Grizzly G5344 Quick start guide

G5344 Parts Breakdown and List































REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PS07M PHLP HD SCR M4-.7 X 8 14 P5344014 CYLINDER
2 PLW02M LOCK WASHER 4MM 15 P5344015 STEEL BALL
3 P5344003 HOUSING COVER 16 P5344016 CLAMP SPRING
4 P5344004 RUBBER SUPPORT ASSEMBLY 17 P5344017 FLAT HEAD SCREW
5 P5344005 TUBE ASSEMBLY 18 P5344018 CYLINDER SUB ASSEMBLY
6 P5344006 MODEL LABEL 19 PFH49M FLAT HD SCR M3-.5 X 6
7 P5344007 RUBBER PAD ASSEMBLY 20 P5344020 VALVE BUSHING
8 P5344008 THROTTLE VALVE 21 P5344021 FLAT HEAD SCREW
9 P5344009 O-RING 22 PLW02M LOCK WASHER 4MM
10 P5344010 VALVE FITTING 23 P5344023 HOSE SUB ASSEMBLY
11 P5344011 HOUSING CAP 24 P5344024 CLAMP STOMPER
12 PS38M PHLP HD SCR M4-.7 X 10 25 P5344025 ROLL PIN
13 P5344013 END PLATE
