Grizzly G1023SLWX Instruction Manual

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3Model G1023SLWX
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G1023SLWX 10" 5 HP SINGLE-PHASE LEFT TILT
CABINET SAW
Product Dimensions:
Weight.............................................................................................................................................................. 430 lbs.
Length/Width/Height.......................................................................................................................56 x 40-3/4 x 34 in.
Foot Print (Length/Width).................................................................................................................20-1/2 x 20-1/2 in.
Shipping Dimensions:
Type.........................................................................................................................................................Not Available
Content.................................................................................................................................................... Not Available
Weight.................................................................................................................................................................... N/A
Length/Width/Height........................................................................................................................... N/A x N/A x N/A
Electrical:
Switch......................................................................................................................................... Heavy Duty Magnetic
Switch Voltage......................................................................................................................................................220V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge....................................................................................................................................................12 gauge
Minimum Circuit Size........................................................................................................................................ 30 amp
Plug Included............................................................................................................................................................No
Motors:
Main
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................5 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................25A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ...............................................................................................................................Triple V-Belt
Bearings.......................................................................................................................Shielded and Lubricated
Main Specifications:
Blade Information
Maximum Blade Diameter..........................................................................................................................10 in.
Maximum Width Of Dado......................................................................................................................13/16 in.
Blade Tilt.......................................................................................................................................Left 0-45 deg.
Arbor Size..................................................................................................................................................5/8 in.
Arbor Speed.......................................................................................................................................4200 RPM
Arbor Bearings................................................................................................................Sealed and Lubricated
Rim Speed........................................................................................................................................10996 FPM

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 3Model G1023SLWX
Cutting Capacities
Maximum Depth Of Cut At 90 Degrees........................................................................................................3 in.
Maximum Depth Of Cut At 45 Degrees..................................................................................................2-1/8 in.
Maximum Rip To Right Of Blade-Standard................................................................................................26 in.
Maximum Rip To Right Of Blade-Optional.................................................................................................51 in.
Maximum Rip To Left Of Blade....................................................................................................................8 in.
Table Information
Floor To Table Height.................................................................................................................................34 in.
Table Size Length................................................................................................................................40-1/8 in.
Table Size Width........................................................................................................................................27 in.
Table Size Thickness.............................................................................................................................1-3/4 in.
Table Size With Extension Wings Length.................................................................................................. 48 in.
Table Size With Extension Wings Width....................................................................................................27 in.
Table Size With Extension Wings Thickness.........................................................................................1-3/4 in.
Distance Front Of Table To Center Of Blade.............................................................................................17 in.
Distance Front Of Table to Blade At Maximum Cut................................................................................... 12 in.
Fence Information
Fence Type..........................................................................................................................SHOP FOX Classic
Fence Size Length..................................................................................................................................... 42 in.
Fence Size Width...............................................................................................................................3-15/16 in.
Fence Size Height..................................................................................................................................2-1/2 in.
Fence Rail Type.................................................................................................Angle Iron/Rectangular Tubing
Fence Rail Length......................................................................................................................................47 in.
Fence Rail Width..............................................................................................................Front 4, Rear 2-5/8 in.
Fence Rail Height.........................................................................................................................................3 in.
Miter Gauge Information
Miter Gauge Slot Type...............................................................................................................................T-Slot
Miter Gauge Slot Size Width.....................................................................................................................3/4 in.
Mither Gauge Slot Size Height..................................................................................................................3/8 in.
Construction
Table Construction..................................................................................................................Precision Ground
Wings Construction..................................................................................................Precision Ground Cast Iron
Cabinet Construction..............................................................................................................Pre-Formed Steel
Trunnions Construction........................................................................................................................ Cast Iron
Body Assembly Contruction....................................................................................................Pre-Formed Steel
Fence Assembly Construction........HDPE Plastic Side Panels, Heavy Walled Rectangular Steel Tubing Body
Rails Construction.............................................................................................................................Steel Angle
Miter Guage Construction.....................................................................................................................Cast Iron
Guard Construction.........................................................................................................Steel and Clear Plastic
Other Related Information
Paint...........................................................................................................................................Powder Coated
Number Of Dust Ports.......................................................................................................................................1
Dust Port Size.............................................................................................................................................. 4 in.
Long Rails................................................................................................................................................ G9221
Mobile Base..............................................................................................................................................G7314
Other Specifications:
Country Of Origin ..............................................................................................................................................Taiwan
Warranty ............................................................................................................................................................1 Year
Serial Number Location .........................................................................................................................Front ID Label
Assembly Time .................................................................................................................................................. 1 hour

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 3 OF 3Model G1023SLWX
Features:
Solid Cast Iron Table is First Heat Treated to Remove Warpage, then Milled Perfectly Flat and Ground to a Mirror
Table has T-slots so Your Miter Gauge will not Fall off the Table When Retracted
Extra Large Handwheels are the Heaviest in the Industry and Really Ease Arbor Movement
Magnetic Safety Switch is Standard and Protects the Motor and Operator
One Piece Steel Cabinet Type Stand
Cast Iron Router Table Extension
Router Table Doubles as an Extra Wide Wing Extension for the Table Saw and Shop Fox Classic Fence Doubles
Router Table Includes Support Legs and Universal T-track Router Clamping System
Motor Cover and Dust Hood Included
Comfortable Polished Chrome Handles
