL THE CHUTE CONTROL
ROD

1. Align the holes(1) in the upper chute control rod(2)
and lower chute control rod(3).
2. Put the hitch pin(4) through the holes(1).
3. Align the arrows in the discharge chute and snow
thrower deck. Make sure the discharge chute faces
forward.
4. Put the end of the chute control rod(5) straight
through the hole(6) in the bracket. Keep the grip
handle down.
5. Push the chute control rod(5) into the hole(7) behind
the deck.
6. Turn the grip handle left and right to make sure that
the discharge chute moves in the same direction.
11
English EN

7 OPERATION
WARNING
Wear eye protection during operation.
7.1 COLD WEATHER OPERATION
The safe battery operation temperature ranges from
-17°C to 45°C.
WARNING
Do not store or charge battery outside.
Battery must be charged and stored indoors prior to use
of the machine.
If the machine does not start below -17°C,
• remove the battery pack from the machine,
• charge the battery pack for 10 minutes in warm
area, or when the changing light turns green.
• Install the battery pack again.
7.2 START THE MACHINE
1
2
1. While holding the safety switch button, pull the bail
lever (2) to start the machine.
NOTE
Lower the scraper to the ground to remove the snow.
WARNING
Keep bystanders a safe distance from the machine.
WARNING
Examine the work area. Remove all stones, sticks,
wire, bones, and other debris that can ricochet
because of the rotating impeller.
7.3 STOP THE MACHINE
2
1. Release the bail lever(2) to stop the machine.
WARNING
Wait until the impeller fully stops before you start the
machine again. Do not quickly turn the machine off
and on.
WARNING
Pull the plug after you complete the work.
7.4 ADJUST THE DISCHARGE CHUTE
You can adjust the discharge chute 180° to change the
snow direction.
1. Turn the grip handle left to move the discharge
chute to the left.
2. Turn the grip handle right to move the discharge
chute to the right.
12
English
EN

7.5 ADJUST THE CHUTE DEFLECTOR
1
You can adjust the chute deflector up and down to
change the throwing distance of the snow.
WARNING
Release the bail switch before you adjust the chute
deflector.
WARNING
Do not push the trigger so far forward that a gap
shows between the deflector and the chute.
1. Push and hold the trigger on the chute deflector.
2. Move the chute deflector(25) up to increase the
snow distance.
3. Move the chute deflector(25) down to decrease the
snow distance.
7.6 LED HEADLIGHTS
1
2
Turning the headlights on：
1. Push and hold the safety switch button(1).
2. Pull the bail switch(2) in the direction of the handle
bar to turn the headlights on.
Turning the headlights off：
3. Release the bail switch(2).
7.7 OPERATION TIPS
• If it is possible, clear the snow in the direction of the
wind.
• In strong winds, lower the chute delfector to direct
the snow to the ground.
• When you complete the work, let the machine
opreate for a while to prevent ice formation in the
discharge chute.
• If the snow is deeper than 20 cm, decrease the
speed and let the machine work at its own rhythm.
• Do not use the scraper to remove compact snow
and ice.
8 MAINTENANCE
WARNING
Disconnect the extension cord before maintenance.
CAUTION
Use only approved replacement parts.
CAUTION
Do not let brake fluids, gasoline, petroleum-based
materials touch the plastic parts. Chemicals can cause
damage to the plastic, and make the plastic
unserviceable.
CAUTION
Do not use strong solvents or detergents on the plastic
housing or components.
8.1 GENERAL MAINTENANCE
• Before each use, examine the machine for
damaged, missing, or loose parts such as screws,
nuts, bolts and caps.
• Tighten correctly all the fasteners and caps.
• Clean the remaining snow on the machine with a
brush.
13
English EN

8.2 REPLACE THE SCRAPER
2
1
1
WARNING
Use only approved replacement scrapers.
WARNING
Wear heavy gloves or wind cloth around the blade
when you touch the blade.
1. Remove the screws(1) from each side plate.
2. Remove and discard the old scraper.
3. Install the new scraper.
4. Put in the mounting screw(2) and spacers and
tighten them.
8.3 REPLACE THE IMPELLER
1
2
3
4
5
6
WARNING
Use only approved replacement scrapers.
1. Remove the screws(1) and side wear pad(2) of left
and right side covers.
2. Remove the nut(3).
3. Remove the belt(4).
4. Remove the the large pulley(5) with a socket wrench
(23 mm).
5. Pull the axle(6) and remove the old impeller.
6. Install the new impeller.
7. Reinstall the components.
8.4 STORE THE MACHINE
• Clean the machine before storage.
• Make sure the engine is not hot when you store the
machine.
• Make sure that the machine does not have loose or
damaged parts. If it is necessary, do these steps/
instructions:
• Replace the damaged parts.
• Tighten the bolts.
• Speak to a person of an approved service
center.
• Store the machine in a dry area.
• Make sure that children cannot come near the
machine.
9 TROUBLESHOOTING
Problem Possible cause Solution
The handle is
not in position.
The bolts are not
engaged correct-
ly.
Adjust the height
of the handle
and make sure
that the knobs
and bolts are
aligned correctly.
14
English
EN

