Original instructions (user manual/instructions for use) are written in English. All other
languages are translations of the original instructions (user manual/instructions for use).
In case of any dispute, the user manual in English prevails.
This user instruction manual is developed for your Greyp bike only. It contains important
safety, performance and technical information, which you should read before your rst ride
and keep for reference. You should also read the entire User Manual, because it contains
additional important general information and instructions that you should follow.
If you do not have a copy of the User Manual, please download it for free at
www.greyp.com or obtain it from your nearest Authorised Greyp Retailer. In case of
discrepancy, the english version shall prevail.
Greyp Bikes Disclaimer
Any modications of the bike are strictly forbidden and Greyp Bikes d.o.o. will bear no liability
whatsoever for the consequences of such modications. Greyp Bikes d.o.o. does not grant,
explicitly or implicitly, to any party any patent rights, licenses or any other IP rights, whether
with regard to such information itself or to anything described by such information. The
information provided by Greyp Bikes d.o.o. hereunder is provided as is, where is and with
all faults, and the entire risk associated with such information is entirely with the buyer. The
information provided in this document is proprietary to Greyp Bikes d.o.o., and Greyp Bikes
d.o.o. reserves the right to make any changes to the information in this document or to any
products and services at any time without notice.
You should check www.greyp.com for any changes made in the User Manual.
Greyp Bikes d.o.o.,
Ljubljanska 7, 10431 Sveta Nedelja, Croatia,
15th of February 2020.

INTRODUCTION
4
General warning
This manual contains many “WARNINGS” and “CAUTIONS” concerning the consequences of
failure to maintain or inspect your bike and of failure to follow safe cycling practices.
The combination of the safety alert symbol and the word WARNING indicates a potentially
hazardous situation which, if not avoided, could result in serious injury or death.
The combination of the safety alert symbol and the word CAUTION indicates a potentially
hazardous situation which, if not avoided, may result in minor or moderate injury, or is an alert
against unsafe practices.
Many of the WARNINGS and CAUTIONS say you may lose control and fall. Because any fall
can result in serious injury or even death, we do not always repeat the warning of possible
injury or death.
As it is impossible to anticipate every situation or condition which can occur while riding, this
User Manual makes no representation about the safe use of the bicycle under all conditions.
There are risks associated with the use of any bicycle which cannot be predicted or avoided,
and which are the sole responsibility of the rider.
General information
»EU - The G6.1, G6.2, G6.4, G6.5, G6.6, G5.1 and G5.2 are high-performance bicycles.
The G6.3, G6.2O, G6.5O and G6.6O are off-road vehicle and they should not be ridden on
public roads.
»US - The G6.1 (US), G6.2 (US), G6.4 (US), G6.5 (US), G6.6 (US), G5.1 (US) and G5.2 (US)
are CLASS 1 electric bicycle. The G6.3 (US), G6.2O, G6.5O (US) and G6.6O (US) are CLASS
3 electric bicycles.
G-series are intended to be used on gravel, paved and non-paved hiking trails (with several roots,
thresholds, rocks and small drops) and rougher unpaved terrain, with jumps and drops not more
than 1m (maximum height).
Motor support will automatically switch off when you reach a maximum speed of: 25km/h for G6.1,
G6.2, G6.4, G6.5, G6.6, G5.1 and G5.2; 32km/h (20 mph) for G6.1 (US), G6.2 (US), G6.4 (US), G6.5
(US), G6.6 (US), G5.1 (US) and G5.2 (US); 45km/h (28mph) for G6.3, G6.3 (US), G6.2O, G6.2O (US),
G6.5O, G6.5O (US), G6.6O and G6.6O (US). A driver’s license or insurance is typically not required.
Regardless of its classication, the bike will only provide motor support only while pedaling.

