Griffin Technology APSI04 User manual

www.Griffin-Stands.com
Microphone
Isolator Panel
www.Griffin-Stands.com
www.Griffin-Stands.com
Griffin™ stands and accessories are manufactured
in several innovative factories responsible for
developing products that address the newest
needs and trends of the current market. We take
pride in the Griffin™ brand and endeavor to be on
the forefront of the musical stands and musical
and lighting accessories market.
Performance Issue, Uneven or Unstable- Make
sure all nuts and bolts are tight on the product. If they
are, then loosen all nuts and bolts 1 full turn counter-
clockwise, then go back and tighten each bolt only ½
turn tight. Then do a final tighten turn for another ½
turn tight. Next, Make sure there are not any missing
nuts or bolts. Third, ensure all parts on the product
are not broken or defective. Finally, Re-read the
assembly instructions or watch the product
demonstration video to ensure you have correctly
assembled or are using the product properly with
factory specifications.
Missing Parts- The pictures, videos and images
shown in this manual might have changed style or
count due to the product being redesigned. So in rare
cases the part may no longer be included or of a
different style. However, if you think you are missing
a part that is necessary to the assembly and use of
your product, then first carefully double check all
packaging for any parts you think are missing. Some
parts might be hiding in the packaging or loose in an
inner box.
User Manual
M o d e l # A P S I 0 4
Griffin | 11408 Hwy 64 W, Tyler, TX 75704 |
[email protected] | www.Griffin-
Stands.com
For current product specifications, please to go
www.griffin-stands.com and type the model number
into the search bar. Locate the product listing to view
the current factory specifications. Thank you for purchasing the Griffin Microphone
Isolator Panel. Your product comes with a 1 year
factory warranty from purchase date. Please read all
assembly instructions prior to assembling your new
cart. Pictures that may aid in assembly can be found
by going to www.griffin-stands.com and typing
APSI04 into the search bar.

Step 4 –Figure 6
shows the shock
mount being screwed
in the microphone
clip. And Figure 7 is
mounting the
microphone by sliding
it through the shock
mount.
Step 1 –Take the panel and open it up by unscrewing
the little knob at the top near the angles of the panel
as shown in Figure 1.
Step 2 –As shown in Figure 2, take the steel track
sheet (Part E) and screw to the middle bottom part of
the panel by using the 3/8” to 5/8” adapter (Part B)
and Steel knob with 3/8” thread male (Part D). On the
end of the steel track sheet (Part D) insert the tube
with 3/8” thread male (Part C) and secure using the
3/8” to 5/8” adapter (Part B) as shown in Figure 3. At
the tip of the tube insert the 3/8” to 5/8” adapter (Part
B) then the 5/8” washer (Part A).
Step 5 - For safety reasons, please always make sure to
test the stability and safety of the product before use.
Double check all nuts and bolts, knobs and connectors,
make sure that these are tight and securely fastened
before use of your product. Test the product under light
use or light loads the first time to confirm assembly and
structure of the product is correct.
Please scan the QR Code below for the product
demonstration video. Or go to the URL shown here and find
the product video. www.Griffin-Stands.com/Videos
Step 3 –Take the clamp (Part G) and screw it in at the
back using M5 Screw (Part F).By this the panel can be
mounted to a tripod vertical stand as this panel is heavy.
A speaker stand will also work. Then screw in the back
knobs to clamp the shield to the vertical stand. (See
Figure 4 and 5)
***Please note that this is NOT a table top mount, this is
designed to be mounted on a heavy-duty stand (speaker
stand preferably) to support the entire panel.