Problem Possible cause Solution
The machine
does not start.
The battery is
not charged.
Charge the bat-
tery by following
the procedures
in the battery
and charger
manual.
The switch is de-
fective.
Charge the bat-
tery pack in the
warm area for 15
minutes.
Battery is too
cold.
Remove battery
from snow throw-
er. Place battery
on charger and
allow to charge
for 10 minutes or
when the chang-
ing light turns
green. Remove
from charger and
install in snow
thrower for use.
The battery is
not attached to
the motor.
Check the con-
nection between
the motor con-
nector and the
battery.
Battery may re-
quire service or
replacement.
Call toll free
helpline, at
1-855-345-3934
or replace bat-
tery.
The engine is
on, but the im-
peller does not
turn.
The belt is dam-
aged.
Replace the belt.
A thin layer of
snow stays be-
hind.
The scraper is
damaged.
Replace the
scraper.
* If you cannot find the solution to these problems, go to
the service center.
10 TECHNICAL DATA
Voltage 60 V
No load speed 1,800 RPM
Working width 20 ''
Clearing depth 10 ''
Impeller size 16 ''
Discharge distance 20 ft
Weight (without battery
pack)
33.5 lbs
Battery model LB60A600
Charger model CH60A00
10 THE RECOMMENDED AMBIENT
TEMPERATURE RANGE:
Item Temperature
Snow thrower storage
temperature range
-4°F (-20°C) - 158°F
(70°C)
Snow thrower operation
temperature range
-4°F (-20°C) - 104°F
(40°C)
Battery charging tempera-
ture range
32°F (0°C) - 104°F (40°C)
Charger operation temper-
ature range
39°F (4°C) - 113°F (45°C)
11 LIMITED WARRANTY
TOOL WARRANTY
YEAR/ANS/AÑOS
GARANTIE DE
L’OUTIL
HERRAMIENTA
Greenworks hereby warranties this product, to the
original purchaser with proof of purchase, for a period of
four (4) years against defects in materials, parts or
workmanship. Greenworks, at its own discretion will
repair or replace any and all parts found to be defective,
through normal use, free of charge to the customer.
This warranty is valid only for units which have been
used for personal use that have not been hired or
rented for industrial/commercial use, and that have
been maintained in accordance with the instructions in
the owners’ manual supplied with the product from new.
ITEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to
misuse, commercial use, abuse, neglect, accident,
improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or
maintained in accordance with the owner's manual;
or
3. Normal wear, except as noted below;
4. Routine maintenance items such as belts and
scrapers;
5. Normal deterioration of the exterior finish due to use
or exposure.
15
English EN

HELPLINE:
Warranty service is available by calling our toll-free
helpline, at 1-855-345-3934 .
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power
equipment unit or attachment are the responsibility of
the purchaser. It is the purchaser’s responsibility to pay
transportation charges for any part submitted for
replacement under this warranty unless such return is
requested in writing by Greenworks.
12 EXPLODED VIEW

No. Part No. Qty Description
1 R0200281-00 1 Impeller assembly
2 R0200283-00 1 Weather bar
3 R0200285-00 1 PCB board
4 R0200284-00 1 Cam Lock Assembly
5 R0200165-00 1 Wheel Assembly
6 R0200166-00 1 Control Rod Assembly
7 R0200173-00 1 Chute Deflector Assembly
8 R0200282-00 1 Scraper Kit
Greenworks Tools
PO Box 1238
Mooresville, NC 28115
16
English
EN

1 Descripción..................................18
1.1 Finalidad...................................................18
1.2 Perspectiva general..................................18
2 Advertencias generales de
seguridad para herramientas
eléctricas..................................... 18
2.1 Formación................................................ 18
2.2 Preparativos............................................. 19
2.3 Funcionamiento........................................20
2.4 Mantenimiento..........................................23
3 Propuesta 65............................... 24
4 Símbolos en el producto..............24
5 Niveles de riesgo ........................25
6 Instalación................................... 25
6.1 Desembalaje de la máquina ....................25
6.2 Instalación de la batería........................... 25
6.3 Retirada de la batería...............................26
6.4 Instalación del asa superior......................26
6.5 Instalación del asa intermedia..................26
6.6 Instalación del deflector del conducto...... 26
6.7 Instalación de la varilla de control del
conducto...................................................26
7 Funcionamiento ..........................27
7.1 Funcionamiento en condiciones de frío....27
7.2 Puesta en marcha de la máquina.............27
7.3 Detención de la máquina..........................27
7.4 Ajuste del conducto de descarga............. 27
7.5 Ajuste del deflector del conducto............. 28
7.6 Luces delanteras LED.............................. 28
7.7 Consejos de funcionamiento.................... 28
8 Mantenimiento.............................28
8.1 Mantenimiento general.............................28
8.2 Sustitución del rascador........................... 29
8.3 Sustitución del rotor..................................29
8.4 Almacenamiento de la máquina............... 29
9 Solución de problemas................29
10 Datos técnicos.............................30
11 Garantía limitada......................... 30
12 Vista despiezada......................... 31
17
Español
ES

