-20- G0489 Metalworking Sander





  










  



 

















   

 

  



   
















84
85 86
89
90 91
87
88
G0489 Parts Breakdown
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.

G0489 Metalworking Sander -21-
G0489 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0489001 STAND 45 P0489045 STOP RING
2 HEX BOLT M12-1.75 X 130 46 P6004 BEARING 6004
3 PW06M FLAT WASHER 12MM 47 P0489047 SHAFT
4 P0489004 PAPER SPACER 48 P0489048 SPACER
5 P0489005 PIVOT BASE 49 P0489049 MOTOR SUPPORT
6 PN02M HEX NUT M10-1.5 50 PN02M HEX NUT M10-1.5
7 PW04M FLAT WASHER 10MM 51 P0489051 THRUST WASHER
8 PW04M FLAT WASHER 10MM 52 P0489052 THREADED ROD M10-1.5 X 80MM
9 PB74M HEX BOLT M10-1.5 X 20 53 PW01M FLAT WASHER 8MM
10 PB96M HEX BOLT M5-.8 X 10 54 P0489054 BASE
11 PW06M FLAT WASHER 12MM 55 PSB06M CAP SCREW M6-1 X 25
12 PB33M HEX BOLT M12-1.75 X 50 56 P0489056 PIVOT PIN
13 P0489013 BODY 57 PRP07M ROLL PIN 6 X 20
14 P0489014 MOTOR 58 P0489058 ECCENTRIC WHEEL
14-1 P0489014-1 FAN COVER 59 PW01M FLAT WASHER 8MM
14-2 P0489014-2 FAN 60 PLW04M LOCK WASHER 8MM
14-3 P0489014-3 JUNCTION BOX 61 PB19M HEX BOLT M8-1.25 X 24
15 P0489015 SPACER 62 P0489062 EXTENSION SPRING
16 P0489016 LEVER HUB 63 P0489063 SOLID PIN
17 PSS09M SET SCREW M8-1.25 X 20 64 P0489064 PIVOT PIN
18 P0489018 LEVER 65 PR01M EXT RETAINING RING 10MM
19 P0489019 LEVER HANDLE 66 P0489066 DRAW BAR
20 P0489020 SHAFT 67 P0489067 THRUST WASHER
21 P0489021 BELT GUARD 68 P0489068 BELT TENSIONER
22 P0489022 TRACKING KNOB 69 PN09M HEX NUT M12-1.75
23 PW04M FLAT WASHER 10MM 70 PSS08M SET SCREW M4-.7 X 5
24 P0489024 GRAPHITE LAYER 71 P0489071 DOOR LATCH
25 P0489025 HEX NUT M8-1.25 72 P0489072 KNOB M8-1.25 X 15
26 PB40M HEX BOLT M10-1.5 X 15 74 PW01M FLAT WASHER 8MM
27 PW04M FLAT WASHER 10MM 75 P0489075 SIDE COVER
28 P0489028 SUPPORT 76 PB01M HEX BOLT M10-1.5 X 30
29 P0489029 SUPPORT PLATE 77 P0489077 SPECIAL WASHER 10MM
30 P0489030 LOCK HANDLE 78 P0489078 DRIVE WHEEL
31 PW01M FLAT WASHER 8MM 79 P0489079 SPARK TRAP
32 P0489032 EYE SHIELD BASE 80 PB87M HEX BOLT M8-1.25 X 15
33 PS05M PHLP HD SCR M5-.8 X 8 81 PW01M FLAT WASHER 8MM
34 PSB109M CAP SCREW M5-.8 X 50 82 P0489082 KNOB M8-1.25
35 PS02M PHLP HD SCR M4-.7 X 12 83 P0489083 OVERLOAD SWITCH
36 P0489036 BRACKET 83-1 P0489083-1 ON/OFF SWITCH
37 P0489037 EYE SHIELD 84 P0489084 MACHINE ID LABEL
38 PN04M HEX NUT M4-.7 85 PLABEL-12 READ MANUAL LABEL
39 P0489039 SQUARE NUT M8-1.25 86 PLABEL-37 RESPIRATOR/GLASSES LABEL
40 P0489040 CONTACT WHEEL 87 PLABEL-41 ENTANGLEMENT LABEL
41 PB40M HEX BOLT M10-1.5 X 15 88 PLABEL-36 UNPLUG 220V LABEL
42 PW04M FLAT WASHER 10MM 89 PLABEL-14 ELECTRICITY LABEL
43 P0489043 WORK SUPPORT 90 G8588 LOGO PLATE
44 PSS34M SET SCREW M5-.8 X 16 91 PLABEL-30 DOOR CLOSED LABEL
