GreenWorks Pro SS60L00 User manual

Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1(855)345-3934
www.GreenWorksTools.com
12" 60V Cordless Snow Shovel
SS60L00

2
Contents .............................................................................................................................. 2
Product Specications ......................................................................................................... 2
Safety Information ............................................................................................................... 3
Symbols............................................................................................................................... 6
Know Your Snow Shovel...................................................................................................... 8
Assembly ............................................................................................................................. 9
Operation........................................................................................................................... 14
Maintenance ...................................................................................................................... 16
Environmentally safe battery disposal ............................................................................... 21
Troubleshooting ................................................................................................................. 22
Warranty ............................................................................................................................ 23
Exploded View/Parts List................................................................................................... 24
PRODUCT SPECIFICATIONS
12" 60V CORDLESS SNOW SHOVEL
Motor ................................................................................................... 60 V Brushless Motor
Battery Type................................................................................................... 60 V Lithium-ion
No-load Speed.......................................................................................................1800 RPM
Clearing Width.......................................................................................................12 in. (30 cm)
Clearing Depth................................................................................................... 4 in. (10.2 cm)
Impeller Size.......................................................................................................11 in. (27.8 cm)
Discharge Distance.................................................................................................. 20 ft. (6 m)
Weight (without battery)................................................................................................ 7.2 kg
Weight (with battery).....................................................................................................8.5 kg
CONTENTS
Cold Weather Operation: Lithium Ion batteries can be safely used from temperatures ranging
from -17 degrees to 45 degrees Celsius. NOTE: Do not store or charge battery outside. Battery
must be charged and stored indoors prior to use of the snow shovel.
Battery may not properly start if its temperatures is -17˚C or lower. If unit does not start remove
battery from snow shovel. Place battery on charger and allow to charge for 10 minutes to allow
battery to warm. Remove from charger and install in snow shovel for use.

3
SAFETY INFORMATION
• Walk. Do not run.
• Verify that the power tool is not in contact with anything before turning it on.
• Stay away from impeller openings at all times. Keep face, hands, and feet away from
concealed, moving, or rotating parts.
• Be attentive when using the power tool, and stay alert for holes in the terrain and other hidden
hazards or trafc.
• Move up and down slopes when clearing snow. Do not go across a slope. Use caution when
changing direction. Do not use this power tool to clear snow from steep slopes.
• Do not operate the power tool if the guards, plates, and other safety protective devices are not
in place.
• Do not operate the power tool near glass enclosures, automobiles, trucks, window wells,
drop-offs, etc. without properly adjusting the angle of the snow discharge. Keep children and
pets away from the work area.
• Do not operate the power tool at high speeds on slippery surfaces. Look behind when backing
up and exercise caution.
• Do not direct the discharge toward anyone. Do not allow anyone to move in front of the snow
thrower while it is in use.
• Wear safety glasses or goggles that meet ANSI Z87.1 standards.
• Use the power tool in daylight or in good articial light. If using at night, turn on the LED lights
and be aware of your surroundings.
• To avoid accidental start-ups, remain in the starting position when turning the power tool on.
The operator and the power tool must be in a stable position during start-up. See the section
titled Starting/Stopping Instructions.
• Use this power tool only for the purposes it was designed.
• Hold the power tool with both hands while it is in use. Keep a rm grip on the handles.
• If the impeller does not rotate freely due to ice, thaw the power tool thoroughly before
attempting to use it.
• Keep the impeller clear of debris.
• Do not attempt to clear the impeller while the motor is running.
• After striking a foreign object, turn the power tool off and remove the battery pack, and then
inspect it for damage. Repair any damage before restarting and using the power tool.
• If the power tool starts to vibrate abnormally, stop the power tool immediately and attempt to
determine the cause. Vibration is generally an indication of danger.
• Stop the motor and remove the battery pack whenever the operator is not in the operating
position, before unclogging the impeller, and before making any repairs, adjustments, or
inspections.
WARNING
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below
may result in electric shock, re, and/or serious personal injury.
FOLLOW THESE RULES WHILE OPERATING (THE POWER TOOL)