1 DESCRIPCIÓN
1.1 FINALIDAD
Esta máquina se utiliza para quitar y despejar la nieve
de aceras, jardines, calzadas y otras superficies a nivel
del suelo.
1.2 PERSPECTIVA GENERAL
1
2
3
4
7
8
65
9
10
11
12
13
14
15
1Manillar
2Palanca de seguridad
3Botón del interruptor de seguridad
4Asa superior
5Asa de transporte o elevación
6Compartimento de la batería
7Deflector del conducto
8Conducto de descarga
9Rotor
10 Rascador
11 Rueda
12 Asa inferior
13 Varilla de control del conducto
14 Asa intermedia
15 Luces LED
2 ADVERTENCIAS GENERALES
DE SEGURIDAD PARA
HERRAMIENTAS ELÉCTRICAS
AVISO
Lea todas las advertencias de seguridad y todas las
instrucciones. El incumplimiento de las advertencias e
instrucciones puede provocar descargas eléctricas,
incendios o lesiones graves.
Guarde todas las advertencias e instrucciones para su
consulta posterior.
El término “herramienta eléctrica” empleado en las
advertencias se refiere a su herramienta eléctrica con
funcionamiento de red (con cable).
2.1 FORMACIÓN
• Esta herramienta eléctrica
puede ser utilizada por
niños a partir de los 8 años
y por personas con
capacidades físicas,
sensoriales o mentales
reducidas, o que no tengan
experiencia ni
conocimientos, sin son
supervisados o instruidos
en el uso de la herramienta
eléctrica de forma segura y
entienden los riesgos
implicados. Los niños no
deben jugar con la
herramienta eléctrica. Los
niños no podrán realizar la
limpieza ni el
mantenimiento reservado al
usuario a menos que
cuenten con supervisión.
• Lea detenidamente el
manual de instrucciones de
funcionamiento y servicio.
Familiarícese a fondo con
los controles y el uso
correcto de la herramienta
18
Español
ES

eléctrica. Debe saber cómo
detener la unidad y
desacoplar los controles
rápidamente.
• Nunca permita que los
niños utilicen la herramienta
eléctrica. Nunca permita
que utilicen la herramienta
eléctrica adultos sin la
debida instrucción.
• Mantenga la zona de
funcionamiento libre de
cualquier persona,
especialmente niños
pequeños y mascotas.
• Tenga precaución para
evitar resbalones o caídas,
especialmente durante la
utilización marcha atrás.
• No utilice en superficies con
grava a menos que el
quitanieves esté ajustado
para tal superficie de
acuerdo con el manual del
operario.
• Lleve indumentaria
adecuada – No lleve ropa o
joyas sueltas. Pueden
quedar atrapadas en las
piezas móviles.
• Lleve botas de goma al
utilizar el quitanieves.
• El funcionamiento del
quitanieves en la posición
de mano no es seguro,
excepto de acuerdo con las
instrucciones especiales
para dicho uso que se
proporcionan en el manual
del operario.
• Evite el arranque accidental
– No transporte la batería
en el quitanieves con el
dedo sobre el interruptor.
Asegúrese de que el
interruptor esté desactivado
al insertar la batería.
2.2 PREPARATIVOS
• Inspeccione
exhaustivamente la
superficie donde va a
utilizarse la herramienta
eléctrica y elimine todos los
felpudos, trineos, planchas,
cables y otros objetos
extraños.
• No utilice la herramienta
eléctrica sin llevar
indumentaria adecuada de
invierno. Lleve calzado, que
mejorará el equilibrio en
superficies resbaladizas.
19
Español
ES

• Ajuste la altura de la
carcasa del colector para
dejar espacio en caso de
superficies de grava o
piedra triturada.
• Nunca intente realizar
ningún ajuste mientras la
máquina esté en
funcionamiento (excepto
cuando el fabricante lo
recomiende
específicamente).
• Lleve siempre gafas de
seguridad o protectores
oculares durante la
utilización o al realizar un
ajuste o una reparación
para proteger los ojos de
objetos extraños que
puedan ser lanzados desde
la máquina.
• Evite el arranque
accidental. Asegúrese de
que el interruptor esté en la
posición de apagado antes
de conectar a la batería y al
coger o transportar el
aparato. El transporte del
aparato con el dedo en el
interruptor o la conexión de
un aparato que tiene el
interruptor activado fomenta
los accidentes.
• Desconecte la batería del
aparato antes de realizar
ajustes, cambiar accesorios
o almacenarlo. Estas
medidas de seguridad
preventivas reducen el
riesgo de que el aparato se
ponga en marcha
accidentalmente.
• Cuando la batería no esté
en uso, manténgala alejada
de otros objetos metálicos
como clips, monedas,
llaves, clavos, tornillos u
otros objetos metálicos
pequeños, que puedan
hacer una conexión entre
los terminales. El
cortocircuito de los
terminales de la batería
puede producir quemaduras
o un incendio.
2.3 FUNCIONAMIENTO
• No ponga las manos ni los
pies cerca o debajo de las
piezas giratorias.
Manténgase alejado en
todo momento de la
abertura de descarga.
20
Español
ES
