Grizzly G3105 User manual

BELT/DISC SANDER
MODEL G3105
PARTS LIST
COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED APRIL, 1999. PRINTED IN U.S.A.
PARTS LIST DISCLAIMER
THIS PARTS LIST AND DRAWINGS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CON-
FIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS
LIST MAY NOT DEPICT YOUR MACHINE EXACTLY. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES.
PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.

-B- G3105 Combination Sander
1P3105001 ROTOR
2P3105002 STATOR
3P6202 BALL BEARING 6202
4P3105004 MOTOR END BELL
6P3105006 CAPACITOR
7P3105007 CAPACITOR CLIP
8P3105008 BOTTOM COVER
9P3105009 RUBBER FOOT
10 P3105010 DISC GUARD
11 P3105011 DISC GUARD BRACKET
12 P3105012 SANDING PLATE
13 P3105013 DISC TABLE
14 P3105014 LEFT TRUNNION
15 P3105015 TABLE SUPPORT BRACKET
16 P3105016 RIGHT TRUNNION
17 P3105017 KNOB
18 P3105018 GUIDE PIN
19 G1445 6" 60-GRIT DISC (3) PACK
20 P3105020 BELT HOUSING
21 P3105021 STOP BRACKET
22 P3105022 DRIVE WHEEL
23 P3105023 WHEEL FLANGE
24 PN06 HEX NUT 1/2" - 12
25 P3105025 BELT PLATEN
26 P3105026 GUARD SUPPORT
27 PB02 HEX BOLT 1/4" - 20 x 5/8"
28 P3105028 BELT GUARD
29 G1209 1"X42" 100-GRIT (2) PACK
30 P6200 BALL BEARING 6200
31 P3105031 TRACKING WHEEL
32 P3105032 TRACKING SHAFT
33 P3105033 TRACKING BRACKET
34 P3105034 TENSION SPRING
REF PART DESCRIPTION REF PART DESCRIPTION
DIAGRAMS & PARTS LISTS
G3105 MOTOR
B&T
CAPACITORS
43 42
44
27
40
44
10
65
3
17
23
4
4
6
8
9
45
11
48
12
19
13
71
14
57
55
57
55
16 18 17
15
64
46
57
47
58

G3105 Combination Sander -C-
35 P3105035 SPRING PLATE
36 P3105036 SPRING CAP
37 P3105037 HANDLE W/KNOB
38 P3105038 BELT TABLE
39 P3105039 BELT TABLE BRACKET
40 P3105040 SWITCH
41 PS01 PHLP HD SCREW 10 - 24 x 1/2"
42 P3105042 STRAIN RELIEF
43 P3105043 POWER CORD
44 PS06 PHLP HD SCREW 10 - 24 x 3/8"
45 PS01 PHLP HD SCREW 10 - 24 x 1/2"
46 PB09 HEX BOLT 5/16" - 18 x 1/2"
47 P3105047 HOUSING SCREW
48 PSS04 SETSCREW 1/4" - 20 x 5/16"
49 PSB02 CAP SCREW 10 - 24 x 3/8"
50 PSB31 CAP SCREW 10 - 24 x 5/8"
51 PSB33 CAP SCREW 10 - 24 x 3/4"
52 PSB16 CAP SCREW 3/8" - 16 x 3/4"
G3105 SAND FRAME
4
8
3
6
59
37
34
5156
3361
32
20 30
31 30 60
26
57 55 1
7
1
7
28
29
25
23
24
22
26
49
50 35
45
21
38
53
39
69
67
54
52
72
62
53 PFH06 FLAT HD SCREW 5/16" - 18 x 7/8"
54 PW02 FLAT WASHER 3/8"
55 PB19 HEX BOLT 1/4" - 20 X 1/2"
56 PN07 HEX NUT 10 - 24
57 PW06 FLAT WASHER 1/4"
58 PLW03 LOCK WASHER 3⁄16"
59 PN05 HEX NUT 1/4" - 20
60 PR01M EXT RET RING 10mm
61 PR05M EXT RET RING 15mm
62 PSB19 CAP SCREW 3/8" - 16 x 1 1/4"
64 PW07 FLAT WASHER 5/16"
65 P3105065 MOTOR SHROUD
67 PN02 HEX NUT 5/16" - 18
69 P3105069 SPACER
71 P3105071 MITER GAUGE
72 PLW04 LOCK WASHER 3/8"
REF PART DESCRIPTION REF PART DESCRIPTION
