USER GUIDE
EN USERGUIDE 3
CS USERGUIDE 10
SK USERGUIDE 17

1 Description.................................... 4
1.1 Purpose......................................................4
1.2 Overview.................................................... 4
2 Safety............................................ 4
3 Installation..................................... 4
3.1 Unpack the machine...................................4
3.2 Attach the guard.........................................4
3.3 Assemble the shaft.....................................4
3.4 Install the battery pack............................... 4
3.5 Remove the battery pack........................... 5
4 Operation.......................................5
4.1 Start the machine....................................... 5
4.2 Stop the machine....................................... 5
4.3 Operation tips.............................................5
4.4 Cutting tips................................................. 5
4.5 Adjust the length of the cutting line............ 5
4.6 Adjust the length of the cutting line
manually.....................................................5
4.7 Adjust the cutting diameter.........................5
4.8 Line cut-off blade........................................6
4.9 Change to the edging mode.......................6
4.10 Pivoting Head Function ............................. 6
5 Maintenance..................................6
5.1 General information....................................6
5.2 Clean the machine..................................... 6
5.3 Replace the spool.......................................6
5.4 Replace the cutting line..............................7
6 Transportation and storage........... 7
6.1 Move the machine......................................7
6.2 Store the machine...................................... 7
7 Troubleshooting.............................7
8 Technical data............................... 8
9 Warranty........................................9
10 EC Declaration of conformity.........9
3
English EN

1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and
other similar vegetation at or around ground level. The
cutting plane must be approximately parallel to the
ground surface. You cannot use the machine to cut or
chop hedges, shrubs, bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 18.
1Trigger
2Rear handle
3Lock-out button
4Auxiliary handle
5Upper shaft
6Coupler
7Lower shaft
8Edger button
9Guard
10 Cut-off blade
11 Edge guide
12 Trimmer head
13 Edger wheel
14 Pivoting button
15 Screw
16 Battery release button
17 Spool retainer button
18 Tab
19 Spool cover
20 Spool
21 Spool housing
22 Hole
ADirection of roatation
BBest cutting area
CDangerous cutting area
2 SAFETY
WARNING
Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Remove the battery pack from the machine before
installation.
WARNING
Do not use accessories that are not recommended for
this machine.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts have damage, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
3.2 ATTACH THE GUARD
Figure 2.
WARNING
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a
Phillips head screwdriver (not included).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw
holes on the trimmer head.
4. Tighten the screws.
3.3 ASSEMBLE THE SHAFT
Figure 3.
1. Insert the lower shaft into the coupler on the upper
shaft.
NOTE
Make sure the upper and lower part of shafts are
securely tightened before installing the battery pack
again.
2. Tighten the coupler.
3.4 INSTALL THE BATTERY PACK
Figure 4.
4
English
EN