INTRODUCTION
5
THE MAXIMUM PERMISSIBLE WEIGHT
VEHICLE
THE PERMISSIBLE
TOTAL PAYLOAD
WEIGHT
(DRIVER + LUGGAGE)
*
VEHICLE
WEIGHT
**
MAXIMUM
PERMISSIBLE TOTAL
WEIGHT (VEHICLE +
DRIVER + LUGGAGE)
G5.1 AND G5.1 (US) 125.5 kg [276.7 lb] 24.5 kg [54 lb] 150 kg [330.7 lb]
G5.2 AND G5.2 (US) 126 kg [277.8 lb] 24 kg [52.9 lb] 150 kg [330.7 lb]
G6.1 AND G6.1 (US) 125.5 kg [276.7 lb] 24.5 kg [54 lb] 150 kg [330.7 lb]
G6.2 , G6.2O, G6.2O (US)
AND G6.2 (US) 125 kg [275.6 lb] 25 kg [55.1 lb] 150 kg [330.7 lb]
G6.3 AND G6.3 (US) 126 kg [277.8 lb] 24 kg [52.9 lb] 150 kg [330.7 lb]
G6.4 AND G6.4 (US) 124.6 kg [274.7 lb] 25.4 kg [56.0 lb] 150 kg [330.7lb]
G6.5, G6.5 (US), G6.5O
AND G6.5O (US) 124 kg [273.4 lb] 26 kg [57.3 lb] 150 kg [330.7lb]
G6.6, G6.6O, G6.6 (US)
AND G6.6O (US) 123.6 kg [272.5 lb] 26.4 kg [58.2 lb] 150 kg [330.7lb]
Please nd additional safety, performance and service information for specic components
such as suspension, brakes or motor in the Manufacture’s Guidelines.
* Frame size S has a higher Permissible Total Payload Weight by up to 0.2kg while frame size L has the
Permissible Total Payload Weight lower by up to 0.2kg, than what is listed in the table.
** Frame size S is up to 0.2kg lighter while frame size L is up to 0.2kg heavier than listed in the table.

INTRODUCTION
6
Out of box assembly
1OPEN BOX 2BIKE OUT 3FRONT WHEEL 4TOOL BOX
Open the marked side
of the box
Pull out the bike
holding the fork
Take out the
front wheel
Lift the bike to access
the toolbox
READ THE USER MANUAL
If you don’t have the knowledge or ability to assemble
the Greyp yourself, please consult a professional mechanic.
5 HANDLEBAR POSITIONING
1. Rotate the handlebar to its natural position (≈90° to the frame, “centered ”).
2. Using the tool (three-arm hex key number 5), lightly tighten the two bolts on the stem.

INTRODUCTION
7
6 FRONT WHEEL MOUNTING TOOLS
4
56
8
mm
mmmm
mm
69 - 13.5Nm / 6.6 - 9.9lbft
1. Guide your wheel into the fork and guide the rotor between the brake pads.
2.
Tighten the axle - line up your hub with the holes at the bottom of your fork. Check which side of the fork
is threaded and push the axle in from the opposite side. Turn the three-arm hex key number 6 clockwise to
thread the axle into the fork.
7 PEDALS MOUNTING (G6.1, G6.2, G6.4, G6.5, G6.6)
1. Take the pedals out of the box, grease
the thread and tighten them using the
tool (three-arm hex key number 6) (see
picture above).
2. Pay attention to the direction of
rotation
while tightening. The thread
on the right pedal is right-handed
(standard). The direction of rotation for
tightening is anti-clockwise. The thread
on the left pedal is left-handed so the
direction of rotation for tightening is
clockwise.

INTRODUCTION
8
CHECK (G6.3)
1.Take the pedals out of the box, grease
the thread and tighten
them usingthe tool
(L shaped 8 allen wrench - see picture).
2. Pay attention to the direction of
rotation
while tightening. The thread on
the rightpedal isright-handed (standard).
The direction of rotation for tightening
is anti-clockwise. The thread on the left
pedal is left-handed so the direction of
rotation for tightening is clockwise.
8 HANDLEBAR MOUNT
1. Slightly loosen the 2 bolts on the stem.
Tighten thetop cap (headsetbolt) to 6Nm
using the three-arm hex key number 5).
2. Center and tighten the 2 bolts on the
stem. The easiest way to get everything
“centered” is to stand in front of your bike
and hold the front wheel between your
feet and legs. Tighten the 2 bolts on stem
(headset bolt) to 12Nm.
9 CHECK
Grab the front brake and use the bars to push/jolt the bike forward. If you feel that the headset is loose (a clinking
sound, or any movement other than the rear wheel coming off the ground), tighten the top cap, but
be careful how much you tighten it (three-arm hex key number 5). The top cap bolt will determine how
loose or tight your headset is, so it plays a major role in the steering and feel of your bike. Tighten the bolt
a little at a time and between each turn.
Once the looseness in the headset is gone, it should be tight enough.
Give the handlebar a turn to the left and
right
to make sure they still move smoothly. If the movement is tight, you’ve gone too far. Back the stem

