Grizzly G0592 User manual

COPYRIGHT © MAY, 2006 BY GRIZZLY INDUSTRIAL, INC., REVISED DECEMBER, 2022 (CS)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#PC7789 PRINTED IN TAIWAN V2.12.22
MODEL G0592
10" X 18" METAL-CUTTING
BANDSAW
OWNER'S MANUAL
(For models manufactured since 01/23)
***Keep for Future Reference***

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

SECTION 5: ACCESSORIES......................... 40
SECTION 6: MAINTENANCE......................... 42
Schedule ...................................................... 42
Cleaning & Protecting .................................. 42
Lubrication ................................................... 42
Coolant System Maintenance ...................... 45
Storing Machine ........................................... 47
SECTION 7: SERVICE ................................... 49
Troubleshooting ........................................... 49
Adjusting Blade Guide Bearings .................. 52
Adjusting Blade Tracking ............................. 54
Squaring Blade to Table .............................. 55
Adjusting Blade Brush ................................. 56
Adjusting Downfeed Stop Bolt ..................... 56
Adjusting Angle Stops .................................. 57
Tensioning/Replacing V-Belt........................ 59
SECTION 8: WIRING...................................... 60
Wiring Safety Instructions ............................ 60
Wiring Diagram ............................................ 61
Electrical Component Photos ...................... 62
SECTION 9: PARTS....................................... 64
Base ............................................................. 64
Swivel Base ................................................. 66
Vise .............................................................. 68
Headstock .................................................... 70
Blade Tension & Motor ................................ 71
Blade Guides ............................................... 73
Electrical ...................................................... 75
Labels & Cosmetics ..................................... 76
WARRANTY & RETURNS ............................. 77
Table of Contents
INTRODUCTION............................................... 2
Contact Info.................................................... 2
Manual Accuracy ........................................... 2
Identification ................................................... 3
Controls & Components ................................. 4
Machine Data Sheet ...................................... 7
SECTION 1: SAFETY....................................... 9
Safety Instructions for Machinery .................. 9
Additional Safety for Horizontal Metal
Bandsaws .................................................... 11
SECTION 2: POWER SUPPLY ...................... 12
SECTION 3: SETUP ....................................... 14
Needed for Setup ......................................... 14
Unpacking .................................................... 14
Inventory ...................................................... 14
Site Considerations ...................................... 16
Lifting & Placing ........................................... 17
Anchoring to Floor ....................................... 17
Assembly ..................................................... 18
Power Connection........................................ 19
Test Run ...................................................... 20
Recommended Adjustments ........................ 21
SECTION 4: OPERATIONS ........................... 22
Operation Overview ..................................... 22
Operation Tips ............................................. 23
Workpiece Inspection................................... 23
Using Vise .................................................... 24
Selecting Blades .......................................... 25
Changing Blade ........................................... 27
Tensioning Blade ......................................... 29
Blade Breakage ........................................... 30
Blade Care & Break-In ................................. 31
Changing Blade Speed ................................ 31
Blade Speed Chart ...................................... 32
Chip Inspection Chart .................................. 33
Setting Blade Feed Rate.............................. 34
Adjusting Cutting Angle ............................... 34
Adjusting Upper Blade Guide ...................... 36
Adjusting Work Stop .................................... 36
Using Coolant System ................................. 37

-2- Model G0592 (Mfd. Since 01/23)
We stand behind our machines! If you have ques-
tions or need help, contact us with the information
below. Before contacting, make sure you get the
serial number
and manufacture date from the
machine ID label. This will help us help you faster.
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: [phone]
Email: [email protected]
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Email: [email protected]
Contact Info
We are proud to provide a high-quality owner’s
manual with your new machine!
We
made every effort to be exact with the
instruc-
tions, specifications, drawings, and photographs
in this manual. Sometimes we make mistakes, but
our policy of continuous improvement also means
that
sometimes the machine
you receive is
slightly different than shown in the manual
.
If you find this to be the case, and the difference
between the manual and machine leaves you
confused or unsure about something
,
check our
website for an updated version. W
e post
current
manuals and
manual updates for free
on our web-
site at
www.grizzly.com.
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write
down the
manufacture date and
serial number
from the machine ID label (see below). This
information is required for us to provide proper
tech support, and it helps us determine if updated
documentation is available for your machine.
Manufacture Date
Serial Number
Manual Accuracy
INTRODUCTION