4
SAFETY INFORMATION
• Do not use on graveled surface unless the power tool is adjusted for such a surface in
accordance with the operator’s manual.
• Keep Children Away– All visitors should be kept a safe distance from work area.
• Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts.
• Wear rubber boots when operating the power tool. Do not operate the equipment when
barefoot or wearing open sandals. Always wear substantial footwear.
• Operation of the power tool in the hand-held position is unsafe, except in accordance with the
special instructions for such use provided in the operator’s manual.
• Keep guards in place and in working order.
• Don’t Force Power tool – It will perform better and safer at the rate for which it was designed.
• Don’t Overreach – Keep proper footing and balance at all times.
• If the power tool strikes a foreign object, follow these steps:
i) Stop the power tool.
ii) Inspect for damage.
iii) Repair any damage before restarting and operating the power tool.
• Store Idle Power tool Indoors – When not in use, power tools should be stored indoors in dry,
locked-up place – out of reach of children.
• Maintain Power tools With Care – Follow instructions for lubricating and changing
accessories.
• Allow the power tool to run for a few minutes after clearing snow in order to prevent moving
parts from freezing.
• Only use identical replacement parts and accessories for this power tool. The use of
nonidentical parts or accessories could lead to serious injury to the user or damage the power
tool, and will void the warranty.
• Do not pick up the power tool while it is running. The power tool is designed to travel along the
ground.
• Never allow children to operate a power tool. Keep the area of operation clear of all persons,
particularly small children, and pets.
• Thoroughly inspect the area where the equipment is to be used and remove all stones, sticks,
wires, bones, and other foreign objects.
• Stop the blade(s) when crossing gravel driveways, walkways, or roads.
• Read the operator’s manual carefully. Be thoroughly familiar with the controls and the proper
use of the equipment.

CONTENTS
5
GENERAL SAFETY RULES
• Verify that the power tool is secure while transporting.
• Store the power tool in a dry area that will prevent unauthorized use or damage. Keep out of
the reach of children.
• Keep handles dry, clean, and free of debris. Clean the power tool after each use. Refer to the
Maintenance Section in this manual for more information.
• If the labels on the power tool become defaced or start to lift off, contact the toll-free helpline,
at 1(855)345-3934.
• Keep these instructions in a safe place for future reference. Refer to them often and use
them to instruct other users. Anyone who uses this power tool must read these instructions
carefully.
• Maintain the power tool with care. Follow the instructions for lubricating and changing
accessories.
CAUTION
USE ONLY GREENWORKS APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES
MAY CAUSE INJURY OR DAMAGE TO THE SNOW SHOVEL. USE ONLY WITH
GREENWORKS 60V BATTERIES (Model#: LB60A00 / LB60A03 / LB60A01 / LB60A02) and
GREENWORKS 60V CHARGER (Model#: CH60A00).
WARNING(PROPOSITION65)
This product contains a chemical known to the state of California to cause cancer, birth defects
or other reproductive harm.
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of
work. To reduce your exposure to these chemicals, work in a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.
SAFETY INFORMATION
SAVE THESE INSTRUCTIONS

6
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOLS
6
SYMBOL DESIGNATION/EXPLANATION
V Voltage
A Current
Hz Frequency (cycles per second)
Wh Watt Hour - Energy Storage Capacity
Ah Amp Hour - Current Capacity
DC Direct current
Type or a characteristic of current
RPM Revolutions per minute
/min Revolutions, strokes, surface speed, orbits, etc., per minute
Indicates a potential personal injury hazard.
To reduce the risk of injury, user must read and understand operator’s manual
before using this product.
Always wear eye protection with side shields marked to comply with ANSI Z87.1
when operating this equipment.
Wear eye and hearing protection.
Stop the motor and remove the battery before leaving the machine.
Thrown objects can ricochet and result in personal injury or property damage.
Danger – Keep hands and feet away from openings while the machine is running.
Do not use hands to unclog chute. Stop motor and remove the battery before
removing debris.
Keep bystanders a safe distance from the machine.
Stay away from moving parts. Keep all guards and shields in place.
Keep hands away.
Keep hands away from the discharge area.

