Grindmaster B-ID User manual

Digitally controlled insulated decanter brewer holds brew temperature to + 1°F throughout
the brew cycle. Brew temperature, brew volume, operator defined pre-infusion/pulse brewing,
and low temp/no brew are programmable from the front display.
Model B-ID
Insulated Decanter Brewer
Model B-ID
(Insulated decanter sold separately)

Grindmaster® Coffee Grinders and Brewers • Espressimo® Espresso Machines • Crathco® Hot Beverage Dispensers
Crathco® Cold and Frozen Beverage Dispensers • American Metal Ware® Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
Features
•Model B-ID is a single, digitally controlled brewer that brews into a
1.9L (64oz.) stainless steel vacuum insulated decanter (decanter
sold separately).
•The vacuum insulated, stainless steel decanters model
SS-1.9LR (regular) and SS1.9LD (decaf), hold freshly brewed coffee
for hours without additional heat.
•Precise Brew Temperature - The brewer will hold the brew
temperature to +/- 1°F during the complete brew cycle.
•Brew Volume - Can be set by ‘teach’ mode to eliminate trial-and-
error set-up.
•Pulse brewing/pre-infusion - Allows the brew sequence to extract up
to 20% more dissolved solids per batch of coffee. Programmable:
number of pulses, pulse-on time and pulse-off time. Changing the
pulse sequence does not affect the brew volume.
•Low Temp/No Brew - Allows the brew cycle to begin only when the
water has reached the optimum brew temperature.
•Cycle Counter - The brewer counts the total number of brew cycles.
•Programming Lock-Out - The brewer settings can be “locked” to
prevent tampering.
•Pour-Over Capability - Automatically converts to pour-over mode
when the inlet valve does not sense water. Also capable of being
manually set to pour-over mode through the front.
•Dual Voltage with toggle switch models are available to accept
120/240V or 120V supply
•Model B-ID-120V has a plastic brew basket.
•Warranty - 2 years parts and labor on the brewer. 4 years part
warranty on the control board.
Specification Model B-ID Model B-ID-120V
Electrical
120V/ 1780W/ 14.9A
120/240V/ 3500W/ 14.6A
120/208V/ 2630W/ 12.7A
European voltages available.
120V/ 1780W/ 14.9A
Brew Capacity
(# of 1.9L insulated decanters / hour)
@ 120V: 8
@ 208V: 12
@ 240V: 16
@ 120V: 8
Water Line 1/4” flare 1/4” flare
Water Line Pressure 30-80 psi 30-80 psi
Tank Drain Yes Yes
Tank Size 1.38 gallons 1.38 gallons
Dimensions (H x W x D) 17-3/4” x 8-1/4” x 17-3/4” (45 cm x 21 cm x 45 cm) 17-3/4” x 8-1/4” x 17-3/4” (45 cm x 21 cm x 45 cm)
Ship Dimensions (H x W x D) 22” x 13” x 24” (56 cm x 33 cm x 61 cm) 22” x 13” x 24” (56 cm x 33 cm x 61 cm)
Weight 28 lbs (12.7 kg) 28 lbs (12.7 kg)
Ship Weight 37 lbs (16.8 kg) 37 lbs (16.8 kg)
Listings UL, CUL, NSF, (CE for E models only) UL, CUL, NSF, (CE for E models only)
0905 Form # AM-200-01
© Grindmaster Corporation, 2003
PRINTED IN USA
Model B-ID
Specifications are subject to improvement or change without notice.
8.1 2.7 17.8
17.1
0.38 - 0.63
7.2
Front View Side View