Model G0592 (Mfd. Since 01/23) -3-
A. Blade Tension Handle
B. Blade Guide Scale
C. Control Panel
D. Headstock
E. Speed Adjustment Knob
F. Belt Cover
G. Electrical Box
H. Vise Lock Handle (1 of 2)
I. Spray Gun
J. Rotational Degree Scale
For Your Own Safety Read Instruction Manual Before Operating Saw
a) Wear eye protection and respirator.
b) Do not remove jammed cutoff pieces until blade has stopped.
c) Maintain proper adjustment of blade tension, blade guides, and thrust bearings.
d) Adjust upper guide to just clear workpiece.
e) Properly support and secure workpiece with table, vise, or some type of support fixture.
Never hold workpiece with hands during cut.
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
K. Work Stop
L. Coolant Pan
M. Vise Handwheel
N. Headstock Handle
O. Speed & Blade Selection Chart
P. Blade Guide Knob
Q. Coolant Valve Controls
R. Blade Guides
S. Fixed Vise Jaw
T. Movable Vise Jaw
A
N
L
K
I
G
E
C
B
P
Q
O
R
D
J
M
F
TS
H

-4- Model G0592 (Mfd. Since 01/23)
Controls &
Components
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
A
Refer to the following figures and descriptions to
become familiar with the basic controls and com-
ponents of this machine. Understanding these
items and how they work will help you understand
the rest of the manual and minimize your risk of
injury when operating this machine.
No list of safety guidelines can be com-
plete. Every shop environment is different.
Always consider safety first, as it applies
to your individual working conditions. Use
this and other machinery with caution and
respect. Failure to do so could result in
serious personal injury, damage to equip-
ment, or poor work results.
Like all machinery there is potential danger
when operating this machine. Accidents
are frequently caused by lack of familiarity
or failure to pay attention. Use this machine
with respect and caution to decrease the
risk of operator injury. If normal safety pre-
cautions are overlooked or ignored, seri-
ous personal injury may occur.
Headstock
Figure 1. Front headstock components.
A. Headstock Handle: Adjusts headstock angle
when swivel lock components are released.
B. Blade Guide Knob: Loosens to adjust upper
blade guide position; tightens to secure.
C. Blade Guides: Support blade. Adjust upper
blade guide as close to workpiece as pos-
sible to prevent blade from twisting.
D. Speed Adjustment Knob: Adjusts blade
speed from 98–394 FPM. Rotate knob clock-
wise to decrease speed or counterclockwise
to increase speed.
IMPORTANT: To avoid damaging machine,
ONLY change blade speed while main motor
is running.
E. Blade Tension Handle: Increases or
decreases blade tension.
B
C
Figure 2. Rear headstock components.
D
E

Model G0592 (Mfd. Since 01/23) -5-
Vise Table
Figure 5. Vise table components.
K. Fixed Vise Jaw: Helps hold workpiece dur-
ing cutting operations.
L. Work Stop Assembly: Adjusts for repetitive
cutting operations.
M. Vise Handwheel: Closes and opens vise to
clamp workpiece.
N. Movable Vise Jaw: Secures workpiece
against fixed vise jaw. Features quick-adjust-
ment latch that allows jaw width to be adjust-
ed quickly.
Swivel
F. Swivel Lock Lever: Loosens to adjust head-
stock angle; tightens to secure angle.
G. Swivel Stop: Secures headstock angle at 0°.
Coolant
H. Coolant Pan: Catches coolant and metal
chips during cutting operations.
I. Coolant Valves: Control flow of coolant onto
blade.
J. Spray Gun: Rinses metal chips into coolant
pan or drain filter.
K
L
M
N
O. Vise Lock Handles: Loosen to adjust vise
base position in relation to blade; tighten to
secure vise base position.
Figure 6. Location of vise lock handles.
O
G
F
Figure 3. Swivel components.
Figure 4. Coolant components.
J
I
H

-6- Model G0592 (Mfd. Since 01/23)
P. Coolant Pump Switch: Turns coolant pump
ON.
Q. Emergency Stop/Off Button: Interrupts
power to system and turns motor OFF. Twist
button until it pops out to re-energize system.
Also works as standard Off button.
Note: Bandsaw has automatic shut-off (limit
switch) that turns machine OFF at completion
of cutting arc.
R. Start Button: Turns main motor ON and acti-
vates moving parts.
Control Panel
Figure 7. Control panel components.
PQ R STU
S. Power Light: When lit, indicates system is
energized and machine is ready to operate.
T. Feed Rate Dial: Fine tunes rate at which
blade feeds into workpiece by controlling
hydraulic valve. Range is from 0 (slowest) to
9 (fastest).
U. Feed Control Dial: Turning dial left lowers
headstock at feed rate you have set. Turning
dial fully right locks headstock in position.