INTRODUCTION
9
cap off a quarter to half a turn and try again. Once there is no looseness in the headset and the handlebar
is smoothly turning, you need to take the tool (three-arm hex key number 5) and tighten the two bolts on
the stem (see picture).
Flip your bike over and spin your wheel: by spinning your wheel, you will make sure your brake pads are not
rubbing on the rotor. If your wheel does not spin, it could be crooked in the fork’s dropouts. Flip your bike
back, loosen your axle, push down on the wheel and tighten the axle again.
USA SPECIFICS
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Contains FCC IDs: QIPPLS8-USR4, Z64-WL18SBMOD
NOTE — This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
»Reorient or relocate the receiving antenna;
»Increase the separation between the equipment and receiver;
»Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected;
»Consult the dealer or an experienced radio/TV technician for help.
CAUTION - Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

GENERAL NOTES ABOUT RIDING
10
2
General notes about riding
SUSPENSION
Rear Suspension (if applicable)
Suspension sag can be used to set the proper suspension spring rate for the rider. Sag is
the amount (percentage) the suspension compresses when the rider, including riding gear,
is seated on the bike in the riding position. Setting the proper sag allows the wheels to
maintain traction without using too much of the travel reserved for shock absorption. More
sag increases small bump sensitivity, while less sag decreases small bump sensitivity. Set the
spring sag before making any other tuning adjustments
Before setting sag, set the dampers to the full open positions. Rotate the adjusters counter
clockwise until they stop. Set the shock to the open position. Beginning with the shock fully
deated, pressurize the air spring chamber to 100 psi. Do not compress the suspension with
the pump attached. Fully compress the shock ve times to equalize the positive and negative
air springs. Compress the shock once more to equalize air pressure. With your riding gear
on, and an assistant holding the bike, step onto the vehicle and lightly cycle the shock two to
three times.
While seated on the bicycle, have an assistant slide the sag o-ring against the wiper seal.
Gently step off the vehicle without compressing the shock. Note the sag percentage where
the o-ring stopped. Usually sag percentage for shocks is around is 25% - 35%. Sag can be set
±5% as preferred. If your target sag percentage is not achieved, air pressure must be adjusted.
Increase air pressure to decrease sag. Decrease air pressure to increase sag.
Additional adjustment
Depending on the exact model of the shock, there are various adjustments that can be made,
and some of them are rebound, low speed compression, high speed compression, threshold,
lockout and other. For further information please contact your Greyp dealer or visit shock
manufacturers website.

GENERAL NOTES ABOUT RIDING
11
Front suspension
Rebound damping controls the suspension fork extension/return speed, which affects traction
and control. Optimal rebound damping allows the fork to extend at a controlled speed and
maintain traction and control. Rebound that is too fast allows the fork to extend too quickly,
which causes the wheel to bounce off objects and the ground resulting in a pogo effect.
Rebound that is too slow prevents the fork from extending quickly enough to regain contact
with the ground or prepare for the next impact. Rebound damping can be tuned to rider weight,
spring rate and travel, as well as for terrain and rider preference. As the air pressure or spring
rate increases, the extension/return speed increases. To achieve the optimal setting, rebound
damping may need to be increased when air pressure or spring rate increases.
Additional adjustment
Depending on the exact model of the fork, there are various adjustments that can be made,
and some of them are rebound, low speed compression, high speed compression, lockout
and other. For further information please contact your Greyp dealer or visit fork manufacturers
website. Usually on fork crown there is level or nut adjuster which if you rotate you can make
fork absorption softer or harder.
Recommended tire pressure
WARNING — If the maximum pressure values in this manual and values on the side wall of a
tire are in any way different, please refer to the ones that are marked on the tire’s sidewall or
wheel (whichever is lowest). Never inate a tire beyond the maximum pressure marked on the
tire’s sidewall. Exceeding the recommended maximum pressure may blow the tire off the rim,
which could cause damage to the bike and injury to the rider and/or bystanders.