7
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualied
service technician. For service we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTER for repair. When servicing, use only identical replacement parts.
WARNING
To avoid serious personal injury, do not attempt to use this product until you have read this
Owner's Manual thoroughly and understand it completely. If you do not understand the
warnings and instructions in this Owner's Manual, do not use this product. Call the Toll-free
Helpline (1(855)345-3934) for assistance.
WARNING
The operation of any power tool can result in foreign objects being thrown into your
eyes, which can result in severe eye damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with side shields and, when needed, a
full face shield. We recommend a Wide Vision Safety Mask for use over eyeglasses
or standard safety glasses with side shields. Always use eye protection which is
marked to comply with ANSI Z87.1.
SYMBOLS
SAVE THESE INSTRUCTIONS
SYMBOLS SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.

8
KNOW YOUR SNOW SHOVEL
Fig. 1
Read this operator's manual and safety rules before operating your snow shovel. Compare the
illustration in Figure 1 to your snow shovel in order to familiarize yourself with the location of
various controls and adjustments. Save this manual for future reference.
Auxiliary handle
Trigger switch
Lock-out button
Lock knob
Belt drive cover
Impeller
Scraper
Battery compartment

9
ASSEMBLY INSTRUCTIONS
PART NAME FIGURE QTY
Snow shovel 1
Auxiliary handle 1
Owner's manual 1
PACKING LIST

10
UNPACKING
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the packing list are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.
• If any parts are damaged or missing, please call 1(855)345-3934 for assistance.
WARNING
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Failure to heed this warning could result in serious personal injury.
WARNING
Do not insert battery until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse, and could result in a hazardous condition
leading to possible serious personal injury.
ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS
11
CONNECTING THE SHAFTS (See Figures 2-3)
• Align the pin on the handle shaft and the hole on the lower shaft. (Fig. 2)
• Once the two shafts are secured, turn the lock knob clockwise until it is fully tightened. (Fig. 3)
Fig. 3Fig. 2
Lower shaft
Handle shaft
Pin
Hole
Lock knob

12
ASSEMBLY INSTRUCTIONS
TO INSTALL BATTERY PACK (See Figure 4)
• Slide the battery (1) down to lock it into position. The battery is fully inserted into the snow
shovel when you hear an audible “click”.
TO REMOVE BATTERY PACK (See Figure 5)
• Release the trigger switch. The lock-out button will pop out, and the snow shovel will stop.
• Press and hold the battery latch button (2) at the rear handle.
• Remove battery pack from the snow shovel.
Fig. 4 Fig. 5
1
2

CONTENTS
13
ASSEMBLY INSTRUCTIONS
Fig. 6.1
Fig. 6.2
1
2
3
ATTACHING THE AUXILIARY HANDLE (See Figure 6)
• Press the auxiliary handle (1) onto the upper shaft so that the handle is angled toward the rear
handle that allows for comfortable operation.
• Slide the auxiliary handle over the metal ring (2) and ensure the metal ring ts between the
slot on the auxiliary handle.
• Align the holes on the auxiliary handle with the holes on metal ring.
• Insert the handle knob (3) through the auxiliary handle.
• Tighten until there is no movement in the handle.

