Model H7790/H7791 Laminate Trim Router -19-
H7791 Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH7791001 POWER CABLE
21 PH7790021 ADJUSTING KNOB M6-1 X 20
2 PH7791002 CABLE JACKET
22 PH7790022 BLOCK
3PH7791003 BACK COVER 23 PH7790023 TRIM GUIDE PLATE
4PH7791004 CABLE CLAMP 24 PH7790024 SHOULDER SCREW M5-.8 X 11
5PS56M PHLP HD SCR M4-.7 X 16 25 PH7790025 BUSHING
6P627 BALL BEARING 627ZZ 26 PH7790026 BASE PLATE
7PH7791007 BEARING GASKET 27 PHTEK15M TAP SCREW M4 X 10
8PH7791008 BRUSH TUBE 28 PH7790028 COLLET NUT
9PH7791009 BRUSH COVER 29 PH7790029 COLLET
10 PH7791010 CARBON BRUSH 30 P6200 BALL BEARING 6200ZZ
11 PH7791011 MID COVER 31 PH7791031 SWITCH
12 PH7791012 SHELL 32 PS65M PHLP HD SCR M4-.7 X 40
13 PH7791013 STATOR 33 PH7790031 CLASPING KNOB
14 PH7791014 PHLP HD SCR M4-.7 X 70 34 PH7791034 LIFT GEAR
15 PH7791015 ROTOR 35 PH7790032 GEAR GUIDING KNOB
16 PH7791016 OUTSIDE COVER 36 PH7790033 STRAIGHT GUIDE
17 PH7790017 LOCK KNOB M6-1 X 25 37 PH7790034 WRENCH 10MM
18 PH7790018 TRIM GUIDE BRACKET 38 PH7790035 WRENCH 17MM
19 PH7790019 KNOB RETAINER 39 PH7790036 GUIDE ADJ BRACKET
20 PFH19M FLAT HD SCR M4-.7 X 10 40 PH7790037 TEMPLATE GUIDE
