Grindmaster PrecisionBrew PBVSA-330 User manual

Models PBVSA-430 & PBVSA-330
Single and Dual
Airpot & Vacuum Insulated Shuttle®Brewers
Model PBVSA-330 Model PBVSA-430
(pictured with optional 3.0L Airpot)
V
Vacuum Insulated Shuttle(s) Included acuum Insulated Shuttle(s) Included

Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
© Grindmaster Corporation, 2005
PRINTED IN USA 0206 Form # AM-294-05
•Model PBVSA-330 is a single, digitally controlled brewer. It includes (1) vacuum insulated, VS-1.5 Shuttle® without stand (VS-S stands sold separately).
•Model PBVSA-430 is a twin, digitally controlled brewer. It includes (2) vacuum insulated, VS-1.5 Shuttles® without stand (VS-S stand sold separately).
•The VS-1.5 Shuttle® is a 1.5 gallons (5.7L) Vacuum insulated, stainless steel container. When used with available stand, it is portable and
will maintain freshly brewed coffee hot without additional heat.
•Bumper guides allow brewer to brew into 3.0L airpots. (Airpots sold separately).
•The following brew variables are programmable through the front display: Water temperature, brew volume, pulse brewing sequence,
bypass percentage, low temp/no brew.
•Precise Brew Temperature - The brewer will hold the brew temperature to +/- 1°F during the complete brew cycle.
•3 Brew Volumes – From ½ gallon (1.9L) to 1½ gallons (5.7L). Each volume can be set by ‘teach’ mode to eliminate trial-and-error set-up.
•Pulse brewing/pre-infusion – Allows the brew sequence to extract up to 20% more dissolved solids per batch of coffee.
Programmable: number of pulses, pulse-on time and pulse-off time. Changing pulse sequence does not affect the brew volume.
•Bypass adjustment – For Large and Medium brew volumes, can program up to 33% of the total brew volume to bypass the coffee
grounds. Changing the percentage of bypass will not affect the brew volume.
•Low Temp/No Brew – Allows the brew cycle to begin only when the water has reached optimum brew temperature. Program On or Off.
•Cycle Counter – The brewer counts the total number of brew cycles.
•Programming Lockout – The brewer settings can be “locked” to prevent tampering.
•Brew Basket Lock – The brew basket(s) are automatically locked in-place throughout the brew cycle.
•Independent or simultaneous brewing on twin brewers.
•Diagnostics – The front display will indicate any water or heater failures.
•Hot Water Faucet – For use in making tea, soup, hot chocolate. Using the faucet will not affect the brew volume.
•Warranty - 2 years parts and labor on the brewer. 4 years part warranty on the control board.
Models PBVSA-430 & PBVSA-330
Features
Specification Model PBVSA-430 (twin) Model PBVSA-330 (single)
Electrical 120/240V, 6600W, 28A
120/208V, 5000W, 24A
120/240V, 6600W, 28A
120/208V, 5000W, 24A
5 oz. (148ml) cups/hour
(140°F ⌬T)
@ 240V: 500
@ 208V: 385
@ 240V: 385
@ 208V: 385
Water Line 3/8” flare 3/8” flare
Water Line Pressure 30 to 80 psi 30 to 80 psi
Cabinet Dimensions
(H x W x D)
28” x 20-1/2” x 18”
(71cm x 52cm x 46cm)
28” x 9” x 18”
(71cm x 23cm x 46cm)
Ship Dimensions
(H x W x D)
33” x 27-1/2” x 22”
(83cm x 69cm x 55cm)
33” x 11” x 26”
(83cm x 28cm x 66cm)
Weight 95 lbs. (43 kg) 50 lbs. (23 kg)
Ship Weight 100 lbs. (45 kg) 55 lbs. (25 kg)
Listings UL, CUL, NSF, (CE models available) UL, CUL, NSF, (CE models available)
Specifications are subject to improvement or change without notice.
Options
BB2.0SS Gourmet brew basket
A418-032 Gourmet spray head
AOPT-248 3-heater 15kW (high output) PBVSA-430 only
AOPT-303 Master power switch
AOPT-304 Shuttle® lockout switch - single
AOPT-305 Shuttle® lockout switch - twin
Accessories
VS-1.5 Additional Vacuum Insulated Shuttle®
VS-S Shuttle® stand
BB1.5WP 13” x 5” filter paper for BB1.5SS - 500/case
BB2.0WP 14” x 6” filter paper for BB2.0SS - 500/case
DP-15 Drip pan for PBVSA-430
DP-8 Drip pan for PBVSA-330
APF3.0-B 3.0L airpot
2.0
8.0
3.0
WATER
HOOK-UP
ELECTRIC
HOOK-UP
28.0
15.2
-5.04.0
9.1
ELECTRIC
HOOK-UP
WATER
HOOK-UP
-5.0
15.2
4.0
20.5
4.0
28.0
ELECTRIC AND WATER
HOOK-UPS
4.5
2.8
18.1
Model PBVSA-330
Front View
Model PBVSA-430
Front View
Models PBVSA-330 &
PBVSA-430 Side View