CONTENTS
14
STARTING THE SNOW SHOVEL (See Figures 7-8)
In order to avoid serious injury, the operator and unit must be in a stable position when starting
the snow shovel.
Follow this sequence exactly in order to start the snow shovel.
• Verify that the battery pack is inserted into the battery compartment.
• Press and hold the lock-out button.
• While holding the lock-out button, press and hold the trigger switch.
NOTE: The Snow Shovel will not start if the lock-out button is not held until the trigger switch is lifted. Once
trigger is pressed and unit is started, release the lock-out button.
• Hold the handles and begin to use the snow shovel.
STOPPING THE SNOW SHOVEL (See Figure 7)
• Release the trigger switch.
• The lock-out button will pop out, and the snow shovel will stop.
OPERATING INSTRUCTIONS
Fig. 8Fig. 7
Lock-Out
Button
Trigger

USING THE SNOW SHOVEL (See Figure 9)
• Start the snow shovel by following the Starting Instructions. The depth and weight of the snow
will determine the forward speed.
• Push the snow shovel forward so that it rides on the scraper.
OPERATING INSTRUCTIONS
15
Fig. 9
scraper

16
MAINTENANCE
REPLACING THE SCRAPER (See Figures 10-11)
WARNING
IN ORDER TO AVOID SERIOUS PERSONAL INJURY, TURN THE SNOW SHOVEL
OFF AND REMOVE BATTERY BEFORE PERFORMING ANY MAINTENANCE.
Use only the manufacturer's original replacement parts.
• Place the snow shovel on the ground or on a work bench. Position the snow shovel so that
the impeller is facing up.
• Remove the four screws that are located beneath the impeller that secure the scraper to
the housing using a Phillips screwdriver. (Fig. 10)
• Remove the scraper, and discard it in the proper manner. (Fig. 11)
• Snap the new scraper into position, and attach it to the snow shovel by reinstalling the
four screws.
scraper
Fig. 11
4 screws
scraper
Fig. 10

MAINTENANCE
17
STORAGE
• Allow the motor to cool down before storing.
• Store the snow shovel in a locked location in order to prevent unauthorized use or damage.
• Store the snow shovel in a dry, well-ventilated area.
• Store the snow shovel out of the reach of children.
CLEANING
In order to avoid serious personal injury, turn the snow shovel off and remove battery before
cleaning or servicing.
Use a small brush to clean the outside of the snow shovel. Do not use strong detergents.
Household cleaners that contain aromatic oils such as pine and lemon, and solvents such as
kerosene can damage the plastic housing and handles. Wipe off any moisture using a soft cloth.

MAINTENANCE
TRANSPORTING THE SNOW SHOVEL (See Figure 12)
• Allow the motor to cool down before transporting.
• Secure the snow shovel while transporting.
• When moving the snow shovel, grasp it by the top handle and auxiliary handle (Fig. 12)
Fig. 12
18

19
MAINTENANCE
19
IMPELLOR REPLACEMENT
• Remove the 4 screws .
• Withdraw the old/damaged
impellor. Be sure not to lose
the shaft sleeve that secures
left side of the shaft.
• Remove the right side
cover by removing 6
screws.
• Remove the left side cover
by removing 6 screws.
• Insert the impellor shaft with
pulley assembly attached in
the new impellor. Be sure to
replace the retained shaft
sleeve that secures left side
of the shaft.
• Remove the belt.
• Remove the impellor shaft
with pulley assembly
attached.
• Pull the belt tensioner (idler
arm) away from the drive
pulley. Be sure not to lose
the washer and screw left.
• Remove the M10 nut that
secures the left side plate.
1 2 3
4 65
789
shaft sleeve
Washer
screw

20
MAINTENANCE
20
• Place the belt back into its
place.
• Replace and tighten the
remaining screws to secure
the right side cover.
• Place the belt tensioner (idler arm) back into its place.
13 14
15
• Replace and tighten the
remaining nut to secure the
left side plate assembly.
• Replace and tighten the
remaining screws to secure
the left side cover.
• Replace and tighten the
remaining screws to secure
the pulley assembly.
10 11 12
IMPELLOR REPLACEMENT
