-24- H7761 2" x 27" Belt & 6" Disc Combo Sander






 

























 

















 












 

























 




Parts Breakdown

H7761 2" x 27" Belt & 6" Disc Combo Sander -25-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH7761001 WORK TABLE 39 PH7761039 SWITCH PLATE
2 PH7761002 DISC PAPER 80 GRIT 40 PH7761040 SWITCH
3 PSB01M CAP SCREW M6-1 X 16 41 PH7761041 TOOL STORAGE BOTTOM COVER
4 PTLW13M INTERNAL TOOTH WASHER 6MM 42 PH7761042 TOOL STORAGE
5 PH7761005 SANDING DISC 43 PS06M PHLP HD SCR M5-.8 X 20
6 PS08M PHLP HD SCR M5-.8 X 12 44 PS26M PHLP HD SCR M6-1 X 20
7 PLW01M LOCK WASHER 5MM 45 PH7761045 TRACKING KNOB M8-1.25
8 PH7761008 DISC GUARD 46 PW01M FLAT WASHER 8MM
9 PS79M PHLP HD SCR M4-.7 X 8 47 PH7761047 TENSIONING KNOB M6-1 X 10
10 PH7761010 DISC COVER/DUST PORT 48 PS09M PHLP HD SCR M5-.8 X 10
11 PH7761011 GAUGE BODY 49 PH7761049 RIGHT SAFE GUARD
12 PH7761012 GAUGE SLIDE 50 PW02M FLAT WASHER 5MM
13 PH7761013 GAUGE INDICATOR 51 PH7761051 SAFE GUARD
14 PTLW02M EXT TOOTH WASHER 5MM 52 PW02M FLAT WASHER 5MM
15 PS05M PHLP HD SCR M5-.8 X 8 53 PN06M HEX NUT M5-.8
16 PW03M FLAT WASHER 6MM 54 PH7761054 TENSION PLATE
17 PH7761017 MITER GAUGE KNOB M6-1 X 22 55 PH7761055 IDLER SHAFT CUSHION
18 PH7761018 LOCK KNOB M6-1 X 18 56 P6201 BALL BEARING 6201RS
19 PH7761019 BULB 10W 57 PR29M INT RETAINING RING 32MM
20 PH7761020 LAMP COVER 58 PH7761058 IDLER DRUM
21 PH7761021 LAMP ARM 59 PH7761059 IDLER SHAFT
22 PH7761022 MOTOR END CAP 60 PH7761060 RIGHT GUARD COVER
23 PH7761023 SPECIAL WAVE WASHER 35MM 61 PH7761061 COVER KNOB M5-.8 X 10
24 P6202 BEARING 6202 62 PH7761062 SANDING BELT 80 GRIT
25 PH7761025 STATOR 63 PN09M HEX NUT M12-1.75
26 PH7761026 ROTOR 64 PH7761064 BELT DRIVE WHEEL
27 PH7761027 BASE 65 PH7761065 BELT SUPPORT
28 PH7761028 CORD CLIP FIXED PLATE 66 PH7761066 TENSIONING ROD
29 PH7761029 CORD BUSHING 67 PN03M HEX NUT M8-1.25
30 PH7761030 CORD CLIP 68 PH7761068 COMPRESSION SPRING
31 PH7761031 CORD 69 PH7761069 DUST PORT
32 PH7761032 RUBBER FOOT 70 PH7761070 RIGHT TOOL REST
33 PLW02M LOCK WASHER 4MM 71 PN04M HEX NUT M4-.7
34 PW05M FLAT WASHER 4MM 72 PN01M HEX NUT M6-1
35 PTLW11M INT TOOTH WASHER 4MM 73 PH7761073 LOCK WASHER 10MM
36 PH7761036 CAPACITOR 9M 300VAC 1.3" X 1.8" 74 PN14M HEX NUT M10-1
37 PH7761037 CAPACITOR BRACKET 75 PLW03M LOCK WASHER 6MM
38 PN03M HEX NUT M8-1.25 76 PH7761076 MACHINE ID LABEL
Parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
