Grindmaster PrecisionBrew B-3 User manual

Models B-3, B-3WL, & B-3WR
Decanter Brewers
Model B-3
(Decanters sold separately)
Model B-3WL
(also available with right side warmers: B-3WR)
(Decanters sold separately)
Digitally controlled decanter brewer holds brew temperature to + 1°F throughout the brew cycle.
Brew temperature, brew volume, operator defined pre-infusion/pulse brewing, energy
savings, and low temp/no brew are programmable from the front display.

Models B-3, B-3WL, & B-3WR
Features:
•Model B-3 is a single, digitally controlled brewer. It has one
warmer under the brew basket and two warmers on top
(Decanters sold separately).
•Model B-3WR is a single, digitally controlled brewer. It has one
warmer under the brew basket and two warmers on the right side
(Decanters sold separately).
•Model B-3WL is a single, digitally controlled brewer. It has one
warmer under the brew basket and two warmers on the left side
(Decanters sold separately).
•Precise Brew Temperature - The brewer will hold the brew
temperature to +/- 1°F during the complete brew cycle.
•Brew Volume - Can be set by ‘teach’ mode to eliminate
trial-and-error set-up.
•Pulse brewing/pre-infusion - Allows the brew sequence to extract
up to 20% more dissolved solids per batch of coffee.
Programmable: number of pulses, pulse-on time and pulse-off time.
Changing the pulse sequence does not affect the brew volume.
•Low Temp/No Brew - Allows the brew cycle to begin only
when the water has reached the optimum brew temperature.
•Cycle Counter - The brewer counts the total number of brew cycles.
•Programming Lock-Out - The brewer settings can be “locked”
to prevent tampering.
•Energy Savings/Coffee Old - The warmers can be programmed
to shut off up to 240 minutes from the last brew cycle.
•Pour-Over Capability - Automatically converts to pour-over
mode when the inlet valve does not sense water. Also capable
of being manually set to pour-over mode through the front.
•Dual Voltage with toggle switch models are available to
accept 120/240V or 120V supply.
•Warranty - 2 years parts and labor on the brewer. 4 years
part warranty on the control board.
Specifications are subject to improvement or change without notice.
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
© Grindmaster Corporation, 2001
PRINTED IN USA
0206 Form # AM-203-05
Specifications Model B-3 Models B-3WR/B-3WL
Electrical
120V/1800W/15Amps
120/240V/3800W/16Amps
120/208V/2860W/13.8Amps
European Voltages Available
120V/1800W/15Amps
120/240V/3800W/16Amps
120/208V/2860W/13.8Amps
European Voltages Available
Brew Capacity (64 oz. decanters per hour) (8) at 120V; (16) at 240V; (15) at 208V (9) at 120V; (16) at 240V; (15) at 208V
Water Line 1/4” flare 1/4” flare
Water Pressure 30-80 psi 30-80 psi
Tank Drain Yes Yes
Tank Size 1.38 gal. (5.2 L) 1.38 gal. (5.2 L)
Dimensions (H x W x D) 19” x 8-1/4” x 17-3/4”
49 cm x 21 cm x 45 cm
17-3/4” x 16-1/4” x 17-3/4”
45 cm x 41 cm x 45 cm
Ship Dimensions (H x W x D) 22” x 13” x 24”
56 cm x 33 cm x 61 cm
22” x 21” x 24”
56 cm x 53 cm x 61 cm
Weight 27 lbs. (12.2 kg) 29-1/2 lbs. (13.4 kg)
Ship Weight 35 lbs. (15.9 kg) 40 lbs. (18.1 kg)
Listings UL, CUL, NSF, (CE for E models only) UL, CUL, NSF, (CE for E models only)
B-3WR/B-3WL Side View B-3WL Front View B-3WR Front View
B-3 Side View B-3 Front View B-3 Top View
B-3WR Top View
17.8
2.7
17.1
.38-.63 16.2
8.1 8.1
16.2
17.8
2.7
18.3
.38-.63
8.1
Water
Connection
Cord
Connection
Water
Connection
Cord
Connection
7.2
7.2