Model G0592 (Mfd. Since 01/23) -7-
Machine Data Sheet
The information contained herein is deemed accurate as of 11/28/2022 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2
Model G0592
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G0592 10" X 18" METAL‐CUTTING BANDSAW
Product Dimensions:
Weight.............................................................................................................................................................. 858 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 72-1/2 x 32 x 58 in.
Footprint (Length x Width)..................................................................................................................... 28-1/2 x 45 in.
Shipping Dimensions:
Type................................................................................................................................................... Wood Slat Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 967 lbs.
Length x Width x Height....................................................................................................................... 79 x 36 x 49 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Full-Load Current Rating................................................................................................................................... 15.45A
Minimum Circuit Size.............................................................................................................................................. 20A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length.............................................................................................................................................. 72 in.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type..................................................................................................................................... 6-20
Switch Type............................................................................................ Control Panel w/Magnetic Switch Protection
Motors:
Main
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 15A
Speed................................................................................................................................................ 1725 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer ............................................................................................................................................ Belt
Bearings..................................................................................................... Shielded & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External
Coolant Pump
Horsepower............................................................................................................................................. 1/8 HP
Phase............................................................................................................................................ Single-Phase
Amps......................................................................................................................................................... 0.45A
Speed......................................................................................................................................................... 3400
Type........................................................................................................................................... TEFC Induction
Power Transfer ......................................................................................................................................... Direct
Bearings..................................................................................................... Shielded & Permanently Lubricated

-8- Model G0592 (Mfd. Since 01/23)
The information contained herein is deemed accurate as of 11/28/2022 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2
Model G0592
Main Specifications:
Operation Info
Blade Speeds............................................................................................................................... 98 - 394 FPM
Std. Blade Length.................................................................................................................................... 132 in.
Blade Length Range.................................................................................................................................... 1 in.
Head Swivel..................................................................................................................... Right 45, Left 60 deg.
Cutting Capacities
Angle Cuts........................................................................................................................ Right 45, Left 60 deg.
Vise Jaw Depth...................................................................................................................................... 7-1/2 in.
Vise Jaw Height........................................................................................................................................... 5 in.
Max. Capacity Rectangular Height at 90 Deg....................................................................................... 9-1/2 in.
Max. Capacity Rectangular Width at 90 Deg............................................................................................. 18 in.
Max. Capacity Round at 90 Deg................................................................................................................ 10 in.
Max. Capacity Rectangular Height at 30 Deg............................................................................................ 10 in.
Max. Capacity Rectangular Width at 30 Deg............................................................................................. 14 in.
Max. Capacity Round at 30 Deg................................................................................................................ 10 in.
Max. Capacity Rectangular Height at 45 Deg............................................................................................ 10 in.
Max. Capacity Rectangular Width at 45 Deg............................................................................................. 11 in.
Max. Capacity Round at 45 Deg................................................................................................................ 10 in.
Max. Capacity Rectangular Height at 60 Deg.............................................................................................. 5 in.
Max. Capacity Rectangular Width at 60 Deg............................................................................................... 8 in.
Max. Capacity Round at 60 Deg.................................................................................................................. 8 in.
Construction
Table.................................................................................................................................................... Cast Iron
Upper Wheel........................................................................................................................................ Cast Iron
Lower Wheel........................................................................................................................................ Cast Iron
Body.............................................................................................................................................. Formed Steel
Base..................................................................................................................................................... Cast Iron
Stand............................................................................................................................................. Formed Steel
Wheel Cover............................................................................................................................ Pre-formed Steel
Paint Type/Finish...................................................................................................................................... Epoxy
Other
Blade Guides Upper........................................................................................................................ Ball Bearing
Blade Guides Lower........................................................................................................................ Ball Bearing
Coolant Capacity.................................................................................................................................. 4 gallons
Table Info
Floor To Cutting Area Height..................................................................................................................... 20 in.
Other Specifications:
Country of Origin .............................................................................................................................................. Taiwan
Warranty ........................................................................................................................................................... 1 Year
Approximate Assembly & Setup Time ...................................................................................................... 1-1/2 Hours
Serial Number Location .................................................................................................................................. ID Label
Features:
Coolant Pump
Blade Speed Chart
Variable Speed
Quick-Release Vise
Adjustable Hydraulic Downfeed
Automatic Shut-off