GENERAL NOTES ABOUT RIDING
12
Maximum tire pressure (please read warning in this chapter):
BIKE FRONT TIRE REAR TIRE
G6.1, G6.2, G6.3, G6.4 2.6 bar (38 psi) 2.6 bar (38 psi)
G5.1 2.1 bar (30 psi) 2.1 bar (30 psi)
G5.2 3.5 bar (50 psi) 3 bar (45 psi)
G6.5 & G6.6 3.0 bar (45 psi) 3.0 bar (45 psi)
4
2
1
3
REFLECTORS
NAME/DESCRIPTION
1FRONT REFLECTOR 313/5K
2REAR REFLECTOR 314/1
3REAR REFLECTOR 313/1ZB
4SPOKE REFLECTOR 309 (M); (US - RR-530-WUW)

SYSTEM FUNCTIONS
13
3
System functions
Bike
parts
1
9
2
4
5
3
8
7
10
6
BIKE PARTS
NAME/DESCRIPTION
1DISPLAY UNIT (CIM) 6CHAINSTAY
2CONTROL UNIT (CBC) 7PUSHPLATE
3REAR CAMERA (BUTS) 8RATIO LEVER
4BATTERY 9FRAME
5SEATSTAY 10 MOTOR

SYSTEM FUNCTIONS
14
Assembling parts supplied unassembled
CAUTION — Do not use the chainguide and chainguard at the same time.
1
2
4
6
3
5
CHAINGUIDE OR CHAINGUARD MOUNT
NAME/DESCRIPTION TORQUE, Nm [lb ft]
1CHAINGUIDE ALUMINUM PART -
2CHAINGUIDE PLASTIC PART -
3DIN 7991 M5X18 4 [3] + low strenght threadlocker
4DIN 7991 M5X12 4 [3] + low strenght threadlocker
5CHAINGUARD -
6ISO 7045 M4X8 4 [3]
Chainguide – use only with positive
foot-retention devices on the pedals
Chainguard

SYSTEM FUNCTIONS
15
Control unit functions
1 2
3 4
76
85
LEGEND
NAME/DESCRIPTION ICON FUNCTION TYPE
1POWER ON/OFF AND STAND BY LONG/SHORT PRESS
2WALK ASSIST WALK ASSIST PRESS & HOLD
3LIGHT TURN ON/OFF FRONT AND
REAR SIGNAL LIGHTS SHORT PRESS
4RETRO VIDEO RECORDS THE LAST 30 SECONDS OF YOUR RIDE
5JOYSTICK
SWITCH BETWEEN
DISPLAY
FUNCTIONS
SHORT PRESS IN ALL
DIRECTIONS
6ASSIST LEVEL UP INCREASE LEVEL OF
ASSISTANCE SHORT PRESS
7ASSIST LEVEL
DOWN
DECREASE LEVEL OF
ASSISTANCE SHORT PRESS
8FUNCTION VARIOUS FUNCTIONALITIES (SEE NEXT PAGES)

SYSTEM FUNCTIONS
16
Display unit information
1
2
3
4
5
6
CIM DISPLAY INTERFACE
NAME/DESCRIPTION
1SPEED
2BATTERY CHARGE /
REMAINING DISTANCE
3RIDE STATISTICS
4TIME
5ASSISTANCE LEVEL
6CADENCE

SYSTEM FUNCTIONS
17
Power on
To turn on the bike, long
press the power button
Long press
Stand by mode on
To put your bike in standby mode,
short press the power button
Short press
Stand by mode off
To wake up the bike from stand-by mode, press any
button on the control unit or move the bike
Press any button

SYSTEM FUNCTIONS
18
Power off
To turn off the bike,
long press the power button
Long press
Walk assist mode
To activate the walk assistance mode,
press and hold walk assist button
Press and hold
Lights on/off
To turn the lights on or off,
short press the light button
Short press

SYSTEM FUNCTIONS
19
Joystick
To switch between different information on the
display unit, move the joystick up or down
»TRIP
ODOMETER
»AVERAGE SPEED
»TRIP TIME
Move up/down
Assist level up/down
To change the assistance level, short press
the plus or minus assist level button
Short press to change by one level
